MSI MAG A650GL, 650W, 80PLUS Gold

Accessories included -
Brand - MSI
BrandPartCode - MAG A650GL
Category - Datortehnika :: Datoru komponentes :: Barošanas bloki (PSU)
category - PC Components|Power Supplies|Modular Power Supplies
Category - Power Supply Units
Category - Root/Electronics/PC parts/PC power supply units
Category Code - PSU
category_en - Computers & Components > Computer components > Universal power supplies PSU
category_lv - Datortehnika > Datoru komponentes > Barošanas bloki PSU
category_ru - Datortehnika > Datoru komponentes > Barošanas bloki PSU
Certificates 80+ - 80 PLUS Gold
CnCode CnCode - 85044095
code - 306-7ZP8C11-CE0
Code - MAG A650GL
Colour - Black
Cooling System - 12cm fan
Desc - Jauda: 650W, Energoefektivitāte: 80 Plus Gold, PFC: Aktīvs, Ventilators: 120mm, SATA pieslēgumi: 6, MOLEX PATA pieslēgumi: 4, PCI-E: 4 x 6 + 2 PIN, Garantija: 2 gadi
Description - - Full modular design, Flat cables - 80 Plus Gold certified for high efficiency - Active PFC design, Industrial level protection with OVP,OCP,OPP,OTP, SCP,UVP - 120mm Fluid Dynamic Bearing Fan - LLC Full Bridge Topology with DC-DC module design
Description - MAG A650GL power supply Fully modular design, flat cables 80 PLUS Gold certified, high performance guaranteed Active design of the PFC power factor correction system, Comprehensive circuit protection using industrial-class protections OVP, OCP, OPP, OTP, SCP, UVP 120 mm fan with hydrodynamic bearing Modular design of the DC-DC converter in the LLC Full Bridge topology Products from the MAG series are devices that fight alongside the player. Thanks to military-style accessories, this gaming equipment appears as a symbol of durability and strength. Compact size The power supply is much smaller than typical power supplies available on the market, which saves a lot of space inside the computer case and makes cable management easier. This way you also have much more space inside your PC. Just what you need When assembling your machine, you can now use only those power supply connectors that are necessary to power all computer components. This way you can reduce the tangle of cables inside the housing and simplify the construction of the system. Additionally, the power supply comes with a cable pouch where you can hide unused cables. Everything can be more organized Organizing cables is often the most tedious part of building a computer. The cables that come with the power supply are flat and black. Flat cables make running them inside your computer much easier! Thanks to flat cables, the entire system can be much more tidy, and there is more space inside the housing for unobstructed air flow. Dynamic oil bearing The fan installed in the power supply is equipped with a dynamic oil bearing that perfectly balances cooling performance and noise level. Power circuit with DC converters and full bridge rectifier design Combining the power circuit with full-bridge rectifier DC converters allows for higher conversion efficiency, stable output voltage, and quick voltage adjustment for various usage scenarios. This ensures a much more stable power supply structure.
description_en - Power: 650W
Energy efficiency: 80 Plus Gold
PFC: Active
Fan: 120mm
SATA connections: 6
MOLEX PATA connections: 4
PCI-E: 4 x 6 + 2 PIN
description_lv - Jauda: 650W
Energoefektivitāte: 80 Plus Gold
PFC: Aktīvs
Ventilators: 120mm
SATA pieslēgumi: 6
MOLEX PATA pieslēgumi: 4
PCI-E: 4 x 6 + 2 PIN
description_ru - Мощность: 650 Вт
Энергоэффективность: 80 Plus Gold
PFC: Активный
Вентилятор: 120 мм
SATA-подключения: 6
Соединения MOLEX PATA: 4
PCI-E: 4 х 6 + 2-контактный
Design - Cooling type - Active
Design - Fan diameter - 12 cm
Design - Illumination - No
Design - Number of fans - 1 fan(s)
Design - On/off switch - Yes
Design - Product colour - Black
dimensionalWeight - 1650
dimension depth - 130 mm
dimension height - 225 mm
Dimensions - 140 x 150 x 86 mm
dimension weight - 2581 g
dimension width - 300 mm
EAN - 4711377084277
ean - 4711377084277
Eans - 4711377084277
Efficiency - 80 PLUS GOLD
Fan - 12 cm
Floppy power connectors - 1
Full Description Line - For gaming|ATX 3.0|650 Watts|Cooling System 12cm fan|80 PLUS GOLD|PFC Active|MTBF 1500000 hours|Colour Black
gross_weight - 2.04 kg
GTIN - 4711377084277
GTIN - 4711377087278
guarantee - 84
guarantee_type - normal
ImageUrl - https://www.balticdata.lv/Gfx/ProductImages/Info/Product_110330_1.png
LargeDescHTML -
Logistics data - Harmonized System (HS) code - 84733020
LongDesc - The MAG series fights alongside gamers in pursuit of honor.With added military-inspired elements in these gaming products, they were reborn as the symbol of sturdiness and durability.80 PLUS GOLD CERTIFIEDThe efficiency of your power supply directly influences your system’s performance and your power consumption. The 80 PLUS Gold certification promises lower energy consumption and higher efficiency.COMPACT SIZINGSmaller than typical PSUs on the market, this power supply unit that can save space and make it easier to organize cables in the computer case by freeing up more room inside.ONLY WHAT YOU NEEDThe connectors that required by the build need to be used, significantly reducing cable clutter and simplifying the system’s overall build. Additionally, the included cable pack provides a storage solution for any unused cables.ALL THE MORE ORGANIZEDOrganizing cables is often the most bothersome part of building a PC. The flat cables make cable management easier and less of headache! Thanks to the flat cables, the entire system can be more organized and has more room for unobstructed airflow.FLUID DYNAMIC BEARINGThe power supply’s fan sports a fluid dynamic bearing that perfectly balances cooling performance and noise level.DC TO DC & FULL BRIDGEDC to DC and Full bridge be combined to achieve higher conversion efficiency, stable output voltage, and quick voltage adjustment for different usage scenarios, thus providing a stable power supply design.THE POWER YOU HAVEThe single rail supply of power can properly deliver the power you need. For high-performance graphics cards and CPUs, this power supply's 5 CPU & PCI-E slots are more than plenty.PROTECTION MECHANISMSTo make sure the entire system can operate safely and stably at all times, the power supply comes with a number of protection mechanisms to give you the best peace of mind.
LongProductName - 650 W, 120 mm, 47-63Hz, 140 x 150 x 86 mm
LongSummaryDescription - MSI MAG A650GL. Total power: 650 W, AC input voltage: 100 - 240 V, Maximum input current (@110V): 10 A. Motherboard power connector: 20+4 pin ATX, Cabling type: Fully-Modular. Purpose: PC, Power supply unit (PSU) form factor: ATX, 80 PLUS certification: 80 PLUS Bronze. Product colour: Black, Cooling type: Active, Fan diameter: 12 cm. Width: 150 mm, Depth: 140 mm, Height: 86 mm
MB power connector - 24 pin
Model - MAG A650GL
Modular power supply - Yes
MOLEX power connectors - 4
MTBF - 1.5e+006 hours
Name - Barošanas bloks MSI MAG A650GL 650W
Name - MSI MAG A650GL
name - MSI MAG A650GL Netzteil, 80 PLUS Gold, vollmodular, ATX 3.0 - 650 Watt
name - Power supply MAG A650GL 650W 80PLUS GOLD F.MODULAR
Number of power supply connector 4+4-pin 12V - 2
Number of power supply connectors PCI-E 6 +2 pin - 4
Other features - Airflow: 19.79 - 71.27 CFM Supported fans (optional): Front: Up to 3 x 120 mm / 3 x 140 mm Top: Up to 3 x 120 mm / 3 x 140 mm Rear: Up to 1 x 120 mm / 1x 140 mm Side: Up to 3 x 120 mm
Packaging data - Package type - Box
Performance - 80 PLUS certification - 80 PLUS Bronze
Performance - 80 PLUS certification - 80 PLUS Gold
Performance - Power Factor Correction (PFC) type - Active
Performance - Power supply unit (PSU) form factor - ATX
Performance - Purpose - PC
PFC - Active
PFC - Yes
Ports & interfaces - ATX power connector (20+4 pin) - Yes
Ports & interfaces - ATX Power connector (24-pin) - No
Ports & interfaces - Cabling type - Fully-Modular
Ports & interfaces - Cabling type - Modular
Ports & interfaces - CPU power connector (4+4 pin) - Yes
Ports & interfaces - EPS power connector (4+4 pin) - Yes
Ports & interfaces - EPS power connector (8-pin) - No
Ports & interfaces - Floppy disk drive connector - No
Ports & interfaces - Motherboard power cable length - 60 cm
Ports & interfaces - Motherboard power connector - 20+4 pin ATX
Ports & interfaces - Number of SATA power connectors - 6
Ports & interfaces - PCI Express power connectors (6+2 pin) - 4
Ports & interfaces - Peripheral (Molex) power connectors (4-pin) - 3
Ports & interfaces - Peripheral (Molex) power connectors (4-pin) - 4
Power - AC input frequency - 47 - 63 Hz
Power - AC input voltage - 100 - 240 V
Power - Combined power (+3.3V) - 100 W
Power - Combined power (+5V) - 100 W
Power - Combined power (+5Vsb) - 12.5 W
Power - Combined power (+12V) - 648 W
Power - Combined power (-12V) - 3.6 W
Power - Efficiency - 90%
Power - Maximum input current (@110V) - 8 A
Power - Maximum input current (@110V) - 10 A
Power - Maximum input current (@220V) - 4 A
Power - Maximum input current (@220V) - 5 A
Power - Max output current (+3.3V) - 20 A
Power - Max output current (+5V) - 20 A
Power - Max output current (+5Vsb) - 2.5 A
Power - Max output current (+5Vsb) - 20 A
Power - Max output current (+12V) - 54 A
Power - Max output current (-12V) - 0.3 A
Power - Power Factor Correction (PFC) type - Active
Power - Power protection features - Over current
Power - Power protection features - Over current, Over power, Over voltage, Short circuit
Power - Power protection features - Overheating
Power - Power protection features - Over power
Power - Power protection features - Over voltage
Power - Power protection features - Short circuit
Power - Total power - 650 W
Power supply - 650 W
producer - MSI
Producer - MSI
producerCode - 306-7ZP8C11-CE0
ProducerCode - 306-7ZP8C11-CE0
ProductName - MAG A650GL
productName - MSI MAG A650GL 650 W 120 mm 80 PLUS Gold power supply
productSize - Normal
PSU - ATX 3.0
PSU features - For gaming
PSU Output Power - 650 Watts
SATA power connectors - 6
Shipping Box Depth Shipping/Package Box Dimensions - 46 cm
Shipping Box Height Shipping/Package Box Dimensions - 32.6 cm
Shipping box quantity - 6
Shipping Box Weight Shipping/Package Box Dimensions - 16.2 kg
Shipping Box Width Shipping/Package Box Dimensions - 39.5 cm
ShortDescription - 550 | ATX | 140 mm | 20 + 4 pin | 150mm x 86mm x 160mm | 80PLUS GOLD
ShortSummaryDescription - MSI MAG A650GL, 650 W, 100 - 240 V, 10 A, 5 A, Active, 100 W
sizeX - 300
sizeY - 220
sizeZ - 125
Title - MSI MAG A650GL power supply unit 650 W 20+4 pin ATX ATX Black
title_en - MSI MAG A650GL 650W Power supply unit
title_lv - MSI MAG A650GL 650W Barošanas bloks
title_ru - MSI MAG A650GL 650W Блок питания
Unit Box Height - 0.125
Unit Box Length - 0.3
Unit Box Width - 0.223
Unit Brutto Volume - 0.009872 cubm
Unit Gross Weight - 2.7 kg
Unit Net Weight - 1.7 kg
URL - https://www.msi.com/Power-Supply/MAG-A650GL/Overview
Vendor Homepage - www.msi.com/Power-Supply/MAG-A650GL/Overview
vendpn - MAG A650GL
Warranty - 24 months
WarrantyInfo -
warrantyLength - 84
warrantyType - G
weight - 2 kg
weight - 2580
Weight & dimensions - Depth - 140 mm
Weight & dimensions - Height - 86 mm
Weight & dimensions - Width - 150 mm
