Brand - Epson
BrandPartCode - V11H923640
Category - Data Projectors
Code - V11H923640
Design - Cable lock slot - Yes
Design - Cable lock slot type - Kensington
Design - Placement - Ceiling, Desktop, Wall
Design - Product colour - Black
Design - Product type - Ultra short throw projector
Design > Colour of product - Black
Design > Producer product family - Ultra Short-throw Laser Projector for Digital Signage
EAN - 8715946688695
Features - Country of origin - China
Features - Noise level - 36 dB
Features - Noise level (economic mode) - 27 dB
Features - Password protection - Yes
GTIN - 8715946688695
Lens system - Fixed focal length - 3.9 mm
Lens system - Focus - Manual
Lens system - Throw ratio - 0.27 - 0.37:1
Lens system - Zoom ratio - 1.35:1
Lens system - Zoom type - Auto
Lens system > Lens type - Optical
Lens system > Throw ratio - 0.27-0.37:1
Light source - Light source type - Laser
Light source - Service life of light source - 20000 h
Light source - Service life of light source (economic mode) - 30000 h
Logistics data - Harmonized System (HS) code - 85286200
Logistics data - Products per pallet - 12 pc(s)
Logistics data - Products per pallet (UK) - 12 pc(s)
Logistics data - Quantity per pack - 1 pc(s)
LongDesc - EB-805FThis laser display solution brings informative signage to life and produces scalable projections of up to 130 inches. It brings a fresh dimension to signage with borderless images and projection onto ultra-wide surfaces, including glass and curved walls. The EB-805F features Full HD 1080p image quality and delivers powerful and informative displays for retail, hospitality and visitor attractions.Innovative and cost effectiveEpson's advanced laser technology is robust and reliable, providing a fit-and-forget digital signage solution. It offers bright and vivid colours in a cost-effective solution that's capable of large display sizes.Large and scalable imagesThe EB-805F enables scalable display sizes of up to 130 inches, in Full HD resolution with 5,000 lumen brightness and 3LCD technology for bright colours and high display quality even in bright spaces.Versatile and easy to installThis sleek, stylish and bright display solution offers the flexibility to fulfil the most exacting brief, and the versatility to work in tight spaces. It can be mounted on the wall, ceiling, floor, or even hidden away to create added mystery. Its ultra-short-throw design enables projection of large images from a short distance. A white version is also available.Flexible playback optionsContent can be played directly from a USB stick, including: playlists, videos, and signage content using the built-in content playback feature and Epson Projector Content Manager software. Users can benefit from multi-projector and daisy-chain support for built-in edge blending, or illuminate an entire wall with one huge image. Also, the split screen feature allows users to connect multiple input sources to display different content sources simultaneously.
LongProductName - 3LCD, 5000 lm, Full HD, 1080p, 1920 x 1080, 16:9, 2.500.000 : 1, Laser
LongSummaryDescription - Epson EB-805F. Projector brightness: 5000 ANSI lumens, Projection technology: 3LCD, Projector native resolution: 1080p (1920x1080). Light source type: Laser, Service life of light source: 20000 h, Service life of light source (economic mode): 30000 h. Focus: Manual, Fixed focal length: 3.9 mm, Zoom type: Auto. Video processing: 10 bit, Video colour modes: Blackboard, Cinema, Dynamic, Presentation, sRGB, DICOM simulation mode, Multi-projection. Serial interface type: RS-232C, HDMI connector type: Full-size
Multimedia - Built-in speaker(s) - Yes
Multimedia - RMS rated power - 8 W
Multimedia > Built-in speaker(s) - Yes
Name - Epson | EB-805F | Full HD (1920x1080) | 5000 ANSI lumens | Black | Lamp warranty 12 month(s)
Network - Ethernet LAN - Yes
Network - Ethernet LAN (RJ-45) ports - 1
Networking > Wi-Fi connection - Yes (optional)
Networking > Wi-Fi standards - 802.11ac
Operational conditions - Operating relative humidity (H-H) - 20 - 80%
Operational conditions - Storage relative humidity (H-H) - 10 - 90%
Operational conditions - Storage temperature (T-T) - -10 - 60 °C
Other features - Supported network protocols - HTTPS, IPv6, SNMP, ESC/VP.net, PJLink
Other features > Aspect ratio - 16:9
Package features > Classification of battery - CL126:NE:2016-12-09
Package features > Composition of battery - CL127:KT:2016-12-09
Package features > Embeeded battery - Yes
Package features > Gross depth (mm) - 590 mm
Package features > Gross height (mm) - 340 mm
Package features > Gross weight - 12.25 kg
Package features > Gross width (mm) - 535 mm
Package features > Packing quantity - 1.00 pc(s)
Package features > Palette Qty - 16 pc(s)
Package features > Paper/Pasteboard - 2300.00 g
Package features > Plastic (No PET) - 585 g
Package features > Tare weight (kg) - 2.85 kg
Package features > TI weight (kg) - 0.02 kg
Package features > Type of battery - Battery
Package features > Volume (m3) - 0.107321 m³
Package features > WEE classification - CL109:5:2017-04-01
Package features > WEEE tax - Yes
Packaging content - Batteries included - Yes
Packaging content - Bundled software - Inhalt DIY-App, EasyMP Multi PC Projection, Epson Projektor Content Manager, Epson Projektor Management
Packaging content - Cables included - AC
Packaging content - Remote control included - Yes
Packaging content - Warranty card - Yes
Packaging content - WLAN adapter included - Yes
Performance > Light source - Laser
Performance > Noise level (economic mode) - 27 dB
Ports & interfaces - Audio (L/R) in - 3
Ports & interfaces - Audio (L/R) out - 1
Ports & interfaces - HDMI connector type - Full-size
Ports & interfaces - HDMI ports quantity - 4
Ports & interfaces - Serial interface type - RS-232C
Ports & interfaces - USB 2.0 ports quantity - 2
Ports & interfaces - USB 2.0 Type-B ports quantity - 1
Ports & interfaces - VGA (D-Sub) ports quantity - 2
Ports & interfaces > HDMI ports quantity - 4
Power - AC input frequency - 50 - 60 Hz
Power - AC input voltage - 220-240 V
Power - Power consumption (economy mode) - 262 W
Power - Power consumption (standby) - 0.5 W
Power - Power consumption (typical) - 366 W
Power - Power source - AC
Producer product name - EB-805F
ProductName - EB-805F
Projector - Colour light output - 5000 ANSI lumens
Projector - Contrast ratio (typical) - 2500000:1
Projector - Heat dissipation - 1244 BTU/h
Projector - Keystone correction, horizontal - -3 - 3°
Projector - Keystone correction, vertical - -3 - 3°
Projector - Matrix size - 1.57 cm (0.62")
Projector - Native aspect ratio - 16:9
Projector - Number of colours - 1.07 billion colours
Projector - Projection distance (tele) - 0 - 0.8 m
Projector - Projection distance (wide) - 0 - 0.4 m
Projector - Projection technology - 3LCD
Projector - Projector brightness - 5000 ANSI lumens
Projector - Projector brightness (economic mode) - 3500 ANSI lumens
Projector - Projector native resolution - 1080p (1920x1080)
Projector - Screen size compatibility - 1651 - 3302 mm (65 - 130")
Projector - Vertical scan range - 192 - 240 Hz
Projector - White light output - 5000 ANSI lumens
ShortSummaryDescription - Epson EB-805F, 5000 ANSI lumens, 3LCD, 1080p (1920x1080), 2500000:1, 16:9, 1651 - 3302 mm (65 - 130")
Software - Software support - via: Crestron Integrated Partner, Crestron RoomView, Extron IP Link, Extron XTP, AMX Device Discovery, Control4 Simple Device Discovery Protocol
Technical details - Sustainability certificates - TCO
Technical details > Brightness - 5000 ANSI lumens
Technical details > Contrast ratio - 2500000 : 1
Technical details > Lamp warranty - 12 month(s)
Technical details > Maximum resolution - Full HD (1920x1080)
Technical details > Net weight - 9.4 kg
Technical details > Producer - Epson
Title - Epson EB-805F data projector Ultra short throw projector 5000 ANSI lumens 3LCD 1080p (1920x1080) Black
URL - https://www.epson.co.uk/products/projectors/home-cinema/eb-805f?productfinder=V11H923640
Video - Full HD - Yes
Video - Video colour modes - Blackboard, Cinema, Dynamic, Presentation, sRGB, DICOM simulation mode, Multi-projection
Video - Video processing - 10 bit
Warranty - 60
Warranty - 60 month(s)
WarrantyInfo - 60 months Carry-in or 12000 h
Weight & dimensions - Depth - 375 mm
Weight & dimensions - Height - 210 mm
Weight & dimensions - Package depth - 595 mm
Weight & dimensions - Package height - 350 mm
Weight & dimensions - Package weight - 13.2 kg
Weight & dimensions - Package width - 535 mm
Weight & dimensions - Weight - 9.4 kg
Weight & dimensions - Width - 458 mm
Weight & dimensions > Weight - 9400 g
