Noctua NF-F12 industrialPPC-2000 PWM

category - Aircooling|Fans|By Size|120mm PC Fans
Category_1 - Computer Cases and Cooling
Category_2 - Fans
code - NF-F12 INDUSTRIALPPC-2000 PWM
Design - Material - Fiberglass
Design - Material - Polyamide
Design - Product colour - Black
Design - Product colour - Bronze
dimensionalWeight - 189
ean - 4716123315391
EAN_code - 4716123315391
Manufacturer - Noctua
Manufacturer_code - NF-F12 iPPC-2000 PWM
Name - Noctua NF-F12 Indu. 2000 PWM - 120mm - industrial PPC
name - Noctua NF-F12 industrialPPC-2000 PWM - 120mm
Other features - Harmonized System (HS) code - 84733080
Performance - Airflow - 121.8 m³/h
Performance - Compatible processor series - Not supported
Performance - Fan diameter - 12 cm
Performance - Maximum air pressure - 3.94 mmH2O
Performance - Mean time between failures (MTBF) - 150000 h
Performance - Noise level (high speed) - 29.7 dB
Performance - Rotational speed (max) - 2000 RPM
Performance - Rotational speed (min) - 450 RPM
Performance - Suitable location - Computer case
Performance - Supported processor sockets - Not supported
Performance - Type - Fan
Power - Power consumption (typical) - 1.2 W
Power - Rated current - 0.1 A
Power - Voltage - 12 V
producerCode - NF-F12 IPPC-2000 PWM
productName - Noctua NF-F12 industrialPPC-2000 PWM Computer case Fan 12 cm Black, Brown
productSize - Normal
sizeX - 175
sizeY - 31
sizeZ - 175
Technical details - Bearing technology - SSO2
Technical_details - Conceived for industrial heavy duty applications that require enhanced cooling performance and advanced ingress protection, the NF-F12 industrialPPC (Protected Performance Cooling) is a ruggedised high-speed version of the award-winning retail model. Thanks to the outstanding aerodynamic efficiency of the NF-F12 design and the use of a novel three-phase motor, the industrialPPC version provides superior airflow and pressure capacity while keeping noise levels and power consumption moderate as against comparable high-speed fans. While its fibre-glass reinforced polyamide construction and certified water and dust protection make the NF-F12 industrialPPC Suitable for operation in challenging environments, the renowned SSO2 bearing technology guarantees an MTBF of over 150.000hrs. Topped off with Noctua’s trusted reliability and 6 years manufacturer’s warranty, the NF-F12 industrialPPC is an ideal choice for highly demanding applications that require superior flow rates and ultimate dependability. Attachment screwed Power Connection PWM fan connector Fan Bearing SSO Power Input 0 - 1.2 watt(s) Voltage Range 0 - 12 V Number of Revolutions 450 - 2000 rpm Volume 0 - 29.7 dB(A) Volumetric Flow 0 - 121.8 m3/h, 0 - 71.7 cfm Dimensions Fans Fan 1 120 x 120 x 25 mm
warrantyLength - 24
warrantyType - G
Weight - 0,26
weight - 268
Weight & dimensions - Depth - 120 mm
Weight & dimensions - Height - 25 mm
Weight & dimensions - Width - 120 mm
