Brand - ARCTIC
BrandPartCode - ACFAN00151A
Category - Computer Cooling Systems
Design - Fan connector - 4-pin
Design - Number of fan blades - 5
Design - Number of fans - 1 fan(s)
Design - Product colour - Black
EAN - 4895213702041
Gross Weight Kg - 0,1
GTIN - 4895213702041
LongDesc - Not only that we at ARCTIC free the IT world from noise – we care for the right sound as well!As an international company, our expertise extends over noise reduction in PCs to consumer electronics products.
LongProductName - 80 x 25 mm, 200 - 3000 RPM, 23.4 CFM, 40.3 m³/h, 0.3 Sone, 12V DC, 78.5 g
LongSummaryDescription - ARCTIC P8 PWM PST CO - Pressure-optimised 80 mm Fan with PWM PST for Continuous Operation. Type: Fan, Fan diameter: 8 cm, Rotational speed (min): 200 RPM, Rotational speed (max): 3000 RPM, Noise level: 0.3 sone, Maximum airflow: 23.4 cfm, Airflow: 40.3 m³/h, Maximum air pressure: 1.9 mmH2O, Bearing type: Fluid Dynamic Bearing (FDB). Voltage: 12 V. Width: 80 mm, Depth: 25 mm, Height: 80 mm. Product colour: Black
Manufacturer Code - ACFAN00151A
Manufacturer Name - Arctic Cooling
Other features - Country of origin - China
Other features - Mounting hole pattern (W x D) - 71.5 x 71.5 mm
Packaging content - Manual - Yes
Packaging content - Number of screws - 4
Packaging content - Package type - Box
Packaging content - Screws included - Yes
Performance - Airflow - 40.3 m³/h
Performance - Bearing type - Fluid Dynamic Bearing (FDB)
Performance - Compatible processor series - Not supported
Performance - Fan diameter - 8 cm
Performance - Maximum airflow - 23.4 cfm
Performance - Maximum air pressure - 1.9 mmH2O
Performance - Noise level - 0.3 sone
Performance - Pulse-width modulation (PWM) support - Yes
Performance - Rotational speed (max) - 3000 RPM
Performance - Rotational speed (min) - 200 RPM
Performance - Suitable location - Computer case
Performance - Supported processor sockets - Not supported
Performance - Type - Fan
Power - Rated current - 0.09 A
Power - Voltage - 12 V
ProductName - P8 PWM PST CO - Pressure-optimised 80 mm Fan with PWM PST for Continuous Operation
Short description - Lüfter Gehäuse Arctic P8 PWM PST CO (black) (24-7) / 4-pin
ShortSummaryDescription - ARCTIC P8 PWM PST CO - Pressure-optimised 80 mm Fan with PWM PST for Continuous Operation, Fan, 8 cm, 3000 RPM, 0.3 sone, 23.4 cfm, 40.3 m³/h
Title - ARCTIC P8 PWM PST CO - Pressure-optimised 80 mm Fan with PWM PST for Continuous Operation
URL - https://www.arctic.ac/eu_en/p8-pwm-pst-co.html
WarrantyInfo - 10 year
Weight & dimensions - Depth - 25 mm
Weight & dimensions - Height - 80 mm
Weight & dimensions - Package depth - 26 mm
Weight & dimensions - Package height - 82.5 mm
Weight & dimensions - Package weight - 97 g
Weight & dimensions - Package width - 82.5 mm
Weight & dimensions - Weight - 78.5 g
Weight & dimensions - Width - 80 mm
