10/100/1000M LAN Ports - 8
Auto MDI/MDI-X - Yes
Bandwidth, Gbit/s - 20
Buffer size, KB - 128
Category 1 - Netzwerk
Category 2 - Switching Hubs
Category Code - SWI
Code - TSW200000050
Description - TELTONIKA IOT SWITCH TSW200 POE 8X 30W PORT TSW200000050
Description - TSW200 is industrial unmanaged switch from Teltonika Networks. TSW200 is equipped with 2 SFP ports for long-range Fiber-optic communication and 8 Gigabit Ethernet ports which support IEEE802.3af and IEE802.3at Power-over-Ethernet standards. Classified as power source equipment (PSE), it enables centralization of the power supply, providing up to 30 watts per port and reducing the effort for installing power. It has 10/100/1000 Mbps Ethernet ports to provide an economical high-bandwidth solution for your industrial Ethernet network. This rugged unmanaged industrial switch is ideal for professional high bandwidth applications where it is necessary to provide both: reliable data connection and power supply.
Design > Case design - Aluminum
Design > Form factor - Desktop
Design > Rack mounting - DIN rail or wall mounting (additional kit needed), flat surface placement
Dimensions W x D x H, mm - 132 x 95.1 x 44.2
EAN - 4779051840120
Ethernet LAN (RJ-45) PoE ports quantity - 8
Ethernet LAN data transfer rates, Mbit/s - 10/100/1000
Fiber ports quantity - 2
Fiber type - SFP
Full Description Line - 8x10/100/1000M|2xSPF|PoE ports 8|PoE power budget 240 Watts|Switching capacity 20 Gbps|Power supply External|Unit Net Weight 0.456 kg
Height - 72.000000
IP classification - IP30
Jumbo Frames support - 9216 bytes
LED indicators - 1 x Power LED, 16 x LAN status LEDs 2 x SFP status LEDs
Length - 175.000000
MAC address table, entries - 2K
Management features > Switch type - Unmanaged
Manufacturer - Teltonika
ManufacturerPartNumber - TSW200000050
Material > Case material - Full aluminum housing
Model name - TSW200
MPN - TSW200000050
Name - 8+2P Teltonika TSW200 Industrial GSwitch 8x PoE+ (240W) 2x SFP
Name - Teltonika Ethernet Switch TSW200 Unmanaged, Desktop, 1 Gbps (RJ-45) ports quantity 8, SFP ports quantity 2, PoE ports quantity 8, Total PoE Power Budget (at PSE): 240 W, PoE Max Power per Port (at PSE): 30W, IP30, Full aluminum housing, ADAPTER NOT INCLUDED | Teltonika | Ethernet Switch | TSW200 | Unmanaged | Desktop | Gigabit Ethernet (copper) ports quantity 8 | 10 Gbps (RJ-45) ports quantity 0 | SFP ports quantity 2 | SFP+ ports quantity 0 | Combo ports quantity 0 | Power over Ethernet (PoE) ports quantity 8 | Power supply type Ingress Protection Rating: IP30 | 24 month(s)
Networking standards - 802.3i, 802.3u, 802.3ab, 802.3x, 802.3az
Operating temperature range (T-T), °C - - 40 - 75
Operational conditions > Operating relative humidity (H-H) - 10 % to 90 % non condensing %
Operational conditions > Operating temperature (T-T) - 40 °C to +75 °C °C
Other features > Bandwidth - 20 (Non-blocking) Gbit/s
Other features > Box contents - TSW200, Quick Start Guide, (NO ADAPTER)
Other features > Connectivity LEDs - 1 x Power LED, 16 x LAN status LED’s 2 x SFP status LED’s
Other features > Dimensions (WxDxH) - 132x44.2x95.1 mm
Other features > Power supply type - Ingress Protection Rating: IP30
Package features > Embeeded battery - No
Package features > Gross depth (mm) - 175 mm
Package features > Gross depth master carton - 375 mm
Package features > Gross height (mm) - 70 mm
Package features > Gross height master carton - 170 mm
Package features > Gross width (mm) - 150 mm
Package features > Gross width master carton - 368 mm
Package features > Net weight master carton - 6.03 kg
Package features > Packing quantity - 10 pc(s)
Package features > Palette Qty - 730 pc(s)
Package features > Paper/Pasteboard - 130.00 g
Package features > Plastic (No PET) - 20.00 g
Package features > Tare weight (kg) - 0.15 kg
Package features > Tare weight master carton - 0.399 kg
Package features > Volume (m3) - 0.0018375 m³
Package features > WEE classification - CL109:6:2017-04-01
Package features > WEEE tax - Yes
Packaging content > AC adapter included - NO
PDF - https://www.blobs.lt/products/9/6/4/1/5/3/7b440e33ac09d2d52b0e68df899b8b95/original.pdf
PDF - https://www.blobs.lt/products/9/6/4/1/5/3/92ba1fefe9e06873e07cf974bd7bf341/original.pdf
PDF - https://www.blobs.lt/products/9/6/4/1/5/3/84646fb34d01942c2e917a1647614af5/original.pdf
PeriodofWarranty - 2 Y
PoE capasity per port W - 30
PoE ports - 8
PoE power budget - 240 Watts
Ports & interfaces > 10 Gbps (RJ-45) ports quantity - 0
Ports & interfaces > Combo ports quantity - 0
Ports & interfaces > Combo SFP ports quantity - 0
Ports & interfaces > Ethernet LAN (RJ-45) ports - 8
Ports & interfaces > Gigabit Ethernet (copper) ports quantity - 8
Ports & interfaces > POE - PoE+ 802.3at/af
Ports & interfaces > Predominant port type - 10/100/1000 Mbps (RJ-45)
Ports & interfaces > SFP+ ports quantity - 0
Ports & interfaces > SFP ports quantity - 2
Ports quantity - 8
Power > Input voltage - 7-57 VDC (Input voltage range for PoE: 44-57 VDC) V
Power > Power consumption (max) - 1,81 W/5.5 W/245.5 W(idle/max no PoE/max) W
Power over Ethernet (PoE), W - 240
Power over Ethernet (PoE) > Power over Ethernet (PoE) - Yes
Power over Ethernet (PoE) > Power over Ethernet (PoE) ports quantity - 8
Power over Ethernet (PoE) > Power over Ethernet (PoE) power per port - 30 W
Power over Ethernet (PoE) > Power over Ethernet plus (PoE+) ports quantity - 30
Power over Ethernet (PoE) > Total Power over Ethernet (PoE) budget - 240 W
Power over Ethernet (PoE) Support - Yes
Power supply - External
Producer product family - Ethernet Switch
Producer product name - TSW200
Shipping Box Depth Shipping/Package Box Dimensions - 17 cm
Shipping Box Height Shipping/Package Box Dimensions - 14.6 cm
Shipping box quantity - 1
Shipping Box Weight Shipping/Package Box Dimensions - 0.6 kg
Shipping Box Width Shipping/Package Box Dimensions - 7 cm
SPF LAN Ports - 2
Switching capacity - 20 Gbps
Switch type - Ethernet
Technical details > Gross weight - 0.603 kg
Technical details > Net weight - 0.453 kg
Technical details > Producer - Teltonika
Technical details > Warranty - 12 month(s)
Unit Box Height - 0.146
Unit Box Length - 0.17
Unit Box Width - 0.07
Unit Brutto Volume - 0.001737 cubm
Unit Gross Weight - 0.6 kg
Unit Net Weight - 0.456 kg
Vendor Homepage - teltonika-networks.com/product/tsw200/
Warranty - 12
Warranty - 24 months
Weight - 0.62
Weight - 0.620000
Weight, g - 517
Width - 147.000000
