D-Link DES-1016D/E 16x10/100

ARTIKEL1 - DES-1016D FASTETHERNET SWITCH
ARTIKEL2 - 16X 10/100MBIT RJ45 NWAY DESKTOP
Brand - D-Link
BrandPartCode - DES-1016D/E
Category - Network Switches
Category - Root/Electronics/Networks and communication/Switchers
Category_1 - Network and Servers
Category_2 - Network - Switches and Hubs
Data transmission - MAC address table - 8000 entries
Data transmission - Maximum data transfer rate - 0.1 Gbit/s
Design - LED indicators - Power
EANCode - 0790069221279
Eans - 0790069221279
EAN_code - 0790069221279
Gewicht - 1.84
GRUPPE1 - Network
GRUPPE2 - Switches Managed
GTIN - 790069221279
GTIN - 0790069221279
GTIN - 0790069801365
GTIN - 790069801365
GTIN - 7900692212626
GTIN - 7900692212794
HERSTELLER - D-LINK
HSTNUMMER - DES-1016D/E
Logistics data - Harmonized System (HS) code - 85176990
LongDesc - 16-Port 10/100Mbps Switch for SOHO/Workgroup10/100Mbps Unmanaged Switch The DES-1016D is an unmanaged 10/100Mbps switch designed to enhance workgroup performance while providing a high level of flexibility. Powerful yet easy to use, this device allows users to simply plug any port to either a 10Mbps or 100Mbps network to multiply bandwidths, boost response time and satisfy heavy load demands.16 Auto-sensing 10/100Mbps PortsThe switch comes with 16 10/100Mbps ports, allowing a small workgroup to flexibly integrate to Ethernet and Fast Ethernet. These intelligent ports detect the network speed and auto-negotiate between 100BASE-TX and 10BASE-T, as well as between full and half-duplex.Flow Control for Secure TransmissionAll ports support flow control. This function minimizes dropped packets by sending out collision signals when the port's receiving buffer is full.Auto-negotiation of MDI/MDIX Cross OverAll ports support auto-negotiation of MDI/MDIX cross over. This eliminates the need for cross over cables or uplink ports. Any port can simply plug to a server, a hub or a switch, using the usual straight-through twisted-pair cable.Plug-and-PlayWith 16 plug-and-play ports, the switch is a perfect choice for workgroups to upgrade performance in a client/server environment. The ports can be connected to servers in fullduplex, or hubs in half-duplex.Direct Connection to WorkstationsWith low-cost connection per-port, the switch can be set up for direct connection from the PCs. This relieves data bottleneck by giving each workstation a dedicated bandwidth on the network.
LongProductName - 16 Port 10/100Mbps Desktop Switch
LongSummaryDescription - D-Link DES-1016D. Switch type: Unmanaged. Basic switching RJ-45 Ethernet ports quantity: 16. Full duplex. MAC address table: 8000 entries
Management features - Switch type - Unmanaged
Manufacturer - D-Link
Manufacturer_code - DES-1016D/E
Name - D-Link DES-1016D
Name - D-Link DES-1016D 100/UNM/16
Network - Full duplex - Yes
Operational conditions - Operating relative humidity (H-H) - 5 - 90%
Operational conditions - Operating temperature (T-T) - 0 - 50 °C
Other features - Connectivity technology - Wired
Other features - Data transfer rate - 100 Mbit/s
Other features - Dimensions (WxDxH) - 324 x 231 x 44.5 mm
Packaging data - Package depth - 376 mm
Packaging data - Package height - 78 mm
Packaging data - Package weight - 1.82 kg
Packaging data - Package width - 282 mm
Performance - Internal memory - 2 MB
Ports & interfaces - Basic switching RJ-45 Ethernet ports quantity - 16
Power over Ethernet (PoE) - Power over Ethernet (PoE) - No
Producer - D-link
ProducerCode - DES-1016D
ProductName - DES-1016D
ShortDescription -
ShortSummaryDescription - D-Link DES-1016D, Unmanaged, Full duplex
Stck_Kart - 5
Stck_Pal - 0
Storno - N
Technical details - Master (outer) cases per pallet (air) - 24 pc(s)
Technical details - Master (outer) cases per pallet (sea) - 36 pc(s)
Technical details - Pallet gross length - 120 cm
Technical details - Pallet gross weight (air) - 256.4 kg
Technical details - Pallet gross weight (sea) - 376.1 kg
Technical details - Pallet gross width - 110 cm
Technical details - Pallet height (air) - 137.9 cm
Technical details - Pallet height (sea) - 2.03 m
Technical details - Products per pallet (air) - 120 pc(s)
Technical details - Products per pallet (sea) - 180 pc(s)
Technical details - Products per shipping (inner) case - 5 pc(s)
Technical details - Shipping (inner) case gross weight - 9.97 kg
Technical details - Shipping (inner) case height - 31.1 cm
Technical details - Shipping (inner) case length - 42 cm
Technical details - Shipping (inner) case net weight - 9.11 kg
Technical details - Shipping (inner) case width - 39.2 cm
Technical_details - 16-Port 10/100Mbps Switch for SOHO/Workgroup
10/100Mbps Unmanaged Switch The DES-1016D is an unmanaged 10/100Mbps switch designed to enhance workgroup performance while providing a high level of flexibility. Powerful yet easy to use, this device allows users to simply plug any port to either a 10Mbps or 100Mbps network to multiply bandwidths, boost response time and satisfy heavy load demands. 16 Auto-sensing 10/100Mbps Ports
The switch comes with 16 10/100Mbps ports, allowing a small workgroup to flexibly integrate to Ethernet and Fast Ethernet. These intelligent ports detect the network speed and auto-negotiate between 100BASE-TX and 10BASE-T, as well as between full and half-duplex. Flow Control for Secure Transmission
All ports support flow control. This function minimizes dropped packets by sending out collision signals when the port's receiving buffer is full. Auto-negotiation of MDI/MDIX Cross Over
All ports support auto-negotiation of MDI/MDIX cross over. This eliminates the need for cross over cables or uplink ports. Any port can simply plug to a server, a hub or a switch, using the usual straight-through twisted-pair cable. Plug-and-Play
With 16 plug-and-play ports, the switch is a perfect choice for workgroups to upgrade performance in a client/server environment. The ports can be connected to servers in fullduplex, or hubs in half-duplex. Direct Connection to Workstations
With low-cost connection per-port, the switch can be set up for direct connection from the PCs. This relieves data bottleneck by giving each workstation a dedicated bandwidth on the network. Transfer Rate LAN 10/100 MBit/s LEDs Activity, 16x Lan Ports RJ-45 LAN 16 Product dimensions 442 x 54 x 207 mm
Title - D-Link DES-1016D Unmanaged
URL - https://www.dlink.co.uk/?go=gNTyP9CgrdFOIC4AStFCF834mptYKO9ZTdvhLPG3yV3oV45/kP98f8p8M6tj5jkkBSjoyiVD94gJBNc=
WarrantyInfo - 2 years
Weight - 1,84
