ID: 1183384
Код товара: IG1004S2P
Можно заказать 1 шт. Доступность: 14 дней после утверждения заказа
Гарантия: 2 лет
Cudy IG1004S2P 4PORT PoE 2SFP
Изображение может отличаться от реального товара, могут быть аксессуары и детали, не поставляемые с реальным товаром.
Варианты доставки
- Доставка на Smartpost 1,99 €: 18.02.2025
- Доставка в почтомат Omniva 1,99 €: 18.02.2025
- Доставка курьером 3,99 €: 18.02.2025
Основные параметры продукции Все параметры
- Количество портов Base T: 4
- Скорость Base T: 10/100/1000
Места подключения и оснащение
Количество портов Base T
: 4
Порты PoE
: 4
Порты SFP
: 2
Скорость Base T
: 10/100/1000
Спецификация
Вес (г)
: 360 g
Количество фанатов
: Fanless
Общий Бюджет Питания PoE
: 120 W
Поддержка PoE
: Ir
PoE Бюджет питания на порт
: 30 W
Сетевые карты
Более подробная спецификация
Certificates - Compliance certificates - CE
Data transmission - Forwarding rate - 15 Mpps
Data transmission - Jumbo frames - 9000
Data transmission - Jumbo frames support - Yes
Data transmission - MAC address table - 8000 entries
Data transmission - Switching capacity - 20 Gbit/s
Design - DIN rail mounting - Yes
Design - Housing material - Aluminium
Design - International Protection (IP) code - IP40
Design - LED indicators - Yes
Design - Product colour - Black
Design - Rack mounting - No
Design - Reset button - Yes
dimensionalWeight - 460
Management features - Switch type - Unmanaged
Network - 10G support - No
Network - Auto MDI/MDI-X - Yes
Network - Cable types supported - Cat3
Network - Cable types supported - Cat4
Network - Cable types supported - Cat5
Network - Cable types supported - Cat6
Network - Copper ethernet cabling technology - 10BASE-T
Network - Copper ethernet cabling technology - 100BASE-TX
Network - Copper ethernet cabling technology - 1000BASE-TX
Network - Ethernet LAN data rates - 10,100,1000 Mbit/s
Network - Full duplex - Yes
Network - Half duplex - Yes
Network - Networking standards - IEEE 802.3
Network - Networking standards - IEEE 802.3ab
Network - Networking standards - IEEE 802.3u
Network - Networking standards - IEEE 802.3x
Network - Networking standards - IEEE 802.3z
Operational conditions - Operating relative humidity (H-H) - 5 - 95%
Operational conditions - Operating temperature (T-T) - -40 - 85 °C
Operational conditions - Storage temperature (T-T) - -40 - 85 °C
Optical fiber - Maximum transfer distance (Multi-mode) - 2000 m
Optical fiber - Maximum transfer distance (Single-mode) - 80000 m
Optical fiber - Transmission distance (max) - 80 km
Packaging data - Package weight - 460 g
Performance - Mean time between failures (MTBF) - 300000 h
Ports & interfaces - Basic switching RJ-45 Ethernet ports quantity - 4
Ports & interfaces - Basic switching RJ-45 Ethernet ports type - Gigabit Ethernet (10/100/1000)
Ports & interfaces - Gigabit Ethernet (copper) ports quantity - 4
Ports & interfaces - Installed SFP modules quantity - 2
Power - DC input voltage - 48 - 57 V
Power - Power consumption (max) - 3 W
Power - Power source - DC/PoE
Power - Power supply included - No
Power - Redundant power supply (RPS) support - Yes
Power - Surge protection - Yes
Power - Surge protection voltage - 4 kV
Power over Ethernet (PoE) - Power over Ethernet (PoE) - Yes
Power over Ethernet (PoE) - Power over Ethernet (PoE) ports quantity - 4
Power over Ethernet (PoE) - Power over Ethernet (PoE) power per port - 30 W
Power over Ethernet (PoE) - Total Power over Ethernet (PoE) budget - 120 W
producerCode - IG1004S2P
productName - Cudy IG1004S2P network switch Unmanaged Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black
productSize - Normal
sizeX - 215
sizeY - 160
sizeZ - 67
Sustainability - Sustainability compliance - Yes
warrantyLength - 24
warrantyType - G
weight - 635
Weight & dimensions - Depth - 103 mm
Weight & dimensions - Height - 44.2 mm
Weight & dimensions - Weight - 360 g
Weight & dimensions - Width - 143.7 mm
