2.5GbE LAN Ports - 8
10/100/1000/2500 Mbps ports - 8
10/100/1000M LAN Ports - 16
Accessories included -
Application - Medium and large companies
brand - Ubiquiti
category - Ubiquiti > UniFi komutatori > Professional Max
Category 1 - Netzwerk
Category 2 - Switching Hubs
Category Code - SWI
Category_1 - Network and Servers
Category_2 - Network - Switches and Hubs
Certificates - CE, FCC, IC
Chassis type - Rack
CnCode CnCode - 85176200
Code - USW-Pro-Max-24-PoE
Console port - No
Data transmission - Switching capacity - 112 Gbit/s
Data transmission - Throughput - 56 Gbit/s
Description - 24-portowy przełącznik Layer 3 Etherlighting obsługujący wysoką moc wyjściową PoE++.
Description - A 24-port, Layer 3 Etherlighting switch with 2.5 GbE and PoE++ output.
Design - Backlight display - Yes
Design - Display type - LCM
Design - Housing material - SGCC
Design - LED indicators - Link
Design - LED indicators - Network
Design - LED indicators - Speed
Design - LED indicators - Status
Design - Product colour - Grey
Design - Rack mounting - Yes
Design - Reset button - Yes
Design - Stackable - Yes
Design > Form factor - Rackmountable
dimensionalWeight - 5314
dimension depth - 520 mm
dimension height - 120 mm
Dimensions - 442 x 325 x 44 mm
Dimensions - 442 x 325 x 44 mm
dimension weight - 6000 g
dimension width - 440 mm
EAN - 0810084692608
EAN - 810084692714
ean - 810084692714
EAN - 0810084692714
EAN_code - 4251876923504
Environment requirements - Temperatura otoczenia: -5 do 40 °C Wilgotność robocza otoczenia: 10 do 90% bez kondensacji
Fan - No
Full Description Line - Type L3|16x10/100/1000M|8x2.5GbE|2xSPF+|PoE power budget 400 Watts|Switching capacity 112 Gbps|Dimensions 442 x 325 x 44 mm|Unit Net Weight 5.1 kg
Gross Weight Kg - 5,4
guarantee - 12
guarantee_type - normal
height - 0.15 m
L2 features - IGMP snooping STP / RSTP with priorities and port-level disable Port isolation Storm control Voice VLAN Port mirroring LACP port aggregation Multicast / broadcast rate limiting MAC address blocking Flow control 802.1X control Jumbo frames Proprietary loop protection DHCP snooping / guarding Egress rate limit LLDP-MED Port restricted by MAC Device isolation with ACLs
L3 features - DHCP for locally-managed networks DHCP relay Inter-VLAN routing between networks on same switch Static routing between local networks Network isolation with ACLs
length - 0.54 m
Management, monitoring, configuration -
Management features - Switch layer - L3
Management features > Switch layer - L3
Management features > Switch type - Managed L3
Manufacturer - Ubiquiti
Manufacturer Code - USW-PRO-MAX-24-POE
Manufacturer Name - Ubiquiti Networks
Manufacturer_code - USW-Pro-Max-24-PoE
Model - USW-Pro-Max-24-PoE
Model name - Pro Max 24 PoE
mpn - USW-Pro-Max-24-POE
MPN - USW-Pro-Max-24-PoE
Name - 24+2P Ubiquiti UniFi USW-Pro-Max-24-PoE SFP+ 400W PoE++ M RM
name - Switch UniFi USW-Pro-Max-24-POE
Name - Ubiquiti Pro Max 24x PoE, Switch (400W PoE Budget)
Name - Ubiquiti Switch | USW-Pro-Max-24-PoE | Managed L3 | Rackmountable | SFP+ ports quantity 2 | Power over Ethernet (PoE) ports quantity 24 | PoE+ ports quantity 8 + 16 PoE++ | Power supply type AC/DC, internal, 450W
Network - 10G support - Yes
Network - VLAN support - Yes
Network architecture - GigabitEthernet
Number of 10/100 Mbps ports - None
Number of 10/100/1000 Mbps ports - 16
Number of 10Gb ports - 2
Number of COMBO ports - None
Number of PoE++ ports - 16
Number of PoE+ ports - None
Number of PoE ports (PoE & PoE+) - 8
Number of QSFP+ ports - None
Number of SFP+ ports - 10
Number of SFP56 ports - None
Number of SFP ports - None
Operational conditions - Operating relative humidity (H-H) - 10 - 90%
Operational conditions - Operating temperature (T-T) - -5 - 40 °C
Other features -
Other features > Power supply type - AC/DC, internal, 450W
Other functions -
Package features > Embeeded battery - No
Package features > Gross depth (mm) - 442 mm
Package features > Gross height (mm) - 44 mm
Package features > Gross width (mm) - 325 mm
Package features > Packing quantity - 1.00 pc(s)
Package features > Palette Qty - 137 pc(s)
Package features > Paper/Pasteboard - 1220 g
Package features > Plastic (No PET) - 300 g
Package features > Tare weight (kg) - 1.52 kg
Package features > Volume (m3) - 0.0063206 m³
Package features > WEE classification - CL109:6:2017-04-01
Package features > WEEE tax - Yes
Packaging data - Cables included - Power
Packaging data - Rack mount kit - Yes
PoE power budget - 400 Watts
Ports & interfaces - 2.5G Ethernet (copper) ports quantity - 8
Ports & interfaces - 10G Ethernet (copper) ports quantity - 2
Ports & interfaces - Basic switching RJ-45 Ethernet ports quantity - 24
Ports & interfaces - Basic switching RJ-45 Ethernet ports type - 2.5G Ethernet (100/1000/2500)
Ports & interfaces - Gigabit Ethernet (copper) ports quantity - 16
Ports & interfaces - Installed SFP+ modules quantity - 2
Ports & interfaces - Power connector - AC/DC
Ports & interfaces > PoE+ ports quantity - 8 + 16 PoE++
Ports & interfaces > Predominant port type - 10/100/1000/2500 Mbps (RJ-45)
Ports & interfaces > SFP+ ports quantity - 2
Power - AC input frequency - 50/60 Hz
Power - AC input voltage - 100 - 240 V
Power - Power consumption (max) - 50 W
Power - Power source - AC/DC
Power - Power supply included - Yes
Power - Redundant power supply (RPS) support - Yes
Power consumption - 50 W
Power over Ethernet (PoE) - Power over Ethernet (PoE) - Yes
Power over Ethernet (PoE) - Power over Ethernet (PoE) ports quantity - 8
Power over Ethernet (PoE) - Power over Ethernet (PoE) power per port - 15.4 W
Power over Ethernet (PoE) - Power over Ethernet (PoE) voltage - 57 V
Power over Ethernet (PoE) - Power over Ethernet 4PPoE (PoE++) ports quantity - 8
Power over Ethernet (PoE) - Power over Ethernet plus (PoE+) ports quantity - 8
Power over Ethernet (PoE) - Total Power over Ethernet (PoE) budget - 400 W
Power over Ethernet (PoE) > Power over Ethernet (PoE) - Yes
Power over Ethernet (PoE) > Power over Ethernet (PoE) ports quantity - 24
Power supply - Metoda mocy: Wejście uniwersalne, 100240 V AC, 50/60 Hz; Wejście prądu stałego USP-RPS Zasilacz: AC/DC, wewnętrzny, 450 W Obsługiwany zakres napięcia: 100240 V prądu przemiennego
Power supply - Internal
Primary port count - 24
producer - UBIQUITI
producerCode - USW-Pro-Max-24-PoE
productName - Ubiquiti USW-Pro-Max-24-PoE L3 2.5G Ethernet (100/1000/2500) Power over Ethernet (PoE) Grey
productSize - Normal
QoS -
Security -
Shipping Box Depth Shipping/Package Box Dimensions - 53.5 cm
Shipping Box Height Shipping/Package Box Dimensions - 46.5 cm
Shipping box quantity - 2
Shipping Box Weight Shipping/Package Box Dimensions - 13.45 kg
Shipping Box Width Shipping/Package Box Dimensions - 26.1 cm
Short description - Ubiquiti Switch UniFi 16xRJ45 GBit/8xRJ45 2.5G/2xSFP+ Managed PoE+ 400W Max 19" Rack-Mountable, 1,3" Touchscreen
sizeX - 430
sizeY - 515
sizeZ - 120
SPF+ LAN Ports - 2
Stackability - No
Supported protocols and standards -
Support for Jumbo frames - Yes
Sustainability - Sustainability certificates - CE
Sustainability - Sustainability certificates - Federal Communications Commission (FCC)
Sustainability - Sustainability compliance - Yes
Switch class - Managed
Switching capacity - 112 Gbps
Switch layer - L3
Switch type - L3
Technical details > Gross weight - 6.72 kg
Technical details > Net weight - 5.20 kg
Technical details > Producer - Ubiquiti
Technical details > Producer product family - Switch
Technical details > Producer product name - USW-Pro-Max-24-PoE
Technical_details - The USW-Pro-Max-24-PoE is the ultimate solution for companies looking for a robust and powerful network switch. Combining state-of-the-art technology with ease of use, this switch offers a wide range of features to meet the needs of demanding network applications. With 24 PoE+ ports and a total power of up to 400 watts, the USW-Pro-Max-24-PoE offers enough power to power a variety of PoE-enabled devices such as IP cameras, VoIP phones and WiFi access points. This Power over Ethernet feature eliminates the need for separate power supplies, simplifying installation and reducing cable clutter. Item No.: 100037037 Switch type EAN 4251876923504 Manufacturer no. USW Pro Max 24 PoE Rack design Network RJ-45 connections 24x (of which: 16x 10/100/1000, 8x 100/1000/2500) Forwarding rate 56 MPP/s Routing & Switching Switching bandwidth 112 GBit/s Power supply Power consumption operation: 50 W, PoE total budget: 400 W, max. PoE supply per port: 60 W Feature 1.3" touch screen Note UniFi Network version 8.0.24 or newer Dimensions Width: 442mm x Height: 44mm x Depth/Length: 325mm
Throughput - 112 Gb/s
title - Ubiquiti UniFi Switch Pro Max 24 PoE
Unit Box Height - 0.435
Unit Box Length - 0.52
Unit Box Width - 0.12
Unit Brutto Volume - 0.03247 cubm
Unit Gross Weight - 6.72 kg
Unit Net Weight - 5.1 kg
Vendor Homepage - store.ui.com/us/en/collections/unifi-switching-pro-max/products/usw-pro-max-24-poe
vendpn - USW-Pro-Max-24-PoE
VLAN -
Warranty - 12
Warranty - 12 month(s)
Warranty - 12 months
warrantyLength - 24
warrantyType - G
Weight - 5.1 kg
Weight - 6,15
Weight - 6.18
weight - 7 kg
weight - 6080
Weight & dimensions - Depth - 325 mm
Weight & dimensions - Height - 43.7 mm
Weight & dimensions - Weight - 5.1 kg
Weight & dimensions - Width - 442.4 mm
width - 0.47 m
