Accessories included - 1 x USB4 connection cable (80cm) 1 x User Manual
Category_1 - Computers and Laptops
Category_2 - Laptop - Accessories
Color - Gray
Compatible with -
Description - The DIGITUS USB4 docking station expands your notebook by another 14 ports via a single USB-C port. It offers e.g. 1 x DisplayPort and 1 x HDMI video ports for connecting monitor, beamer and TV. With dual monitor support, you can operate your displays simultaneously. Under Windows, you can output video signal to two different video ports simultaneously (SST mode), and you can also display 2 different video signals through 2 video ports (MST mode). Only SST mode is supported on Mac OS. There is a network port, further USB connectors (USB-C, USB-A), audio output and two independent card readers. The integrated USB-C port with support for Power Delivery (PD Charging) allows you to charge your laptop while using the docking station. In addition, the docking station offers various USB-C and 3.0 ports for data transfer, connecting peripherals such as mice and keyboards, and charging mobile devices. Support for 2 monitors with a maximum resolution of 4K/60 Hz - up to 3840x2160p Video interfaces 1 x DP + 1 x HDMI for connecting up to 2 monitors simultaneously (dual display support) Support dual displays under Windows OS mirroring mode and monitor screen extension Mac OS single display support monitor screen mirroring Suitable for notebooks with USB4 1 x USB-C connector - data transmission at 10 Gbps, 1 x USB-C connector with Power Delivery (PD) 3 x USB 3.2 connector - data transfer at 10 Gbps SuperSpeed, all ports with BC 1.2 functionality for charging mobile devices (max. 7.5 A). 3 x USB 2.0 connector (max. transfer rate: 480 Mbps) 1 x Gigabit LAN 10/100/1000Mbps RJ45 port 2 x card reader (microSD / SDHC, SDHX, MMC) - parallel operation possible 1 x SD card slot and 1 x microSD card slot: Supports SD 3.0 (UHS-I), SD 4.0 (UHS-II) 1 x DisplayPort 1.4 connector 1 x HDMI 2.1 connector 1 x USB Type-C connector for connecting to a notebook/laptop 1 x USB Type-C connector - for data transfer (max. 40 Gbps) 1 x stereo audio jack for headphones (3.5 mm)
dimension depth - 60 mm
dimension height - 175 mm
Dimensions - L 14.7 x W 8.0 x D 1.7 cm
dimension weight - 545 g
dimension width - 150 mm
Docking connector - No
ean - 4016032483458
EAN_code - 4016032483458
guarantee - 24
guarantee_type - external
I/O ports - 1 x 3,5 mm minijack (Headphones)
I/O ports - 1 x DisplayPort
I/O ports - 1 x HDMI Type A
I/O ports - 1 x RJ-45 (LAN)
I/O ports - 2 x Card reader
I/O ports - 2 x USB 3.1 Type C
I/O ports - 3 x USB 2.0 Type A
I/O ports - 3 x USB 3.0 Type A
Manufacturer - Digitus
Manufacturer_code - DA-70897
Name - Digitus USB4 docking station 8K, USB Type-C (grey/black, HDMI, DP, USB-A, USB-C, USB4, 3.5mm, SD/MicroSD)
name - Docking Station DA-70897
Other features - USB-C version: USB 3.1 (Gen 2) 10Gbps UHD-2 support up to 8K/30Hz up to 7680 x 4320p Power Delivery 3.0 support (max. 100W) for fast charging of the user's notebook/laptop DisplayPort Alternate Mode support DisplayPort (DP) 1.4 support USB-C Power Delivery: 100W SST and MST (Single Stream Transport Mode / Multi Stream Transport Mode) support Simultaneous display of two video outputs resolution: SST mode up to 3840p / 60Hz, MST mode up to 7680p / 30Hz Housing type: Aluminum Not all USB-C ports support all USB Type-C features. Make sure your notebook's USB-C port supports DisplayPort Alternate Mode (DP-Alt Mode) and USB Power Delivery (PD). Video output performance depends on the graphics card of the notebook and the connected monitor. Some graphics cards have limited MST support, while some monitors limit the available resolution. Only one additional external monitor can be connected to M1 chipset MacBook devices
producer - Digitus
System Requirements -
vendpn - DA-70897
Weight - 0,53
Weight - 410 g
