Digitus Universal Docking Station USB 3.0

Accessories included - 1 x Thunderbolt 3 connection cable (30cm) 1 x power adapter 1 x User Manual
Category_1 - Computers and Laptops
Category_2 - Laptop - Accessories
Code - DA-70895
Color - Black
Color - Gray
Compatible with -
Description - The Thunderbolt 3 dock provides 10 additional ports, including for video, data, power, ethernet connectivity and audio The DIGITUS Thunderbolt 3 docking station expands your notebook by another 10 ports via just one USB-C port. It offers e.g. 2 DisplayPort video ports for connecting monitor, beamer and TV. With dual monitor support, you can operate your displays simultaneously. Under Windows, you can output video signal to two different video ports simultaneously (SST mode), and you can also display two different video signals through 2 video ports (MST mode). Only SST mode is supported on Mac OS. The other interfaces provide all the common connectivity options that a modern docking station must offer. For example, there is a network port, further USB connectors (USB-C, USB-A), audio output and two independent card readers. The integrated USB-C port with support for Power Delivery (PD Charging) allows you to charge your laptop while using the docking station. In addition, the docking station offers various USB-C and 3.0 ports for data transfer, connecting peripherals such as mice and keyboards, and charging mobile devices. You can expand the functionality of your notebook, and thus also your capabilities, all you need is a free USB-C port. 10 extra connectors on your notebook for video, data, power, ethernet and audio Support for 4K Ultra HD (4096 x 2160 30-bit color @ 60Hz) on dual monitors or 8K @ 30Hz on a single monitor via Thunderbolt 3 Support for 4K @ 30Hz on dual monitors when connected to devices with DisplayPort 1.4 (HBR3) and 1080p @ 60Hz on dual monitors when connected to devices with DisplayPort 1.2 (HBR) 2) via USB-C Support dual displays under Windows OS mirroring mode and monitor screen extension Mac OS single display support monitor screen mirroring 3 x USB 3.0 2 x with SuperSpeed data transfer up to 10 Gbps, one port with BC 1.2 functionality for charging mobile devices (max. 1.5 A), 1 x with SuperSpeed data transfer up to 5 Gbps 1 x Thunderbolt port with Power Delivery (PD), data transfer rate up to 40 Gbps Supports Power Delivery 3.0 (max. 60W) for fast charging of the user's notebook/laptop 1 x Gigabit LAN 10/100/1000Mbps RJ45 port 1 x SD card slot and one microSD card slot: Supports SD 3.0 (UHS-I), SD 4.0 (UHS-II)
Designation - CE+WEEE
dimension depth - mm
dimension height - mm
Dimensions - L 14.7 x W 8.0 x D 1.7 cm
dimension weight - g
dimension width - mm
Docking connector - No
EAN - 4016032480921
ean - 4016032480921
EAN_code - 4016032480921
Features > Colour of product - Grey
guarantee - 24
guarantee_type - external
I/O ports - 1 x 3,5 mm minijack (Headphones)
I/O ports - 1 x RJ-45 (LAN)
I/O ports - 1 x USB 3.0 Type C
I/O ports - 2 x Card reader
I/O ports - 2 x DisplayPort
I/O ports - 3 x USB 3.1 Type A
Link - https://de.assmann.shop/de/Computer-und-Office-Zubehoer/Computer-Zubehoer/USB-Komponenten-und-Zubehoer/Docking-Stations-und-Docks/Thunderbolt-3-Dockingstation-8K-USB-Type-C.html
Manufacturer - Digitus
Manufacturer_code - DA-70895
Name - Digitus Digitus Thunderbolt 3 docking station 8K (silver, HDMI. VGA, USB-A, USB-C, 3.5mm, SD/MicroSD)
Name - Digitus | Thunderbolt™ 3 Dockingstation 8K, USB Type-C™ | Ethernet LAN
name - Docking Station DA-70895
Networking > Ethernet LAN - Yes
Other features - Suitable for notebooks with Thunderbolt 3 port UHD-2 support up to 8K/30Hz up to 7680 x 4320p Support for two monitors, it is possible to connect two monitors at the same time USB-C version: USB 3.1 (gen 1) 1 x USB Type-C connector for connecting to a notebook/laptop 2 x USB 3.0 (data transfer rate up to 10 Gbps), port with additional BC 1.2 support (up to 1.5 A) 1 x USB 3.0 port (data transfer speed up to 5 Gbps) 2 x DisplayPort (up to 8K / 30Hz) 1 x Gigabit Ethernet port to connect your notebook to the Internet/LAN 2 x card reader (microSD / SDHC, SDHX, MMC) parallel operation possible 1 x stereo audio headphone jack (3.5mm) DisplayPort Alternate Mode support DisplayPort (DP) 1.2 support SST and MST (Single Stream Transport Mode / Multi Stream Transport Mode) support Simultaneous display of two video outputs resolution: SST mode up to 3840p / 60Hz, MST mode up to 7680p / 30Hz Power adapter: input current: AC 100 ~ 240 V / 50 ~ 60 Hz / 3.0 A output current: 20 V / 6 A Housing type: Aluminum USB-C Power Delivery: 60W Only one additional external monitor can be connected to M1 chipset MacBook devices Not all USB-C ports support all USB Type-C features. Make sure your notebook's USB-C port supports DisplayPort Alternate Mode (DP-Alt Mode) and USB Power Delivery (PD) Video output performance depends on the graphics card of the notebook and the connected monitor. Some graphics cards have limited MST support, while some monitors limit the available resolution
Package features > Embeeded battery - No
Package features > Gross depth (mm) - 265 mm
Package features > Gross height (mm) - 181 mm
Package features > Gross width (mm) - 67 mm
Package features > Packing quantity - 1.00 pc(s)
Package features > Palette Qty - 538 pc(s)
Package features > Paper/Pasteboard - 34 g
Package features > Plastic (No PET) - 20.00 g
Package features > Tare weight (kg) - 0.054 kg
Package features > Volume (m3) - 0.003213655 m³
Package features > WEE classification - CL109:6:2017-04-01
Package features > WEEE tax - Yes
PDF - https://www.blobs.lt/products/6/8/9/7/6/3/2f83ddaa4813543a18cc3da7e80612d7/original.pdf
Ports & interfaces > Interface - USB 3.0, 7-Port, Travel 2x Video, 3x USB 3.0, 1x USB-C, RJ45, 1 x Audio Stereo jack (3.5 mm)
producer - Digitus
Producer product name - Thunderbolt™ 3 Dockingstation 8K, USB Type-C™
System Requirements -
Technical details > Gross weight - 1.081 kg
Technical details > Net weight - 1.027 kg
Technical details > Other features - 11 more interfaces on your notebook for video, data, power, Ethernet & audio. Supports 4K Ultra HD (4096 x 2160 30-bit color 60 Hz) on two monitors or 8K 30Hz on one monitor via Thunderbolt 3. 2 x card readers (microSD / SDHC, SDHX, MMC) - parallel operation possible
Technical details > Producer - Digitus
vendpn - DA-70895
Warranty - 24
Warranty - 24 month(s)
Weight - 1,08
Weight - 318 g
