Accessories included -
Active power - 510 W
Apparent power - 850 VA
Backup time (100% load) - 4 min
Battery - Automatic battery test - Yes
Battery - Battery technology - Sealed Lead Acid (VRLA)
Battery - Cold start - Yes
Battery - Hot-swap battery - No
Category - Root/Accessories | Exploitation/Power supply/UPSs and power strips/UPSs
Chassis type - Tower
Color - Black
Color - White
Description -
Design - Cable length - 1.5 m
Design - Certification - CE/EAC/Ukr/Cm/CB report
Design - LED indicators - Yes
Design - Product colour - Black
Design - Safety - IEC 62040-1; IEC 62040-2 C2; IEC 62040-3; IEC 62040-4; IEC 61643-11
Designation - CE+WEEE
dimensionalWeight - 3234
dimension depth - 160 mm
dimension height - 390 mm
Dimensions - 86 x 170 x 335 mm
dimension weight - 5300 g
dimension width - 245 mm
ean - 743172101808
Eans - 743172101808
Environment requirements -
Features - Input frequency - 50/60 Hz
Features - Input operation voltage (max) - 284 V
Features - Input operation voltage (min) - 161 V
Features - Maximum current - 10 A
Features - Output frequency - 50 Hz
Features - Output operation voltage (max) - 240 V
Features - Output operation voltage (min) - 220 V
Features - Output power - 510 W
Features - Output power capacity - 0.85 kVA
Features - Power protection features - Overdischarge
Features - Surge protection - Yes
Features - UPS topology - Standby (Offline)
Filters / protection - Surge
guarantee - 24
guarantee_type - external
I/O connectors - 2 x USB (Type B)
Input power ports - Wtyczka sieciowa
Logistics data - Harmonized System (HS) code - 85078000
name - 3S 850 FR 3S850F 850VA 510W
Name - Eaton 3S 850 FR
No. of batteries - 1
Number of phases input - 1 (230V)
Operational conditions - Operating altitude - 0 - 3000 m
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Other features -
Other features - Nominal input voltage - 230 V
Output power ports - 8 x C/F type (Schuko)
Ports & interfaces - AC outlets quantity - 8 AC outlet(s)
Ports & interfaces - USB 2.0 ports quantity - 2
Ports & interfaces - USB port - Yes
producer - Eaton
Producer - Eaton
producerCode - 3S850F
ProducerCode - 3S850F
productName - Eaton 3S850F uninterruptible power supply (UPS) Standby (Offline) 0.85 kVA 510 W 8 AC outlet(s)
productSize - Normal
ShortDescription - 850 VA / 510 W
sizeX - 165
sizeY - 400
sizeZ - 245
Software -
Special functions -
UPS Architecture - off-line (standby)
vendpn - 3S850F
Video -
warrantyLength - 24
warrantyType - G
Weight - 4.3 kg
weight - 5000
Weight & dimensions - Depth - 170 mm
Weight & dimensions - Height - 86 mm
Weight & dimensions - Weight - 4.3 kg
Weight & dimensions - Width - 335 mm
