Accessories included - - User's guide
Active power - 600 W
Alarm -
Alarm when on batterydistinctive low battery alarm overload continuous tone alarm
Apparent power - 1000 VA
ARTIKEL1 - APC BACK-UPS BV 1000VA AVR
ARTIKEL2 - IEC OUTLET 230V IN
Battery - Battery capacity - 9 VAh
Battery - Battery life (max) - 5 year(s)
Battery - Battery recharge time - 8 h
Battery capacity - 9 Ah
Battery life (max), years - 3 - 5
BatteryType - Maintenance-free sealed Lead-Acid battery with suspended electrolyte leakproof
Brand - APC
BrandPartCode - BV1000I
Breite - 0.24
Cable length, m - 1.52
Category - Root/Accessories | Exploitation/Power supply/UPSs and power strips/UPSs
Category - Uninterruptible Power Supplies (UPSs)
Category 1 - Energie & USV
Category 2 - USV & Stromversorgung
Category_1 - Power
Category_2 - UPS
Certification - CE, EAC, IEC 62040-1-1, IEC 62040-2, IEC 62040-3, IEC 62040-4, ISTA 2B, RCM, WEEE
Charging time - 8 h
Chassis type - Desktop
Color - -
Color - Black
ControlPanel - LED status display with On LineOn Battery
Depth - 305 mm
Depth, mm - 305
Description - APC EASY UPS BV 1000VA, AVR, IEC OUTLET, 230V
Description - BV1000I BackUPS BV 1000VA/600W/AVR/6xC13
- Automatic voltage regulation (AVR) Automatically increases the low voltage and lowers the high voltage to levels appropriate for powered devices.
- Wall mounting holes. The strip is suitable for convenient installation in confined spaces, as well as on a wall or other surface
Design - Cable length - 1.52 m
Design - Certification - CE
Design - Product colour - Black
dimension depth - 140 mm
dimension height - 370 mm
Dimensions - 92mm x 160mm x 305mm
dimension weight - 4500 g
dimension width - 240 mm
ean - 731304338222
EAN - 0731304338222
EANCode - 0731304338222
Eans - 0731304338222
EAN_code - 0731304338222
Environment requirements - - Operating temperature 0 - 40°C
- Relative humidity during operation 0 - 90%
- Height during operation 0-1968.3metres
- Noise heard at a distance of 1 m from the surface of the device 40.0dBA
Features - Audible alarm(s) - Yes
Features - Audible alarm modes - Low battery alarm, Overload alarm
Features - Automatic Voltage Regulation (AVR) - Yes
Features - Input frequency - 50/60 Hz
Features - Input operation voltage (max) - 280 V
Features - Input operation voltage (min) - 170 V
Features - Noise level - 40 dB
Features - Output frequency - 50/60 Hz
Features - Output frequency regulation - 50/60 Hz
Features - Output power - 600 W
Features - Output power capacity - 1 kVA
Features - Output voltage regulation - 10%
Features - Surge energy rating - 156 J
Features - Surge protection - Yes
Features - Transfer time (Line Mode to Battery Mode) - 6 ms
Features - UPS topology - Line-Interactive
Features - Waveform - Sine
Filters / protection - Surge
FormFactor - Other
Frequency range, Hz - 50, 60
Gewicht - 6.14
GrossWeight - 6.150 kg
Gross Weight Kg - 6
GRUPPE1 - Power Protection
GRUPPE2 - UPS (Uninterruptable Power Supply)
GTIN - 731304338222
GTIN - 0731304338222
guarantee - 24
guarantee_type - external
Height - 92 mm
Height - 232.000000
Height, mm - 92
HERSTELLER - APC
Hoehe - 0.15
Hold-up time (maks) - 10 ms
HSTNUMMER - BV1000I
I/O connectors - None
Input connection - IEC-320 C14
InputConnections - IEC-320 C14
InputFrequency - 50/60 Hz +/- 5 Hz (auto sensing)
Input frequency, Hz - 45 - 65
Input power ports - IEC-C14
InputVoltage - 230 V
InterfacePorts - -
Laenge - 0.38
Length - 375.000000
Logistics data - Harmonized System (HS) code - 85078000
LongDesc -
LongDesc - Automatic Voltage Regulation (AVR)Automatically steps up low voltage and steps down high voltage to levels that are suitable for your equipment.Automatic Voltage Regulation (AVR)Allow flexibility for setup in tight locations and mounting on wall or other surfaces.Battery and surge protected outletsBack up and protect your hardware and data during power outages, surges and spikes.Battery backup and surge protectionOutlets provide abundant runtime for network gateway equipment and other critical low-power devices, allowing for hours of internet access during a power outage.Advanced Safety FeaturesSafeguard your Home UPS from overloads, excessive mains voltages, short circuits, installation mishaps and battery damage due to low voltage situations.Intelligent battery managementMaximizes battery performance, life, and reliability through intelligent, precision charging.Battery failure notificationProvides early-warning fault analysis on batteries enabling timely preventive maintenanceCold-start capableProvides temporary battery power when the utility power is out.Boost Automatic Voltage Regulation (AVR)Preserves battery life and maximizes runtime by correcting low voltages without discharging the battery.Sleek designSlim, modern design can be upright, flat, or wall-mounted to comfortably fit any electronics set-up and complement home décor.Transformer-block spaced outletsProtect equipment with input transformer blocks without blocking access to other receptacles.Audible alarmsProvides notification of changing utility power and UPS power conditionsLED IndicatorsProvide easy-to-read status of the unit and utility power conditions.Safety-agency approvedEnsures the product has been tested and approved to work safely with the connected service provider equipment and within the specified environment.
LongProductName - EASY UPS BV 1000VA, AVR, IEC, 230V
LongSummaryDescription - APC BV1000I. UPS topology: Line-Interactive, Output power capacity: 1 kVA, Output power: 600 W. AC outlet types: C13 coupler, AC outlets quantity: 1 AC outlet(s). Battery capacity: 9 VAh, Battery life (max): 5 year(s), Battery recharge time: 8 h. Product colour: Black, Cable length: 1.52 m, Certification: CE. Width: 160 mm, Depth: 305 mm, Height: 92 mm
Manufacturer - APC
Manufacturer Code - BV1000I
Manufacturer Name - APC by Schneider Electric
ManufacturerPartNumber - BV1000I
Manufacturer_code - BV1000I
MANUFDATASHEET - https://www.apc.com/shop/hr/en/products/APC-EASY-UPS-BV-1000VA-AVR-IEC-Outlet-230V/P-BV1000I?isCurrentSite=true
Maximum power, W - 600
MPN - BV1000I
Name - APC Back BV1000I
Name - APC Easy-UPS BV - BV1000I
Name - APC Easy-UPS BV BV1000i 1000VA 600W
name - BV1000I BackUPS BV 1000 VA/600W/AVR/6xC13
No. of batteries - 1
Noise level, dB - 40
Nominal input voltage, V - 400
Nominal output voltage, V - 400
Number of phases input - 1 (230V)
Operating relative humidity range, % - 0 - 95
Operating temperature range (T-T), °C - 0 - 40
Operational conditions - Operating relative humidity (H-H) - 0 - 90%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Other features -
Other features - Battery type - leakproof
Other features - Output voltage - 230 V
OutputConnections - (6) IEC 320 C13 (Battery Backup)
OutputFrequency - 50/60 Hz +/-1 Hz
Output interface - 6 x IEC 320 C13 (Battery Backup)
Output power, W - 600
Output power capacity (VA) - 1000
Output power ports - 6 x IEC-C13
OutputVoltage - 230 V
PackageContents - -
Packaging data - Manual - Yes
PeriodofWarranty - 2 Y
Ports & interfaces - AC outlets quantity - 1 AC outlet(s)
Ports & interfaces - AC outlet types - C13 coupler
PowerVAW - 1000 VA
PowerW - 600 W
ProdDesc - APC Easy UPS BV 1000VA, AVR, IEC Outlet, 230V
producer - APC
Producer - APC
ProducerCode - BV1000I
ProductName - BV1000I
ProductPicture - http://www.tdbaltic.ee/images/ds4/BV1000I-01.jpg
ProductPicture2 -
ProductPicture3 -
ProductPicture4 -
RechargeTime - -
RJ45 - -
Runtime - -
ShortDescription -
Short description - APC EASY-UPS BV 1000 VA BV1000I
ShortSummaryDescription - APC BV1000I, Line-Interactive, 1 kVA, 600 W, Sine, 170 V, 280 V
SmartSlot - -
Software -
Special functions -
Stck_Kart - 4
Stck_Pal - 9998
Storno - N
Technical details - Compliance certificates - RoHS
Title - APC BV1000I uninterruptible power supply (UPS) Line-Interactive 1 kVA 600 W 1 AC outlet(s)
Topology - Line interactive
UPS Architecture - line-interactive
UPS devices and accessories - Yes
URL - https://www.apc.com/shop/hr/en/products/APC-EASY-UPS-BV-1000VA-AVR-IEC-Outlet-230V/P-BV1000I?isCurrentSite=true
USB - -
vendpn - BV1000I
Voltage - 12 V
Warranty - 2 years
WarrantyInfo - 2 Year
WaveformType - Stepped approximation to a sinewave
Weight - 5.7 kg
Weight - 5.700 Kg
Weight - 6,15
Weight - 6.18
Weight - 6.180000
Weight & dimensions - Depth - 305 mm
Weight & dimensions - Height - 92 mm
Weight & dimensions - Package depth - 373 mm
Weight & dimensions - Package height - 237 mm
Weight & dimensions - Package weight - 6 kg
Weight & dimensions - Package width - 143 mm
Weight & dimensions - Weight - 5.7 kg
Weight & dimensions - Width - 160 mm
Weight, kg - 5.7
Width - 141.000000
Width - 160 mm
Width, mm - 160
