Power Walker VI 2200 SH FR, 2200VA 1200W

Accessories included - - PowerWalker VI 2200
- Power cord
- Cable IEC
- USB cable
- Software CD
- User manual
Active power - 1200 W
Apparent power - 2200 VA
Battery - Battery capacity - 9 Ah
Battery - Battery recharge time - 4 h
Battery - Battery voltage - 12 V
Battery - Typical backup time at full load - 0.5 min
Battery - Typical backup time at half load - 5 min
Battery capacity - 9 Ah
Category - Root/Accessories | Exploitation/Power supply/UPSs and power strips/UPSs
Charging time - 6 h
Chassis type - Tower
Color - Black
Connectors - 1 x USB (Typ B)
Connectors - RJ-11
Connectors - RJ-45
Description - Power Walker VI 2200 provides comprehensive protection and high power density in small and economic package. Compared to traditional UPS towers of the same size, this UPS is more compact and offers greater comprehensive power protection against surges and spikes. Equipped with a voltage stabilizer, this UPS will continue providing clean and stable power to connected equipment and is perfect for any home or small office application.Full specification: http://web.impakt.com.pl/Z13528_23069.pdf
Design - Display type - LCD
Design - Form factor - Mini Tower
Design - Product colour - Black
Designation - CE+WEEE
dimensionalWeight - 6279
dimension depth - 270 mm
dimension height - 230 mm
Dimensions - 365 x 139 x 195 mm
dimension weight - 9000 g
dimension width - 450 mm
ean - 4260074975123
Eans - 4260074975123
Environment requirements - - Operating temperature: 0 - 40°C
- Recommended humidity: 0 - 90%
Features - Efficiency - 95%
Features - Input frequency - 50/60 Hz
Features - Input operation voltage (max) - 280 V
Features - Input operation voltage (min) - 170 V
Features - Output frequency regulation - 1 Hz
Features - Output operation voltage (max) - 230 V
Features - Output operation voltage (min) - 230 V
Features - Output power - 1200 W
Features - Output power capacity - 2.2 kVA
Features - Output power factor - 0.55
Features - Output voltage regulation - 10%
Features - UPS topology - Line-Interactive
Filters / protection - Circuit
Filters / protection - Overcharging
Filters / protection - Overdischarge
Filters / protection - Surge
Filters / protection - Thermal
guarantee - 24
guarantee_type - normal
Input power ports - IEC-C14
Logistics data - Harmonized System (HS) code - 85078000
Name - Power Walker VI 2200 SH FR
name - UPS POWER WALKER LINE-INTERACTIVE 2200VA 2X 230V PL + 2X IEC OUT,RJ11/RJ45 IN/OUT, USB
No. of batteries - 2
Number of phases input - 1 (230V)
Operational conditions - Operating relative humidity (H-H) - 0 - 90%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Other features - - Power 1100W
- Input voltage: 230V AC
- Input voltage range: 170 - 280 VAC
- Input frequency range: 50 to 60 Hz
- Output voltage: 230V
- Adjustable output voltage: +/- 10%
- Adjustable output frequency +/- 1 Hz
- The waveform: Modified sine wave
Output power ports - 2 x C/E type
Output power ports - 2 x IEC-C13
Packaging data - Bundled software - WinPower
Packaging data - Cables included - Input power cable, USB cable
Packaging data - Manual - Yes
Packaging data - Quick installation guide - Yes
Ports & interfaces - AC outlets quantity - 4 AC outlet(s)
Ports & interfaces - AC outlet types - C13 coupler
Ports & interfaces - Ethernet LAN (RJ-45) ports - 1
Ports & interfaces - Modem (RJ-11) ports - 1
Ports & interfaces - Power plug - C14 coupler
Ports & interfaces - USB 2.0 ports quantity - 1
Ports & interfaces - USB port - Yes
producer - PowerWalker
Producer - Power Walker
producerCode - VI 2200 SH FR
ProducerCode - VI 2200 SH FR
productName - PowerWalker VI 2200 SH uninterruptible power supply (UPS) Line-Interactive 2.2 kVA 1200 W 4 AC outlet(s)
productSize - Normal
ShortDescription - LINE-INTERACTIVE 2200VA | 2X 230V PL + 2X IEC OUT | RJ11/RJ45 IN/OUT | USB
sizeX - 455
sizeY - 230
sizeZ - 300
Software - WinPower
Special functions - - Reduced loading time
- Excellent microprocessor control guarantees high reliability
- Built-in AVR voltage stabilization system
- Simulated sine wave
- Automatic restart after power is restored
- Charging off mode
- Cold start
- USB communication port
- Surge Protection RJ-11/RJ-45
- Power Saving Function
- LED indicating diodes
Transfer time (max) - 8 ms
UPS Architecture - line-interactive
vendpn - VI 2200 SH FR
Voltage - 12 V
warrantyLength - 24
warrantyType - G
Weight - 10.2 kg
weight - 11800
Weight & dimensions - Depth - 364 mm
Weight & dimensions - Height - 195 mm
Weight & dimensions - Package height - 292 mm
Weight & dimensions - Package width - 230 mm
Weight & dimensions - Weight - 10.2 kg
Weight & dimensions - Width - 139 mm
