8-pin 12V power connectors - 1
Accessories included -
Brand - be quiet!
BrandPartCode - BN284
Category - Power Supply Units
Category - Root/Electronics/PC parts/PC power supply units
Category_1 - Power
Category_2 - Computer Power Supplies
Certificates - Certification - CE, FCC, TÜV, cTUVus, RCM, BSMI, CU
Certificates - Compliance certificates - RoHS
Certificates 80+ - 80 PLUS Gold
Description - STRAIGHT POWER 11
be quiet! Straight Power 11 provides a new level of quiet performance for systems requiring virtually inaudible operation without the slightest compromise in power quality. The latest generation of Straight Power has been maximally updated and enriched with premium features by our German team. All this makes Straight Power 11 quieter than ever and is definitely "the best choice" when building new systems or upgrading existing computers.
Design - Fan diameter - 13.5 cm
Design - Illumination - No
Design - Number of fans - 1 fan(s)
Design - On/off switch - Yes
Design - Product colour - Black
Designation - CE+WEEE
dimension depth - 100 mm
dimension height - 250 mm
Dimensions - 170 x 150 x 86 mm
dimension weight - 3700 g
dimension width - 330 mm
ean - 4260052185797
Eans - 4260052185797
EAN_code - 4260052185797
Fan - 13.5 cm
Floppy power connectors - 1
GTIN - 4260052185797
guarantee - 60
guarantee_type - normal
Logistics data - Harmonized System (HS) code - 84733020
LongDesc - World Class Quiet and Efficiencybe quiet! Straight Power 11 850W raises the bar for systems that demand virtually inaudible operation without power quality compromises. This PSU is clearly the best choice for super silent systems.
LongProductName - Straight Power 11, 850 W, ATX 12V 2.4, EPS 12V 2.92, 100 - 240 V, 50/60 Hz, active PFC, SilentWings 3 135mm, ATX 20+4-pin, 4x PCIe 6+2-pin, 11x SATA, 4x PATA, FDD, Black
LongSummaryDescription - be quiet! Straight Power 11. Total power: 850 W, AC input voltage: 100 - 240 V, Peak power: 920 W. Motherboard power connector: 20+4 pin ATX, Motherboard power cable length: 60 cm, SATA power cable length: 550 mm. Purpose: PC, Power supply unit (PSU) form factor: ATX, 80 PLUS certification: 80 PLUS Gold. Product colour: Black, Fan diameter: 13.5 cm, Number of fans: 1 fan(s). Compliance certificates: RoHS, Certification: CE, FCC, TÜV, cTUVus, RCM, BSMI, CU
Manufacturer - Be quiet
Manufacturer_code - BN284
MB power connector - 20 + 4 pin
Modular power supply - Yes
MOLEX power connectors - 4
Name - be quiet! Straight Power 11 850W
Name - be quiet! STRAIGHT POWER 11 CM 850W
name - PSU Straight Power 11 850W 80+ GOLD F.MODU BN284
Number of power supply connector 4+4-pin 12V - 1
Number of power supply connector 4-pin 12V - 0
Number of power supply connectors PCI-E 6 +2 pin - 4
Other features - - OCP overcurrent protection
- OVP overvoltage protection
- UVP undervoltage protection
- SCP short-circuit protection
- OTP temperature protection
- OPP overload protection
Other features - Cable management - Yes
Other features - Cable ties included - Yes
Other features - Noise level (full-load mode, 100%) - 24.98 dB
Other features - Noise level (quiet mode, 50%) - 10.61 dB
Other features - Noise level (silent mode, Other features - Screws included - Yes
Packaging data - Manual - Yes
Packaging data - Package depth - 328 mm
Packaging data - Package height - 102 mm
Packaging data - Package weight - 3.38 kg
Packaging data - Package width - 248 mm
PCI-E 6-pin power connectors - 0
PCI-E 8-pin power connectors - 0
Performance - 80 PLUS certification - 80 PLUS Gold
Performance - ATX version - 2.4
Performance - Bearing technology - FDB
Performance - EPS version - 2.92
Performance - Power supply unit (PSU) form factor - ATX
Performance - Purpose - PC
Performance - Silent mode - Yes
PFC - Active
Ports & interfaces - Cabling type - Fully-Modular
Ports & interfaces - CPU power cable length - 70 cm
Ports & interfaces - CPU power connector (4+4 pin) - Yes
Ports & interfaces - Floppy disk drive connector - Yes
Ports & interfaces - Motherboard power cable length - 60 cm
Ports & interfaces - Motherboard power connector - 20+4 pin ATX
Ports & interfaces - Number of PATA power connectors - 4
Ports & interfaces - Number of SATA power connectors - 11
Ports & interfaces - PCI Express power cable length - 60 cm
Ports & interfaces - PCI Express power connectors (6+2 pin) - 4
Ports & interfaces - SATA power cable length - 550 mm
Power - AC input frequency - 50 - 60 Hz
Power - AC input voltage - 100 - 240 V
Power - Combined power (+3.3V) - 150 W
Power - Combined power (+5V) - 150 W
Power - Combined power (+5Vsb) - 15 W
Power - Combined power (+12V) - 849.6 W
Power - Combined power (-12V) - 6 W
Power - Efficiency - 93%
Power - Hold time - 21.1 ms
Power - Input current - 10 A
Power - Max output current (+3.3V) - 25 A
Power - Max output current (+5V) - 25 A
Power - Max output current (+5Vsb) - 3 A
Power - Max output current (+12V1) - 21 A
Power - Max output current (+12V2) - 21 A
Power - Max output current (+12V3) - 26 A
Power - Max output current (+12V4) - 26 A
Power - Max output current (-12V) - 0.5 A
Power - Peak power - 920 W
Power - Power factor - 0.99
Power - Power Factor Correction (PFC) type - Active
Power - Power protection features - Over current, Over power, Over voltage, Overheating, Short circuit, Under voltage
Power - Total power - 850 W
Power supply - 850 W
producer - Be quiet!
Producer - be quiet!
ProducerCode - BN284
ProductName - Straight Power 11
SATA power connectors - 11
ShortDescription - 850 | ATX | 135 mm | 20 + 4 pin | 150mm x 86mm x 160mm | 80 PLUS Gold
ShortSummaryDescription - be quiet! Straight Power 11, 850 W, 100 - 240 V, 920 W, 50 - 60 Hz, 10 A, Active
Technical details - Sustainability certificates - ENERGY STAR
Title - be quiet! Straight Power 11 power supply unit 850 W 20+4 pin ATX ATX Black
URL - https://www.bequiet.com/en/download/straight-power/1248?utm_source=newsletter
vendpn - BN284
WarrantyInfo - 5 years
Weight - 3,46
Weight & dimensions - Depth - 170 mm
Weight & dimensions - Height - 86 mm
Weight & dimensions - Weight - 1.8 kg
Weight & dimensions - Width - 150 mm
