NEC E224F-BK, 21.5"

Name: NEC E224F-BK, 21.5"
Brand: NEC
SKU: 966015
Price: 194.27 EUR
Availability: InStock

Picture may differ from actual product, there can be accessories and parts not supplied with the actual product.

ID: 966015 Product code: 60005828

Can be ordered 392 units Availability: 14 days after order approval

Warranty: 3 years

Compare

Delivery options

Courier delivery 3.99 €: 01.04.2025

Main product parameters All parameters

Curved: Nav
Panel Type: IPS
Refresh rate: 75 Hz
Response time: 6ms
Contrast ratio: 1000:1
Brightness: 250cd/m2
Size: 21.5"
Resolution: FHD 1920x1080

Description

We offer to buy NEC 21.5" a monitor with FHD 1920x1080 resolution.

Thanks to FullHD (1920px X 1080px) resolution this monitor will be perfectly suitable for enjoying BlueRay quality films in the full screen mode.
IPS matrix for this monitor provides high colour correspondence parameters, superior picture contrast and good visibility from eventually all viewing angles.
The compatibility with the modern graphics cards and video players will be ensured by HDMI input.
DisplayPort port ensures the receipt of a higher quality picture from the computer graphics card supporting this technology.
The port DVI ensures the compatibility with the classic video cards equipped with this port.
The port D-SUB supports graphics cards with the preceding generation analogous VGA plug-in and the comparatively newer generation DVI-I standard using a transition DVI-I -> D-Sub.
The speakers system built in the monitor allows to listen to music and enjoy films with sound without making it necessary to buy additional speakers.

Display characteristics

AMD FreeSync : Nav

Curved : Nav

NVIDIA G-SYNC : Nav

Panel Type IPS

Teh monitor panel is the main feature of the visible part of the screen or the technology where the display of the colour dots (pixels) is implemented.

TN is the standard technology with average contract, brightness and colour compliance indices.

IPS is the matrix with high colour compliance and good response speed, therefore it is well suited for graphics tasks and photo editing. IPS matrix provide an excellent viewing angle maintaining the colours and contrast from almost any angle.

VA matrix ensures superior colour compliance, however, the response time of this matrix is lagging behind that of the IPS and TN; the viewing angle is somewhere between both these technologies.

The TN type monitor is fully sufficient for an average user. If you have more money available the VA or IPS can be chosen.

Refresh rate : 75 Hz

Touchscreen : NO

VESA DisplayHDR : Nav

Response time 6ms

The response time of the monitor screen determines how fast the monitor will display moving images (films, games, animations, etc.). The response time is measured in miliseconds. The less the response time the better the ability of the monitor to display moving images.
www.toppc.ee recommends to buy monitors with 5ms response time or lower.

Contrast ratio 1000:1

Ekrāna kontrasts nosaka attēla asumu. Tā ir atšķirība starp vistumšāko (pilnīgi melnu) un visgaišāko (pilnīgi baltu) pikseli. Jo lielāks kontrasts, jo skaidrāk salasāms teksts uz ekrāna, kontrasts arī nosaka, cik izteiksmīgas līnijas būs redzamas monitora attēlā.

Augsts kontrasts ir nozīmīgs faktors izvēloties monitoru biroja, vai mācību vajadzībām, kad lielākoties tiek strādāts ar tekstuālu informāciju.

Mājas vajadzībām svarīgāks izvēles rādītājs ir gaišums un attēla reakcijas laiks. Kontrastu labāk novērtēt tumšā istabā.
Lielākais LCD monitoru trūkums ir tas, ka samazinot attēla spilgtumu, kontrasts var pazust.

Brightness 250cd/m2

Monitora gaišums ir attēla redzamības rādītājs, kas nosaka, cik labi saskatāms ir attēls pie spēcīga ārējā apgaismojuma (saules gaisma, gaiša telpa, utt.). LCD monitoru gaišums tiek mērīts kandelās uz kvadrātmetru (Cd/m2).
Izvēloties monitoru jāņem vērā - jo lielāks gaišuma rādītājs, jo labāka attēla redzamība.

Ikdienas vajadzībām TopPC.ee iesaka iegādāties monitoru ar gaišumu, ne mazāku par 250 cd/m2.

Basic information

Application : Home & Office

Aspect ratio : 16:9

Color : Black

Size 21.5"

The size of the monitor screen is measured in inches across the diagonal. The screen size must be proportionate to the resolution of the screen for achieving the maximum utilisation of the desktop and details of the image.

Mainly two forms of LCD monitors are available: with standard width and height proportion 4:3 or the widescreen proportion 16:9 or 16:10. A widescreen monitor is wider and its resolution is higher than that of the monitors with standard proportion.

The bigger the monitor size the higher resolution usually is supported. Possibilities to increase the resolution of the screen usually depend on the size and possibilities of the monitor and the type of the video card.

Resolution FHD 1920x1080

The resolution of the monitor screen determines the number of colour dots (pixels) a monitor can display. It refers to the clarity of the text and images displayed on the screen. The higher the resolution the sharper the items look.

The applied resolution depends on the resolution supported by the monitor. LCD monitors, including the screens of laptop computers usually work best if their local resolution has been set. The setting of this resolution for the monitor is not mandatory, but usually it is recommended to set it for ensuring the highest possible sharpness of texts and images. The bigger the monitor size the higher resolution usually is supported.

Possibilities to increase the resolution of the screen usually depend on the size and possibilities of the monitor and the type of the video card.
• 19 inches screen (standard proportions): 1280x1024 pixels
• 20 inches screen (standard proportions): 1600x1200 pixels
• 22 inches screen (widescreen): 1680x1050 pixels
• 24 inches screen (widescreen): 1900x1200 pixels

Functionality

Flicker-free : Ir

Height adjustment : Ir

Pivot : Ir

Swivel : And

Tilt : YES

VESA wall mount : 100x100 mm

Ports and equipment

D-SUB 1

D-SUB is the classic (analogous) monitor connection plug. This standard is gradually disappearing from the market giving the place to the higher quality HDMI or DisplayPort (digital) plugs.

If the resolution of the monitor is FullHD or below the average user will experience no problems with this connection. Those who want to achieve higher image quality and resolution should look for the monitor with the DisplayPort or HDMI connection slot.

DisplayPort 1

DisplayPort is the digital connection for transmitting the image via a single wire at a high quality level. Contrary to the HDMI, this connection allows to connect several external monitors to the computer via a single connector.

Prior to buying the monitor with the DisplayPort you should verify whether your computer has the DisplayPort plug available!

DVI Nav

DVI is a digital standard and ensures high image quality, however, thanks to the big size of the plug and the inability of the standard to develop further due to a few technical restrictions this type of connection is gradually losing its popularity to modern HDMI and DisplayPort standards.

DVI is compatible with HDMI and transitions of both directions are available.

DVI is not compatible with DisplayPort, however, there are DualMode DisplayPort connectors which contains the HDMI/DVI signal, and in the relevant direction DisplayPort -> DVI can transmit an image.

If the monitor resolution exceeds 1920px in any direction a graphics card with the DVI-D Dual Link support and the relevant quality cable will be required.

Before buying a monitor you should verify whether your graphics card has the corresponding connection slot!

HDMI port 1

HDMI is the digital high quality image transmission standard that allows to connect the monitor to the computer via a thin cable by using an elegant small-size connector. HDMI is compatible with DVI if the relevant transition or cable is used.

Speakers Ir

Some monitors may have built-in speakers that quite often allow to give up external speakers thus freeing a space on the desk and saving money. The sound quality of built-in speakers is quite moderate and therefore we recommend to use this possibility just for infrequent needs.

For enjoying music, movies and games we recommend buying the corresponding quality and capacity speakers.

USB Hub : NO

USB-C Power Delivery : Nav

USB-C video input : 0

More detailed specification

Accessories included - DisplayPort cable; Power cable; Installation Guide
ARTIKEL1 - E224F-BK 22IN LCD LED
ARTIKEL2 - 1920X1080 DP HDMI
Aspect ratio - 16:9
Auto Pivot - Yes
Bluetooth - No
Brand - NEC
BrandPartCode - 60005828
Breite - 0.36
Brightness - 250 cd/m²
Category - Computer Monitors
Certificates - RoHS
Color - Black
Depth with stand - 233.2 mm
Description - With the workplace in mind E Series desktop monitors deliver Sharp/NEC reliability and performance at a very competitive price, helping you reduce costs without sacrificing quality. When designing them, the main emphasis was placed on the ergonomics of the workplace, because user comfort is our priority. Thanks to the height adjustment of up to 120 mm with the ability to change the screen orientation, tilt and horizontal rotation, the device can be adapted to individual needs, and the built-in technologies for filtering harmful blue light (Low Blue Light) and eliminating flicker (Flicker-Free) protect the eyes without harming image quality. The devices are available in black or white, so they can be matched to the office interior, while ensuring ergonomics. White monitors installed in front of white walls reduce the impression of tunnel vision. The refreshed on-screen display (OSD) layout ensures intuitive operation, saves time and eliminates frustration during configuration and adjustments. This Full HD monitor with VA screen technology is perfect for home offices and general office applications in small and medium-sized businesses. Benefits Saving costs and time, the intuitive OSD menu layout simplifies configuration. Ergonomics in the office full height adjustment (120 mm) with the ability to change the screen orientation (pivot), tilt and horizontal rotation (swivel) allow the monitor to be perfectly adjusted to the user's ergonomic requirements. Black or white versions are worth considering the white version to reduce the feeling of tunnel vision when placing the monitor in front of a white background, such as office walls. Taking care of the user's well-being, the built-in Low Blue Light technology filters out harmful blue light emissions, and the Flicker-Free technology eliminates backlight flickering, thus protecting users' eyes against cataracts and macular degeneration. Advantages of form and functionality, the device is ready for future technologies, has a three-sided ultra-narrow bezel, is available in black or white and fits perfectly into the design of modern office spaces.
Design - Front bezel colour - Black
Design - Product colour - Black
Designation - CE+WEEE
dimension depth - 650 mm
dimension height - 360 mm
dimension weight - 7000 g
dimension width - 200 mm
Display - Backlight type - W-LED
Display - Contrast ratio (typical) - 3000:1
Display - Display brightness (typical) - 250 cd/m²
Display - Display diagonal - 55.9 cm (22")
Display - Display diagonal (metric) - 55 cm
Display - Display number of colours - 16.7 million colours
Display - Display resolution - 1920 x 1080 pixels
Display - Display technology - LCD
Display - HD type - Full HD
Display - Maximum refresh rate - 60 Hz
Display - Native aspect ratio - 16:9
Display - Panel type - TFT
Display - Pixel pitch - 0.249 x 0.249 mm
Display - Response time - 6 ms
Display - Screen shape - Flat
Display - Touchscreen - No
Display - Vertical scan range - 50 - 75 Hz
Display - Viewing angle, horizontal - 178°
Display - Viewing angle, vertical - 178°
Display surface - Matt
Dot pitch - 0.249 mm
ean - 5028695125421
EANCode - 5028695125421
Energy class - D
Energy label - Pobierz
Ergonomics - Adjustable height (max) - 12 cm
Ergonomics - Cable lock slot - Yes
Ergonomics - Cable lock slot type - Kensington
Ergonomics - Cable management - Yes
Ergonomics - Height adjustment - Yes
Ergonomics - On Screen Display (OSD) - Yes
Ergonomics - Panel mounting interface - 100 x 100 mm
Ergonomics - Pivot - Yes
Ergonomics - Pivot angle - -90 - 90°
Ergonomics - Swivel angle range - -170 - 170°
Ergonomics - Swivelling - Yes
Ergonomics - Tilt adjustment - Yes
Ergonomics - Tilt angle range - -5 - 25°
Ergonomics - VESA mounting - Yes
Gewicht - 6.76
GRUPPE1 - Displays
GRUPPE2 - Lcd Monitor
GTIN - 5028695125421
guarantee - 36
guarantee_type - external
Height (max) - 493.2 mm
Height adjustment - Yes
Height with stand - 363.4 mm
HERSTELLER - SHARP NEC
Hoehe - 0.19
HSTNUMMER - 60005828
I/O connectors - 1 x 15-pin D-Sub
I/O connectors - 1 x DisplayPort
I/O connectors - 1 x HDMI
Laenge - 0.64
LongDesc - The workspace essentialDriving down costs without compromising quality, the desktop E Series presents all the reliable performance you expect from Sharp/NEC, against a very competitive price tag.With user comfort prioritised, workspace ergonomics is a key design feature. Height adjustability to 120 mm with swivel, tilt and pivot functionality ensures a personalised set up, whilst built-in Low Blue Light and Flicker-Free technology protects the viewers’ eyes without sacrificing best picture quality. Available in black or white, choose the best fit to complement your office setting and ergonomics – white displays reduce the impression of tunnel vision when in front of white walls.With a fresh On-Screen Display (OSD) design, users benefit from highly intuitive operation, saving time and frustration during set up and adjustment. This Full HD display with VA screen technology is well placed to equip the home office and small to medium sized businesses for general office applications.
LongProductName - LCD 22" Enterprise Display, 1920 x 1080, 250 cd/m², 16:9, D, 12 kWh/1000h, 1 x DisplayPort, 1 x HDMI, 1 x D-sub 15 pin, Black
LongSummaryDescription - NEC MultiSync E224F. Display diagonal: 55.9 cm (22"), Display resolution: 1920 x 1080 pixels, HD type: Full HD, Display technology: LCD, Response time: 6 ms, Native aspect ratio: 16:9, Viewing angle, horizontal: 178°, Viewing angle, vertical: 178°. Built-in speaker(s). VESA mounting, Height adjustment. Product colour: Black
Matrix type - VA
Model - MultiSync E224F
Multimedia - Built-in camera - No
Multimedia - Built-in speaker(s) - Yes
Multimedia - Number of speakers - 2
Multimedia - RMS rated power - 2 W
name - Monitor MultiSync E224F black 22 inches DP HDMI
Number of colors - 16,7 mln
Operational conditions - Operating relative humidity (H-H) - 20 - 80%
Operational conditions - Operating temperature (T-T) - 5 - 35 °C
Operational conditions - Storage relative humidity (H-H) - 10 - 85%
Operational conditions - Storage temperature (T-T) - -10 - 60 °C
Optional accessory -
Other features -
Other features - Compliance certificates - RoHS, cTUVus, WEEE
Packaging content - Cables included - AC, DisplayPort
Packaging content - Stand included - Yes
Performance - Flicker-free technology - Yes
Ports & interfaces - Built-in USB hub - No
Ports & interfaces - DisplayPorts quantity - 1
Ports & interfaces - HDMI - Yes
Ports & interfaces - HDMI ports quantity - 1
Ports & interfaces - Headphone out - Yes
Ports & interfaces - VGA (D-Sub) ports quantity - 1
Power - Energy consumption (SDR) per 1000 hours - 12 kWh
Power - Energy efficiency class (SDR) - D
Power - Energy efficiency scale - A to G
Power - European Product Registry for Energy Labelling (EPREL) code - 1338529
Power - Power consumption (PowerSave) - 0.22 W
Power - Power consumption (typical) - 14 W
Power consumption - 14 W
producer - NEC
ProductName - E224F
Resolution - 1920 x 1080 (FHD 1080)
Response time - 6 ms
Screen size (diag.) - 22"
ShortSummaryDescription - NEC MultiSync E224F, 55.9 cm (22"), 1920 x 1080 pixels, Full HD, LCD, 6 ms, Black
Speakers built-in - Yes
Static contrast - 3 000:1
Stck_Kart - 1
Stck_Pal - 10
Storno - Y
TCO Certified - Yes
Title - NEC MultiSync E224F computer monitor 55.9 cm (22") 1920 x 1080 pixels Full HD LCD Black
Touch screen - No
Transreflective technology - LED
TV tuner built-in - No
URL - https://www.sharpnecdisplays.eu/p/eeme/en/products/details/t/desktop-displays/enterprise-displays/rp/e224f.xhtml
vendpn - 60005828
VESA - 100 x 100
Viewing angle, horizontal - 178 °
Viewing angle, vertical - 178 °
Warranty -
WarrantyInfo - 3 years
Web camera - None
Weight - 3.1 kg
Weight & dimensions - Bezel width (bottom) - 1.68 cm
Weight & dimensions - Bezel width (side) - 2.5 mm
Weight & dimensions - Bezel width (top) - 2.5 mm
Weight & dimensions - Depth (with stand) - 233.2 mm
Weight & dimensions - Height (with stand) - 483.4 mm
Weight & dimensions - Weight (without stand) - 3.1 kg
Weight & dimensions - Weight (with stand) - 5.2 kg
Weight & dimensions - Width (with stand) - 493.2 mm
Weight with stand - 5.2 kg
Width - 493.2 mm
WiFi - No
