Accessories included - DisplayPort cable; Power cable; Installation Guide
ARTIKEL1 - E224F-BK 22IN LCD LED
ARTIKEL2 - 1920X1080 DP HDMI
Aspect ratio - 16:9
Auto Pivot - Yes
Bluetooth - No
Brand - NEC
BrandPartCode - 60005828
Breite - 0.36
Brightness - 250 cd/m²
Category - Computer Monitors
Certificates - RoHS
Color - Black
Depth with stand - 233.2 mm
Description - With the workplace in mind E Series desktop monitors deliver Sharp/NEC reliability and performance at a very competitive price, helping you reduce costs without sacrificing quality. When designing them, the main emphasis was placed on the ergonomics of the workplace, because user comfort is our priority. Thanks to the height adjustment of up to 120 mm with the ability to change the screen orientation, tilt and horizontal rotation, the device can be adapted to individual needs, and the built-in technologies for filtering harmful blue light (Low Blue Light) and eliminating flicker (Flicker-Free) protect the eyes without harming image quality. The devices are available in black or white, so they can be matched to the office interior, while ensuring ergonomics. White monitors installed in front of white walls reduce the impression of tunnel vision. The refreshed on-screen display (OSD) layout ensures intuitive operation, saves time and eliminates frustration during configuration and adjustments. This Full HD monitor with VA screen technology is perfect for home offices and general office applications in small and medium-sized businesses. Benefits Saving costs and time, the intuitive OSD menu layout simplifies configuration. Ergonomics in the office full height adjustment (120 mm) with the ability to change the screen orientation (pivot), tilt and horizontal rotation (swivel) allow the monitor to be perfectly adjusted to the user's ergonomic requirements. Black or white versions are worth considering the white version to reduce the feeling of tunnel vision when placing the monitor in front of a white background, such as office walls. Taking care of the user's well-being, the built-in Low Blue Light technology filters out harmful blue light emissions, and the Flicker-Free technology eliminates backlight flickering, thus protecting users' eyes against cataracts and macular degeneration. Advantages of form and functionality, the device is ready for future technologies, has a three-sided ultra-narrow bezel, is available in black or white and fits perfectly into the design of modern office spaces.
Design - Front bezel colour - Black
Design - Product colour - Black
Designation - CE+WEEE
dimension depth - 650 mm
dimension height - 360 mm
dimension weight - 7000 g
dimension width - 200 mm
Display - Backlight type - W-LED
Display - Contrast ratio (typical) - 3000:1
Display - Display brightness (typical) - 250 cd/m²
Display - Display diagonal - 55.9 cm (22")
Display - Display diagonal (metric) - 55 cm
Display - Display number of colours - 16.7 million colours
Display - Display resolution - 1920 x 1080 pixels
Display - Display technology - LCD
Display - HD type - Full HD
Display - Maximum refresh rate - 60 Hz
Display - Native aspect ratio - 16:9
Display - Panel type - TFT
Display - Pixel pitch - 0.249 x 0.249 mm
Display - Response time - 6 ms
Display - Screen shape - Flat
Display - Touchscreen - No
Display - Vertical scan range - 50 - 75 Hz
Display - Viewing angle, horizontal - 178°
Display - Viewing angle, vertical - 178°
Display surface - Matt
Dot pitch - 0.249 mm
ean - 5028695125421
EANCode - 5028695125421
Energy class - D
Energy label - Pobierz
Ergonomics - Adjustable height (max) - 12 cm
Ergonomics - Cable lock slot - Yes
Ergonomics - Cable lock slot type - Kensington
Ergonomics - Cable management - Yes
Ergonomics - Height adjustment - Yes
Ergonomics - On Screen Display (OSD) - Yes
Ergonomics - Panel mounting interface - 100 x 100 mm
Ergonomics - Pivot - Yes
Ergonomics - Pivot angle - -90 - 90°
Ergonomics - Swivel angle range - -170 - 170°
Ergonomics - Swivelling - Yes
Ergonomics - Tilt adjustment - Yes
Ergonomics - Tilt angle range - -5 - 25°
Ergonomics - VESA mounting - Yes
Gewicht - 6.76
GRUPPE1 - Displays
GRUPPE2 - Lcd Monitor
GTIN - 5028695125421
guarantee - 36
guarantee_type - external
Height (max) - 493.2 mm
Height adjustment - Yes
Height with stand - 363.4 mm
HERSTELLER - SHARP NEC
Hoehe - 0.19
HSTNUMMER - 60005828
I/O connectors - 1 x 15-pin D-Sub
I/O connectors - 1 x DisplayPort
I/O connectors - 1 x HDMI
Laenge - 0.64
LongDesc - The workspace essentialDriving down costs without compromising quality, the desktop E Series presents all the reliable performance you expect from Sharp/NEC, against a very competitive price tag.With user comfort prioritised, workspace ergonomics is a key design feature. Height adjustability to 120 mm with swivel, tilt and pivot functionality ensures a personalised set up, whilst built-in Low Blue Light and Flicker-Free technology protects the viewers’ eyes without sacrificing best picture quality. Available in black or white, choose the best fit to complement your office setting and ergonomics – white displays reduce the impression of tunnel vision when in front of white walls.With a fresh On-Screen Display (OSD) design, users benefit from highly intuitive operation, saving time and frustration during set up and adjustment. This Full HD display with VA screen technology is well placed to equip the home office and small to medium sized businesses for general office applications.
LongProductName - LCD 22" Enterprise Display, 1920 x 1080, 250 cd/m², 16:9, D, 12 kWh/1000h, 1 x DisplayPort, 1 x HDMI, 1 x D-sub 15 pin, Black
LongSummaryDescription - NEC MultiSync E224F. Display diagonal: 55.9 cm (22"), Display resolution: 1920 x 1080 pixels, HD type: Full HD, Display technology: LCD, Response time: 6 ms, Native aspect ratio: 16:9, Viewing angle, horizontal: 178°, Viewing angle, vertical: 178°. Built-in speaker(s). VESA mounting, Height adjustment. Product colour: Black
Matrix type - VA
Model - MultiSync E224F
Multimedia - Built-in camera - No
Multimedia - Built-in speaker(s) - Yes
Multimedia - Number of speakers - 2
Multimedia - RMS rated power - 2 W
name - Monitor MultiSync E224F black 22 inches DP HDMI
Number of colors - 16,7 mln
Operational conditions - Operating relative humidity (H-H) - 20 - 80%
Operational conditions - Operating temperature (T-T) - 5 - 35 °C
Operational conditions - Storage relative humidity (H-H) - 10 - 85%
Operational conditions - Storage temperature (T-T) - -10 - 60 °C
Optional accessory -
Other features -
Other features - Compliance certificates - RoHS, cTUVus, WEEE
Packaging content - Cables included - AC, DisplayPort
Packaging content - Stand included - Yes
Performance - Flicker-free technology - Yes
Ports & interfaces - Built-in USB hub - No
Ports & interfaces - DisplayPorts quantity - 1
Ports & interfaces - HDMI - Yes
Ports & interfaces - HDMI ports quantity - 1
Ports & interfaces - Headphone out - Yes
Ports & interfaces - VGA (D-Sub) ports quantity - 1
Power - Energy consumption (SDR) per 1000 hours - 12 kWh
Power - Energy efficiency class (SDR) - D
Power - Energy efficiency scale - A to G
Power - European Product Registry for Energy Labelling (EPREL) code - 1338529
Power - Power consumption (PowerSave) - 0.22 W
Power - Power consumption (typical) - 14 W
Power consumption - 14 W
producer - NEC
ProductName - E224F
Resolution - 1920 x 1080 (FHD 1080)
Response time - 6 ms
Screen size (diag.) - 22"
ShortSummaryDescription - NEC MultiSync E224F, 55.9 cm (22"), 1920 x 1080 pixels, Full HD, LCD, 6 ms, Black
Speakers built-in - Yes
Static contrast - 3 000:1
Stck_Kart - 1
Stck_Pal - 10
Storno - Y
TCO Certified - Yes
Title - NEC MultiSync E224F computer monitor 55.9 cm (22") 1920 x 1080 pixels Full HD LCD Black
Touch screen - No
Transreflective technology - LED
TV tuner built-in - No
URL - https://www.sharpnecdisplays.eu/p/eeme/en/products/details/t/desktop-displays/enterprise-displays/rp/e224f.xhtml
vendpn - 60005828
VESA - 100 x 100
Viewing angle, horizontal - 178 °
Viewing angle, vertical - 178 °
Warranty -
WarrantyInfo - 3 years
Web camera - None
Weight - 3.1 kg
Weight & dimensions - Bezel width (bottom) - 1.68 cm
Weight & dimensions - Bezel width (side) - 2.5 mm
Weight & dimensions - Bezel width (top) - 2.5 mm
Weight & dimensions - Depth (with stand) - 233.2 mm
Weight & dimensions - Height (with stand) - 483.4 mm
Weight & dimensions - Weight (without stand) - 3.1 kg
Weight & dimensions - Weight (with stand) - 5.2 kg
Weight & dimensions - Width (with stand) - 493.2 mm
Weight with stand - 5.2 kg
Width - 493.2 mm
WiFi - No
