Accessories included -
Aspect ratio - 32:9
Auto Pivot - No
Bluetooth - No
Brand - ASUS
BrandPartCode - 90LM0720-B01170
Brightness - 400 cd/m²
Category - Computer Monitors
Category - Root/Electronics/PC peripherals/Monitors
Category_1 - Monitors and TV
Category_2 - LCD Monitors up to 19 inches
Certificates - Calman Verified
Certificates - TUV
Color - Black
Depth with stand - 20.71 mm
Description -
Design - Market positioning - Graphics design
Design - Product colour - Black
dimension depth - 450 mm
dimension height - 300 mm
dimension weight - 2000 g
dimension width - 100 mm
Display - Anti-glare screen - Yes
Display - Backlight type - LED
Display - Colour gamut standard - DCI-P3
Display - Contrast ratio (typical) - 1200:1
Display - Digital horizontal frequency - 24 - 83 kHz
Display - Digital vertical frequency - 23 - 60 Hz
Display - Display brightness (typical) - 400 cd/m²
Display - Display diagonal - 35.6 cm (14")
Display - Display number of colours - 16.7 million colours
Display - Display resolution - 1920 x 550 pixels
Display - Display surface - Matt
Display - Display technology - LCD
Display - Maximum refresh rate - 60 Hz
Display - Native aspect ratio - 32:9
Display - Panel type - IPS
Display - Pixel density - 143 ppi
Display - Pixel pitch - 0.179 x 0.179 mm
Display - Response time - 5 ms
Display - Screen shape - Flat
Display - sRGB coverage (typical) - 100%
Display - Touchscreen - Yes
Display - Viewable size, horizontal - 34.4 cm
Display - Viewable size, vertical - 9.86 cm
Display - Viewing angle, horizontal - 178°
Display - Viewing angle, vertical - 178°
Display surface - Matt
Dot pitch - 0.179 mm
ean - 4711081218265
Eans - 4711081218265
EAN_code - 4711081218265
Energy class - not applicable
Ergonomics - Pivot - Yes
Ergonomics - Pivot angle - 0 - 90°
Ergonomics - Tilt adjustment - Yes
Ergonomics - Tilt angle range - 25 - 70°
Frequency, horizontal max. - 83 kHz
Frequency, horizontal min. - 24 kHz
Frequency, vertical max. - 60 Hz
Frequency, vertical min. - 23 Hz
GTIN - 0195553388047
GTIN - 195553388047
GTIN - 4711081218265
guarantee - 36
guarantee_type - external
Height with stand - 127.66 mm
I/O connectors - 1 x HDMI
I/O connectors - 2 x USB (Type C)
LongDesc - ProArt Display PA147CDV Creative ToolDial up Your Creative FlowProArt Display PA147CDV is a 14-inch creative tool with a 32:9 aspect ratio. Built to empower creators and streamline creative workflows inside the studio or out on location, it features the intuitive ASUS Dial, customizable Control Panel, 10-point multitouch controls, and Microsoft Pen Protocol 2.0 (MPP 2.0) support. PA147CDV is Calman Verified and factory calibrated to Delta E < 2, and it covers 100% of sRGB and Rec. 709 color spaces for exceptional color. Aesthetically, PA147CDV looks the part, too – winning the 2021 Good Design and 2021 Computex d&i Gold awards.Built for CreatorsStreamline Your WorkflowThe customizable Control Panel puts the tools and functions you need front and center, allowing you to make adjustments quickly for a more efficient workflow. For easier multitasking, you can even use split-screen mode to show shortcuts for different apps side by side.Ready for that Creative SparkWith ProArt Display PA147CDV, you’re always ready when an idea comes. Take notes or sketch on the go with a stylus, or hook it up to your laptop with just a single cable.Natural Writing or DrawingWith MPP 2.0 support, you’re able to use a pen or stylus to jot down or sketch ideas whenever inspiration strikes*.*ASUS Pen or stylus not included.Creativity with a SpinASUS Dial works with Photoshop, Photoshop Lightroom Classic, Premiere Pro and After Effects Classic for shortcuts accessASUS Dial is designed to work with compatible Adobe software* such as Photoshop, Photoshop Lightroom Classic, Premiere Pro and After Effects**. Customized shortcuts enable you to zoom in and out of images or adjust brush size by simply turning the ASUS Dial. You can even tailor the default interface to suit your own work style.Intuitive Control at Your FingertipsControl Panel provides an intuitive interface that’s unique to each supported Adobe software*. The 10-point multitouch functionality** of PA147CDV means you can quickly reach out and switch tools, turn a dial to get the exact color you’re looking for, or adjust a key parameter for the tool you’re using – it’s all neatly laid out so you can work more efficiently.Experience Full ColorWide Color GamutColor AccuracyWide 100% sRGB and 100% Rec. 709 color gamut offers more vivid colors, ensuring deeper primary colors like red, green and blue, and richer secondary colors.Pre-Calibrated forOut-of-the-Box AccuracyColor professionals rely on color-accurate displays to ensure that their creations render as intended. PA147CDV is pre-calibrated at the factory and Calman Verified to guarantee industry-leading color accuracy. Every ProArt display undergoes meticulous testing to ensure smooth color gradation and to guarantee the very best visuals.Quick Color Gamut AdjustmentASUS-exclusive ProArt Preset provides multiple modes for quick color-gamut adjustment. Whether you're grading colors, editing videos or manipulating photos, you can switch and match your needs easily.Rich ConnectivityPA147CDV offers a host of ports to cater to your creative needs. Two USB-C ports deliver video and power input over a single cable, with additional flexibility offered by the HDMI port for a connection to various input sources.*Connected device requires USB Type-C (DisplayPort Alt Mode and at least 10W power output.)Create in ComfortBuilt-in Adjustable KickstandCaring for Your EyesPA147CDV has a multi-award winning design that bagged the 2021 Good Design and Computex d&I Gold awards. Its patented mechanical kickstand lets you adjust the display to the perfect angle. Lay PA147CDV flat on the desk to do some sketching, or tilt it up to an almost-vertical position to track the timeline in your video editing app. Simply set the right tilt angle to suit the task at hand.Free 3 Months of Adobe Creative CloudGet complimentary membership with the purchase of selected ASUS products.* (Up to a $238.47 value)
LongProductName - ASUS ProArt Display PA147CDV Creative Tool – 14-inch, 32:9, IPS, Full HD (1920 x 550), 100% sRGB, 100% Rec.709, Color Accuracy ΔE < 2, Calman Verified, USB-C, 10-point Touch, MPP2.0, ASUS Dial, Control Panel, Compatible with Adobe Software
LongSummaryDescription - ASUS ProArt PA147CDV. Display diagonal: 35.6 cm (14"), Display resolution: 1920 x 550 pixels, Display technology: LCD, Display surface: Matt, Response time: 5 ms, Native aspect ratio: 32:9, Viewing angle, horizontal: 178°, Viewing angle, vertical: 178°. Built-in speaker(s). Product colour: Black
Manufacturer - Asus
Manufacturer_code - 90LM0720-B01170
Matrix type - TFT IPS
Model - PA147CDV
Multimedia - Built-in camera - No
Multimedia - Built-in speaker(s) - Yes
Multimedia - Number of speakers - 2
Multimedia - RMS rated power - 2 W
Name - ASUS ProArt Display PA147CDV - 14 - black
Name - ASUS ProArt PA147CDV - 14'' | IPS | 1920 x 540
name - Monitor 14 inches PA147CDV BK/5MS/EU/HDMI+TYPEC*2
Number of colors - 16,7 mln
Optional accessory -
Other features -
Packaging data - Package depth - 92 mm
Packaging data - Package height - 290 mm
Packaging data - Package type - Box
Packaging data - Package weight - 2.3 kg
Packaging data - Package width - 440 mm
Performance - Flicker-free technology - Yes
Performance - Low Blue Light technology - Yes
Ports & interfaces - Built-in USB hub - No
Ports & interfaces - HDCP - Yes
Ports & interfaces - HDCP version - 1.4
Ports & interfaces - HDMI - Yes
Ports & interfaces - HDMI ports quantity - 1
Ports & interfaces - HDMI version - 1.4
Ports & interfaces - Headphone out - No
Ports & interfaces - USB Type-C DisplayPort Alternate Mode - Yes
Ports & interfaces - USB Type-C downstream ports quantity - 2
Power - AC input frequency - 50 - 60 Hz
Power - AC input voltage - 100 - 240 V
Power - Energy consumption (SDR) per 1000 hours - 9 kWh
Power - Energy efficiency class (SDR) - E
Power - Energy efficiency scale - A to G
Power - European Product Registry for Energy Labelling (EPREL) code - 1118999
Power - Power consumption (PowerSave) - 0.5 W
Power - Power consumption (typical) - 10 W
Power consumption - 10 W
producer - Asus
Producer - Asus
ProducerCode - PA147CDV
ProductName - PA147CDV
Refresh rate - 60 Hz
Resolution - 1920 x 550
Response time - 5 ms
Screen size (diag.) - 14''
ShortDescription - 14'' | IPS | 1920 x 540
ShortSummaryDescription - ASUS ProArt PA147CDV, 35.6 cm (14"), 1920 x 550 pixels, LCD, 5 ms, Black
Speakers built-in - Yes
Static contrast - 1 200:1
Title - ASUS ProArt PA147CDV computer monitor 35.6 cm (14") 1920 x 550 pixels LCD Touchscreen Black
Touch screen - Yes
Transreflective technology - LED
TV tuner built-in - No
URL - https://www.asus.com/displays-desktops/monitors/proart/proart-display-pa147cdv/
vendpn - PA147CDV
Viewing angle, horizontal - 178 °
Viewing angle, vertical - 178 °
Visible area, horizontal - 344.22 mm
Visible area, vertical - 96.8 mm
Warranty -
WarrantyInfo -
Web camera - None
Weight - 2,05
Weight & dimensions - Depth (with stand) - 20.7 mm
Weight & dimensions - Height (with stand) - 127.7 mm
Weight & dimensions - Weight (with stand) - 950 g
Weight & dimensions - Width (with stand) - 357.2 mm
Weight with stand - 0.95 kg
Width - 357.23 mm
WiFi - No
