Asus ROG Loki SFX-L Platinum, 850W, ATX 3.0, 80PLUS Platinum, White

Picture may differ from actual product, there can be accessories and parts not supplied with the actual product.
ID: 963540 Product code: 90YE00N2-B0NA00
Can be ordered 2 units Availability: 14 days after order approval
Warranty: 2 years (Warranty for business entities 1 year)
236.57 €
Delivery options
  • Delivery to Smartpost parcel locker 1.99 €: {delivery_2_txt_full}
  • Delivery to Omniva parcel locker 1.99 €: 27.11.2024
  • Courier delivery 3.99 €: 27.11.2024
Main product parameters All parameters
  • Producer: Asus
  • Power output: 850W
  • 80 PLUS certification: 80 PLUS Platinum
  • Fan size: 120 mm
  • Modular cables: Fully-Modular
  • Processor plug-in: 2 x 8-pin(4+4) EPS
  • PCI-E: 3 x 6+2pin
Description

This Asus brand power supply unit has an 80 PLUS Platinum energy efficiency certificate and a power output of 850W.

850W power supply unit designed for a high-performance gaming computer or workstation. It will be able to power a top-tier processor (possibly overclocked), a high-end graphics card (for example, RTX 4070 Ti SUPER), multiple hard drives (SSD/HDD), and water cooling.

The diameter of this power supply unit's fan is 120 mm, which will ensure quiet operation in mid-range computers. For especially quiet power supply unit operation, we recommend selecting a fan with a 135 mm or 140 mm diameter.

The power supply has been awarded the 80 PLUS Platinum energy efficiency certificate, which ensures at least 92% efficiency at 50% load. This indicates that at least 92 W out of 100 W of power that the power supply receives from the power grid is delivered to the computer components, while the remaining 8 W is lost as heat.

This power supply unit is equipped with a 1 x 600W 12VHPWR plug intended for use with modern graphics cards – Nvidia GeForce RTX 4070 and up. The RTX 4060 uses a standard 8-pin connector.

The color of the power supply is Balta. It is equipped with flat cables, whose color is Balta.

This power supply is assigned the ATX 3.0 standard. This means that the unit has a 16-pin (12VHPWR) connector, providing up to 600W of power for the newest generation (RTX 30 and 40 series) PCIe 5.0 graphics cards. Additionally, the ATX 3.0 standard supports a 200% power increase for 1 millisecond to ensure more stable power for the components.

The power supply has received the Cybenetics A noise level certificate – the noise generated by the unit will be 20-25 decibels.

This power supply has modular cables, which provide the possibility to add video card cables, hard disk cables, etc. as needed from the supplied range. This way, the wire clutter in the computer is reduced, improving ventilation and the aesthetic factor (particularly important for those who purchase a partially transparent case).

This power supply has received RGB lighting.

This power supply type is SFX. While it is not as powerful or large as AFX type blocks, it is ideal for small form factor (SFF) computers with limited space and compatible with motherboards like Mini-ITX, and it has smaller fans.

The manufacturer of the power supply unit is Asus. All power supply units produced by Asus can be viewed here.

Basic information
Cybenetics Efficiency certification : Cybenetics Platinum
Cybenetics Noise level certification : Cybenetics A
Power supply type : SFX-L
Power output 850W
The capacity of the power supply unit in watts. A higher capacity means higher stability of the computer operation. The recommended capacity of the power supply unit of a modern average computer is 500 W and above. If you use several HDDs, a powerful video card and processor it is recommended to buy a power supply unit with the capacity 600 W or above.
80 PLUS certification : 80 PLUS Platinum
Total amperage (+12V) : 70.8A
Fan size : 120 mm
Functionality
Cable colour : White
Lighting : RGB
Color : White
Modular cables : Fully-Modular
Ports and equipment
PCI-E 5.0 : 1 x 600W 12VHPWR
Processor plug-in : 2 x 8-pin(4+4) EPS
Motherboard power : 20+4pin
PCI-E : 3 x 6+2pin
SATA cconnectors : 6
4pin Molex : 4
Case
More detailed specification
Additional information in manufacturers website Asus ROG Loki SFX-L Platinum, 850W, ATX 3.0, 80PLUS Platinum, White
Brand - ASUS
BrandPartCode - 90YE00N2-B0NA00
category - PC Components|Power Supplies|PCIe 5.0
Category - Power Supply Units
Category - Root/Electronics/PC parts/PC power supply units
Category_1 - Power
Category_2 - Computer Power Supplies
code - 90YE00N2-B0NA00
Design - Cooling type - Active
Design - Fan diameter - 12 cm
Design - Illumination - Yes
Design - Number of fans - 1 fan(s)
Design - On/off switch - Yes
Design - Product colour - White
ean - 4711081722229
Eans - 4711081722229
EAN_code - 4711081722229
GTIN - 4711081722229
LongDesc - The Quietest SFX-L PSUTaking after the ROG Thor, the ROG Loki SFX-L 850W Platinum White Edition brandishes the same enthusiast-grade components and features, all packed into an SFX-L form factor. Boasting quiet operation and high performance, the Loki is primed to power your next SFF build.COOLINGROG HeatsinksCool under pressureROG heatsinks facilitate lower temperatures, longer component lifespan, and extended 0dB operation.Axial-tech Fan DesignBetter, faster, strongerAxial-tech fan design features a smaller fan hub that facilitates longer blades and a barrier ring that increases downward air pressure. For ROG Loki PSUs, we've scaled that design to 120mm so it keeps things cool at low RPMs while producing less noise.Dual Ball Fan Bearings2x longer lifespanThe fan impeller spins on a dual ball bearing setup that will last up to twice as long as a sleeve bearing design.0dB TechnologyQuiet intelligenceTo reduce noise output, the PWM-controlled fan shuts off entirely when the PSU load is 40% or below.Lambda A CertificationQuietly deviantOn average, ROG Loki emits less than 25 dB of noise – earning a coveted Cybenetics Lambda A certification.ENGINEERING80 PLUS Platinum CertifiedEffortless outputLow-ESR Japanese capacitors further improve efficiency and reduce heat, readying ROG Loki to reliably fuel your build for years to come.ATX 3.0 CompatibleStep into the futureThe latest power specification updates have landed. ATX 3.0 ushers in tighter voltage and current regulation guidelines for next-gen hardware - and ROG Loki steps ahead of the curve by being fully compliant. A 16-pin PCIe cable ripe for piping up to 600W of power to PCIe Gen 5.0 graphics cards is bundled with the PSU, bringing large-scale capabilities to SFF rigs.EXPERIENCEARGB-illuminated Fan & Aura SyncMagical glowThe Loki's 120 mm fan features eight addressable LEDs ready to be customized with Aura Sync to create coordinated lighting patterns across your build.* If the connector cable is not used, the default color effect is rainbow.* To enjoy Aura Sync, you’ll need an Aura Sync-compatible ASUS or ROG motherboard. Similarly, the Smart Mode lighting effect, which reflects GPU temperature, requires use of a compatible ASUS or ROG graphics card.10-Year WarrantyA decade of powerWe're so confident about the reliability of the ROG Loki SFX-L 850W Platinum White Edition that we back it with a 10-year worldwide warranty.*Core product operation is guaranteed for 10 years. The RGB LEDs are subject to a 3-year warranty.
LongProductName - ROG Loki SFX-L 850W Platinum power supply (fully modular power supply, 80+ Platinum, Lambda A certified, 120mm PWM ARGB fan, Aura Sync RGB lighting, ATX 3.0 compatible, PCIe 5.0 ready, white)
LongSummaryDescription - ASUS ROG Loki SFX-L 850W Platinum White. Total power: 850 W, AC input voltage: 100 - 240 V, Combined power (+3.3V): 110 W. Motherboard power connector: 24-pin ATX, Motherboard power cable length: 45 cm, SATA power cable length: 600 mm. Purpose: PC, Power supply unit (PSU) form factor: SFX-L, 80 PLUS certification: 80 PLUS Platinum. Product colour: White, Cooling type: Active, Fan diameter: 12 cm. Width: 125 mm, Depth: 125 mm, Height: 63.5 mm
Manufacturer - Asus
Manufacturer_code - 90YE00N2-B0NA00
Name - ASUS ROG-LOKI-850P-WHITE-SFX-L-GAMING
name - ASUS ROG Loki SFX-L 80 PLUS Platinum netzteil, modular - 850 Watt - weiß
Name - ASUS ROG Loki SFX-L 850W Platinum, PC power supply (white, 4x PCIe, cable management, 850 watts)
Packaging data - Package depth - 190 mm
Packaging data - Package height - 100 mm
Packaging data - Package type - Box
Packaging data - Package weight - 2.5 kg
Packaging data - Package width - 285 mm
Performance - 80 PLUS certification - 80 PLUS Platinum
Performance - Bearing technology - Ball bearing
Performance - Power supply unit (PSU) form factor - SFX-L
Performance - Purpose - PC
Performance - Supported motherboard form factors - ATX
Ports & interfaces - Cabling type - Fully-Modular
Ports & interfaces - CPU power cable length - 55 cm
Ports & interfaces - CPU power connector (4+4 pin) - Yes
Ports & interfaces - Motherboard power cable length - 45 cm
Ports & interfaces - Motherboard power connector - 24-pin ATX
Ports & interfaces - Number of SATA power connectors - 6
Ports & interfaces - PCI Express power cable length - 45 cm
Ports & interfaces - PCI Express power connectors (8-pin) - 3
Ports & interfaces - PCI Express power connectors (16-pin) - 1
Ports & interfaces - Peripheral (Molex) power cable length - 600 mm
Ports & interfaces - Peripheral (Molex) power connectors (4-pin) - 4
Ports & interfaces - SATA power cable length - 600 mm
Power - AC input voltage - 100 - 240 V
Power - Combined power (+3.3V) - 110 W
Power - Combined power (+5V) - 110 W
Power - Combined power (+5Vsb) - 12.5 W
Power - Combined power (+12V) - 850 W
Power - Combined power (-12V) - 9.6 W
Power - Max output current (+3.3V) - 20 A
Power - Max output current (+5V) - 20 A
Power - Max output current (+5Vsb) - 2.5 A
Power - Max output current (+12V) - 70.8 A
Power - Max output current (-12V) - 0.8 A
Power - Power protection features - Over power, Over voltage, Overcharge, Overheating, Short circuit, Under voltage
Power - Total power - 850 W
Producer - Asus
ProducerCode - 90YE00N2-B0NA00
ProductName - Loki SFX-L 850W Platinum White
ShortDescription - 850 | ATX | biały | 135mm | 20 + 4 pin | 80 Plus Platinum| 125 x 125 x 63.5 mm |
ShortSummaryDescription - ASUS ROG Loki SFX-L 850W Platinum White, 850 W, 100 - 240 V, 110 W, 850 W, 110 W, 9.6 W
Technical details - Compliance certificates - RoHS
Technical details - Sustainability certificates - RoHS
Technical details - Sustainability compliance - Yes
Title - ASUS ROG Loki SFX-L 850W Platinum White power supply unit 24-pin ATX
URL - https://rog.asus.com/power-supply-units/rog-loki/rog-loki-850p-white-sfx-l-gaming-model/
WarrantyInfo -
Weight - 1,80
Weight & dimensions - Depth - 125 mm
Weight & dimensions - Height - 63.5 mm
Weight & dimensions - Weight - 1.81 kg
Weight & dimensions - Width - 125 mm
