Lc-power LC500-12 V2.31, 400W, 80PLUS Bronze

Picture may differ from actual product, there can be accessories and parts not supplied with the actual product.
ID: 233373 Product code: LC500-12 V2.31
Can be ordered 18 units Availability: 14 days after order approval
Warranty: 2 years (Warranty for business entities 1 year)
43.46 €
Delivery options
  • Delivery to Smartpost parcel locker 1.99 €: {delivery_2_txt_full}
  • Delivery to Omniva parcel locker 1.99 €: 11.12.2024
  • Courier delivery 3.99 €: 11.12.2024
Main product parameters All parameters
  • Producer: LC-POWER
  • Power output: 400W
  • 80 PLUS certification: 80 PLUS Bronze
  • Fan size: 120 mm
  • Modular cables: Nav
  • Processor plug-in: 1 x 8-pin(4+4) EPS
  • PCI-E: 1 X 6pin
Description

120 mm fans, with which this power supply unit is equipped, will ensure industry standard quiet operation. For especially quiet power supply unit operation, we recommend purchasing a 135 mm or 145 mm diameter fan.

The power supply has been awarded the 80 PLUS Bronze energy efficiency certificate, which ensures at least 85% efficiency at 50% load. This indicates that at least 85 W out of 100 W of power received by the power supply from the electrical grid is delivered to the computer components, with the remaining 15 W being lost as heat.

The color of the power supply is Sudraba. It is equipped with flat cables, whose color is Raiba.

This power supply unit has been assigned the ATX 2.0 standard. This means that the unit is equipped only with 6-pin and 8-pin connectors, providing 75W and 150W power respectively. It's important to note that this unit will be compatible with RTX 4070 and more powerful cards, but you will need to use the 2x8-pin to 16-pin 12VHPWR adapter included with the graphics card. ATX 2.0 power connectors are not designed to handle the high power fluctuations of modern graphics cards; therefore, if you are building a system with a powerful GPU, such as the RTX 4070, we recommend choosing a power supply unit with the ATX 3.* standard and 12VHPWR (PCIe 5.0) connector.

The power supply unit does not have modular cables; all cables are attached to the power supply unit and are not removable. Despite this, it will work just as well as a power supply unit with modular cables.

Basic information
Cybenetics Efficiency certification : Nav
Cybenetics Noise level certification : Nav
Power supply type : ATX
Power output 400W
The capacity of the power supply unit in watts. A higher capacity means higher stability of the computer operation. The recommended capacity of the power supply unit of a modern average computer is 500 W and above. If you use several HDDs, a powerful video card and processor it is recommended to buy a power supply unit with the capacity 600 W or above.
80 PLUS certification : 80 PLUS Bronze
Total amperage (+12V) : 11A
Fan size : 120 mm
Functionality
Cable colour : Raiba
Lighting : Nav
Color : Silver
Modular cables : Nav
Ports and equipment
PCI-E 5.0 : Nav
Processor plug-in : 1 x 8-pin(4+4) EPS
Motherboard power : 20+4pin
PCI-E : 1 X 6pin
SATA cconnectors : 4
4pin Molex : 2
Case
More detailed specification
8-pin 12V power connectors - 0
Accessories included -
Certificates - - TUV
- CE
Certificates 80+ - 80 PLUS Bronze
dimension depth - 95 mm
dimension height - 205 mm
Dimensions - 85 x 150 x 140 mm
dimension weight - 1380 g
dimension width - 160 mm
ean - 4260070124402
Fan - 12 cm
Floppy power connectors - 1
guarantee - 24
guarantee_type - normal
MB power connector - 20 + 4 pin
Modular power supply - No
MOLEX power connectors - 2
name - PSU 400W LC500-12 V2.31 80+ BRONZE
Number of power supply connector 4+4-pin 12V - 1
Number of power supply connector 4-pin 12V - 0
Number of power supply connectors PCI-E 6 +2 pin - 0
Other features - - Seria Office
- Standard ATX: ATX V2.31
- Efektywność: do 88.63 %
- Pobór prądu w trybie StandBy: 0.21W (ErP 2013)
- Kontrola temperatury
- Zabezpieczenia: OVP/OPP/SCP/UVP
- Haswell Compatible
Wymiary przewodów/złącz:
- 20+4 pin: 1x 45 cm
- 4+4 pin 12V: 1x PCI-Express 45 cm
- SATA: 2x 45 cm/ 2x 60 cm
- PATA: 2x 70 cm
- FDD: 1x 85 cm
PCI-E 6-pin power connectors - 1
PCI-E 8-pin power connectors - 0
PFC - Active
Power supply - 400 W
producer - LC-POWER
SATA power connectors - 4
vendpn - LC500-12 V2.31
Weight - 1.378 kg
