Gigabyte P750BS, 750W, 80 PLUS Bronze

Picture may differ from actual product, there can be accessories and parts not supplied with the actual product.
News
ID: 1181529 Product code: GP-P750BS
In stock 3 units
Warranty: 3 years
77.84 €
Delivery options
  • Delivery to Smartpost 1.99 €: on Wednesday, 05.02.2025
  • Delivery to Omniva parcel locker 1.99 €: on Wednesday, 05.02.2025
  • Courier delivery 3.99 €: on Wednesday, 05.02.2025
Main product parameters All parameters
  • Producer: Gigabyte
  • Power output: 750W
  • 80 PLUS certification: 80 PLUS Bronze
  • Fan size: 120 mm
  • Modular cables: Nav
  • Processor plug-in: 2 x 8-pin(4+4) EPS
  • PCI-E: 4 X 6+2pin
Description

We offer to purchase a Gigabyte power supply unit with a power capacity of 750W, which has received the 80 PLUS Bronze energy efficiency certification.

To ensure a good mid-range gaming experience, 750W of power will be sufficient. With this power supply unit, you will be able to run a computer with a high-end processor, multiple SSD/HDD drives, and a powerful mid-range graphics card (for example, RTX 4070).

The diameter of this power supply unit's fan is 120 mm, which will ensure quiet operation in mid-range computers. For especially quiet power supply unit operation, we recommend selecting a fan with a 135 mm or 140 mm diameter.

The power supply has received the 80 PLUS Bronze energy efficiency certificate, which guarantees at least 85% efficiency at 50% load. This means that for every 100W of power the power supply draws from the electrical grid, at least 85W is delivered to your computer components, while the remaining 15W is lost as heat.

The color of the power supply is Melna. It is equipped with flat cables, whose color is Melna.

ATX 2.0 standard, which is assigned to this power supply unit, ensures that the unit is equipped only with 6-pin and 8-pin connectors (with respective power of 75W and 150W). For a system with a very powerful graphics card (such as RTX 4070), an ATX 3.* standard unit will be required, and ATX 2.0 will not be sufficient.

This power supply unit does not have modular cables – all its cables are attached to the unit and are not detachable. Despite the simple design, it will fulfill its functions just as well as a power supply unit with modular cables.

The manufacturer of the power supply unit is Gigabyte. All power supply units produced by Gigabyte can be viewed here.

Basic information
Cybenetics Efficiency certification : Nav
Cybenetics Noise level certification : Nav
Power supply type : ATX
Power output 750W
The capacity of the power supply unit in watts. A higher capacity means higher stability of the computer operation. The recommended capacity of the power supply unit of a modern average computer is 500 W and above. If you use several HDDs, a powerful video card and processor it is recommended to buy a power supply unit with the capacity 600 W or above.
80 PLUS certification : 80 PLUS Bronze
Total amperage (+12V) : 62.5A
Fan size : 120 mm
Functionality
Cable colour : Melna
Lighting : Nav
Color : Melna
Modular cables : Nav
Ports and equipment
PCI-E 5.0 : Nav
Processor plug-in : 2 x 8-pin(4+4) EPS
Motherboard power : 20+4pin
PCI-E : 4 X 6+2pin
SATA cconnectors : 4
4pin Molex : 2
Case
More detailed specification
Category Code - PSU
Colour - Black
Cooling System - 12cm fan
Description - P750BS - Intel Form Factor ATX 12V - 80 PLUS Bronze certified (230V EU) - 120mm Silent Fluid Dynamic Bearing (FDB) fan - Soft-textured embossed cables - Single +12V rail - OVP/OPP/SCP/UVP/OCP/OTP protection
Dimensions - 150 x 140 x 86 mm
Efficiency - 80 PLUS BRONZE
Full Description Line - GP-P750BS|For gaming|750 Watts|Cooling System 12cm fan|80 PLUS BRONZE|PFC Active|MTBF 100000 hours|Colour Black
Model name - GP-P750BS
MTBF - 100000 hours
PFC - Active
PSU features - For gaming
PSU Output Power - 750 Watts
Shipping Box Depth Shipping/Package Box Dimensions - 62 cm
Shipping Box Height Shipping/Package Box Dimensions - 28.2 cm
Shipping box quantity - 5
Shipping Box Weight Shipping/Package Box Dimensions - 10.75 kg
Shipping Box Width Shipping/Package Box Dimensions - 22.5 cm
Unit Box Height - 0.12
Unit Box Length - 0.256
Unit Box Width - 0.21
Unit Brutto Volume - 0.007868 cubm
Unit Gross Weight - 2.15 kg
Unit Net Weight - 2 kg
Vendor Homepage - www.gigabyte.com/Power-Supply/GP-P750BS#kf
Warranty - 36 months
