Accessories included - Power adapter (12V/2A EU/US/UK plug) Ethernet cable Quick Start Guide Warranty Card CE certificate Safety Warning
Antenna - Built-in
Antenna - Antenna design - Internal
Antenna gain - 5 dBi
Antennas quantity - 4
Antenna type - MIMO
ARTIKEL1 - LTE5398-M904 CAT 18
ARTIKEL2 - MODEM ROUTER
Brand - Zyxel
BrandPartCode - LTE5398-M904-EU01V1F
Breite - 0
Category - Root/Electronics/Networks and communication/Routers
Category - Wireless Routers
Category 1 - Netzwerk
Category 2 - Router
Color - White
Description - Maximum Network Efficiency, Easier Life! It combines the functions of WAN AP, LAN gateway and VoIP/VoLTE*/telephone in one box. With an easy-to-navigate interface and minimalist design, it helps make your life easier! Wireless freedom Installing cable internet is not cost-effective/time-consuming at all. It can free you from cable installation with 4G LTE wireless technology for any location with poor wired connection. Whether you already have a router or not, the device can operate in both bridge and router modes, making it easy to deploy and integrate into your existing environment. Exceptional speed, signal and performance Equipped with Cat.18, the highest level of 4G LTE-A technology, downlink speeds can reach up to 1.2 Gbps thanks to 5-band carrier aggregation and built-in 4x4 high performance MIMO antennas. Even better, two external LTE antenna ports are embedded, which can enhance signal reception. Enjoy fast mobile internet. Seamless connectivity The "Dual-WAN failover" function allows you to configure LTE as a backup when the performance of the main wired connection drops, or set LTE as the main connection and the LAN port as a backup WAN to maintain a reliable network connection. Connection possible anywhere It uses dual-band concurrent 2.4/5GHz Wi-Fi. Share your Wi-Fi with up to 32* Wi-Fi devices simultaneously. Combine it with powerful security gateways, switches, NAS servers, VoIP/VoLTE phones, or other devices to meet your business or family's networking needs throughout the day. Simple design, Easy management It is designed with elegance and space-saving style. The plug-and-play function, the user-friendly free "Zyxel Air" app and the intuitive web-based GUI ensure pleasant and easy-to-use management via mobile device or PC.
Description - ZYXEL LTE5398-M904 4G PRO LTE-A INDOOR IAD CAT18 AC2050 4X4 MIMO DUAL-WAN
Design - Indication light - Yes
Design - LED indicators - Status
Design - Product colour - Silver
Design - Product type - Tabletop router
dimensionalWeight - 999
dimension depth - 120 mm
dimension height - 245 mm
Dimensions - 100 x 100 x 205 mm
dimension weight - 1320 g
dimension width - 170 mm
ean - 4718937606801
EANCode - 4718937606801
Eans - 4718937606801
GRUPPE1 - Network
GRUPPE2 - Wireless Lan Ap
GTIN - 4718937606801
guarantee - 24
guarantee_type - external
Height - 170.000000
HERSTELLER - ZYXEL
Hoehe - 0
HSTNUMMER - LTE5398-M904-EU01V1F
I/O ports - 1 x USB 2.0
I/O ports - 2 x 10/100/1000 Mbit/s
Laenge - 0
Length - 245.000000
LongDesc - 4G Pro LTE-A Indoor IAD Zyxel LTE5398-M904 4G Pro LTE-A Indoor IAD supports Cat. 18 and AC2050 dual-band concurrent links. Its “Dual-WAN Failover” design guarantees a reliable broadband internet access via either mobile WAN or fixed-line WAN for premium services with lower CAPEX.Lightning-fast internet connectivityZyxel LTE5398-M904 employs 3GPP UE downlink Category 18 – the highest-level practice LTE-A Pro technology with data rates of up to 1200/150 Mbps**. The built-In 4x4 MIMO high-performance antennas increase your service capacity and expand the internet coverage for your subscribers.Easy installation with with space-saving designThe simple and intuitive device design of Zyxel LTE5398-M904 provides your subscribers with a trouble-free installation and configuration experience, while allowing you to maintain an excellent service quality with a lower OPEX.Remote management with TR-069 With TR-069, TR-181 and TR-143 support, the Zyxel LTE5398-M904 effectively secures OPEX by reducing the frequency of on-site support and by providing simplified diagnostic, configuration and troubleshooting processes.Boosts efficiency of the existing infrastructure with dual-mode flexibilityThe bridge/router function allows service providers to start a new deployment or upgrade services by connecting to the subscriber’s existing broadband router with a lower CAPEX. Dual-mode flexibility and built-in VoIP/VoLTE function*** of LTE5398-M904 fulfills different deployment scenarios and subscribers’ demand of high-quality voice services.Non-stop connectivity with “Dual-WAN Failover” designDesigned with the “Dual-WAN Failover” function, the Zyxel LTE5398-M904 guarantees reliable connectivity by using LAN1 port as recovery WAN.Network setup and management in handZyxel LTE5398-M904 supports Zyxel Air, an in-house developed app for Zyxel Fixed Wireless Access devices. The simple, intuitive yet powerful app simplifies the setup, configuration, and management of your customer's home or office networks. Your technicians can provide prompt and satisfying services with reduced average service time for each customer.
LongProductName - LTE5398-M904, CAT 18 IAD, EU region
LongSummaryDescription - Zyxel LTE5398-M904. WAN connection type: RJ-45. Wi-Fi band: Dual-band (2.4 GHz / 5 GHz), Top Wi-Fi standard: Wi-Fi 5 (802.11ac), WLAN data transfer rate (max): 1200 Mbit/s. Ethernet LAN interface type: Gigabit Ethernet. Mobile network generation: 4G, 3G standards: HSPA+, HSUPA, WCDMA, 4G standard: LTE-TDD & LTE-FDD. Security algorithms: WPA, WPA2
Management, monitoring, configuration - APN management SIM PIN/PUK management SMS management Network selection Selection of the operating frequency band Zyxel Air APP support (iOS and Android) for easy installation and local management
Management features - MU-MIMO technology - Yes
Management features - Web-based management - Yes
Management features - Wi-Fi Multimedia (WMM)/(WME) - Yes
Manufacturer - Zyxel
Manufacturer - ZYXEL NETWORKS
ManufacturerPartNumber - LTE5398-M904-EU01V1F
Mobile network - 3G standards - HSPA+
Mobile network - 3G standards - HSPA+, HSUPA, WCDMA
Mobile network - 3G standards - HSUPA
Mobile network - 3G standards - WCDMA
Mobile network - 4G standard - LTE-TDD & LTE-FDD
Mobile network - Mobile network generation - 4G
Mobile network - Short Message Service (SMS) - Yes
Mobile network - SIM card type - MicroSIM
Model - LTE5398-M904
Modem type - 4G
MPN - LTE5398-M904-EU01V1F
name - Router wireless LTE5398-M904-EU01V1F
Name - Zyxel LTE5398-M904-EU01V1F
Name - Zyxel LTE Router LTE5398-M904
Network - Dynamic DNS (DDNS) - Yes
Network - Ethernet LAN - Yes
Network - Ethernet LAN interface type - Gigabit Ethernet
Network - Port forwarding - Yes
Network architecture - GigabitEthernet
Number of antennas - 6
Operating frequency - 2,4 GHz
Operating frequency - 5 GHz
Other features - LEDs (from left to right on the panel): Power/USB (green/blue) internet (green) LTE Signal Strength (Green/Red/Orange) WiFi/WPS (Green) One button WPS & Wi-Fi on/off One slot for 3FF micro SIM card One button reset to default settings One button power on/off Automatic channel selection Wi-Fi Multimedia (WMM) Multiple SSID/Hide SSID WLAN planning Up to 32 Wi-Fi clients per band
Packaging content - AC adapter included - Yes
Packaging content - Cables included - LAN (RJ-45)
Packaging content - Quick start guide - Yes
Packaging content - Warranty card - Yes
Packaging data - Package depth - 170 mm
Packaging data - Package height - 120 mm
Packaging data - Package weight - 1.6 kg
Packaging data - Package width - 247 mm
PeriodofWarranty - 24 M
Ports & interfaces - DC-in jack - Yes
Ports & interfaces - Ethernet LAN (RJ-45) ports - 2
Ports & interfaces - USB port - Yes
Power supply -
producer - Zyxel
Producer - Zyxel
producerCode - LTE5398-M904-EU01V1F
ProducerCode - LTE5398-M904-EU01V1F
ProductName - LTE5398-M904
productName - Zyxel LTE5398-M904 wireless router Gigabit Ethernet Dual-band (2.4 GHz / 5 GHz) 4G Silver
productSize - Normal
Protocols - DHCP client - Yes
Protocols - DHCP server - Yes
Security - WPA2-Personal, WPA+WPA2 Wi-Fi Protected Setup (WPS)
Security - DMZ support - Yes
Security - Firewall - Yes
Security - Security algorithms - WPA
Security - Security algorithms - WPA, WPA2
Security - Security algorithms - WPA2
ShortDescription -
ShortSummaryDescription - Zyxel LTE5398-M904, Wi-Fi 5 (802.11ac), Dual-band (2.4 GHz / 5 GHz), Ethernet LAN, 4G, Silver, Tabletop router
sizeX - 245
sizeY - 120
sizeZ - 170
Software -
Special functions -
Standards - 802.11a
Standards - 802.11ac
Standards - 802.11b
Standards - 802.11g
Standards - 802.11n
Stck_Kart - 6
Stck_Pal - 0
Storno - Y
System Requirements -
Title - Zyxel LTE5398-M904 wireless router Gigabit Ethernet Dual-band (2.4 GHz / 5 GHz) 4G Silver
Type - GSM 3G/4G
Type - xDSL
URL - https://zyxel.com/
vendpn - LTE5398-M904-EU01V1F
WAN connection - Ethernet WAN - Yes
WAN connection - SIM card slot - Yes
WAN connection - WAN connection type - RJ-45
WarrantyInfo -
warrantyLength - 24
warrantyType - F
Weight - 1.300000
Weight - 599 g
weight - 1315
Weight & dimensions - Depth - 100 mm
Weight & dimensions - Height - 205 mm
Weight & dimensions - Weight - 599 g
Weight & dimensions - Width - 100 mm
Width - 120.000000
Wireless LAN features - Top Wi-Fi standard - Wi-Fi 5 (802.11ac)
Wireless LAN features - Wi-Fi band - Dual-band (2.4 GHz / 5 GHz)
Wireless LAN features - Wi-Fi standards - 802.11a
Wireless LAN features - Wi-Fi standards - 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Wireless LAN features - Wi-Fi standards - 802.11b
Wireless LAN features - Wi-Fi standards - 802.11g
Wireless LAN features - Wi-Fi standards - Wi-Fi 4 (802.11n)
Wireless LAN features - Wi-Fi standards - Wi-Fi 5 (802.11ac)
Wireless LAN features - WLAN data transfer rate (max) - 1200 Mbit/s
Wireless network support - Yes
