10/100/1000M LAN Ports - 1
Accessories included - EAP650-Wall Installation manual Installation kit
Antenna - Built-in
Antenna - Antenna type - Internal
Antenna gain - 3 dBi
ARTIKEL1 - AX3000 WI-FI 6 ACCESS POINT
ARTIKEL2 - WALL-PLATE OMADA SDN
Brand - TP-Link
BrandPartCode - EAP650-WALL
Breite - 0.13
Category - Wireless Access Points
Category 1 - Netzwerk
Category 2 - Accesspoints
Category Code - WAP
Category_1 - Network and Servers
Category_2 - Network - WiFi Access Points
Color - White
Data transmission speed - 3000 Mbps
Description - AX3000 Wall Plate WiFi 6 Access Point Blazing-Fast AX3000 WiFi 6 Speeds:: Simultaneous 574 Mbps on 2.4 GHz and 2402 Mbps on 5 GHz totals 2976 Mbps WiFi speeds.† Higher Network Efficiency: Deliver data to more devices at the same time with less lag.‡ Complete In-Room WiFi Coverage: Guaranteed strong signals and corner-to-corner WiFi coverage. Gigabit Port: Connect wired devices with one downlink gigabit port. Centralized Cloud Management: Integrates into Omada SDN for cloud access and remote management. Secure Guest Network: Implement multiple authentication options (SMS/Facebook Wi-Fi/ Voucher) packed with high-quality wireless security technologies.§ Easy Installation and PoE Support: Easy-to-install design, compatible with 86 mm & EU standard junction box, and 802.3af/at PoE support.
Description - Wireless wall-mounted WiFi access point 6, AX3000 Extremely fast WiFi 6 AX3000: Simultaneous speeds of 574Mbps in the 2.4GHz band and 2402Mbps in the 5GHz band, offers a total Wi-Fi speed of 2976Mbps. High connection performance: Higher network performance and lower latency at the same time. Full room Wi-Fi coverage: Guarantee strong signal and Wi-Fi coverage in every corner of the room. Gigabit Port: Connect your wired device using the available gigabit downlink port. Centralised management: Integration with the Omada SDN platform provides Cloud access and remote management. Secure guest networking: Multiple authentication methods (SMS/Facebook Wi-Fi/ Voucher) and numerous technologies are available to protect access to the wireless network.§ Easy installation and PoE support: The design ensures ease of installation with compatibility with the 86mm and standard EU installation box and support for 802.3af/at PoE power. Designed entirely for a private Wi-Fi network in every room Hospitality Room-by-room connectivity with a sleek design Dormitories Stable wired and wireless connections Flats Private and secure network access for every family Home Wi-Fi coverage with seamless roaming throughout the home Meeting room Faster streaming, downloading, video conferencing and more to meet your needs Lightning fast Wi-Fi 6, AX3000 Wi-Fi 6 delivers higher speeds, lower latency, less interference and more capacity. Enjoy more than double the speed of Wi-Fi 5 available in new era Wi-Fi 6, reaching speeds of up to 2976Mbps. High connection performance for greater user experience The latest Wi-Fi 6 technology offers advanced wireless features that guarantee higher network performance and lower latency. Not just Speed, but Security too Secure your network and its data against Brute Force and Snooping attacks with Enterprise Grade WPA3 encryption, portal authentication and guest network segregation. Secure guest network with up to 16 SSIDs The guest network provides extended security for users. Different SSIDs allow for easy management. Guest network with Facebook WiFi and SMS login A welcome page (including SMS, Facebook WiFi and Voucher) and 802.1x authentication help maintain guest authentication and access to the network. Grow your business with a personalised advertising page. WPA3 for open public networks With advanced enterprise-grade security, WPA3 provides enhanced data security for previously unsecured WiFi hotspots. Gigabit port - Connecting to your network The Gigabit downlink port allows a wired device to connect to a gigabit network. Seamless deployment with PoE power supply With support for PoE 802.3af/802.3at, there is no need to distribute additional cabling. Just connect the device to your existing Ethernet cables and you're done! Quick and easy installation Thanks to the easy-to-install design, there is no need to spend time and money on a specialist to install our EAP. Automatic channel selection and power control optimise performance Ensures high wireless performance, while reducing WiFi interference, by automatically adjusting the channel settings and transmission power levels of neighbouring access points on the same network. Integration with Omada SDN platform The Omada Software Defined Networking (SDN) platform integrates network devices such as Access Points, switches and routers together to provide 100% centralised cloud-based management and a highly scalable network managed from a single interface. Easy management through the Omada app Setting up your network through the app takes just a few minutes. Omada allows you to customise settings to your preferences, monitor network status and manage connected clients - all from your smartphone or tablet.
Design - Certification - CE, RoHS
Design - LED indicators - Yes
Design - Placement - Wall
Design - Product colour - White
Design - Reset button - Yes
dimensionalWeight - 218
dimension depth - 55 mm
dimension height - 125 mm
Dimensions - 86 × 86 × 42.6 mm
dimension weight - 313 g
dimension width - 140 mm
ean - 4897098683569
EAN - 4897098683569
EANCode - 4897098683569
EAN_code - 4897098683569
Features - 2.4 GHz - Yes
Features - 5 GHz - Yes
Features - 6 GHz - No
Features - Airtime Fairness (ATF) - Yes
Features - Automatic channel scanning - Yes
Features - Automatic channel selection - Yes
Features - Band steering - Yes
Features - Ethernet LAN data rates - 10
Features - Ethernet LAN data rates - 10,100,1000 Mbit/s
Features - Ethernet LAN data rates - 100
Features - Ethernet LAN data rates - 1000 Mbit/s
Features - Frequency band - 2.4 - 5 GHz
Features - Maximum data transfer rate - 3000 Mbit/s
Features - Maximum data transfer rate (2.4 GHz) - 574 Mbit/s
Features - Maximum data transfer rate (5 GHz) - 2402 Mbit/s
Features - Networking standards - IEEE 802.3af
Features - Networking standards - IEEE 802.3at
Features - Networking standards - IEEE 802.11a
Features - Networking standards - IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3af, IEEE 802.3at
Features - Networking standards - IEEE 802.11ac
Features - Networking standards - IEEE 802.11ax
Features - Networking standards - IEEE 802.11b
Features - Networking standards - IEEE 802.11g
Features - Networking standards - IEEE 802.11n
Features - Number of users - 100 user(s)
Features - Quality of Service (QoS) support - Yes
Features - Rate limiting - Yes
Features - VLAN support - Yes
Full Description Line - Omada|EAP650-Wall|Type Wireless Access Point|Data transmission speed 3000 Mbps|IEEE 802.11a|IEEE 802.11b|IEEE 802.11g|IEEE 802.11n|IEEE 802.11ac|IEEE 802.11ax|1x10/100/1000M|Number of antennas 2|Wireless Frequency Range 2.4/5 GHz|Dimensions 86 × 86 × 42.6 mm
Gewicht - 0.31
Gross Weight Kg - 0,35
GRUPPE1 - Network
GRUPPE2 - Wireless Lan Ap
GTIN - 4897098682104
GTIN - 4897098683569
guarantee - 60
guarantee_type - normal
HERSTELLER - TP-LINK
Hoehe - 0.06
HSTNUMMER - EAP650-WALL
I/O ports - 1 x 10/100/1000 Mbit/s
I/O ports - 1 x 10/100/1000 Mbit/s PoE
IEEE 802.11ac Network standard - Yes
IEEE 802.11a Network standard - Yes
IEEE 802.11ax Network standard - Yes
IEEE 802.11b Network standard - Yes
IEEE 802.11g Network standard - Yes
IEEE 802.11n Network standard - Yes
Laenge - 0.14
LongDesc - Match Your Room withAX3000 WiFi 6AX3000 Wall Plate WiFi 6 Access PointAX3000 WiFi 6 Speed2402 Mbps on 5 GHz + 574 Mbps on 2.4 GHz†High-Efficiency WiFi 6More connected devices enjoy faster speedsCentralized Cloud ManagementManage the whole network locally or from the cloud160 MHz ChannelDouble the data at peak transmission times on a single stream with HE160Enhanced SecurityWith guest networks, Captive Portal, and WPA3 encryptionSeamless RoamingUninterrupted streaming when moving between APs§Two Gigabit PortsOne downlink and one uplink for fast wired connection802.3af/at PoE SupportFlexible and convenient deploymentQuick, Simplified InstallationCompatible with 86 mm & EU standard junction boxLightning-Fast AX3000 WiFi 6 SpeedsWiFi 6 brings faster speeds, lower lag, less interference, and higher capacity. Enjoy more than twice the speed of WiFi 5 with new-era business WiFi 6 with speeds up to 2976 Mbps.Better User Experience with High-PerformanceWiFi 6 ConnectivityThe latest WiFi 6 features and advanced wireless techniques guarantee higher network efficiency and lower latency. More than Speed, Security MattersSafeguard your network against brute force attack and snooping with WPA3 enterprise-grade security protection, portal authentication, and segregated guest networks.Secure Guest Network with Up to 16 SSIDsGuest networks provide enhanced security. Different SSIDs also enable flexible access management.Boost Business with Facebook WiFi and SMS LoginCaptive portals (including SMS, Facebook WiFi, Voucher) and 802.1x authentication ensure authorized guests can access the network. Boost your business with a customized marketing page.WPA3 for Worry-Free Open Public NetworksWPA3 provides more data security for previously unsecured and open WiFi hotspots with advanced enterprise security.Gigabit Ports to Bridge NetworkThe gigabit downlink port allows to connect wired device to the gigabit network.Effortless Deployment with PoE PoweredWith 802.3af/802.3at PoE support, there’s no need for more wiring. Plug it into the existing Ethernet cables, and you’re ready.Quick, Simplified InstallationWith an easy-to-install design, there is no need to bring someone in to install our EAP.Auto Channel Selection and Power Adjustment to Optimize Overall PerformanceProvides powerful wireless performance while significantly reducing WiFi interference by automatically adjusting the channel settings and transmission power levels of neighboring APs in the same networkSeamless Integration into Omada SDNThe Omada Software Defined Networking (SDN) platform integrates network devices including access points, switches, and routers to provide 100% centralized cloud management and create a highly scalable network—all controlled from a single interface.Easy Management with the Omada AppFollow configuration instructions on the Omada app to get set up in minutes. Omada lets you configure settings, monitor the network status, and manage clients, all from the convenience of your mobile device.
LongProductName - 2.4GHz (574Mbps), 5 GHz (2402 Mbps), 802.3af/at PoE, 802.11ax/ac/n/g/b/a, 86 x 86 x 42.6 mm
LongSummaryDescription - TP-Link Omada AX3000 Wall Plate WiFi 6 Access Point. 2.4 GHz, 5 GHz, Maximum data transfer rate: 3000 Mbit/s. Security algorithms: SNMP, SSH, WPA-Enterprise, WPA2-Enterprise. Ethernet LAN data rates: 10,100,1000 Mbit/s. Power over Ethernet (PoE). Product colour: White
Management, monitoring, configuration - Omada application Cloud access (via OC300, OC200, Omada software controller or Omada Cloud-based controller) Email notifications LED switch Access control by MAC address SNMP - v1, v2c, v3 System log - Local and remote SSH Management via HTTP/HTTPS browser L3 management Multi-site management VLAN management Maintenance-free ZTP configuration. Requires the use of Omada's Cloud-based controller. Central management Omada hardware controller (OC300) Omada hardware controller (OC200) Omada Software Controller Omada Cloud-based Controller
Manufacturer - TP-Link
Manufacturer Code - EAP650-WALL
Manufacturer Name - TP-LINK
Manufacturer_code - EAP650-Wall
Model name - EAP650-Wall
MPN - EAP650-WALL
Name - TP-Link EAP650-Wall, access point (white)
name - TP-Link EAP650-Wall 2GE PoE AX3000
Name - TP-LINK Omada EAP650-Wall AX3000 Wifi6
Network architecture - GigabitEthernet
Network Device Type - Wireless Access Point
Number of antennas - 2
Operating frequency - 2,4 GHz
Operating frequency - 5 GHz
Operational conditions - Operating relative humidity (H-H) - 10 - 920%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 5 - 90%
Operational conditions - Storage temperature (T-T) - -40 - 70 °C
Other features - Certifications: CE, RoHS Permissible operating temperature: 040 (32104) Permissible storage temperature: -4070 (-40158) Permissible humidity: 10%90%, non-condensing Permissible storage humidity: 5%90%, non-condensing
Packaging content - Number of products included - 1 pc(s)
Packaging content - Quick start guide - Yes
Packaging data - Package depth - 139 mm
Packaging data - Package height - 55 mm
Packaging data - Package type - Box
Packaging data - Package weight - 290 g
Packaging data - Package width - 127 mm
Ports & interfaces - Ethernet LAN (RJ-45) ports - 2
Power - DC voltage range - 12 V
Power - Power over Ethernet (PoE) - Yes
Power supply -
producer - TP-LINK
producerCode - EAP650-WALL
ProductName - AX3000 Wall Plate WiFi 6 Access Point
productName - TP-Link Omada AX3000 Wall Plate WiFi 6 Access Point
productSize - Normal
Security - Welcome page authentication§ Access control MAC address filtering Wireless client isolation VLAN Detection of unauthorised APs 802.1X support WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise encryption
Security - MAC address filtering - Yes
Security - Number of SSID supported - 16
Security - Remote Authentication Dial-In User Service (RADIUS) - Yes
Security - Security algorithms - SNMP
Security - Security algorithms - SNMP, SSH, WPA-Enterprise, WPA2-Enterprise
Security - Security algorithms - SSH
Security - Security algorithms - WPA-Enterprise
Security - Security algorithms - WPA2-Enterprise
Series - Omada
Shipping Box Depth Shipping/Package Box Dimensions - 14 cm
Shipping Box Height Shipping/Package Box Dimensions - 5 cm
Shipping box quantity - 1
Shipping Box Weight Shipping/Package Box Dimensions - 0.313 kg
Shipping Box Width Shipping/Package Box Dimensions - 13 cm
Short description - TP-LINK WLAN AX3000 Access Point Dualband EAP650-Wall
ShortSummaryDescription - TP-Link Omada AX3000 Wall Plate WiFi 6 Access Point, 2.4 GHz, 5 GHz, 3000 Mbit/s, SNMP, SSH, WPA-Enterprise, WPA2-Enterprise, 10,100,1000 Mbit/s
sizeX - 130
sizeY - 140
sizeZ - 60
Software -
Special functions -
Standards - 802.11a
Standards - 802.11ac
Standards - 802.11ax
Standards - 802.11b
Standards - 802.11g
Standards - 802.11n
Stck_Kart - 30
Stck_Pal - 0
Storno - Y
System Requirements - Microsoft Windows XP Vista Windows 7 Windows 8 Windows10 Windows 11 Linux
Title - TP-Link Omada AX3000 Wall Plate WiFi 6 Access Point
Unit Box Height - 0.05
Unit Box Length - 0.14
Unit Box Width - 0.13
Unit Brutto Volume - 0.00091 cubm
Unit Gross Weight - 0.313 kg
Unit Net Weight - 0.25 kg
URL - https://www.tp-link.com/uk/business-networking/wall-plate-ap/eap650-wall/
Vendor Homepage - www.tp-link.com/uk/business-networking/omada-sdn-access-point/eap650-wall/
vendpn - EAP650-Wall
Warranty - 60 months
WarrantyInfo -
warrantyLength - 24
warrantyType - G
Weight - 0,31
Weight - 0.3
weight - 316
Weight & dimensions - Depth - 86 mm
Weight & dimensions - Height - 42.6 mm
Weight & dimensions - Width - 86 mm
Wireless Frequency Range - 2.4/5 GHz
