Benq MW809STH

Accessories included - Projektor Pilot i baterie Skrócona instrukcja obsługi Karta gwarancyjna Przewód zasilający
ANSI Lumens (Max.) - 3600
AspectRatio - 16:10
Aspect ratio - 16:10
Audio - Yes
AudioFeatures - 10W
Brand - BenQ
BrandCode - BENQ
BrandPartCode - MW809STH
Brightness - 3500 ANSI Lumen
Category - Data Projectors
Category - Root/Electronics/PC peripherals/Projectors and screens/Projectors
Code - 9H.JMF77.13E
Color - White
Compatibility with computer standards -
Compatibility with video standards - Frame Sequential: do 720p Frame Packing: do 24 Hz 1080p Side by Side Half: do 60Hz 1080p Top Bottom: do 60Hz 1080p Zgodność z HDTV: 480i, 480p, 576i, 567p, 720p, 1080i, 1080p
CompressedResolution - -
ComputerCompatibility - HDTV compatability: 480i, 480p, 576i, 576p, 720p, 1080i, 1080p
Connections - Audio (3.5mm)
Connections - HDMI
Connections - PC (D-Sub)
Connections - Serial (RS-232)
Connections - USB-A
Connections - USB-B
ContrastRatio - 22,000:1
Contrast ratio (typical) - 12000:1
Depth - 239 mm
Description - BENQ MW809STH 3600ANSI WXGA 0.49:1 DLP LAMP
Description - Projektor interaktywny z krótkim rzutem, WXGA | MW809STH
Design - Cable lock slot - Yes
Design - Cable lock slot type - Kensington
Design - Market positioning - Short throw
Design - Placement - Desktop
Design - Product colour - White
Design - Product type - Short throw projector
Design > Colour of product - White
Design > Producer product family - Interactive Projector with Short Throw
dimension depth - 190 mm
dimension height - 340 mm
Dimensions - 296 x 239 x 120 mm
Dimensions - depth - 12
Dimensions - height - 23.9
Dimensions - weight - 2.6
Dimensions - width - 29.6
Dimensions W x D x H, mm - 296 x 239 x 120
dimension weight - 3780 g
dimension width - 420 mm
Display - Built-in display - No
Display number of colours - 1.07 B
Display technology - DLP
DisplayType - DLP
EAN - 4718755082849
ean - 4718755082849
Eans - 4718755082849
Features - On Screen Display (OSD) - Yes
Frequency - 15-102 kHz
Frequency, horizontal max. - 102 kHz
Frequency, horizontal min. - 15 kHz
Frequency, vertical max. - 120 Hz
Frequency, vertical min. - 23 Hz
FrequencyVertical - 23-120 Hz
General parameters - colour - white
General parameters - manufacturer - BenQ
GrossWeight - 3.800 kg
GrossWeight - 4.7500
Group - IT > PROJECTORS > PROJECTORS
GTIN - 4718755082849
guarantee - 36
guarantee_type - external
HDMI ports quantity - 2
Height - 0.3400
Height - 120 mm
Height - 340.000000
I/O connectors - 1 x Audio out
I/O connectors - 1 x Mini-DIN-4 (S-Video)
I/O connectors - 1 x mini USB (Type B)
I/O connectors - 1 x RCA
I/O connectors - 1 x RJ-45 LAN
I/O connectors - 1 x RS-232 (COM)
I/O connectors - 1 x USB 2.0
I/O connectors - 2 x Audio in
I/O connectors - 2 x HDMI
I/O connectors - 3 x 15-pin D-Sub
InputOutput -

3x D-sub

2x RCA

S-video

2x HDMI

3x Audio jack

USB Type-A

USB mini B

RS-232

RJ-45

Interfaces - 3,5 mm stereo audio jack
Interfaces - USB-A
Interfaces - VGA
Keystone correction, vertical, ° - +/- 30
LampLife -

Normal: 6,000 hours

Economic: 10,000 hours

SmartEco: 10,000 hours

LampSave: 15,000 hours

Lamp power, W - 200
LampWarranty - -
Length - 0.4250
Length - 423.000000
Lens -
Lens - -
Lens system > Throw ratio - 0.61
light life time - 6000 h
light life time (ECO mode) - 15000 h
Light source - Lamp
Light source - Service life of light source - 15000 h
Link - https://www.benq.com/en-ap/business/projector/mw809sth/specifications.html
LongDesc -
LongDesc - Advanced Interactive Instruction for Leading SchoolsMW809STH education projector enhances interactive learning and classroom collaboration with outstanding picture quality, high brightness, and short throw capability. Smart installation flexibility combined with reduced maintenance and ownership costs make MW809STH the ideal choice for today’s schools.Ensuring Stable Operation in Challenging Classroom EnvironmentAnti-Dust Accumulation SensorResists Dust BuildupIncorporating color wheel sensors with an ingenious anti-dust accumulation feature, MW809STH prolongs optimal performance by rejecting dust which can accumulate on traditional sensors to block the IR signal and cause flickering, abnormal colors, or even shutdown.Expanding Classroom Possibilities with Short Throw RatioUnobstructed Instruction Without Space ConstraintsOffering a big screen in short distance with a 0.49 short-throw ratio, MW809STH eliminates distracting shadows and glare for students and teachers to engage and collaborate freely in front of the board.Creating Lasting Lessons with Striking Picture QualityUncompromised High BrightnessMW809STH produces 3,600 high ANSI lumen brightness and resolution for perfect projection performance with crisp images and sharp text even in bright lecture room. High brightness provides clear content under high ambient lighting, allowing lights to be kept on during classes for note taking and interactive collaboration.Bigger ImagesBenQ education projectors offer a range of resolutions and projected image sizes to meet diverse classroom needs. Featuring crisp image quality up to 120 inches, our ultra-short throw education projectors deliver increased classroom versatility at reduced costs.Enduring Picture Perfection from DLP TechnologyLong Lasting Picture QualityWith sealed design that protects the DLP chip from dust-induced image degradation and the industrial-grade durability of DLP projection technology, BenQ education projectors are capable of maintaining long-lasting picture quality by eliminating color decay. Unlike non-DLP projectors, BenQ education projectors deliver premium picture quality equivalent to the result from brand new projectors after lamp replacement.High DLP Pixel Fill Factor for Superb Viewing ExperienceBenQ DLP projectors feature class-leading high fill factor, minimizing black borders around each pixel to eliminate the dreaded “screen door effect” commonly observed in non-DLP projectors. BenQ education projectors produce superior definition and clarity in small-size text and fine details for beautifully rendered images instead of pixelated graphics.Crisp Readability via High Contrast RatioIdeal for text, numbers, and tables widely used in instruction, BenQ education projectors leverage the native DLP advantage of digitally controlled micromirrors on the DMD chip. By completely toggling off reflective micromirrors to generate deep true blacks, BenQ education projectors create high native contrast ratio for sharp readability and crisp resolution at every single sub-pixel.Enabling Interactive LearningInteraction on Any SurfacePointWrite technology transforms BenQ education projectors into collaborative platforms that turn any surface into an interactive whiteboard. Seamless integration of PointWrite kit and QWrite software with BenQ projectors encourages a truly collaborative learning environment where students and teachers work together using intuitive templates along with annotation tools.Multi-Touch & Multi- Screen DrawingWith enhanced multi-touch capability for pens or fingers, two PointWrite projectors can be used in conjunction to double the interactive projection surface, creating vast new opportunities for interactive learning in modern digital classrooms. In QWrite Whiteboard Mode, teachers can also run different applications or display, view, and annotate across two surfaces.Intuitive SetupReliably accurate in any ambient lighting, PointWrite auto calibrates and saves its settings immediately when plugged into a computer’s USB port, remaining ready with no manual configuration or complicated training for teachers.Windows Gesture SupportPointWrite projectors support intuitive Windows gestures such as zooming in and out or scrolling while browsing webpages, pictures or Google Maps. All multi-touch commands and gestures are supported for Windows 8 or above and future applications.Making Collaboration Easier with BYODSimple and Convenient Wireless DongleBenQ education projectors are ready for BYOD collaboration and creating more engaging lessons via QCast wireless dongle that allows up to 4 participants to stream content from smart devices or computers to the big screen, displaying them in 4 split screens.Optimizing Educational InvestmentThe exclusive BenQ innovation SmartEcoTM technology intelligently modulates light output and perfects DLP's energy saving capabilities to increase lamp life with uncompromised brightness and exquisite picture quality. Reducing energy consumption, SmartEco extends lamp life up to 15,000 hours, 3X* more than without SmartEco technology. And Eco Blank mode further increases energy saving capability by dimming lamp power automatically to lower total power by 70% when blanking the projection.* The lamp life under LampSave mode is three times longer than under Normal mode.Sharp Details in Dark ScenesBenQ’s exclusive SmartEco Technology ingeniously adjusts light output based on content, enhancing contrast to produce richer blacks and the best possible picture quality especially important for detailed and dynamic dark scenes such as astronomy courses.Simplifying InstallationDigital Shrink & ShiftBenQ education projectors allow convenient screen size fine tuning through OSD menu to significantly save setup time, without need to physically adjust projector installation in case the sensitive short-throw image is not precisely aligned on the desired frame.Remote Control HotkeyPress the “Quick Install” hotkey on the remote control to setup the projector. This is a great time saver for managers performing initial projector installation work.
LongProductName - DLP, 1024x768, HDMI, USB
LongSummaryDescription - BenQ MW809STH. Projector brightness: 3600 ANSI lumens, Projection technology: DLP, Projector native resolution: XGA (1024x768). Service life of light source: 15000 h. Serial interface type: RS-232, HDMI connector type: Full-size. Product type: Short throw projector, Market positioning: Short throw, Product colour: White. Power source: AC
Lumens - 3600 lumens
Manufacturer - BENQ
ManufacturerPartNumber - 9H.JMF77.13E
MANUFDATASHEET - https://www.benq.com/en-ap/business/projector/mw809sth/specifications.html
Maximum image diagonal - 120 ''
MediumDescription EN - MW809STH education projector enhances interactive learning and classroom collaboration with outstanding picture quality, high brightness, and short throw capability. Smart installation flexibility combined with reduced maintenance and ownership costs make MW809STH the ideal choice for today’s schools.
MediumDescription ET - MW809STH on interaktiivne projektor, mis on loodud klassiruumides ja õppeasutustes kasutamiseks. • 3600 luumenit
• 16:10 kuvasuhe (kokku 5 erinevat valikut)
• WXGA, 1280x800 resolutsioon
• 10W sisseehitatud kõlar
• Kensington lukustamise võimalus
Minimum image diagonal - 70 ''
Model - MW809STH
MountingCapability - Yes
Name - BenQ MW809STH short throw
Name - Benq | MW809STH | WXGA (1280x800) | 3500 ANSI lumens | White | Lamp warranty 12 month(s)
name - Projector MW809STH WXGA 3500AL/20000:1/HDMI
Name EN - Projector BenQ MW809STH WXGA HDReady, white
Name ET - Projektor BenQ MW809STH WXGA HDReady, valge
NameInWeb EN - BenQ MW809STH, WXGA, 3600 lm, white - Projector
NameInWeb ET - BenQ MW809STH, WXGA, 3600 lm, valge - Projektor
NativeResolution - 1280 x 800
Native resolution - WXGA (1280x800)
NetWeight - 4.6000
Network - Ethernet LAN - No
Network - Smart TV - No
Network - Wi-Fi - No
Networking > Wi-Fi connection - No
Noise - 33 dB
Noise level, dB - 33
Number of colors - 1,07 mld
Other features -
Other features > Aspect ratio - Native 16:10 (5 aspect ratio selectable)
PackageContents -

Remote Control w/ Battery RCE013

Power Cord (by region)

Warranty card (by Region)

User Manual e-edition

QSG

Package features > Classification of battery - CL126:NE:2016-12-09
Package features > Composition of battery - CL127:KT:2016-12-09
Package features > Embeeded battery - Yes
Package features > Gross depth (mm) - 423 mm
Package features > Gross height (mm) - 335 mm
Package features > Gross width (mm) - 187 mm
Package features > Packing quantity - 1.00 pc(s)
Package features > Palette Qty - 65 pc(s)
Package features > Paper/Pasteboard - 500.00 g
Package features > Plastic (No PET) - 50.00 g
Package features > Tare weight (kg) - 0.55 kg
Package features > TI weight (kg) - 0.02 kg
Package features > Type of battery - Battery
Package features > Volume (m3) - 0.026498835 m³
Package features > WEE classification - CL109:5:2017-04-01
Package features > WEEE tax - Yes
PeriodofWarranty - 36 M
Ports & interfaces - AC (power) in - Yes
Ports & interfaces - DVI port - No
Ports & interfaces - HDMI connector type - Full-size
Ports & interfaces - HDMI ports quantity - 1
Ports & interfaces - Mini-USB 2.0 ports quantity - 1
Ports & interfaces - PC Audio in - Yes
Ports & interfaces - PC Audio out - Yes
Ports & interfaces - Serial interface type - RS-232
Ports & interfaces - USB 2.0 ports quantity - 1
Ports & interfaces - VGA (D-Sub) ports quantity - 3
Ports & interfaces > HDMI ports quantity - 2
Power - Power source - AC
Power consumption - 260 W
Power consumption (standby), W - 0.5
Power consumption, W - 260
ProdDesc - BenQ MW809STH - DLP projector - portable - 3D - 3600 ANSI lumens - WXGA (1280 x 800) - 16:10 - 720p - short-throw fixed lens
producer - Benq
Producer - BenQ
ProducerCode - 9H.JMF77.13E
Producer product name - MW809STH
ProductCode - 9H.JMF77.13E
ProductionCountry - CN
ProductName - MW809STH
ProductPicture - http://www.tdbaltic.ee/images/ds4/9H.JMF77.13E-01.jpg
ProductPicture2 - http://www.tdbaltic.ee/images/ds4/9H.JMF77.13E-02.jpg
ProductPicture3 -
ProductPicture4 -
ProjectionSize - 1.78 m
Projection size, " - 70 - 120
ProjectionSizeMax - 3.05 m
Projection technology - DLP
Projector - remote control
Projector - brightness - 3600
Projector - Matrix size - 1.24 cm (0.49")
Projector - Matrix type - DMD
Projector - noise level - 29
Projector - Projection technology - DLP
Projector - Projector brightness - 3600 ANSI lumens
Projector - Projector native resolution - XGA (1024x768)
Projector - type - DLP
Resolution - 1280 x 800 (WXGA)
RS-232 ports quantity - 1
SalesUnitOfMeasureCode - tk
Service life of lamp, h - 6000
ShortDescription - 1280 x 800 | DLP | 3600 lm | HDMI | contrast 12 000:1| USB | 3D |
ShortSummaryDescription - BenQ MW809STH, 3600 ANSI lumens, DLP, XGA (1024x768), 1.24 cm (0.49"), DMD, 15000 h
Static contrast - 20 000:1
Storage - Card reader integrated - No
TariffNo - 85286200
Technical details > Brightness - 3500 ANSI lumens
Technical details > Contrast ratio - 20000:1
Technical details > Gross weight - 3.8 kg
Technical details > Lamp warranty - 12 month(s)
Technical details > Maximum resolution - WXGA (1280x800)
Technical details > Net weight - 3.25 kg
Technical details > Producer - Benq
ThrowDistance - -
ThrowDistanceMax - -
Throw ratio - 0.49
Title - BenQ MW809STH data projector Short throw projector 3600 ANSI lumens DLP XGA (1024x768) White
UnitOfMeasureCode - tk
UnitsPerPackage - 1
URL - https://business-display.benq.com/en/findproduct/projector/interactive-classroom-projectors/mw809sth.html
USB-A (USB 2.0) ports quantity - 1
USB-B (USB 2.0) ports quantity - 1
UserControls - -
vendpn - 9H.JMF77.13E
VGA (D-Sub) ports quantity - 1
VideoCompatibility -

Frame Sequential: Up to 720p

Frame Packing: Up to 24 Hz 1080p

Side by Side Half: Up to 60Hz 1080p

Top Bottom: Up to 60Hz 1080p

Volume - 0.02745500
Warranty -
Warranty - 3 years
Warranty - 36
Warranty - 36 month(s)
WarrantyInfo -
Weight - 2.6 kg
Weight - 2.600 kg
Weight - 3.870000
Weight & dimensions > Weight - 2600 g
Weight, g - 2600
Width - 0.1900
Width - 187.000000
Width - 296 mm
Wireless - No
Wireless communication - No
WirelessInterface - -
Zoom - Automatic (Digital)
