ARTIKEL1 - LH7575UHS-B1AG 75IN UHD IPS
ARTIKEL2 - 3840X2160 24/7 500CD ANDROID OS
Audio - Built-in speaker(s) - Yes
Audio - Number of built-in speakers - 2
Audio - RMS rated power - 20 W
Brand - iiyama
BrandPartCode - LH7575UHS-B1AG
Breite - 1.15
Category - Signage Displays
Certificates - Certification - CB, CE, TÜV-Bauart, EAC, ErP, WEEE, REACH
Computer system - Built-in processor - Yes
Computer system - Internal memory - 4 GB
Computer system - Internal storage capacity - 32 GB
Computer system - On-board graphics card model - ARM Mali-G52
Computer system - Operating system installed - Android 11
Computer system - Processor architecture - ARM Cortex-A53+Cortex-A73
Computer system - Processor cores - 4
Computer system - Processor family - ARM Cortex
Computer system - Processor manufacturer - ARM
Design - Bezel width (bottom) - 1.49 cm
Design - Bezel width (side) - 1.49 cm
Design - Bezel width (top) - 1.49 cm
Design - Orientation - Horizontal/Vertical
Design - Panel mounting interface - 600 x 400 mm
Design - Placement supported - Indoor
Design - Product colour - Black
Design - Product design - Digital signage flat panel
Design - VESA mounting - Yes
Display - Active display area (W x H) - 1650 x 928 mm
Display - Contrast ratio (typical) - 1200:1
Display - Display brightness - 500 cd/m²
Display - Display diagonal - 190.5 cm (75")
Display - Display diagonal (metric) - 189.3 cm
Display - Display number of colours - 1.07 billion colours
Display - Display resolution - 3840 x 2160 pixels
Display - Display technology - LCD
Display - Haze rate - 25%
Display - HD type - 4K Ultra HD
Display - Horizontal scan range - 28 - 160 kHz
Display - Maximum frame rate - 60 fps
Display - Native aspect ratio - 16:9
Display - Panel type - IPS
Display - Pixel pitch - 0.429 x 0.429 mm
Display - Response time - 8 ms
Display - RGB colour space - sRGB
Display - Touchscreen - No
Display - Viewing angle, horizontal - 178°
Display - Viewing angle, vertical - 178°
EANCode - 4948570123483
Gewicht - 38.5
GRUPPE1 - Displays
GRUPPE2 - Led Large Format
GTIN - 4948570123483
HERSTELLER - IIYAMA CONSIGNMENT
Hoehe - 0
HSTNUMMER - LH7575UHS-B1AG
Laenge - 1.88
Logistics data - Harmonized System (HS) code - 85285210
LongDesc - 75" 4K UHD Professional Digital Signage 24/7 display featuring Android OS, FailOver and Intel® SDM slotChoose non-stop high performance and reliability with the ideal all-in-one signage solution for mission critical environments. The LH7575UHS from iiyama can be operated in landscape or portrait orientation in continual around the clock environments, 24/7 without any interruption. Its versatility can be adapted to your industry’s display needs. On-board Android 11 OS means you can easily customize the display to your needs and install applications directly to it. The on-board iiSignage² (Content Management System) gives you total control of your messaging and advertising remotely and safely. The SDM Slot provides embedded PC option for total flexibility, security and control, while the FailOver feature ensures your content is always actively displayed through your choice of inputs. The built-in (and removable) WiFi module means this series is ready for remote content delivery using your network.With the EShare app you bring effortless ideation and efficient collaboration in your enterprise or school. You can start sharing wirelessly easier than ever before.ANDROID OSThanks to Android OS, you can easily customize the display to your needs by installing applications directly to it.IISIGNAGE²iiSignage² is our digital signage content management platform to easily show and control your content and to manage your displays in a secure way. The Content Management System (CMS) gives you total control of your messaging and advertising remotely and safely.SIGNAL FAILOVERFailOver is a feature which automatically detects input sources. When there is no signal on the default input it will automatically switch to the next available input. FailOver allows customers to prioritize a number of inputs (incl. Browser, Media Player and Custom) and ensures your content is always actively displayed, assuring active content at all times.SMART DISPLAY MODULEA Smart Display Module (Small/Large) is a plug-in module which can easily be inserted into the most stylish and ultra-slim displays. This small sized module delivers great performance with minimum implementation and management. Available as optional.4KUHD resolution (3840x2160), better known as 4K, offers a gigantic viewable area with 4 times more information and work space than a Full HD screen. Due to the high DPI (dots per inch), it displays an incredibly sharp and crisp image.
LongProductName - 75", 3840x2160, 16:9, IPS, HDMI, DP, RS-232C, RJ-45, RMS 2x 10W, USB, Android OS 11
LongSummaryDescription - iiyama LH7575UHS-B1AG. Product design: Digital signage flat panel. Display diagonal: 190.5 cm (75"), Display technology: LCD, Display resolution: 3840 x 2160 pixels, Display brightness: 500 cd/m², HD type: 4K Ultra HD. Wi-Fi. Operating hours (hours/days): 24/7. Operating system installed: Android 11. Product colour: Black
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage temperature (T-T) - -20 - 60 °C
Other features - Housing material - Metal
Other features - Quick start guide - Yes
Packaging content - Batteries included - Yes
Packaging content - Cables included - AC, HDMI, RS-232
Packaging content - Remote control included - Yes
Packaging data - Package depth - 186 mm
Packaging data - Package height - 1140 mm
Packaging data - Package weight - 41 kg
Packaging data - Package width - 1883 mm
Performance - HDCP - Yes
Performance - HDCP version - 2.2
Performance - Mean time between failures (MTBF) - 44000 h
Performance - Number of OSD languages - 15
Performance - On Screen Display (OSD) - Yes
Performance - On Screen Display (OSD) languages - Simplified Chinese, Czech, Danish, German, Dutch, English, Spanish, Finnish, French, Italian, Japanese, Polish, Russian, Swedish
Performance - Operating hours (hours/days) - 24/7
Performance - Purpose - Universal
Ports & interfaces - Card reader integrated - Yes
Ports & interfaces - Compatible memory cards - MicroSD (TransFlash)
Ports & interfaces - DisplayPorts quantity - 1
Ports & interfaces - DisplayPort version - 1.2
Ports & interfaces - Ethernet LAN - Yes
Ports & interfaces - Ethernet LAN (RJ-45) ports - 1
Ports & interfaces - HDMI ports quantity - 3
Ports & interfaces - HDMI version - 2.0
Ports & interfaces - PC Audio in - Yes
Ports & interfaces - Remote (IR) input - 1
Ports & interfaces - Remote (IR) output - 1
Ports & interfaces - RS-232C - Yes
Ports & interfaces - USB port - Yes
Ports & interfaces - USB ports quantity - 2
Ports & interfaces - USB version - 2.0
Ports & interfaces - Wi-Fi - Yes
Ports & interfaces - Wi-Fi standards - Wi-Fi 5 (802.11ac)
Power - AC input frequency - 50 - 60 Hz
Power - AC input voltage - 100 - 240 V
Power - Energy consumption (SDR) per 1000 hours - 189 kWh
Power - Energy efficiency class (SDR) - G
Power - Energy efficiency scale - A to G
Power - Power consumption (off) - 0.5 W
Power - Power consumption (standby) - 0.5 W
Power - Power consumption (typical) - 189 W
ProductName - LH7575UHS-B1AG
ShortSummaryDescription - iiyama LH7575UHS-B1AG, Digital signage flat panel, 190.5 cm (75"), LCD, 3840 x 2160 pixels, Wi-Fi, 24/7
Stck_Kart - 1
Stck_Pal - 0
Storno - Y
Technical details - Compliance certificates - RoHS
Title - iiyama LH7575UHS-B1AG Signage Display Digital signage flat panel 190.5 cm (75") LCD Wi-Fi 500 cd/m² 4K Ultra HD Black Built-in processor Android 11 24/7
URL - https://iiyama.com/gl_en/products/prolite-lh7575uhs-b1ag/
WarrantyInfo -
Weight & dimensions - Display depth - 55 mm
Weight & dimensions - Display height - 958.5 mm
Weight & dimensions - Display weight - 29.5 kg
Weight & dimensions - Display width - 1679.5 mm
