LG 75UH5J-M

600 mm x 400 mm VESA mounting interface - Yes
Accessories included - Remote control (including 2pcs battery) Power cable QSG
Aspect ratio - 16:9
Audio - Built-in speaker(s) - Yes
Audio-In Input/Output connectors - 1/1
Audio-Out Input/Output connectors - 1/1
Audio > Built-in speaker(s) - Yes
Auto Pivot - No
Bluetooth - No
Brand - LG
BrandPartCode - 75UH5J-M.AEU
Brightness - 500
Brightness - 500 nits
Category - Signage Displays
Category Code - LCD
Certificates - CB
Certificates - EMC
Certificates - Energy Star
Code - 75UH5J-M.AEU
Color - Black
Colour - Black/Black
Computer system - Internal memory - 16 GB
Computer system - Operating system installed - WebOS
Computer system - Operating system version - 6.0
Contrast - 1000:1/1000:1
Depth - 57.9 mm
Depth Unit Dimensions - 57.9 mm
Description - New UHD screen with a high degree of matte Standard Signage screen Appropriate screen brightness The UH5J-H series screen with a recommended brightness of 500 cd/m2 for indoor screens provides a clear image that attracts attention. It is the perfect choice for presenting marketing content in conference rooms, airports, stores, shopping malls, etc. High performance and webOS The LG webOS platform with an intuitive user interface and easy-to-use developer tools enables convenient work. Cover The UH5J-H series screens are intended for use in places where it is impossible to avoid exposure to dust, moisture, etc. factors that may cause the device's parameters to deteriorate over time. The conformal coating covering the power board of the UH5J-H screen reduces the risk of it being damaged by salt, dust, iron powder, moisture, etc. IP5x certified The IP5x tightness certificate guarantees that the product is protected against dust that may impair its performance. Compatibility with AV control system. The UH5J-H series devices support Crestron Connected technology, thanks to which they are highly compatible with professional audio-video devices, which allows for perfect integration and control automation and improves management.
Description - UHD Standard Signage Brightness (Typ.) : 500 nit Surface Treatement (Haze) : 28% Bezel : 14.9 mm (Even bezel) Depth : 57.9 mm Interface : HDMI(3) / DP / DVI-D / USB 2.0 / RS232C / RJ45 / Audio / IR Built-in Speaker
Design - Bezel width (bottom) - 1.49 cm
Design - Bezel width (side) - 1.49 cm
Design - Bezel width (top) - 1.49 cm
Design - Orientation - Horizontal
Design - Panel mounting interface - 600 x 400 mm
Design - Placement supported - Indoor
Design - Product colour - Black
Design - Product design - Digital signage flat panel
Design - VESA mounting - Yes
Design > Colour of product - Black
Design > VESA mounting - Yes
Design > VESA mounting interfaces - 600 × 400 mm
dimension depth - 1800 mm
dimension height - 1150 mm
dimension weight - 47500 g
dimension width - 220 mm
Display - Colour gamut - 72%
Display - Contrast ratio (dynamic) - 1000000:1
Display - Contrast ratio (typical) - 1000:1
Display - Display brightness - 500 cd/m²
Display - Display diagonal - 190.5 cm (75")
Display - Display number of colours - 1.07 billion colours
Display - Display resolution - 3840 x 2160 pixels
Display - Display technology - LCD
Display - Haze rate - 28%
Display - HD type - 4K Ultra HD
Display - LED backlight - Yes
Display - LED backlighting type - Edge-LED
Display - Native aspect ratio - 16:9
Display - Native refresh rate - 120 Hz
Display - Panel life - 50000 h
Display - Panel type - IPS
Display - Response time - 6 ms
Display - Touchscreen - No
Display - Viewing angle, horizontal - 178°
Display - Viewing angle, vertical - 178°
Display > Contrast ratio (typical) - 1000 : 1
Display > Display - 3840 x 2160 pixels
Display > Placement (L/P) - Landscape/Portrait
Display > Response time - 6 ms
Display > Viewing angle, horizontal - 178 °
Display > Viewing angle, vertical - 178 °
Display surface - Matt
DVI-D Input/Output connectors - 1/1
Dynamic contrast - 1 000 000:1
Dynamic contrast (DCR) - 1000000:1
EAN - 8806084227829
ean - 8806084227829
Energy class - A+
Full Description Line - 75"|Resolution 3840x2160|Form factor 16:9|Refresh rate 120Hz|Brightness 500|Contrast 1000:1|Dynamic contrast (DCR) 1000000:1|Response time 6 ms|Horizontal 178 degrees|Vertical 178 degrees|1xDVI-D|4xHDMI|1xAudio-In|1xAudio-Out|2xRS232|1xUSB 2.0|1xRJ45|Speakers|PSU Inbuilt|600 mm x 400 mm|Operation time hours/day 24/7|Colour Black
GTIN - 8806084227829
guarantee - 24
guarantee_type - external
HDMI Input/Output connectors - 4/4
Height - 960.3 mm
Height adjustment - No
Height Unit Dimensions - 960.3 mm
I/O connectors - 1 x Audio in
I/O connectors - 1 x Audio out
I/O connectors - 1 x DVI-D
I/O connectors - 1 x RJ-11/RJ-45
I/O connectors - 1 x USB 2.0
I/O connectors - 2 x RS-232 (COM)
I/O connectors - 3 x HDMI
Link - https://www.lg.com/global/business/digital-signage/lg-75uh5j-m#
LongDesc - New High Haze UHD Standard SignageAdequate Brightness LevelThe 75UH5J-M series boasts an adequate brightness level of 500 cd/m² for indoor displays, effectively showcasing content and capturing the public’s attention. This makes it an adequate display solution for marketing purposes in various settings, including meeting rooms, airports, retail outlets, and shopping malls.High-Performance with webOSLG webOS platform enhances user convenience with intuitive GUI and simple app development tools.Conformal CoatingIn various places the 75UH5J-M series is unable to avoid exposure to environments containing dust, humidity, etc. which may hamper performance over time. The conformal coating on power board reduces these risks by protecting 75UH5J-M series from salt, dust, iron powder, humidity, etc.IP5x Certified DesignThe IP5x Dust-Proof Certification ensures that the product is protected from dust, reducing the risk of performance degradation.Compatible with AV Control SystemThe 75UH5J-M series has supported Crestron Connected® for high compatibility with professional AV controls to achieve seamless integration and automated control*,boosting business management efficiency.
LongProductName - 75", 4K UHD (3840 x 2160), IPS, 500 nit, 6 ms, Wi-Fi, PIP, PBP, Pro:Idiom, SuperSign CMS, webOS6.0
LongSummaryDescription - LG 75UH5J-M. Product design: Digital signage flat panel. Display diagonal: 190.5 cm (75"), Display technology: LCD, Display resolution: 3840 x 2160 pixels, Display brightness: 500 cd/m², HD type: 4K Ultra HD. Wi-Fi. Operating hours (hours/days): 24/7. Operating system installed: WebOS. Product colour: Black
Matrix type - TFT IPS
Model - 75UH5J-M
name - LG 75UH5J-M UHD IPS 75' 500cd/m2 24/7
Name - LG | 75UH5J-M | 75 " | Landscape/Portrait | 24/7 | WebOS | 500 cd/m² | 6 ms | 178 ° | 178 °
Native resolution - 3840x2160/3840x2160
Number of colors - 1,07 mld
Operational conditions - Operating relative humidity (H-H) - 10 - 80%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions > Operating temperature (T-T) - 0/40 °C
Operation time hours/day - 24/7
Optional accessory - OPS kit (KT-OPSF), LSW640A/B (wall mounting)
Other features -
Other features - Audio output - 1
Other features - Plug and Play - Yes
Other features - Power consumption (PowerSave) - 120 W
Other features > Signage product family - Digital Signage
Package features > Embeeded battery - No
Package features > Gross depth (mm) - 57.90 mm
Package features > Gross height (mm) - 960.30 mm
Package features > Gross width (mm) - 1682.40 mm
Package features > Packing quantity - 1.00 pc(s)
Package features > Palette Qty - 10 pc(s)
Package features > Paper/Pasteboard - 7760.00 g
Package features > Plastic (No PET) - 1940.00 g
Package features > Tare weight (kg) - 9.70 kg
Package features > Volume (m3) - 0.09 m³
Package features > WEE classification - CL109:2:2017-04-01
Package features > WEEE tax - Yes
Packaging content - Batteries included - Yes
Packaging content - Cables included - AC
Packaging content - Remote control included - Yes
Packaging data - Package depth - 228 mm
Packaging data - Package height - 1123 mm
Packaging data - Package weight - 51.2 kg
Packaging data - Package width - 1816 mm
PDF - https://www.blobs.lt/products/5/4/0/6/0/4/100c51a23fcbd873b9390b89b0ba86c5/original.pdf
Performance - Automatic brightness control - Yes
Performance - HDCP - Yes
Performance - HDCP version - 1.4/2.2/2.3
Performance - On Screen Display (OSD) - Yes
Performance - Open Pluggable Specification (OPS) - Yes
Performance - Operating hours (hours/days) - 24/7
Performance - Picture-in-Picture - Yes
Performance - Purpose - Universal
Ports & interfaces - DisplayPorts quantity - 1
Ports & interfaces - DVI port - No
Ports & interfaces - Ethernet LAN - Yes
Ports & interfaces - Ethernet LAN (RJ-45) ports - 1
Ports & interfaces - HDMI input ports quantity - 3
Ports & interfaces - HDMI output ports quantity - 1
Ports & interfaces - HDMI ports quantity - 4
Ports & interfaces - Remote (IR) input - 1
Ports & interfaces - RS-232C - Yes
Ports & interfaces - USB connector type - USB Type-A
Ports & interfaces - USB port - Yes
Ports & interfaces - USB ports quantity - 1
Ports & interfaces - USB version - 2.0
Ports & interfaces - Wi-Fi - Yes
Ports & interfaces > Device connectivity - Input: HDMI (3 (HDMI1/2 : HDCP 2.2/1.4, HDMI3 : HDCP 1.4)), DP (HDCP 2.2/1.3), DVI-D (HDCP 1.4), Audio In, RS-232C In (4 Pin Phone-jack), RJ45 (LAN), IR In, USB 2.0 (Type A)
Power - AC input frequency - 50-60 Hz
Power - AC input voltage - 100-240 V
Power - Power consumption (max) - 230 W
Power - Power consumption (standby) - 0.5 W
Power - Power consumption (typical) - 170 W
Power consumption - 260 W
Power supply - Inbuilt/Inbuilt
producer - LG Electronics
Producer product name - 75UH5J-M
ProductName - 75UH5J-M
Refresh rate - 120 Hz
Refresh rate - 120Hz
Resolution - 3840 x 2160
Response time - 6 ms
Response time - 6/6 ms
RJ45 Input/Output connectors - 1/1
RS232 Input/Output connectors - 2/2
Screen form factor - 16:9
Screen size - 75"
Screen size (diag.) - 75''
Shipping Box Depth Shipping/Package Box Dimensions - 182/182 cm
Shipping Box Height Shipping/Package Box Dimensions - 112/112 cm
Shipping box quantity - 1
Shipping Box Weight Shipping/Package Box Dimensions - 51.2/51.2 kg
Shipping Box Width Shipping/Package Box Dimensions - 23/23 cm
ShortSummaryDescription - LG 75UH5J-M, Digital signage flat panel, 190.5 cm (75"), LCD, 3840 x 2160 pixels, Wi-Fi, 24/7
Software > Operating system - WebOS
Software > Operating system version - 6.0
Speakers - Yes/Yes
Speakers built-in - Yes
Static contrast - 1 100:1
Technical details - Real Time Clock (RTC) - Yes
Technical details > Bezel width - 14.9 mm
Technical details > Brightness - 500 cd/m²
Technical details > Diagonal - 75 "
Technical details > Dimensions (WxDxH) - 1682.4 × 57.9 × 960.3 mm
Technical details > Gross weight - 51.20 kg
Technical details > Net weight - 41.50 kg
Technical details > Operating hours/days - 24/7
Technical details > Producer - LG
Title - LG 75UH5J-M Digital signage flat panel 190.5 cm (75") LCD Wi-Fi 500 cd/m² 4K Ultra HD Black WebOS 24/7
TV tuner built-in - No
Unit Box Height - 1.12
Unit Box Length - 1.82
Unit Box Width - 0.23
Unit Brutto Volume - 0.4688/0.4688 cubm
Unit Gross Weight - 51.2/51.2 kg
Unit Net Weight - 41.5/41.5 kg
URL - https://www.lg-informationdisplay.com/product/digital-signage/standard/75UH5J-M
USB 2.0 Input/Output connectors - 1/1
Vendor Homepage - www.lg.com/global/business/digital-signage/lg-75uh5j-m
vendpn - 75UH5J-M
VESA - 600 x 400
Viewing angle, horizontal - 178 °
Viewing angle, vertical - 178 °
Viewing angle horizontal - 178/178 degrees
Viewing angle vertical - 178/178 degrees
Warranty -
Warranty - 36
Warranty - 36 month(s)
Warranty - 36 months
WarrantyInfo -
Web camera - None
Weight - 41.5 kg
Weight & dimensions - Display depth - 57.9 mm
Weight & dimensions - Display height - 960.3 mm
Weight & dimensions - Display weight - 41.5 kg
Weight & dimensions - Display width - 1682.4 mm
Width - 1682.4 mm
Width Unit Dimensions - 1682.4 mm
WiFi - No
