Accessories included - Avtek DS 55 information monitor (Monitor + holder) CMS - license for the Avtek DS content management system HDMI cable Power cable Remote Quick start guide
Aspect ratio - 16:9
Auto Pivot - No
Bluetooth - No
Brightness - 450 cd/m²
Certificates - CE
Color - Black
Depth - 71.4 mm
Description - Innovative design. Wide possibilities. Avant-garde technology. - ANDROID 11 The Avtek DS monitor is a combination of advanced technology and elegant design, created especially for demanding information applications. With excellent image quality, a slim profile and advanced features, Avtek DS raises the standards of information displays to a whole new level. Whether you need a monitor for digital signage or conference rooms, Avtek DS will meet your expectations. Available in a variety of sizes, from a compact 43-inch model to an impressive 98-inch screen, Avtek DS monitors deliver rich and vivid images that capture attention and engage the viewer. The design of Avtek DS monitors is a perfect combination of aesthetics and functionality. Their slim and elegant profiles make them a perfect complement to any interior, regardless of whether they are used in commercial spaces or at home. Minimalist frames, even on each side, subtly blend into the image, allowing you to focus on the displayed content. Additionally, the matte finish of the matrices minimizes light reflections, ensuring excellent image readability even in brightly lit rooms. The design of Avtek DS monitors not only attracts attention, but also emphasizes their functionality and professionalism. One of the innovative elements of Avtek DS monitors is the built-in infrared sensor, which is located directly under the matrix. This technologically advanced sensor eliminates the need for additional external infrared sensors that often protrude or disrupt the aesthetics of the monitor. In practice, this means that we can precisely control the monitor using the remote control, aiming directly at the matrix. The USB-C connector in the Avtek DS monitor is also a convenient solution for professionals who want to connect their laptop or computer directly to the monitor, using one cable to transmit data, image and power. The Avtek DS monitor offers advanced scheduling features that allow you to precisely schedule your monitor to turn on and off and manage content at specific times. Thanks to this, the user can configure monitor operation schedules, specifying the start and end times of operation and selecting specific content to play on specific days and times. This functionality eliminates the need to manually turn the monitor on and off and manually select content. The Avtek DS monitor enables wireless screen sharing from various devices, opening up new possibilities for presenting and sharing content. Thanks to technologies such as AirPlay, Miracast and Chromecast, we can easily and quickly transmit image and sound from mobile devices, laptops or computers directly to the monitor screen. And thanks to the Bytello Share application, it is also possible to share content remotely via a QR code, which means that we can send content directly from our smartphone by scanning the QR code and selecting the content to be displayed on the monitor screen. The Avtek DS monitor has an advanced CMS (Content Management System) application, enabling remote management of content on monitors. With the CMS application, after configuring the CMS server, users can easily share content, manage schedules, group monitors, and create and edit content using an intuitive interface. The application also allows you to store materials on the server and divide users in the organization. Thanks to the Bytello DMS (Device Management System) application, users can remotely manage the monitors themselves. DMS allows you to update firmware, manage installed applications, trigger alarms on monitors, change monitor inputs and many other functions. Thanks to this, users can easily maintain and update the monitor software, adapting it to their needs. The Bytello DMS application is a reliable tool for the effective management and maintenance of Avtek DS monitors. (Bytello DMS is an additionally paid service) Avtek DS monitors offer a slot for a WiFi/Bluetooth module, which is available as an optional accessory. The user can purchase this module to expand the functionality of the monitor with WiFi and Bluetooth wireless connectivity - available under the index: TLAVTLMODWIFIBT Working time: 18/7 RAM: 4GB ROM: 32GB Speakers: 2x10w Android 11 Haze: 25% Frame thickness: (g/l/p/d) mm 9.9/9.9/9.9/9.9 Vesa 400x200 mm CMS SOFTWARE AVAILABLE AT THE LINK: https://vidissa.sharepoint.com/sites/AVTEK/DOWNLOAD/Forms/AllItems.aspx?id=%2Fsites%2FAVTEK%2FDOWNLOAD%2FFILES%2FSoftware%2FAvtek%20CMS%2FAvtek%20CMS%2Ezip&parent=%2Fsites%2FAVTEK% 2FDOWNLOAD%2FFILES%2FSoftware%2FAvtek%20CMS&p=true&ga=1 CMS Tutorial - (801) Avtek CMS - Tutorial - YouTube
dimension depth - 155 mm
dimension height - 815 mm
dimension weight - 21000 g
dimension width - 1320 mm
Display surface - Matt
ean - 5907731319003
guarantee - 36
guarantee_type - external
Height - 1233 mm
Height adjustment - No
I/O connectors - 1 x 3,5 mm minijack
I/O connectors - 1 x RJ-45 LAN
I/O connectors - 1 x RS-232 (COM)
I/O connectors - 1 x SPDIF out
I/O connectors - 1 x USB (Type C)
I/O connectors - 1 x USB 2.0
I/O connectors - 1 x USB 3.2 Type-A Gen 1
I/O connectors - 2 x HDMI
Matrix type - VA
Model - DS 55
name - Information monitor DS 55 inch - 18/7 2x10W Android 11.0
Number of colors - 1,07 mld
Optional accessory - WiFi/BT module
Other features - Airplay Chromecast Miracast, Screenshare Launch schedule Content schedule Remote content management Remote monitor management PIP, PBP, automatic image rotation
producer - Avtek
Refresh rate - 60 Hz
Resolution - 3840 x 2160
Response time - 6.5 ms
Screen size (diag.) - 55"
Speakers built-in - Yes
Static contrast - 4 000:1
TV tuner built-in - No
vendpn - 1TV313
Viewing angle, horizontal - 178 °
Viewing angle, vertical - 178 °
Warranty - 3 years (door-to-door)
Web camera - None
Weight - 13.4 kg
Width - 703.5 mm
WiFi - No
