Satel POWER SUPPLY 12VDC 4A DIN/APS-412

Accessories included -
Category Code - SPS
Description - Switching-mode buffer power supply APS-412 Switching-mode power supply intended for supplying power to 12 V devices. It is equipped with a dedicated connector for cooperation with SATEL devices. The design enables convenient mounting in housings from the SATEL offer or on a DIN rail. Compliant with EN50131-6 Grade 2 requirements. Switching-mode 12 V DC power supply with high efficiency, requiring no mains transformer. Total current capacity of the power supply: 4 A Short-circuit and overload protection Lead gel battery can be connected Selectable battery charging current Battery charging circuit with current regulation Full battery discharge protection 3 OC fault outputs Optical indication of mains, battery and overload status Acoustic fault indication Dedicated connector for cooperation with new SATEL modules Designed for mounting on DIN 35 mm rail and in OPU-3 P, OPU-4 P and OPU-4 PW enclosures
Description - The switching mode power supply designed to power 12 V devices. It is equipped with a dedicated connector for use with SATEL devices. Its design enables it to be easily installed in the SATEL offered enclosure or on the DIN rail. - EN50131-6 Grade 2 compliant - high efficiency 12 V DC switching mode power supply, requiring no mains transformer - 4 A total output current - short circuit and overload protection - designed for use with sealed lead-acid batteries - optionally selected battery charging current - battery deep discharge protection - 3 OC outputs for trouble indication - optical indication of mains, battery and overload status - audible trouble signal - dedicated connector for use with new SATEL modules - DIN 35 mm rail mountable
Design - Form factor - Compact
Design - Product colour - Grey
dimensionalWeight - 256
dimension depth - 75 mm
dimension height - 100 mm
Dimensions - Housing: 77 x 122 x 59 mm
dimension weight - 420 g
dimension width - 165 mm
ean - 5905033332584
Features - Input operation voltage (min) - 10.5 V
Features - Maximum current - 4 A
Features - Output operation voltage (max) - 12 V
Features - Power protection features - Overload
guarantee - 24
guarantee_type - normal
name - Buffer power supply APS-412
Operational conditions - Operating temperature (T-T) - -10 - 55 °C
Other features - Environmental class: II Power supply type: A Operating temperature range -10...+55 °C Supply voltage: 230 V AC Battery fault notification voltage: (10%) 11,5 [V] Battery cut-off voltage: (10%) 10,5 [V] Rated output voltage: 12 [V DC]. Current capacity: 4[A] Battery charging current (switchable): 0.5 A / 1 A Current-carrying capacity of outputs: WS, WB, WP (OC type): 50 [mA]. Current consumption of power supply circuits: 57 [mA].
producer - Satel
producerCode - APS-412
productName - SATEL APS-412 Buffer power supply (12V)
productSize - Normal
Shipping Box Depth Shipping/Package Box Dimensions - 14.5 cm
Shipping Box Height Shipping/Package Box Dimensions - 6.5 cm
Shipping box quantity - 1
Shipping Box Weight Shipping/Package Box Dimensions - 0.368 kg
Shipping Box Width Shipping/Package Box Dimensions - 9.5 cm
sizeX - 160
sizeY - 80
sizeZ - 100
Unit Box Height - 0.065
Unit Box Length - 0.145
Unit Box Width - 0.095
Unit Brutto Volume - 0.0008954 cubm
Unit Gross Weight - 0.368 kg
Unit Net Weight - 0.306 kg
Vendor Homepage - http://www.satel.pl/en/produktid/477
vendpn - APS-412
Warranty - 36 months
warrantyLength - 24
warrantyType - G
Weight - 306 g
weight - 410
Weight & dimensions - Depth - 59 mm
Weight & dimensions - Height - 122 mm
Weight & dimensions - Weight - 306 g
Weight & dimensions - Width - 77 mm
