ID: 1050283
Product code: IPC-HFW5442E-ZE-2712-S3-B
In stock 24 units
Warranty: 3 years
Dahua HFW5442E-ZE-2712-S3-B, 1520p, 4MP, White
Picture may differ from actual product, there can be accessories and parts not supplied with the actual product.
All parameters
Aperture
: F1.6
Atmiņas kartes ligzda
: microSD
Colour
: Melna
Encoding
: H.264, H.265
Feeding
: 12V adapteris, PoE
FPS at maximum resolution
: 30
Microphone
: Ir
Network connections
: Ir, Nav
Number of cameras per set
: 1
Operating temperature MAX (°C)
: 60
Operating temperature MIN (°C)
: -30
Resolution
: 2688x1520
SIM card socket
: Nav
Use
: Indoor/Outdoor
Viewing angle
: 115°
Water resistance
: IP67
Weight (g)
: 1120
More detailed specification
Alarm In Input/Output connectors - 2
Alarm Out Input/Output connectors - 1
Audio-In Input/Output connectors - 1
Audio-Out Input/Output connectors - 1
Camera design - Bullet
Category Code - FNC
Colour - Black
Description - 1/1.8” 4 Megapixel progressive scan CMOS, 2688 × 1520 @30FPS Minimum illumination: 0.0007 lux @ F1.6 (Color, 30 IRE); 0.0004 lux @ F1.6 (B/W, 30 IRE); 0 lux (Illuminator on) True Day/Night with ICR Filter, BLC / HLC / True WDR (140dB), 3D DNR, Defog 2.7-12 mm varifocal lens (115°–47°) Up to 60 meters Smart IR Illumination H.265; H.264; H.264H; H.264B; MJPEG, ONVIF (Profile S/Profile G/Profile T); CGI Built-in MIC, Micro SD: Max 512GB, 1/1 Audio I/O, 2/1 Alarm I/O With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc. Bullet design, metal shell, IP67, IK10, -30°C~+60°C Power ePoE / PoE / 12VDC power, 9.8W max Free IP monitoring software available
Dimensions - 273.2 × 95.0 × 95.0 mm
Effective pixels - 2688 (H) × 1520 (V)
Electronic Shutter Speed - Auto/Manual 1/3 s–1/100,000 s
Environment - Outdoor
Focal Length - 2.7-12 mm
Full Description Line - Type HDTV/Megapixel/Outdoor|Pixel Resolution 4 Mega Pixel|Focal Length 2.7-12 mm|IR Illumination|Sensor size 1/1.8"|Microphone Built-in|Lens Mount M14|Min. Illumination 0.0007 Lux|Effective pixels 2688 (H) × 1520 (V)|Electronic Shutter Speed Auto/Manual 1/3 s–1/100,000 s|1xAudio-In|1xAudio-Out|1xRJ45|2xAlarm In|1xAlarm Out|Supports card capacities up to 512GB|Power options PoE/12V|Power supply requirements 12 VDC/PoE (802.3af)/ePoE|Environment Outdoor|Operating temperature range -30°C~+60°C|Colour Black|Dimensions 273.2 × 95.0 × 95.0 mm
IR Illumination - Yes
Lens Mount - M14
Microphone - Built-in
Min. Illumination - 0.0007 Lux
Model - IPC-HFW5442E-ZE-2712-S3-B
Network Camera Type - HDTV/Megapixel/Outdoor
Operating temperature range - -30°C~+60°C
Pixel Resolution - 4 Mega Pixel
Power consumption - 4.9 Watts
Power options - 12V/PoE
Power supply requirements - 12 VDC/PoE (802.3af)/ePoE
RJ45 Input/Output connectors - 1
Sensor size - 1/1.8"
Shipping Box Depth Shipping/Package Box Dimensions - 36.8 cm
Shipping Box Height Shipping/Package Box Dimensions - 14 cm
Shipping box quantity - 1
Shipping Box Weight Shipping/Package Box Dimensions - 1.6 kg
Shipping Box Width Shipping/Package Box Dimensions - 15 cm
Supports card capacities up to - 512GB
Unit Box Height - 0.14
Unit Box Length - 0.368
Unit Box Width - 0.15
Unit Brutto Volume - 0.007728 cubm
Unit Gross Weight - 1.6 kg
Unit Net Weight - 1.12 kg
Vendor Homepage - www.dahuasecurity.com/ceen/products/All-Products/Network-Cameras/WizMind-S-Series/4MP/IPC-HFW5442E-ZE-S3=S3
Warranty - 36 months
Alarm Out Input/Output connectors - 1
Audio-In Input/Output connectors - 1
Audio-Out Input/Output connectors - 1
Camera design - Bullet
Category Code - FNC
Colour - Black
Description - 1/1.8” 4 Megapixel progressive scan CMOS, 2688 × 1520 @30FPS Minimum illumination: 0.0007 lux @ F1.6 (Color, 30 IRE); 0.0004 lux @ F1.6 (B/W, 30 IRE); 0 lux (Illuminator on) True Day/Night with ICR Filter, BLC / HLC / True WDR (140dB), 3D DNR, Defog 2.7-12 mm varifocal lens (115°–47°) Up to 60 meters Smart IR Illumination H.265; H.264; H.264H; H.264B; MJPEG, ONVIF (Profile S/Profile G/Profile T); CGI Built-in MIC, Micro SD: Max 512GB, 1/1 Audio I/O, 2/1 Alarm I/O With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc. Bullet design, metal shell, IP67, IK10, -30°C~+60°C Power ePoE / PoE / 12VDC power, 9.8W max Free IP monitoring software available
Dimensions - 273.2 × 95.0 × 95.0 mm
Effective pixels - 2688 (H) × 1520 (V)
Electronic Shutter Speed - Auto/Manual 1/3 s–1/100,000 s
Environment - Outdoor
Focal Length - 2.7-12 mm
Full Description Line - Type HDTV/Megapixel/Outdoor|Pixel Resolution 4 Mega Pixel|Focal Length 2.7-12 mm|IR Illumination|Sensor size 1/1.8"|Microphone Built-in|Lens Mount M14|Min. Illumination 0.0007 Lux|Effective pixels 2688 (H) × 1520 (V)|Electronic Shutter Speed Auto/Manual 1/3 s–1/100,000 s|1xAudio-In|1xAudio-Out|1xRJ45|2xAlarm In|1xAlarm Out|Supports card capacities up to 512GB|Power options PoE/12V|Power supply requirements 12 VDC/PoE (802.3af)/ePoE|Environment Outdoor|Operating temperature range -30°C~+60°C|Colour Black|Dimensions 273.2 × 95.0 × 95.0 mm
IR Illumination - Yes
Lens Mount - M14
Microphone - Built-in
Min. Illumination - 0.0007 Lux
Model - IPC-HFW5442E-ZE-2712-S3-B
Network Camera Type - HDTV/Megapixel/Outdoor
Operating temperature range - -30°C~+60°C
Pixel Resolution - 4 Mega Pixel
Power consumption - 4.9 Watts
Power options - 12V/PoE
Power supply requirements - 12 VDC/PoE (802.3af)/ePoE
RJ45 Input/Output connectors - 1
Sensor size - 1/1.8"
Shipping Box Depth Shipping/Package Box Dimensions - 36.8 cm
Shipping Box Height Shipping/Package Box Dimensions - 14 cm
Shipping box quantity - 1
Shipping Box Weight Shipping/Package Box Dimensions - 1.6 kg
Shipping Box Width Shipping/Package Box Dimensions - 15 cm
Supports card capacities up to - 512GB
Unit Box Height - 0.14
Unit Box Length - 0.368
Unit Box Width - 0.15
Unit Brutto Volume - 0.007728 cubm
Unit Gross Weight - 1.6 kg
Unit Net Weight - 1.12 kg
Vendor Homepage - www.dahuasecurity.com/ceen/products/All-Products/Network-Cameras/WizMind-S-Series/4MP/IPC-HFW5442E-ZE-S3=S3
Warranty - 36 months
