Cudy GS1005P 5xGE 4xPoE+

Picture may differ from actual product, there can be accessories and parts not supplied with the actual product.
ID: 974010 Product code: GS1005P
Can be ordered 54 units Availability: 14 days after order approval
Warranty: 2 years (Warranty for business entities 1 year)
44.74 €
Delivery options
  • Delivery to Smartpost 1.99 €: 17.04.2025
  • Delivery to Omniva parcel locker 1.99 €: 17.04.2025
  • Courier delivery 3.99 €: 17.04.2025
Main product parameters All parameters
  • Base-T speed: 10/100/1000
  • RJ-45 Ports: 5
Ports and equipment
Base-T speed : 10/100/1000
PoE Ports : 4
RJ-45 Ports : 5
SFP Ports : N/A
Specifikācija
Number of fans : Fanless
PoE Per-Port Power Budget : 30 W
PoE Support : Ir
PoE Total Power Budget : 60 W
Weight (g) : 260 g
Network cards
More detailed specification
10/100/1000/2500 Mbps ports - None
Accessories included -
Application - Home and small office
Category - Root/Electronics/Networks and communication/Switchers
Category 1 - Netzwerk
Category 2 - Switching Hubs
Chassis type - Desktop
Console port - No
Description - GS1005P 5-port gigabit POE+ switch Compliant with IEEE802.3, IEEE 802.3u, IEEE 802.3ab, IEEE802.3af, IEEE802.3at It has 5 10/100/1000Base-TX ports Total PoE power output 60W 10Gbps high throughput IEEE802.3x flow control EMI standards compliant with FCC, CE class B
Designation - CE+WEEE
dimension depth - 175 mm
dimension height - 180 mm
Dimensions - 119 x 85 x 28 mm
dimension weight - 740 g
dimension width - 80 mm
ean - 6971690790998
EAN - 6971690790998
Eans - 6971690790998
Environment requirements - Working Temperature: 0~40C Storage Temperature: -40~70C Humidity: 0~90% Non-condensing
Fan - No
guarantee - 24
guarantee_type - normal
L2 features -
L3 features -
MAC address table size - 2000
Management, monitoring, configuration -
Manufacturer - Cudy
MPN - GS1005P
Name - 5P Cudy GS1005P PoE+
Name - Cudy GS1005P
name - Switch GS1005P 5xGE (4xPoE+) 60W
Network architecture - GigabitEthernet
Number of 10/100 Mbps ports - None
Number of 10/100/1000 Mbps ports - 5
Number of 10Gb ports - None
Number of COMBO ports - None
Number of PoE+ ports - None
Number of PoE ports (PoE & PoE+) - 4
Number of QSFP+ ports - None
Number of SFP+ ports - None
Number of SFP56 ports - None
Number of SFP ports - None
Other features - Transmission speed: 14,880pps for 10Mbps 148,800pps for 100Mbps 1,488,000pps for 1000Mbps
Other functions -
Power consumption - 60 W
Power supply - External power supply: DC 48~57V Switch consumption: < 5W PoE budget: 60W
Power supply - External
producer - Cudy
Producer - Cudy
ProducerCode - GS1005P
QoS -
Security -
ShortDescription -
Stackability - No
Supported protocols and standards - IEEE 802.3 IEEE 802.3u IEEE 802.3ab IEEE 802.3af/at
Support for Jumbo frames - No
Switch class - Unmanaged
Throughput - 10 Gb/s
vendpn - GS1005P
VLAN -
Weight - 0.86
44.74 €
Cudy GS1005P 5xGE 4xPoE+
