10/100/1000/2500 Mbps ports - None
Accessories included -
Application - Medium and large companies
ARTIKEL1 - 28-PORT SMART POE SWITCH
ARTIKEL2 - GIGABIT STACKABLE 4X SFP+
Brand - D-Link
BrandPartCode - DGS-1510-28XMP/E
Breite - 0.45
Category - Network Switches
Category_1 - Network and Servers
Category_2 - Network - Switches and Hubs
Certificates - CE FCC C-Tick VCCI BSMI CCC IPv6 Ready Logo Phase 2 cUL CB
Chassis type - Rack
Console port - Yes
Data transmission - Jumbo frames - 9216
Data transmission - Jumbo frames support - Yes
Data transmission - MAC address table - 16384 entries
Data transmission - Number of queues - 8
Data transmission - Packet buffer memory - 1.5 MB
Data transmission - Store-and-forward - Yes
Data transmission - Switching capacity - 128 Gbit/s
Data transmission - Throughput - 95.24 Mpps
Description - DGS-1510 Series Gigabit Stackable Managed Smart Switches L2 management and security with L3 features CLI command line, console port and Web GUI 10G SFP+ physical stackable Static and MSTP routes PoE (Power over Ethernet) option Lifetime-Limited warranty upon registration CLI command line Supports a standard and commonly used command line interface for system management. Physical racking Physical stacking of up to 6 units in a stack with a total of 288 ports. 10G uplink ports With SFP+ ports, you can connect to other areas of the network with 10G throughput. Static routing Segregation of L3 traffic between switches, regardless of VLAN segemntation. Multiple images and confusion files Firmware updates and configuration testing without any risk of losing settings. Limited Lifetime Warranty Register your product to benefit from the Lifetime Limited Warranty. A large PoE power budget and extensive Layer 2 features make the DGS-1510 family switches a flexible and cost-effective solution for expanding any corporate network. The DGS1510 series is the latest generation of managed Smart switches with 10G SFP+ fibre ports for physical stacking or uplinks. The combination of high throughput, industry-standard CLI console compliance and the ability to use PoE makes the DGS1510 switch series an ideal solution for SMBs as well as enterprise environments. Full feature set with L3 traffic management The DGS1510 switch series features advanced network management tools via an industry-standard CLI console, console serial port and the GUI browser-based user interface. This provides your business with VLAN, multiple spanning tree protocol (MSTP), link aggregation (LACP), static routes, multiple firmware images and multiple configuration files. With powerful security features in the form of IGMP snooping, access control lists, port security tools and the D-Link Safeguard Engine, which protects the network from malicious denial-of-service attacks from broadcast, multicast and unicast flooding, the DGS-1510 switch family is a versatile tool for networked enterprise environments. Fibre optic Uplink ports Network expansion to suit the needs of any business is possible with fibre uplink ports with advanced management and security features. D-View 7: free network design and management system D-Link's free Network Assistant (DNA) system provides information on all connected devices and speeds up initial configuration. The free D-View 7 network management system comes with a licence for 25 nodes and 2 probes and full access to management tools. An optional licence upgrade allows for expanded network and analysis capabilities. Energy saving D-Link's DGS-1510 family of switches with D-Link Green technology enables energy savings without affecting operational performance or functionality.
Design - LED indicators - Activity, Link, PoE, Power, Speed
Design - Number of fans - 2 fan(s)
Design - Product colour - Black, Grey
Design - Rack mounting - Yes
Design - Safety - cUL, CB
Design - Stackable - Yes
Designation - CE+WEEE
dimension depth - 110 mm
dimension height - 450 mm
Dimensions - 440 x 308 x 44 mm
dimension weight - 5000 g
dimension width - 500 mm
ean - 790069467943
EAN - 0790069467943
EANCode - 0790069467943
EAN_code - 0790069467943
Environment requirements - Operating temperature: -5 to 50 C (23 to 122 F) Storage temperature: -20 to 70C (-4 to 158F) Operating humidity: 0% to 95% non-condensing Storage humidity: 0% to 95% non-condensing
Fan - Yes
Forwarding mode - Store-and-forward
Forwarding rate - 95.24 Mpps
Gewicht - 6.02
Gross Weight Kg - 6,52
GRUPPE1 - Network
GRUPPE2 - Switches Managed
GTIN - 790069467943
GTIN - 0790069467943
guarantee - 0
guarantee_type - perpetual
HERSTELLER - D-LINK
Hoehe - 0.12
HSTNUMMER - DGS-1510-28XMP/E
Jumbo frame size - 9.216 KB
L2 features - MAC Address Table: Up to 16,384 Flow Control 802.3x Flow Control HOL Blocking Prevention Jumbo Frame up to 9,216 Bytes IGMP Snooping IGMP v1/v2 Snooping IGMP v3 awareness Supports 512 IGMP groups Supports 128 static multicast addresses IGMP per VLAN Supports IGMP Snooping Querier Host-based IGMP Snooping Fast Leave MLD Snooping Supports MLD v1/v2 Supports 512 groups Supports 128 Static Multicast Addresses Per VLAN MLD Snooping Host-based MLD Fast Leave MLD Snooping Querier Spanning Tree Protocol 802.1D STP 802.1w RSTP 802.1s MSTP Loopback Detection v4.07 802.3ad Link Aggregation Max. 32 groups per device/8 ports per group Port Mirroring Support 4 mirroring groups One-to-One, Many-to-One Supports Mirroring for Tx/Rx/Both Multicast Filtering Forwards all unregistered groups Filters all unregistered groups Ethernet Ring Protection Switching (ERPS)
L3 features - ARP 256 Static ARP Supports Gratuitous ARP IPv6 Neighbour Discovery (ND) 16 IP interfaces Default Routing Static Routing 64 IPv4 Static Route Entries 32 IPv6 Static Route Entries UDP helper
Laenge - 0.52
Logistics data - Harmonized System (HS) code - 85176990
LongDesc - Industry Standard CLI with 10G SFP+ stackingThe D-Link DGS-1510 Series is the latest generation of Smart Managed switches with 10G SFP+ fibre ports for physical stacking or uplinks. The combination of high bandwidth connections, an Industry Standard CLI, and PoE options make the DGS-1510 Series ideal for Small-Medium Enterprise environments.Fully‑Featured with Layer 3 Traffic ManagementThe DGS-1510 family has advanced network management options, accessible via Industry Standard CLI, Serial Port Console or the Web-based UI, that equip your business with network capabilities such as VLANs, multiple spanning tree protocol (MSTP), link aggregation (LACP), static routing, multiple firmware images,and multiple configuration files.10G SFP+ StackingCreate a physical stack of up to 6 units in a fault‑tolerant ring or linear topology using Direct Attach Cables or any compatible SFP+ transceivers for a total of 288 Gigabit ports. The remaining uplink ports can be used for other functions, offering 10G connectivity to core networks and servers.1With powerful security features like IGMP snooping, access control lists, port security, and the unique D-Link Safeguard Engine that protects your network against malicious denial-of-service attacks from broadcast, multicast and unicast flooding, the DGS-1510 family is a versatile solution for enterprise network environments.Max PoE with budgets up to 740W2Choose between 193W and 370W power budget options. Or utilise a total of 740W when adding a redundant power supply to the DGS-1510-52XMP.Powerful Network Design and Management SoftwareThe DGS-1510 Series supports D-View 8, an intelligent management platform that allows for centralized management of the core network. This extensive toolset enables administrators to easily set up and remotely manage their networks, greatly reducing switch deployment time.Smart Energy‑Saving DesignD-Link Green technology enables the DGS-1510 series to save power without sacrificing performance. The entire series of switches feature a smart fan that adjusts fan-speed and only powers on above a certain temperature. With advanced silicon technology, the DGS-1510 series saves up to 73% of energy compared to normal switches.
LongProductName - 24 x 10/100/1000 RJ-45, 4 x 10G SFP+, PoE, 128 Gbps, 95.24 Mpps, 440 x 308.5 x 44 mm, 4.25 kg
LongSummaryDescription - D-Link DGS-1510-28XMP. Switch type: Managed, Switch layer: L2/L3. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 24. Full duplex. MAC address table: 16384 entries, Switching capacity: 128 Gbit/s. Networking standards: IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE.... Power over Ethernet (PoE). Rack mounting
MAC address table size - 16384
Management, monitoring, configuration - Command Line Interface (CLI) Telnet Server TFTP Client IPv6 Neighbor Discovery Configurable MDI/MDIX SNMP Supports v1, v2c, v3 SNMP Trap System Log Max. 10,000 log entries Debug command Multiple images DHCP Server DHCP Client Surveillance mode DHCP Client D-Link Network Assistant support SNTP ICMPv6 IPv4/v6 Dual Stack DHCP Auto Configuration RMON v1 LLDP, LLDP-MED DHCP relay Web-based GUI NTP Telnet client (supports CLI only) PD-Alive (PoE models only)
Management features - Quality of Service (QoS) support - Yes
Management features - Switch layer - L2/L3
Management features - Switch type - Managed
Management features - System event log - Yes
Management features - Traffic classification - Yes
Manufacturer - D-Link
Manufacturer Code - DGS-1510-28XMP/E
Manufacturer Name - D-Link
Manufacturer_code - DGS-1510-28XMP/E
Maximum number of units per stack - 6
Mean time between failures (MTBF) - 274796 h
Memory buffer - 1.5 MB
Multicast features - Multicast support - Yes
Name - D-Link DGS-1510-28XMP/E, Switch
name - Switch DGS-1510-28XMP 24GE PoE+ 4SFP+
Network - 10G support - Yes
Network - Auto-negotiation - Yes
Network - Auto MDI/MDI-X - Yes
Network - Broadcast storm control - Yes
Network - Cable types supported - Cat5, Cat5e
Network - Copper ethernet cabling technology - 10BASE-T, 100BASE-TX, 1000BASE-T
Network - Flow control support - Yes
Network - Full duplex - Yes
Network - Head-of-line (HOL) blocking - Yes
Network - Link aggregation - Yes
Network - MAC address auto-learning supported - Yes
Network - Networking standards - IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3at, IEEE 802.3x
Network - Number of VLANs - 4094
Network - Port mirroring - Yes
Network - Spanning tree protocol - Yes
Network - Virtual LAN features - Tagged VLAN, Protocol-based VLAN
Network - VLAN support - Yes
Network architecture - GigabitEthernet
Number of 10/100 Mbps ports - None
Number of 10/100/1000 Mbps ports - 24
Number of 10Gb ports - 4
Number of COMBO ports - None
Number of PoE+ ports - None
Number of PoE ports (PoE & PoE+) - 24
Number of QSFP+ ports - None
Number of SFP+ ports - 4
Number of SFP ports - None
Number of VLAN groups - 4000
Operational conditions - Heat dissipation - 1487.78 BTU/h
Operational conditions - Operating relative humidity (H-H) - 0 - 95%
Operational conditions - Operating temperature (T-T) - -5 - 50 °C
Operational conditions - Storage relative humidity (H-H) - 0 - 95%
Operational conditions - Storage temperature (T-T) - -20 - 70 °C
Other features - PoE standard: IEEE 802.3af, 802.3at PoE ports: 1 - 24: up to 30 W Maximum PoE budget: 370 W
Other functions - Virtual Stacking Support: D-Link Single IP Management Up to 32 devices per virtual stack Up to 20G stacking bandwidth Physical Stacking: Supports Duplex Chain/Ring topology Up to 40G stacking bandwidth full duplex Up to 6 units per stack
Packaging data - Package depth - 510 mm
Packaging data - Package height - 121 mm
Packaging data - Package weight - 7.06 kg
Packaging data - Package width - 450 mm
Performance - Built-in processor - Yes
Performance - Flash memory - 32 MB
Performance - Internal memory - 256 MB
Performance - Mean time between failures (MTBF) - 274796 h
Performance - Processor frequency - 400 MHz
Ports & interfaces - Basic switching RJ-45 Ethernet ports quantity - 24
Ports & interfaces - Basic switching RJ-45 Ethernet ports type - Gigabit Ethernet (10/100/1000)
Ports & interfaces - Fiber optic connector - SFP+
Ports & interfaces - SFP+ module slots quantity - 4
Power - AC input voltage - 100 - 240 V
Power - Power consumption (max) - 436.3 W
Power - Power source - AC
Power - Power supply included - Yes
Power consumption - 436.3 W
Power over Ethernet (PoE) - Power over Ethernet (PoE) - Yes
Power over Ethernet (PoE) - Power over Ethernet (PoE) ports quantity - 24
Power over Ethernet (PoE) - Power over Ethernet (PoE) power per port - 30 W
Power over Ethernet (PoE) - Total Power over Ethernet (PoE) budget - 370 W
Power supply - 100 - 240 VAC 50/60 Hz
Power supply - Internal
producer - D-Link
ProductName - DGS-1510-28XMP
QoS - 802.1p Quality of Service Queue Handling Strict Priority Queue (SPQ) Weighted Round Robin (WRR) Deficit Round Robin (DRR) SPQ + WRR 8 queues per port Bandwidth Control Port-based (Ingress/Egress, min. granularity for 10/100/1000 BASE-T ports is 64 Kb/s) CoS based on: 802.1p priority VLAN MAC address Ether type IP address DSCP Protocol type TCP/UDP port number DSCP of IPv6 Traffic Class IPv6 flow label
Security - Port Security Supports up to 128 MAC addresses per port Broadcast/Multicast/Unicast Storm Control Dynamic ARP Inspection D-Link Safeguard Engine DHCP Server Screening ARP Spoofing Prevention Max. 64 entries SSH Supports v2 Supports IPv4/IPv6 BPDU Attack Protection DoS Attack Prevention SSL Supports v1/v2/v3 Supports IPv4/IPv6 Traffic Segmentation IP-MAC-Port Binding DHCP snooping IP Source Guard Dynamic ARP Inspection IPv6 DHCP Guard IPv6 RA Guard IPv6 Snooping IPv6 Source Guard IPv6 ND Inspection
Security - Access Control List (ACL) - Yes
Security - Access Control List (ACL) rules - 768
Security - Authentication - MAC-based authentication, Port-based authentication
Security - BPDU filtering/protection - Yes
Security - DHCP features - DHCP server, DHCP client
Security - IGMP snooping - Yes
Security - Security algorithms - 802.1x RADIUS, EAP, SNMP, SSH, SSH-2, SSL/TLS
Security - SSH/SSL support - Yes
Short description - D-Link Switch DGS-1510-28XMP/E 24xGBit PoE (370W)/4xSFP+
ShortSummaryDescription - D-Link DGS-1510-28XMP, Managed, L2/L3, Gigabit Ethernet (10/100/1000), Full duplex, Power over Ethernet (PoE), Rack mounting
Stackability - Yes
Stck_Kart - 1
Stck_Pal - 17
Storno - Y
Supported protocols and standards - IEEE 802.3 10BASE-T Ethernet IEEE 802.3u 100BASE-TX Fast Ethernet IEEE 802.3ab 1000BASE-T Gigabit Ethernet 802.3ae 10 GbE IEEE 802.3x Flow Control for Full-Duplex Mode
Support for Jumbo frames - Yes
Switch class - SMART
Switch layer - L2
Switch layer - L3
Technical details - Master (outer) cases per pallet (air) - 24 pc(s)
Technical details - Master (outer) cases per pallet (sea) - 24 pc(s)
Technical details - Pallet gross length - 110 cm
Technical details - Pallet gross weight (air) - 561.6 kg
Technical details - Pallet gross weight (sea) - 561.6 kg
Technical details - Pallet gross width - 120 cm
Technical details - Pallet height (air) - 2.08 m
Technical details - Pallet height (sea) - 2.08 m
Technical details - Products per pallet (air) - 72 pc(s)
Technical details - Products per pallet (sea) - 72 pc(s)
Technical details - Products per shipping (inner) case - 3 pc(s)
Technical details - Shipping (inner) case gross weight - 22.6 kg
Technical details - Shipping (inner) case height - 48.5 cm
Technical details - Shipping (inner) case length - 53 cm
Technical details - Shipping (inner) case net weight - 14.3 kg
Technical details - Shipping (inner) case width - 38.5 cm
Throughput - 128 Gb/s
Title - D-Link DGS-1510-28XMP Managed L2/L3 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black, Grey
URL - https://www.dlink.com/en/products/dgs-1510-28xmp--gigabit-stackable-smart-managed-switch-with-10g-uplinks
vendpn - DGS-1510-28XMP/E
VLAN - 802.1Q Tagged VLAN 4K VLAN Groups Configurable VID: 0~4094 GVRP VLAN Wizard Asymmetric VLAN Auto Voice VLAN Auto Surveillance VLAN 2.1 MAC-based VLAN Protocol-based VLAN
WarrantyInfo -
Weight - 4.25 kg
Weight - 6,05
Weight & dimensions - Depth - 308.5 mm
Weight & dimensions - Height - 44 mm
Weight & dimensions - Weight - 4.25 kg
Weight & dimensions - Width - 440 mm
