Startech IES81GPOEW 8x1GBE POE+

ARTIKEL1 - ETHERNET SWITCH 8-PORT
ARTIKEL2 - 4X RJ45/4X POE+/2GBIT/S
Brand - StarTech.com
BrandPartCode - IES81GPOEW
Breite - 0.17
Category - Network Switches
Certificates - Certification - CE, FCC, RoHS
Data transmission - Jumbo frames - 9000
Data transmission - Jumbo frames support - Yes
Data transmission - Store-and-forward - Yes
Design - Housing material - Steel
Design - International Protection (IP) code - IP30
Design - LED indicators - Activity, Link, Power
Design - Product colour - Black
Design - Rack mounting - No
Design - Wall mountable - Yes
EANCode - 0065030871112
Gewicht - 0.99
GRUPPE1 - Network
GRUPPE2 - Lan Switch Unmanaged
GTIN - 0065030871112
GTIN - 065030871112
HERSTELLER - STARTECH
Hoehe - 0.09
HSTNUMMER - IES81GPOEW
Laenge - 0.3
Logistics data - Harmonized System (HS) code - 85176990
Logistics data - Master (outer) case height - 475 mm
Logistics data - Master (outer) case length - 363 mm
Logistics data - Master (outer) case width - 335 mm
Logistics data - Products per master (outer) case - 10 pc(s)
LongDesc - Connect up to 8 different GbE (4 PoE+) devices, using this IP30 industrial Ethernet switch with intelligent Layer 2 managementEasily deploy or scale your network with this Gigabit Ethernet switch, by adding eight copper Gigabit Ethernet (GbE) connections, including four PoE+ ports. This IP30 industrial network switch provides intelligent Layer 2 management. Its rugged, compact design and wall-mount option with front access make it ideal for demanding applications, even where space is limited.Expand your networkThis Gigabit Ethernet switch lets you expand your network by connecting up to eight RJ45 devices (four PoE+). The 8-port switch enables up to eight users to share files and devices, such as printers and scanners, over a LAN connection, by enhancing your existing network capacity with additional ports.Supports PoE+ for flexible useThe switch gives you the freedom to place your equipment in locations where power outlets are not available, with support for Power over Ethernet Plus. The network switch provides abundant PoE power, with up to 30 watts for each PoE port (120W budget).Wall-mountable with front accessWith its compact design, you can wall-mount the Gigabit switch to provide convenient front access to ports and indicators. It’s ideal for a wide range of applications, including tight installation areas with significant electromagnetic interference, such as control cabinets and panels. The network switch is also DIN-rail mountable.Efficient Layer 2 managementThe switch delivers efficient and stable performance, with Layer 2 management capabilities. This lets you control packet traffic on a busy network, and customize your settings to achieve optimal network performance, offering improved efficiency and reliability.Rugged industrial designThis rugged network switch features an IP30-rated metal housing and extended operating temperature range of -40°C to 75°C, which makes it ideal for a wide range of conditions. The sturdy metal enclosure offers durability, even in harsh industrial environments.Reliable connection for seamless network performanceWith support for 10/100/1000Mbps transfer speeds, this managed switch supports full/half-duplex auto-negotiation, jumbo frames, and auto MDI/MDIX operation. This lets you connect your network devices quickly and easily, with little to no configuration required.To help prevent any unnecessary downtime, the switch features redundant 12-58V DC terminal block power inputs, which ensures seamless operation in the event of power dips or failures.The IES81GPOEW is backed by a StarTech.com 2-year warranty and free lifetime technical support.The StarTech.com Advantage
LongProductName - StarTech.com Industrial 8 Port Gigabit PoE Switch - 4 x PoE+ 30W - Power Over Ethernet - Hardened GbE Layer/L2 Managed Switch - Rugged High Power Gigabit Network Switch IP-30/-40C to +75C (IES81GPOEW)
LongSummaryDescription - StarTech.com Industrial 8 Port Gigabit PoE Switch - 4 x PoE+ 30W - Power Over Ethernet - Hardened GbE Layer/L2 Managed Switch - Rugged High Power Gigabit Network Switch IP-30/-40C to +75C. Switch type: Managed, Switch layer: L2. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 8. Full duplex, Networking standards: IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE.... Power connector: DC-in jack. Power over Ethernet (PoE). Wall mountable
Management features - Switch layer - L2
Management features - Switch type - Managed
Network - 10G support - No
Network - Auto MDI/MDI-X - Yes
Network - Flow control support - Yes
Network - Full duplex - Yes
Network - Link aggregation - Yes
Network - Networking standards - IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3z
Network - Spanning tree protocol - Yes
Network - Virtual LAN features - Tagged VLAN
Operational conditions - Operating relative humidity (H-H) - 5 - 95%
Operational conditions - Operating temperature (T-T) - -40 - 75 °C
Operational conditions - Storage temperature (T-T) - -40 - 90 °C
Other features - Terminal block port - Yes
Packaging content - Quick start guide - Yes
Packaging data - Package depth - 30 mm
Packaging data - Package height - 92 mm
Packaging data - Package weight - 930 g
Packaging data - Package width - 173 mm
Packaging data - Terminal block included - Yes
Performance - Buffer size - 512 KB
Performance - Maximum data transfer rate - 2000 Mbit/s
Performance - Mean time between failures (MTBF) - 100000 h
Ports & interfaces - Basic switching RJ-45 Ethernet ports quantity - 8
Ports & interfaces - Basic switching RJ-45 Ethernet ports type - Gigabit Ethernet (10/100/1000)
Ports & interfaces - Power connector - DC-in jack
Power - Input current - 1 A
Power - Input voltage - 12 - 48 V
Power - Power plug type - Type M
Power over Ethernet (PoE) - Power over Ethernet (PoE) - Yes
Power over Ethernet (PoE) - Power over Ethernet (PoE) power per port - 30 W
Power over Ethernet (PoE) - Power over Ethernet plus (PoE+) ports quantity - 4
Power over Ethernet (PoE) - Total Power over Ethernet (PoE) budget - 120 W
ProductName - Industrial 8 Port Gigabit PoE Switch - 4 x PoE+ 30W - Power Over Ethernet - Hardened GbE Layer/L2 Managed Switch - Rugged High Power Gigabit Network Switch IP-30/-40C to +75C
Security - Access Control List (ACL) - Yes
ShortSummaryDescription - StarTech.com Industrial 8 Port Gigabit PoE Switch - 4 x PoE+ 30W - Power Over Ethernet - Hardened GbE Layer/L2 Managed Switch - Rugged High Power Gigabit Network Switch IP-30/-40C to +75C, Managed, L2, Gigabit Ethernet (10/100/1000), Full duplex, Power over Ethernet (PoE), Wall mountable
Stck_Kart - 9998
Stck_Pal - 0
Storno - N
Title - StarTech.com Industrial 8 Port Gigabit PoE Switch - 4 x PoE+ 30W - Power Over Ethernet - Hardened GbE Layer/L2 Managed Switch - Rugged High Power Gigabit Network Switch IP-30/-40C to +75C
URL - https://www.startech.com/en-us/IES81GPOEW
WarrantyInfo - 2 Years
Weight & dimensions - Depth - 134 mm
Weight & dimensions - Height - 25 mm
Weight & dimensions - Weight - 650 g
Weight & dimensions - Width - 148 mm
