Zyxel GS1100-16, 16-Port, GIGABIT UNMANAGED SWITCH V3

10/100/1000/2500 Mbps ports - None
Accessories included - Kabel zasilający Zestaw do montażu na ścianie Zestaw do montażu w stojaku
Application - Home and small office
ARTIKEL1 - GS1100-16 V3 16-PORT GIG SWITCH
ARTIKEL2 - UNMANAGED
Brand - Zyxel
BrandPartCode - GS1100-16-EU0103F
Broadcast storm control - Yes
Category - Network Switches
Category - Root/Electronics/Networks and communication/Switchers
Category 1 - Netzwerk
Category 2 - Switching Hubs
Category_1 - Network and Servers
Category_2 - Network - Switches and Hubs
Certificates - Certification - LVD, BSMI
RoHS, REACH
Colour of product - Black
Console port - No
Data transmission - Forwarding rate - 23.8 Mpps
Data transmission - Jumbo frames - 9216
Data transmission - Jumbo frames support - Yes
Data transmission - MAC address table - 8000 entries
Data transmission - Packet buffer memory - 0.5 MB
Data transmission - Switching capacity - 32 Gbit/s
Description - ZYXEL GS1100-16 16 PORT GIGABIT UNMANAGED SWITCH V3
Description - Łączność typu Plug and Play
Po prostu rozpakuj niezarządzany przełącznik GS1100, aby cieszyć się natychmiastową łącznością Gigabit typu plug-n-play bez żadnych dodatkowych ustawień wymaganych z automatyczną negocjacją i automatycznym MDI/MDI-X. Obsługując priorytetyzację 802.1p i ramkę Jumbo, przełącznik zapewnia płynny ruch głosowy i wideo w sieci biurowej.
Cicha praca
Seria GS1100 ma konstrukcję bez wentylatora, która zapewnia cichą pracę w małych lub cichych środowiskach biurowych.
Oszczędzanie energii
GS1100 posiada funkcję Energy Efficient Ethernet (IEEE 802.3az), która automatycznie wykrywa ruch w sieci i dynamicznie dostosowuje zużycie energii. Ekologiczne funkcje Zyxel dostosowują również zużycie energii, wykrywając stan łącza i długość kabla, zmniejszając koszty operacyjne firmy.
Design - Certification - LVD, BSMI
RoHS, REACH
Design - Electromagnetic compatibility - CE, FCC, RCM, ICES-003, BSMI
Design - LED indicators - Activity
Design - LED indicators - Activity, Link, Power
Design - LED indicators - Link
Design - LED indicators - Power
Design - Rack mounting - Yes
Design - Wall mountable - Yes
dimensionalWeight - 1121
dimension depth - 70 mm
dimension height - 230 mm
Dimensions - 215 x 133 x 42
dimension weight - 1640 g
dimension width - 330 mm
Drive device, buffer size, MB - 0.256
ean - 4718937614066
EAN - 4718937614066
EANCode - 4718937614066
Eans - 4718937614066
EAN_code - 4718937614066
Ethernet LAN (RJ-45) ports quantity - 16
Fan - No
Forwarding rate - 23.8 Mbit/s
GRUPPE1 - Network
GRUPPE2 - Lan Switch Unmanaged
GTIN - 4718937614066
guarantee - -1
guarantee_type - external
Height - 225.000000
HERSTELLER - ZYXEL
HSTNUMMER - GS1100-16-EU0103F
Jumbo frame size - 9 KB
L2 features -
L3 features -
LED indicators - Link activity, Port status, Power, System
Length - 320.000000
Logistics data - Harmonized System (HS) code - 85176990
LongDesc - Plug and play connectivitySimply unbox the GS1100 unmanaged switch, you can enjoy instant plug-n-play Gigabit connectivity without any additional settings required with auto-negotiation and auto MDI/MDI-X. Supporting 802.1p prioritization and jumbo frame, the switch ensures smooth voice and video traffic for your office network.Whisper quiet operationThe GS1100 Series has fanless design that ensures silent operation in small or quiet office environments. The GS1100-10HP PoE model is specifically designed with an external power adapter that eliminates the need for an additional fan to cool down the device, making it perfect for quiet PoE deployments.Energy savingThe GS1100 features Energy Efficient Ethernet(IEEE 802.3az) which automatically detects network traffic and adjusts power consumption dynamically. Zyxel’s green features also adjust power consumption by detecting the link status and cable length reducing business operating expenses.
LongProductName - GS1100-16 Revision B1 - 16-port GbE Unmanaged
LongSummaryDescription - Zyxel GS1100-16. Switch type: Unmanaged. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 16. MAC address table: 8000 entries, Switching capacity: 32 Gbit/s. Networking standards: IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z. Wall mountable, Rack mounting
MAC address filtering - Yes
MAC address table, entries - 8000
MAC address table size - 8000
Management, monitoring, configuration -
Management features - Switch type - Unmanaged
Manufacturer - Zyxel
Manufacturer - ZYXEL NETWORKS
ManufacturerPartNumber - GS1100-16-EU0103F
Manufacturer_code - GS1100-16-EU0103F
Maximum data transfer rate, Gbit/s - 1
Mean time between failures (MTBF) - 1156 h
MPN - GS1100-16-EU0103F
Name - 16P Zyxel GS1100-16 V3 RM
name - GS1100-16-EU0103F 16x Gigabit Unmanaged Switc
Name - Zyxel GS1100-16 rev. 3, switches
Name - Zyxel GS1100-16-EU0103F
Network - 10G support - No
Network - Active link detection - Yes
Network - Auto MDI/MDI-X - Yes
Network - Cable types supported - Cat3
Network - Cable types supported - Cat3, Cat4, Cat5, Cat5e, Cat6
Network - Cable types supported - Cat4
Network - Cable types supported - Cat5
Network - Cable types supported - Cat5e
Network - Cable types supported - Cat6
Network - Flow control support - Yes
Network - Networking standards - IEEE 802.1p
Network - Networking standards - IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Network - Networking standards - IEEE 802.3
Network - Networking standards - IEEE 802.3ab
Network - Networking standards - IEEE 802.3az
Network - Networking standards - IEEE 802.3u
Network - Networking standards - IEEE 802.3x
Network - Networking standards - IEEE 802.3z
Network architecture - GigabitEthernet
Networking features - Gigabit Ethernet
Networking standards - IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3x, IEEE 802.1p
Number of 10/100 Mbps ports - None
Number of 10/100/1000 Mbps ports - 16
Number of 10Gb ports - None
Number of COMBO ports - None
Number of PoE+ ports - None
Number of PoE ports (PoE & PoE+) - None
Number of QSFP+ ports - None
Number of SFP+ ports - None
Number of SFP ports - None
Operating temperature range (T-T), °C - 0 - 50 °C
Operational conditions - Heat dissipation - 32.86 BTU/h
Operational conditions - Operating relative humidity (H-H) - 10 - 90%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 10 - 95%
Operational conditions - Storage temperature (T-T) - -40 - 70 °C
Other features -
Other functions -
Packaging content - Cables included - AC
Packaging content - Rack mount kit - Yes
Packaging data - Cables included - AC
Packaging data - Package type - Box
Packaging data - Rack mount kit - Yes
Packet buffer - 525 KB
Packet transfer speed - 28.8
Performance - Fanless - Yes
Performance - Mean time between failures (MTBF) - 1156942 h
PeriodofWarranty -
Ports & interfaces - Basic switching RJ-45 Ethernet ports quantity - 16
Ports & interfaces - Basic switching RJ-45 Ethernet ports type - Gigabit Ethernet (10/100/1000)
Ports quantity - 16
Power - AC input frequency - 50 - 60 Hz
Power - AC input voltage - 100 - 240 V
Power - Number of power supply units - 1
Power - Power consumption (max) - 10 W
Power - Power supply included - Yes
Power consumption - 10 W
Power consumption, W - 6.4
Power over Ethernet (PoE) - Power over Ethernet (PoE) - No
Power over Ethernet (PoE) Support - No
Power requirements - 100 - 240 V AC, 50/60 Hz
Power supply -
Power supply - Internal
producer - Zyxel
Producer - Zyxel
producerCode - GS1100-16-EU0103F
ProducerCode - GS1100-16-EU0103F
ProductName - GS1100-16
productName - Zyxel GS1100-16 Unmanaged Gigabit Ethernet (10/100/1000)
productSize - Normal
QoS -
Safety - UL 60950-1, CSA 60950, EN 60950-1, IEC 60950-1, RoHS
Security -
ShortDescription -
ShortSummaryDescription - Zyxel GS1100-16, Unmanaged, Gigabit Ethernet (10/100/1000), Rack mounting, Wall mountable
sizeX - 325
sizeY - 230
sizeZ - 75
Stck_Kart - 8
Stck_Pal - 24
Storage temperature range (T-T), °C - -40 - 70 °C
Storno - Y
Supported protocols and standards - 802.3 10BASE-T Ethernet 802.3u 100BASE-TX Ethernet 802.3ab 1000BASE-T Ethernet 802.3az EEE support 802.3x flow control 802.3z 1000BASE-X IEEE 802.1p CoS 802.3af PoE (GS1100-10HP) 802.3at PoE+ (GS1100-10HP)
Support for Jumbo frames - Yes
Switch class - Unmanaged
Switching capacity, Gbit/s - 32
Switch type - Unmanaged
Throughput - 32 GB/s
Title - Zyxel GS1100-16 Unmanaged Gigabit Ethernet (10/100/1000)
URL - https://www.zyxel.com/products_services/8-16-24-port-GbE-Unmanaged-Switch-GS1100-Series/overview
vendpn - GS1100-16-EU0103F
VLAN -
WarrantyInfo - Limited Lifetime
warrantyType - W
Weight - 1,63
Weight - 1.64
Weight - 1.640000
Weight - 900 g
weight - 1645
Weight & dimensions - Depth - 133 mm
Weight & dimensions - Height - 42 mm
Weight & dimensions - Weight - 900 g
Weight & dimensions - Width - 215 mm
Width - 70.000000
