Accessories included -
Application - Home and small office
ARTIKEL1 - 24 X 10G BASE-T PORTS + 4 X 10G
ARTIKEL2 - 25G SFP28 PORTS SM SWITCH
Brand - D-Link
BrandPartCode - DXS-1210-28T
Category - Network Switches
Category_1 - Network and Servers
Category_2 - Network - Switches and Hubs
Certificates - Certification - CE Class A
FCC Class A
VCCI Class A
IC
BSMI
Chassis type - Desktop
Console port - Yes
Data transmission - Forwarding rate - 505.92 Mpps
Data transmission - Jumbo frames - 9000
Data transmission - Jumbo frames support - Yes
Data transmission - MAC address table - 32000 entries
Data transmission - Store-and-forward - Yes
Data transmission - Switching capacity - 680 Gbit/s
Description -
Design - Form factor - 1U
Design - LED indicators - Activity, Link, Speed
Design - Number of fans - 2 fan(s)
Design - Product colour - Black
Design - Rack mounting - Yes
Designation - CE+WEEE
dimension depth - 90 mm
dimension height - 570 mm
Dimensions - 441 x 209.5 x 44 mm
dimension weight - 4370 g
dimension width - 350 mm
ean - 790069456800
EANCode - 0790069456800
EAN_code - 0790069456800
Fan - Yes
Forwarding mode - Store-and-forward
Forwarding rate - 505.92 Mpps
GRUPPE1 - Network
GRUPPE2 - Switches Managed
GTIN - 790069456800
GTIN - 0790069456800
guarantee - -1
guarantee_type - external
HERSTELLER - D-LINK
HSTNUMMER - DXS-1210-28T
Jumbo frame size - 9 KB
L2 features - MAC Address Table Up to 32K entries Static MAC Addresses 256 IGMP Snooping IGMP v1/v2/v3 Snooping Obsługuje 512 grup (współdzielone między dynamicznymi i statycznymi, maksymalnie 128 statycznych) Per VLAN IGMP Snooping Support port-based fast leave Report Suppression MLD Snooping MLD v1/v2 Snooping Obsługuje 256 grup (współdzielone między dynamicznymi i statycznymi, z maksymalnie 128 statycznymi) Support port-based fast leave LLDP LLDP-MED Spanning Tree Protocol 802.1D STP 802.1w RSTP 802.1s MSTP Flow Control 802.3x Flow Control HOL Blocking Prevention Port Mirroring One-to-One Many-to-One Supports Mirroring for Tx/Rx/Both 802.3ad Link Aggregation: Maximum of 8 groups/8 ports per group Jumbo Frame Up to 12,288 Bytes Loopback Detection
L3 features -
Logistics data - Harmonized System (HS) code - 85176990
LongDesc - The DXS-1210-28T/28S 10 Gigabit Ethernet Smart Managed Switches are a cost-effective 10Gigabit switches capable of servicing a range of network needs in any business environment.The DXS-1210-28T is equipped with 4 x 10/25G SFP28 ports, enabling this series to serve aseither an aggregation/access switch in large enterprise environments or deployed at thecore of an SMB network. With high performance and low latency, these 10G smart-managedswitches fulfil the needs of virtualisation, cloud services, and server-to-server applications.The DXS-1210-28T/28S comes with a complete line-up of L2 features, including port mirroring,Spanning Tree Protocol (STP), and Link Aggregation Control Protocol (LACP). At the same time,inter-VLAN static routing helps by reducing the pressure of routers and backbone networks,improving overall network efficiency. The free D-Link Network Assistant utility allows multipleD-Link devices within the same L2 network to be discovered and managed. These switches alsoprovide management through the multi-lingual web UI, a full command-line interface (CLI)through Telnet, a console port, as well as D-View 7 Network Management System.
LongProductName - DXS-1210-28T - 24 x 10GBASE-T, 4 x 10/25G SFP28
LongSummaryDescription - D-Link DXS-1210-28T. Switch type: Managed, Switch layer: L2/L3. Basic switching RJ-45 Ethernet ports type: 10G Ethernet (100/1000/10000), Basic switching RJ-45 Ethernet ports quantity: 24, Console port: RJ-45. MAC address table: 32000 entries, Switching capacity: 680 Gbit/s. Networking standards: IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3an, IEEE 802.3az, IEEE 802.3u, IEEE 802.3z. Rack mounting, Form factor: 1U
MAC address table size - 32000
Management, monitoring, configuration - Web-based GUI D-Link Network Assistant Utility Full CLI Telnet Server TFTP Client Configurable MDI/MDIX SNMP Supports v1/v2c/v3 SNMP Trap Smart Wizard LLDP LLDP-MED ICMP v4 DHCP Relay DHCP Auto-image System Log BootP/DHCP Client SNTP ICMP v6 IPv4/v6 Dual Stack DHCP Auto Configuration RMON v1/v2 Dual Images Dual Configurations DNS Client
Management features - Quality of Service (QoS) support - Yes
Management features - Switch layer - L2/L3
Management features - Switch type - Managed
Management features - Web-based management - Yes
Manufacturer - D-Link
Manufacturer_code - DXS-1210-28T
Name - D-Link DXS-1210-28T, switch
name - D-Link DXS-1210-28T Swi tch Smart 24x10GE 4xSFP
Network - Auto MDI/MDI-X - Yes
Network - Cable types supported - Cat6, Cat6a, Cat7
Network - Flow control support - Yes
Network - Link aggregation - Yes
Network - Networking standards - IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3an, IEEE 802.3az, IEEE 802.3u, IEEE 802.3z
Network - Number of VLANs - 4094
Network - Port mirroring - Yes
Network - Spanning tree protocol - Yes
Network - VLAN support - Yes
Network architecture - GigabitEthernet
Number of 10/100 Mbps ports - None
Number of 10/100/1000 Mbps ports - None
Number of 10Gb ports - 24
Number of PoE+ ports - None
Number of PoE ports (PoE & PoE+) - None
Number of QSFP+ ports - None
Number of SFP+ ports - None
Number of SFP ports - 4
Number of VLAN groups - 4000
Operational conditions - Operating relative humidity (H-H) - 0 - 95%
Operational conditions - Operating temperature (T-T) - -5 - 50 °C
Operational conditions - Storage relative humidity (H-H) - 0 - 95%
Operational conditions - Storage temperature (T-T) - -20 - 70 °C
Other features -
Other functions -
Performance - Noise level - 51.9 dB
Ports & interfaces - 10G Ethernet (copper) ports quantity - 24
Ports & interfaces - Basic switching RJ-45 Ethernet ports quantity - 24
Ports & interfaces - Basic switching RJ-45 Ethernet ports type - 10G Ethernet (100/1000/10000)
Ports & interfaces - Console port - RJ-45
Ports & interfaces - SFP28 ports quantity - 4
Power - AC input voltage - 100 - 240 V
Power - Power consumption (max) - 87.3 W
Power consumption - 87.3 W
Power over Ethernet (PoE) - Power over Ethernet (PoE) - No
Power supply - AC Input 100 to 240 VAC
Power supply - Internal
producer - D-Link
ProductName - DXS-1210-28T
Protocols - GARP VLAN Registration Protocol (GVRP) - Yes
Protocols - Management protocols - SNMP v1/v2c/v3
QoS - CoS based on Switch port 802.1p Priority Queues Outer 802.1p priority DSCP ToS IPv6 Traffic Class TCP/UDP port MAC Address Ether Type IP Address Protocol Type IPv6 Flow Label/Traffic Class 802.1p Priority Queue 8 queues per port Queue Handling Strict Priority Que (SPQ) Weighted Round Robin (WRR) Bandwidth Control Port-based (Ingress/Egress, min. granularity 64 Kbps) Queue-based (Egress, min. granularity 64 Kbps)
Security - UL CB BSMI
Security - Access Control List (ACL) - Yes
Security - Access Control List (ACL) rules - 256
Security - IGMP snooping - Yes
ShortSummaryDescription - D-Link DXS-1210-28T, Managed, L2/L3, 10G Ethernet (100/1000/10000), Rack mounting, 1U
Stck_Kart - 1
Stck_Pal - 6
Storno - Y
Supported protocols and standards - IEEE 802.3u IEEE 802.3ab IEEE 802.3az IEEE 802.3an IEEE 802.3ae
Support for Jumbo frames - Yes
Switch class - SMART
Switch layer - L2+
Throughput - 680 GB/s
Title - D-Link DXS-1210-28T network switch Managed L2/L3 10G Ethernet (100/1000/10000) 1U Black
URL - https://www.dlink.com/en/
vendpn - DXS-1210-28T
VLAN - 802.1Q VLAN Port-based VLAN Configurable VID 1~4094 Voice VLAN Auto Surveillance VLAN Asymmetric VLAN 4K VLAN Groups
WarrantyInfo -
Weight - 3,00
Weight - 3.07 kg
Weight & dimensions - Depth - 209.5 mm
Weight & dimensions - Height - 44 mm
Weight & dimensions - Weight - 3.07 kg
Weight & dimensions - Width - 441 mm
