D-Link DGS‑1016D 16-Port Gigabit Unmanaged Desktop Switch

Application - Home and small office
ARTIKEL1 - GIGAEXPRESS 16-PORT
ARTIKEL2 - GIGABIT SWITCH 16X 10/100/1000
Brand - D-Link
BrandPartCode - DGS-1016D/E
Category - Network Switches
Category - Root/Electronics/Networks and communication/Switchers
Category_1 - Network and Servers
Category_2 - Network - Switches and Hubs
Certificates - Certification - FCC Class A, CE, ICES-003, VCCI, C-Tick, RoHS
Code - DGS-1016D/E
Data transmission - Jumbo frames support - Yes
Data transmission - MAC address table - 8000 entries
Data transmission - Maximum data transfer rate - 1 Gbit/s
Data transmission - Packet buffer memory - 0.340 MB
Data transmission - Store-and-forward - Yes
Data transmission - Switching capacity - 32 Gbit/s
Description - DGS-1016D Switch is an non-managed switch 10/100/1000 Mb/s dedicated to operate on small working groups. Device is characterized by simplicity of operation and installation, and at the same time ensures maximum performance of the network.
Design - Certification - FCC Class A, CE, ICES-003, VCCI, C-Tick, RoHS
Design - LED indicators - Yes
Design - Product colour - Black
Design - Product colour - Black, Metallic
Design - Product colour - Metallic
Design - Rack mounting - Yes
Design - Stackable - Yes
Design > Form factor - Desktop
dimensionalWeight - 1846
dimension depth - 100 mm
dimension height - 355 mm
dimension weight - 1762 g
dimension width - 255 mm
EAN - 790069269974
ean - 790069269974
EAN - 0790069269974
EANCode - 0790069269974
Eans - 790069269974
EAN_code - 0790069269974
Gewicht - 1.59
Gross Weight Kg - 2,77
GRUPPE1 - Network
GRUPPE2 - Lan Switch Unmanaged
GTIN - 790069269974
GTIN - 0790069269974
GTIN - 7900692699748
GTIN - 9789800333440
guarantee - 24
guarantee_type - external
HERSTELLER - D-LINK
Hoehe - 0.11
HSTNUMMER - DGS-1016D/E
Laenge - 0.33
Link - https://eu.dlink.com/uk/en/products/dgs-1016d-16-port-copper-gigabit-switch
Logistics data - Harmonized System (HS) code - 85176990
LongDesc - Power Savings by Number of Connected Ports and Link StatusComputers do not require Internet access all the time; neither do switches utilize all ports at all times. When a computer or network equipment is shutdown, switches often remain on and continue to consume considerable amount of power. With Green Ethernet technology, D-Link switches can automatically detect link status and reduce power usage of ports that are idle. Computers or any connecting parties set to standby mode (not power off), however, will not provide significant power savings.Power Savings by Cable LengthThe Green Ethernet switches have the ability to analyze the length of any Ethernet cable connected to them for adjustment of power usage accordingly. Shorter lengths require less power.Overall Power Savings Per DayFor a traditional switch, power consumption remains constant even when the ports are not in use. In a standard workday scenario where PCs are used for 10 hours a day and powered off 14 hours a day, and connected to the switch using 20 meter cables, D-Link's Green Ethernet can save up to 20% power used for each system.Get the blazing speed of Gigabit Ethernet with the D-Link GigaExpress DGS-1016D, an 16-port 10/100/1000Mbps Gigabit Switch that delivers power, performance, and reliability in one cost-effective, space-saving design. Increase the speed of your network server and backbone connections, or make Gigabit to the desktop a reality.Power users in the office, workgroup, or creative production environment can now move large, bandwidth-intensive files faster. Transfer graphics, CGI, CAD, or multimedia files across the network instantly. The versatile and compact 1RU height design of the DGS-1016D enables the device to be rackmounted in a standard 19 inch rack, while conserving valuable rack space.Power-PackedIt features a non-blocking switching architecture that filters and forwards packets at full wire-speed for maximum throughput. An 8K MAC address table provides scalability for even the largest networks. Address learning and aging, 802.3x Flow Control for full-duplex mode, and back pressure flow control for half-duplex mode alleviates traffic congestion and ensures reliable data transmission.Designed using industry standards, it is compatible with virtually all 10, 100, and 1000Mbps Ethernet devices and other vendor equipment. The D-Link DGS-1016D 10/100/1000 Mbps Gigabit Switch protects your existing network investments while providing you with a straightforward migration path to faster Gigabit speeds.Easy to useThe auto features of this gigabit switch make installation plug and play and hassle-free. No configuring is required. Auto MDI/MDI-X crossover on all ports eliminate the need for crossover cables or uplink ports. Auto-negotiation on each port senses the link speed of a network device (either 10, 100, or 1000 Mbps) and intelligently adjusts for compatibility and optimal performance.It also features diagnostic LEDs which display status and activity, allowing you to quickly detect and correct problems on the network. Every port also supports a cable diagnostic feature that helps to detect cable related problems.
LongProductName - DGS-1016D/E - Gigabit Ethernet, QoS, Flow Control, 32Gbps
LongSummaryDescription - D-Link DGS-1016D/E. Switch type: Unmanaged. Basic switching RJ-45 Ethernet ports quantity: 16. Full duplex. MAC address table: 8000 entries, Switching capacity: 32 Gbit/s. Networking standards: IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x. Rack mounting
MAC address table size - 800
Management features - Quality of Service (QoS) support - Yes
Management features - Switch type - Unmanaged
Management features > Switch type - Unmanaged
Manufacturer - D-Link
Manufacturer Code - DGS-1016D/E
Manufacturer Name - D-Link
Manufacturer_code - DGS-1016D/E
Name - D-Link DGS-1016D
Name - D-Link DGS-1016D 1000/UNM/16
Name - D-Link | 16-Port Gigabit Unmanaged Desktop Switch | DGS-1016D | Unmanaged | Desktop
name - DGS-1016D switch L2 16x1GBE Desktop/Rack 19''
Network - 10G support - No
Network - Auto MDI/MDI-X - Yes
Network - Copper ethernet cabling technology - 10BASE-T
Network - Copper ethernet cabling technology - 100BASE-T
Network - Copper ethernet cabling technology - 1000BASE-T
Network - Copper ethernet cabling technology - 1000BASE-T, 100BASE-T, 10BASE-T
Network - Flow control support - Yes
Network - Full duplex - Yes
Network - Networking standards - IEEE 802.1p
Network - Networking standards - IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x
Network - Networking standards - IEEE 802.3
Network - Networking standards - IEEE 802.3ab
Network - Networking standards - IEEE 802.3u
Network - Networking standards - IEEE 802.3x
Network architecture - GigabitEthernet
Number of 10/100 Mbps ports - None
Number of 10/100/1000 Mbps ports - 16
Operational conditions - Operating relative humidity (H-H) - 5 - 95%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage temperature (T-T) - -10 - 55 °C
Other features - Complies with IEEE 802.3, IEEE 802.3x 802.3ui
Automatic recognition of link speed and duplex (autosensing)
Jobs in half and full-duplex
Auto MDI / MDIX
Flow Control to prevent data loss in full duplex mode
Switching in the "store-and-forward" mode
Automatic correction of converted cable poles
RAM buffer with dynamic assignment to each port
Package features > Embeeded battery - No
Package features > Gross depth (mm) - 281.94 mm
Package features > Gross depth master carton - 310 mm
Package features > Gross height (mm) - 44.96 mm
Package features > Gross height master carton - 225 mm
Package features > Gross width (mm) - 180.09 mm
Package features > Gross width master carton - 210 mm
Package features > Net weight master carton - 3 kg
Package features > Packing quantity - 1.00 pc(s)
Package features > Palette Qty - 757 pc(s)
Package features > Paper/Pasteboard - 90.00 g
Package features > PET - 4 g
Package features > Plastic (No PET) - 10.00 g
Package features > Tare weight (kg) - 0.10 kg
Package features > Tare weight master carton - 0.249 kg
Package features > Volume (m3) - 0.00 m³
Package features > WEE classification - CL109:4:2017-04-01
Package features > WEEE tax - Yes
Packaging data - Package depth - 328 mm
Packaging data - Package height - 108 mm
Packaging data - Package weight - 1.71 kg
Packaging data - Package width - 180 mm
Performance - Mean time between failures (MTBF) - 828109 h
Ports & interfaces - Basic switching RJ-45 Ethernet ports quantity - 16
Ports & interfaces > POE - No
Ports & interfaces > Predominant port type - 10/100/1000 Mbps (RJ-45)
Power - AC input frequency - 50 - 60 Hz
Power - AC input voltage - 100 - 240 V
Power - Power consumption (typical) - 11.7 W
Power over Ethernet (PoE) - Power over Ethernet (PoE) - No
producer - D-Link
Producer - D-link
ProducerCode - DGS-1016D
producerCode - DGS-1016D/E
Producer product family - 16-Port Gigabit Unmanaged Desktop Switch
Producer product name - DGS-1016D
productName - D-Link DGS-1016D/E network switch Unmanaged Black, Metallic
ProductName - DGS-1016D/E
productSize - Normal
ShortDescription -
Short description - D-Link Switch DGS-1016D 16xGBit 19" Unmanaged
ShortSummaryDescription - D-Link DGS-1016D/E, Unmanaged, Full duplex, Rack mounting
sizeX - 100
sizeY - 355
sizeZ - 260
Stck_Kart - 10
Stck_Pal - 20
Storno - Y
Switch class - Unmanaged
Technical details - Master (outer) cases per pallet (air) - 30 pc(s)
Technical details - Master (outer) cases per pallet (sea) - 50 pc(s)
Technical details - Pallet gross length - 110 cm
Technical details - Pallet gross weight (air) - 295.7 kg
Technical details - Pallet gross weight (sea) - 480.3 kg
Technical details - Pallet gross width - 120 cm
Technical details - Pallet height (air) - 121.2 cm
Technical details - Pallet height (sea) - 193 cm
Technical details - Products per pallet (air) - 150 pc(s)
Technical details - Products per pallet (sea) - 250 pc(s)
Technical details - Products per shipping (inner) case - 5 pc(s)
Technical details - Shipping (inner) case gross weight - 9.21 kg
Technical details - Shipping (inner) case height - 35.9 cm
Technical details - Shipping (inner) case length - 57.2 cm
Technical details - Shipping (inner) case net weight - 8.54 kg
Technical details - Shipping (inner) case width - 19.7 cm
Technical details > Gross weight - 1.12 kg
Technical details > Net weight - 1.02 kg
Technical details > Other features - Gigabit Connectivity; Improved Network Efficiency; Innovative Design
Technical details > Producer - D-Link
Technical_details - Power Savings by Number of Connected Ports and Link Status
Computers do not require Internet access all the time; neither do switches utilize all ports at all times. When a computer or network equipment is shutdown, switches often remain on and continue to consume considerable amount of power. With Green Ethernet technology, D-Link switches can automatically detect link status and reduce power usage of ports that are idle. Computers or any connecting parties set to standby mode (not power off), however, will not provide significant power savings. Power Savings by Cable Length
The Green Ethernet switches have the ability to analyze the length of any Ethernet cable connected to them for adjustment of power usage accordingly. Shorter lengths require less power. Overall Power Savings Per Day
For a traditional switch, power consumption remains constant even when the ports are not in use. In a standard workday scenario where PCs are used for 10 hours a day and powered off 14 hours a day, and connected to the switch using 20 meter cables, D-Link's Green Ethernet can save up to 20% power used for each system. Get the blazing speed of Gigabit Ethernet with the D-Link GigaExpress DGS-1016D, an 16-port 10/100/1000Mbps Gigabit Switch that delivers power, performance, and reliability in one cost-effective, space-saving design. Increase the speed of your network server and backbone connections, or make Gigabit to the desktop a reality. Power users in the office, workgroup, or creative production environment can now move large, bandwidth-intensive files faster. Transfer graphics, CGI, CAD, or multimedia files across the network instantly. The versatile and compact 1RU height design of the DGS-1016D enables the device to be rackmounted in a standard 19 inch rack, while conserving valuable rack space. Power-Packed
It Featuress a non-blocking switching architecture that filters and forwards packets at full wire-speed for maximum throughput. An 8K MAC address table provides scalability for even the largest networks. Address learning and aging, 802.3x Flow Control for full-duplex mode, and back pressure flow control for half-duplex mode alleviates traffic congestion and ensures reliable data transmission. Designed using industry standards, it is compatible with virtually all 10, 100, and 1000Mbps Ethernet devices and other vendor equipment. The D-Link DGS-1016D 10/100/1000 Mbps Gigabit Switch protects your existing network investments while providing you with a straightforward migration path to faster Gigabit speeds. Easy to use
The auto Featuress of this gigabit switch make installation plug and play and hassle-free. No configuring is required. Auto MDI/MDI-X crossover on all ports eliminate the need for crossover cables or uplink ports. Auto-negotiation on each port senses the link speed of a network device (either 10, 100, or 1000 Mbps) and intelligently adjusts for compatibility and optimal performance. It also Featuress diagnostic LEDs which display status and activity, allowing you to quickly detect and correct problems on the network. Every port also supports a cable diagnostic Features that helps to detect cable related problems. Transfer Rate LAN 10/100/1000 MBit/s LEDs 16x Lan, Power Ports RJ-45 LAN 16 Power Operating 11 watt(s) Remarks alle Ports with Uplink Erkennung Features Puffer-RAM with automaticer Zuweisung for jeden connection, automatices Lernen der Netzwerkkonfiguration, Plug&Play Installation, Verwendung von herkömmlichen Cat.5 Kupfercablen Product dimensions 280 x 44 x 180 mm Weight 1.59 kg
Throughput - 32 GB/s
Title - D-Link DGS-1016D/E network switch Unmanaged Black, Metallic
URL - https://www.dlink.com/products/?pid=337#
vendpn - DGS-1016D/E
Warranty - 24
Warranty - 24 month(s)
WarrantyInfo - lifetime
warrantyLength - 24
warrantyType - G
Weight - 1,80
weight - 2413
Weight & dimensions - Depth - 180.3 mm
Weight & dimensions - Height - 44.5 mm
Weight & dimensions - Weight - 1.35 kg
Weight & dimensions - Width - 281.9 mm
