D-Link DES‑108 8-Port Fast Ethernet Unmanaged Desktop Switch

Application - Home and small office
ARTIKEL1 - DES-108/E FAST ETHERNET SWITCH
ARTIKEL2 - IN
Brand - D-Link
BrandPartCode - DES-108/E
Category - Network Switches
Category - Root/Electronics/Networks and communication/Switchers
Category_1 - Network and Servers
Category_2 - Network - Switches and Hubs
Certificates - FCC Class B
ICES-003 Class B
CE Class B
C-Tick Class B
VCCI Class B
cUL
CB
Certificates - Certification - RoHS, FCC Class B, ICES-003 Class B, CE Class B, C-Tick Class B, VCCI Class B, cUL, CB
Chassis type - Desktop
Code - DES-108/E
Data transmission - Jumbo frames support - Yes
Data transmission - MAC address table - 1000 entries
Data transmission - Maximum data transfer rate - 0.1 Gbit/s
Data transmission - Packet buffer memory - 0.768 MB
Data transmission - Store-and-forward - Yes
Data transmission - Supported data transfer rates - 10/100 Mbps
Data transmission - Switching capacity - 1.6 Gbit/s
Description - Przełącznik o prędkości magistrali wynoszącej 1.6 Gbps, wyposażony w 8 gniazd sieciowych 10BASE-T/100BASE-TX. Urządzenie posiada tablicę adresów MAC o pojemności 1000 pozycji.
Design - Housing material - Metal
Design - LED indicators - Link, Power
Design - Product colour - Black
Design - Rack mounting - No
Design > Form factor - Desktop
dimension depth - 68 mm
dimension height - 250 mm
Dimensions - 162 x 102 x 28mm
dimension weight - 718 g
dimension width - 208 mm
EAN - 790069368202
ean - 790069368202
EANCode - 0790069368202
Eans - 790069368202
EAN_code - 0790069368202
Gewicht - 0.69
GRUPPE1 - Network
GRUPPE2 - Lan Switch Unmanaged
GTIN - 790069368202
GTIN - 0790069368202
guarantee - 60
guarantee_type - external
HERSTELLER - D-LINK
HSTNUMMER - DES-108/E
Link - https://eu.dlink.com/uk/en/products/des-108-8-port-fast-ethernet-switch
Logistics data - Harmonized System (HS) code - 85176990
LongDesc - - Plug and Play operation- 8 Fast Ethernet ports- Non-blocking architecture: simultaneous full speed on all ports- Fanless, silent operation to fit in any environment- Quality of Service (QoS) queues for traffic prioritisation- Solidly built with metal housing- D-Link Green™ technology, saves energy and increases the product’s lifespanD-Link’s DES-108 Fast Ethernet switch provides a cost-effective way for SOHO and SMB to create a small network and connect computers, wireless Access Points, IP cameras, network printers and other Ethernet devices quickly and easily without complicated configurations. This switch comes with 8 Fast Ethernet ports with an auto-sensing function to detect the maximum speed of the connected devices, allowing you to run your network with the best possible performance. Its fanless design makes the DES-108 completely silent so it is ideal for offices, libraries or meeting rooms.Robust designThe DES-108 is designed with durability and performance in mind. The sturdy metal housing will protect it against accidental harm, while helping to dissipate heat and to reduce stress on internal components. The visible LEDs allow for an easy reading of each port status, helping to troubleshoot connectivity problems. For a convenient placement, this switch comes with a wall mounting kit and a slot for a Kensington security lock to protect it from theft.QoS (Quality of Service)Despite being an unmanaged, Plug and Play switch, the DES-108 is able to classify network traffic by assessing the 802.1p field in the Ethernet frames, and forward them out of its ports depending on their priority. This allows for a smooth integration of video, voice and data traffic without delays or loss of quality.Power-saving technologyThe DES-108 is part of D-Link Green™, D-Link’s eco-friendly technology, providing energy savings, reduced power consumption, and a longer product lifespan without sacrificing operational performance or functionality. This switch implements the 802.3az Energy Efficient Ethernet (EEE) standard, which can save a substantial amount of energy by detecting the port status, putting them in low-power, stand-by mode when no network traffic is detected. This helps businesses to save money by reducing their electricity bills with no compromise on performance.
LongProductName - 8x 10/100 Mbps LAN, 1 Gbps, 2K MAC
LongSummaryDescription - D-Link DES-108. Basic switching RJ-45 Ethernet ports quantity: 8. Full duplex. MAC address table: 1000 entries, Switching capacity: 1.6 Gbit/s. Networking standards: IEEE 802.1p, IEEE 802.3, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x. Power connector: DC-in jack
MAC address table size - 1000
Management features - Quality of Service (QoS) support - Yes
Management features > Switch type - Unmanaged
Manufacturer - D-Link
Manufacturer_code - DES-108/E
Mean time between failures (MTBF) - 511323 h
Memory buffer - 768 KB
Name - D-Link DES-108 100/UNM/ 8
Name - D-Link DES-108/E
Name - D-Link | Ethernet Switch | DES-108/E | Unmanaged | Desktop | 10/100 Mbps (RJ-45) ports quantity 8 | 60 month(s)
name - Switch 8-port 10/100 Metal Housing
Network - 10G support - No
Network - Auto MDI/MDI-X - Yes
Network - Copper ethernet cabling technology - 100BASE-TX, 10BASE-T
Network - Flow control support - Yes
Network - Full duplex - Yes
Network - Networking standards - IEEE 802.1p, IEEE 802.3, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
Network architecture - FastEthernet
Number of 10/100 Mbps ports - 8
Operational conditions - Operating relative humidity (H-H) - 10 - 90%
Operational conditions - Operating temperature (T-T) - 0 - 50 °C
Operational conditions - Storage relative humidity (H-H) - 5 - 90%
Operational conditions - Storage temperature (T-T) - -10 - 70 °C
Other features - Data transfer rate - 200 Mbit/s
Other features - Dimensions (WxDxH) - 162 x 102 x 28 mm
Package features > Embeeded battery - No
Package features > Gross depth (mm) - 250.00 mm
Package features > Gross depth master carton - 310 mm
Package features > Gross height (mm) - 68.00 mm
Package features > Gross height master carton - 225 mm
Package features > Gross width (mm) - 208.00 mm
Package features > Gross width master carton - 210 mm
Package features > Net weight master carton - 3 kg
Package features > Packing quantity - 1.00 pc(s)
Package features > Palette Qty - 244 pc(s)
Package features > Paper/Pasteboard - 590.00 g
Package features > PET - 4 g
Package features > Plastic (No PET) - 10.00 g
Package features > Tare weight (kg) - 0.60 kg
Package features > Tare weight master carton - 0.249 kg
Package features > Volume (m3) - 0.00 m³
Package features > WEE classification - CL109:6:2017-04-01
Package features > WEEE tax - Yes
Packaging data - Package depth - 250 mm
Packaging data - Package height - 68 mm
Packaging data - Package weight - 610 g
Packaging data - Package width - 208 mm
Performance - Mean time between failures (MTBF) - 511323 h
Ports & interfaces - Basic switching RJ-45 Ethernet ports quantity - 8
Ports & interfaces - Power connector - DC-in jack
Ports & interfaces > 10/100 Mbps (RJ-45) ports quantity - 8
Ports & interfaces > POE - No
Ports & interfaces > Predominant port type - 10/100 Mbps (RJ-45)
Power - Input current - 1 A
Power - Input voltage - 5 V
Power - Power consumption (typical) - 4.5 W
producer - D-Link
Producer - D-link
ProducerCode - DES-108/E
Producer product family - Ethernet Switch
Producer product name - DES-108/E
ProductName - DES-108
Security - MAC address filtering - Yes
ShortDescription -
ShortSummaryDescription - D-Link DES-108, Full duplex
Stck_Kart - 10
Stck_Pal - 100
Store-and-forward - Yes
Storno - Y
Supported protocols and standards - IEEE 802.3 10BASE-T Ethernet (twisted-pair copper)
IEEE 802.3u 100BASE-TX Fast Ethernet (twisted-pair copper)
ANSI/IEEE 802.3 NWay auto-negotiation
IEEE 802.3x Flow Control
IEEE 802.1p QoS
IEEE 802.3az Energy-Efficient Ethernet (EEE)
CSMA/CD
Support for Jumbo frames - Yes
Switch class - Unmanaged
Technical details - Master (outer) cases per pallet (air) - 48 pc(s)
Technical details - Master (outer) cases per pallet (sea) - 48 pc(s)
Technical details - Pallet gross length - 102 cm
Technical details - Pallet gross weight (air) - 357.5 kg
Technical details - Pallet gross weight (sea) - 357.5 kg
Technical details - Pallet gross width - 122 cm
Technical details - Pallet height (air) - 2.07 m
Technical details - Pallet height (sea) - 2.07 m
Technical details - Products per pallet (air) - 480 pc(s)
Technical details - Products per pallet (sea) - 480 pc(s)
Technical details - Products per shipping (inner) case - 10 pc(s)
Technical details - Shipping (inner) case gross weight - 7 kg
Technical details - Shipping (inner) case height - 44.3 cm
Technical details - Shipping (inner) case length - 37 cm
Technical details - Shipping (inner) case net weight - 6.1 kg
Technical details - Shipping (inner) case width - 26 cm
Technical details > Gross weight - 1.01 kg
Technical details > Net weight - 0.41 kg
Technical details > Producer - D-Link
Technical details > Warranty - 60 month(s)
Technical_details - Effortless High Speed Networking
Featuring easy access auto sensing 10/100 front Ethernet ports with two color LED indicators per port to quickly distinguish link, speed, and half/full duplex transmission status. The DES-108 switch also supports Auto MDI/MDIX Crossover allowing each port can be plugged directly to a server, hub, router, or switch using regular straight-through twisted-pair Ethernet cables. Support for IEEE 802.1p QoS is included, which organizes and prioritizes time-sensitive and important data for efficient delivery. Think Green
The DES-108 is a plug-and-play networking switch that offers D-Link’s Green Technology to save energy and reduce heat, which in turn extends product life without sacrificing performance or functionality. The switch supports IEEE 802.3az Energy-Efficient Ethernet (EEE) which detects when a connected computer is shut down or when there is no Ethernet traffic, at which time the switch will automatically power down the idle port, saving a substantial amount of power. Environmentally Friendly
The DES-108 Gigabit switch was designed with the environment in mind. It is compliant with Energy Star Level V, CEC, and MEPS regulations which require the use of energy efficient power adapters. Built to comply with RoHS standards to minimize use of hazardous materials and is packaged with an EnergyStar Level V qualified power adapter all in a recyclable packaging making this product truly environmental friendly. Transfer Rate LAN 10/100 MBit/s LEDs 8x Lan, Power Ports RJ-45 LAN 8 Remarks IEEE 802.3x Flow Control Features Metallchassis Product dimensions 162 x 28 x 102 mm Weight 412 grams
Title - D-Link DES-108 Black
URL - https://www.dlink.co.uk/cs/Satellite?c=Product_C&childpagename=DLinkEurope-GB%2FDLProductCarouselMultiple&cid=1197392550808&p=1197356142823&packedargs=ParentPageID%3D1197335068935%26ProductParentID%3D1195808623774%26TopLevelPageProduct%3DBusiness%26categor
vendpn - DES-108/E
Warranty - 60
WarrantyInfo -
Weight - 0,71
Weight - 412 g
