TP-LINK Omada SG2452LP

Accessories included -
Application - Medium and large companies
ARTIKEL1 - OMADA 52-PORT POE SMART SWITCH
ARTIKEL2 - 230 W POE POWER 4X SFP
Brand - TP-Link
BrandPartCode - SG2452LP
Breite - 0
Category - Network Switches
Certificates - CE FCC RoHS
Chassis type - Rack
Data transmission - Forwarding rate - 77.37 Mpps
Data transmission - Jumbo frames - 9000
Data transmission - Jumbo frames support - Yes
Data transmission - MAC address table - 16000 entries
Data transmission - Static route - Yes
Data transmission - Switching capacity - 104 Gbit/s
Description - Omada 52-portowy gigabitowy inteligentny przełącznik z 32-portowym PoE+ 32× porty Gigabit 802.3af/at PoE+ 16× portów Gigabit RJ45 bez PoE i 4× sloty Gigabit SFP Całkowity budżet PoE 230 W z mocą wyjściową PoE do 30 W na port Centralne zarządzanie w chmurze za pośrednictwem sieci lub aplikacji Omada Samodzielne zarządzanie za pośrednictwem sieci, CLI, SNMP i RMON Statyczne trasowanie pomaga kierować ruchem wewnętrznym w celu zwiększenia wydajności VLAN, ACL, QoS i IGMP Snooping Konstrukcja bez wentylatora zapewniająca cichą pracę Trwała metalowa obudowa i konstrukcja umożliwiająca montaż w szafie
Design - Form factor - 1U
Design - LED indicators - Yes
Design - Product colour - Black
Design - Rack mounting - Yes
dimension depth - mm
dimension height - mm
Dimensions - 440 x 330 x 44 mm
dimension weight - g
dimension width - mm
ean - 8885020620818
EAN - 8885020620818
EANCode - 8885020620818
Environment requirements -
Fan - No
Forwarding rate - 77.37 Mpps
Gross Weight Kg - 4
GRUPPE1 - Network
GRUPPE2 - Switches Managed
GTIN - 8885020620818
GTIN - 8885020620825
guarantee - 60
guarantee_type - normal
HERSTELLER - TP-LINK
Hoehe - 0
HSTNUMMER - SG2452LP
Jumbo frame size - 9 KB
L2 features - 16 IP Interfaces: Support IPv4/IPv6 Interface Static Routing: 32 IPv4/IPv6 Static Routes DHCP Server DHCP Relay DHCP Interface Relay DHCP VLAN Relay DHCP L2 Relay Static ARP Proxy ARP Gratuitous ARP Link Aggregation Spanning Tree Protocol Loopback Detection 802.3x Flow Control Mirroring Device Link Detect Protocol (DLDP) 802.1ab LLDP/ LLDP-MED 511 IPv4, IPv6 shared multicast groups IGMP Snooping Multicast VLAN Registration (MVR) Multicast Filtering Limited IP Multicast (256 profiles and 16 entries per profile)
L3 features -
Laenge - 0
LongDesc - Power over Ethernet, Flexible Network DeploymentEasily Build a Whole 10G Multi-gigabit NetworkSoftware Defined Networking (SDN) with Cloud AccessRemotely manage your access points, switches, and gateways across multiple sites all from a single interface.
LongProductName - 32× 10/100/1000 Mbps PoE+ RJ45, 16× 10/100/1000 Mbps non-PoE RJ45, 4× Gigabit SFP, 104 Gbps, 16 K MAC, 9 KB Jumbo, 440x330x44 mm
LongSummaryDescription - TP-Link Omada 52-Port Gigabit Smart Switch with 32-Port PoE+. Switch type: Managed, Switch layer: L2/L2+. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 48. MAC address table: 16000 entries, Switching capacity: 104 Gbit/s. Networking standards: IEEE 802.1Q, IEEE 802.1p, IEEE 802.3ab, IEEE 802.3x. Power connector: AC-in jack. Power over Ethernet (PoE). Rack mounting, Form factor: 1U
MAC address table size - 16000
Management, monitoring, configuration -
Management features - ARP inspection - Yes
Management features - Cloud-managed - Yes
Management features - Configuring Location Settings (CLI) - Yes
Management features - MIB support - Y
Management features - Quality of Service (QoS) support - Yes
Management features - Switch layer - L2/L2+
Management features - Switch type - Managed
Management features - System event log - Yes
Management features - Web-based management - Yes
Manufacturer Code - SG2452LP
Manufacturer Name - TP-LINK
Memory buffer - 12 MB
name - SG2452LP Switch 48xGE PoE/PoE+ 4xSFP
Network - 10G support - No
Network - Active link detection - Yes
Network - Auto MDI/MDI-X - Yes
Network - Ethernet LAN data rates - 10,100,1000 Mbit/s
Network - Flow control support - Yes
Network - IP routing - Yes
Network - Link aggregation - Yes
Network - Networking standards - IEEE 802.1Q, IEEE 802.1p, IEEE 802.3ab, IEEE 802.3x
Network - Port mirroring - Yes
Network - VLAN support - Yes
Network architecture - GigabitEthernet
Number of 10/100/1000 Mbps ports - 16
Number of PoE ports (PoE & PoE+) - 32
Number of SFP ports - 4
Operational conditions - Heat dissipation - 1035.4 BTU/h
Operational conditions - Operating relative humidity (H-H) - 10 - 90%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 5 - 90%
Operational conditions - Storage temperature (T-T) - -40 - 70 °C
Other features -
Other functions -
Ports & interfaces - Basic switching RJ-45 Ethernet ports quantity - 48
Ports & interfaces - Basic switching RJ-45 Ethernet ports type - Gigabit Ethernet (10/100/1000)
Ports & interfaces - Power connector - AC-in jack
Ports & interfaces - SFP module slots quantity - 4
Power - AC input frequency - 50/60 Hz
Power - AC input voltage - 100 - 240 V
Power - Power consumption (max) - 304.5 W
Power - Power source - AC
Power - Power supply included - Yes
Power consumption - 304.5 W
Power over Ethernet (PoE) - Power over Ethernet (PoE) - Yes
Power over Ethernet (PoE) - Power over Ethernet (PoE) power per port - 30 W
Power over Ethernet (PoE) - Power over Ethernet plus (PoE+) ports quantity - 32
Power over Ethernet (PoE) - Total Power over Ethernet (PoE) budget - 230 W
Power supply - 100-240 V AC~50/60 Hz
Power supply - External
producer - TP-LINK
ProductName - Omada 52-Port Gigabit Smart Switch with 32-Port PoE+
QoS - Priorytet 802.1p CoS/DSCP 8 kolejek priorytetowych Tryb harmonogramu priorytetowego: SP (Strict Priority), WRR (Weighted Round Robin) Konfiguracja wagi kolejki Kontrola przepustowości: Port/limit oceny oparty na przepływie Płynniejsza wydajność Kontrola sztormu: Wiele trybów kontroli (kbps/współczynnik), kontrola rozgłoszeniowa/wielokierunkowa/nieznana-jednokierunkowa
Security - IP-MAC-Port Binding AAA 802.1X
- Port based authentication
- MAC (Host) based authentication
- Authentication Method includes PAP/EAP-MD5
- MAB
- Guest VLAN
- Radius authentication and accountability support IP/IPv6-MAC Binding
- 512 Binding Entries
- DHCP Snooping
- DHCPv6 Snooping
- ARP Inspection
- ND Detection IP Source Guard
- 253 Entries
- Source IP+Source MAC IPv6 Source Guard
- 183 Entries
- Source IPv6 Address+Source MAC DoS Defend Static/Dynamic/Permanent Port Security: Up to 64 MAC addresses per port Broadcast/Multicast/Unicast Storm Control: kbps/ratio control mode Port Isolation Secure web management through HTTPS with SSLv3/TLS 1.2 Secure Command Line Interface (CLI) management with SSHv1/SSHv2 IP/Port/MAC-based access control
Security - Authentication type - RADIUS
Security - DHCP features - DHCP relay, DHCP server
Security - IGMP snooping - Yes
Security - Loop protection - Yes
Security - MAC address filtering - Yes
Security - Security algorithms - SNMP, SNMPv2, SNMPv3
Security - SSH/SSL support - Yes
Short description - TP-LINK Switch SG2452LP Omada 52-Port Gigabit Smart Switch with 32-Port PoE+
ShortSummaryDescription - TP-Link Omada 52-Port Gigabit Smart Switch with 32-Port PoE+, Managed, L2/L2+, Gigabit Ethernet (10/100/1000), Power over Ethernet (PoE), Rack mounting, 1U
Stck_Kart - 1
Stck_Pal - 0
Storno - Y
Supported protocols and standards -
Support for Jumbo frames - Yes
Switch class - Managed
Throughput - 104 GB/s
Title - TP-Link Omada 52-Port Gigabit Smart Switch with 32-Port PoE+
URL - https://www.tp-link.com/en/business-networking/omada-switch-poe/sg2452lp/
vendpn - SG2452LP
VLAN - VLAN Group: Max. 4K VLAN Groups 802.1Q tag VLAN MAC VLAN: 12 Entries Protocol VLAN GVRP Voice VLAN
WarrantyInfo - 5 Years
Weight & dimensions - Depth - 330 mm
Weight & dimensions - Height - 44 mm
Weight & dimensions - Width - 440 mm
