ID: 896799
Product code: EG-UPSRACK-10
Can be ordered 2 units Availability: 14 days after order approval
Warranty: 2 years
Gembird EG-UPSRACK-10, 1000VA 800W, 3.4U
Picture may differ from actual product, there can be accessories and parts not supplied with the actual product.
Delivery options
- Courier delivery 3.99 €: 28.03.2025
Main product parameters All parameters
- Battery capacity (VA): 1000 VA
- Output power (W): 800 W
Display characteristics
Display
: Ir
Basic information
Battery capacity (VA)
1000 VA
The capacity of the battery pack is the index of the long-term operation of the UPS device without a permanent power supply source. This parameter applies to a UPS device with a fully charged battery pack. If you want to verify how big capacity is required for your computer equipment visit www.apc.ru where you will find the UPS capacity determination configuration tool.
Battery type
: Lead acid
Charging time (hours)
: 8h
Output power (W)
: 800 W
Ports and equipment
Number of nests (total)
: 4
Number of sockets (Battery Backup)
: 4
RJ-45
: 0
Socket type
: Schuko & IEC
USB
: 0
More detailed specification
Accessories included -
Active power - 800 W
Apparent power - 1000 VA
Battery capacity - 7 Ah
Charging time - 8 h
Chassis type - Tower
Code - EG-UPSRACK-10
Color - Black
Description - Rack-mounted UPS, 1000 VA Protects important data from power cuts Protects valuable equipment Protects users Automatic voltage regulation (AVR) Metal enclosure of the 3.4U rack USB control interface LCD display Short-circuit protection Compatible with any brand of generator set Overvoltage protection Audible and visual alarms Protection against overcharge and over-discharge
Designation - CE+WEEE
dimension depth - 450 mm
dimension height - 195 mm
Dimensions - 440 x 338 x 88 mm
dimension weight - 17000 g
dimension width - 615 mm
EAN - 8716309124775
ean - 8716309124775
Environment requirements - 0°C~40°C, at 10~90%RH humidity without condensation
Filters / protection - Circuit
Filters / protection - Overcharging
Filters / protection - Overdischarge
Filters / protection - Surge
guarantee - 24
guarantee_type - normal
Hold-up time (maks) - 10 ms
I/O connectors - 1 x mini USB (Type B)
I/O connectors - 2 x RJ-11/RJ-45
Input power ports - IEC-C14
Link - https://gembird.nl/item_view.aspx?id=%2012477
Name - EnerGenie | Rack UPS | EG-UPSRACK-10 | 1000 VA | 800 W
name - UPC 1000VA Line-In 3xC1 3 1xSchuko USB RJ45
No. of batteries - 2
Number of phases input - 1 (230V)
Other features -
Output power ports - 1 x t C/F type (Schuko)
Output power ports - 3 x IEC-C13
Package features > Classification of battery - CL126:NE:2016-12-09
Package features > Composition of battery - CL127:KT:2016-12-09
Package features > Embeeded battery - Yes
Package features > Gross depth (mm) - 615 mm
Package features > Gross height (mm) - 195 mm
Package features > Gross width (mm) - 450 mm
Package features > Packing quantity - 1.00 pc(s)
Package features > Palette Qty - 32 pc(s)
Package features > Paper/Pasteboard - 2000 g
Package features > Plastic (No PET) - 740 g
Package features > Tare weight (kg) - 2.74 kg
Package features > TI weight (kg) - 0.06 kg
Package features > Type of battery - Accumulator
Package features > Volume (m3) - 0.05396625 m³
Package features > WEE classification - CL109:5:2017-04-01
Package features > WEEE tax - Yes
PDF - https://www.blobs.lt/products/7/0/3/6/7/3/6c22a3b0936143a56036397c281c2f31/original.pdf
Performance > Capacity - 1000 VA
Performance > UPS topology - Line-Interactive
producer - Gembird
Producer product family - Rack UPS
Producer product name - EG-UPSRACK-10
Software -
Special functions -
Technical details > Capacity - 800 W
Technical details > Gross weight - 17.4 kg
Technical details > Net weight - 14.66 kg
Technical details > Other features - Protects important data from power cuts. Protects valuable equipment. Protects users. Audible and visual alarms
Technical details > Producer - EnerGenie
The shape of the output voltage - Full sine wave
UPS Architecture - line-interactive
vendpn - EG-UPSRACK-10
Voltage - 12 V
Warranty - 24
Warranty - 24 month(s)
Weight - 14.6 kg
