Accessories included - Basic RS-232 cable for UPS signaling Software CD Support rails for rack mounting USB cable User manual
Active power - 800 W
Alarm - Provides notification of changing utility power and UPS power conditions
Apparent power - 1000 VA
ARTIKEL1 - EASY UPS SRV RM 1000VA 230V
ARTIKEL2 - IN
ARTIKEL2 - WITH RAILKIT IN
Battery - Automatic battery test - Yes
Battery - Battery recharge time - 4 h
Battery - Battery technology - Sealed Lead Acid (VRLA)
BatteryType - -
Brand - APC
BrandPartCode - SRV1KRI
BrandPartCode - SRV1KRIRK
Category - Root/Accessories | Exploitation/Power supply/UPSs and power strips/Management cards
Category - Root/Accessories | Exploitation/Power supply/UPSs and power strips/UPSs
Category - Uninterruptible Power Supplies (UPSs)
Certificates - Certification - CE, IEC 62040-1-1, IEC 62040-1-2
REACH
Certificates - Compliance certificates - RoHS
Certification - CE, IEC 62040-1-1, IEC 62040-1-2
Charging time - 4 h
Chassis type - Rack
Color - Black
ControlPanel - Multi-function LCD status and control console
Depth - 312 mm
Depth, mm - 312
Description - APC EASY UPS SRV RM 1000VA 230V
Description - APC EASY UPS SRV RM 1000VA 230V ,WITH RAILKIT
Description - High-performance double-conversion UPS designed to meet basic power protection needs, even under the most unstable power conditions
Design - Display type - LCD
Design - Form factor - Rackmount
Design - LED indicators - Yes
Design - Product colour - Black
Design - Rack capacity - 2U
Designation - CE+WEEE
dimension depth - 290 mm
dimension height - 560 mm
Dimensions - 8,6 x 43,7 x 31,2 cm
dimension weight - 15700 g
dimension width - 450 mm
ean - ABEAN-AU71125
EANCode - 0731304341666
EANCode - 0731304346166
Eans - 731304341666
Eans - 731304346166
Environment requirements - Operating temperature 0 - 40 ° C Relative humidity during operation 0-95% Operating altitude 0-9000 meters Storage temperature -20 - 50 ° C Relative humidity during storage 0-95% Storage altitude 0-15000 meters Audible noise at 1 meter distance from the device surface 50.0 dBA Protection class IP 20
Features - Audible alarm(s) - Yes
Features - Audible alarm modes - Alarm when on battery, Fault, Low battery alarm, Overload alarm
Features - Audible alarm modes - Alarm when on battery, Low battery alarm, Overload alarm
Features - Auto-restart - Yes
Features - Crest factor - 3:1
Features - ECO mode - Yes
Features - Efficiency - 88%
Features - Emergency Power Off (EPO) - No
Features - Input frequency - 40/70 Hz
Features - Input operation voltage (max) - 280 V
Features - Input operation voltage (min) - 160 V
Features - Input power factor - 0.95
Features - Maintenance-free - Yes
Features - Noise level - 50 dB
Features - Number of input phases - 1
Features - Number of output phases - 1
Features - Output frequency - 50/60 Hz
Features - Output operation voltage (max) - 240 V
Features - Output operation voltage (min) - 220 V
Features - Output power - 800 W
Features - Output power capacity - 1 kVA
Features - Output power factor - 0.8
Features - Output voltage regulation - 1%
Features - Output voltage Total Harmonic Distortion (THD) - 3%
Features - Socket circuit breaker - Yes
Features - Surge energy rating - 600 J
Features - Transfer time (Line Mode to Battery Mode) - 0 ms
Features - UPS topology - Double-conversion (Online)
Features - Waveform - Sine
Form factor - Rack
FormFactor - Tower
Gewicht - 21
GrossWeight - -
GRUPPE1 - Power Protection
GRUPPE2 - UPS (Uninterruptable Power Supply)
GTIN - 0731304341666
GTIN - 731304341666
GTIN - 0731304346166
GTIN - 731304346166
GTIN - 8592978154929
guarantee - 24
guarantee_type - external
Height - 86 mm
Height - 225.000000
Height - 290.000000
Height, mm - 86
HERSTELLER - APC
HSTNUMMER - SRV1KRI
HSTNUMMER - SRV1KRIRK
I/O connectors - 1 x RS-232 (COM)
I/O connectors - 1 x USB (Power)
Input connection - IEC-320 C14
InputConnections - IEC-320 C14
InputFrequency - 40-70 Hz
Input frequency, Hz - 40-70
Input power ports - IEC-C14
InputVoltage - 230 V
InterfacePorts - -
Length - 550.000000
Length - 556.000000
Logistics data - Harmonized System (HS) code - 85078000
LongDesc -
LongDesc - For small to medium businesses, APC by Schneider Electric delivers a new category of UPSs designed for essential power protection needs even in the most unstable power conditions. APC Easy UPS 1 Ph Online is a versatile, high quality, cost competitive UPS developed to handle a wide voltage range, inconsistent power conditions and delivering the quality millions of IT professionals trust around the world.
LongDesc - This APC Single phase Easy UPS is designed for IT professionals or network administrators to maintain business uptime and continuity. This 1000VA double-conversion on-line 2U rackmount UPS provides pure sine wave power to support critical electronics during power disruptions. The SRV comes with IEC 320 C14 input and 3x IEC 320 C13 outlets. The On-Line UPS has a intelligent card slot for optional Network Management Card (AP9544, SRVSMB001, VGL9601l) that enables network-based UPS monitoring and management. The UPS can connect to EcoStruxure IT or third-party centralized management platforms. The Built-in automatic and manual bypass provide seamless power to the load even in the event of an internal detected fault or error in UPS. The SRV UPS is compatible with replacement battery cartridge APCRBCV200. The UPS is compatible with SRVRK1 rail kit sold separately. The UPS and the built-in lead-acid battery has a 2-year warranty. Ideal for small data centers, manufacturing facilities, computer rooms, network storage devices, telecommunication, and healthcare IT.
LongProductName - Easy UPS On-Line, 1000VA/800W, Rackmount 2U, 230V, 3x IEC C13 outlets, Intelligent Card Slot, LCD, W/O rail kit
LongProductName - Easy UPS On-Line SRV RM, 1000 VA, 230V, w / Rail Kit
LongSummaryDescription - APC Easy UPS On-Line, 1000VA/800W, Rackmount 2U, 230V, 3x IEC C13 outlets, Intelligent Card Slot, LCD, W/O rail kit. UPS topology: Double-conversion (Online), Output power capacity: 1 kVA, Output power: 800 W. AC outlet types: C13 coupler, Power plug: C14 coupler, AC outlets quantity: 3 AC outlet(s). Battery technology: Sealed Lead Acid (VRLA), Battery recharge time: 4 h. Form factor: Rackmount, Product colour: Black, Rack capacity: 2U. Compliance certificates: RoHS, Certification: CE, IEC 62040-1-1, IEC 62040-1-2 REACH
LongSummaryDescription - APC SRV1KRIRK. UPS topology: Double-conversion (Online), Output power capacity: 1 kVA, Output power: 800 W. Power plug: C14 coupler, AC outlets quantity: 3 AC outlet(s), Serial interface type: RS-232. Form factor: Rackmount, Product colour: Black, Display type: LCD. Compliance certificates: RoHS, Certification: CE, IEC 62040-1-1, IEC 62040-1-2 REACH. Width: 437 mm, Depth: 312 mm, Height: 86 mm
Manufacturer - APC
ManufacturerPartNumber - SRV1KRI
ManufacturerPartNumber - SRV1KRIRK
MANUFDATASHEET - https://www.apc.com/shop/mk/en/products/APC-Easy-UPS-On-Line-SRV-RM-1000-VA-230V-with-Rail-Kit/P-SRV1KRIRK
Name - APC SRV1KRI
Name - APC SRV1KRIRK
name - SRV1KRIRK Easy UPS SRV 1kVA/800W with rack kit
Nominal input voltage, V - 230
Nominal output voltage, V - 230
Number of phases input - 1 (230V)
Operating relative humidity range, % - 0-95
Operating temperature range (T-T), °C - 0-40
Operational conditions - Non-operating altitude - 0 - 14763.6 m
Operational conditions - Operating altitude - 0 - 3000 m
Operational conditions - Operating altitude - 0 - 9000 m
Operational conditions - Operating relative humidity (H-H) - 0 - 95%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 0 - 95%
Operational conditions - Storage temperature (T-T) - -20 - 50 °C
Other features - Approvals: CE, IEC 62040-1-1, IEC 62040-1-2
Other features - Nominal input voltage - 230 V
Other features - Nominal output voltage - 230 V
OutputConnections - -
OutputFrequency - 50/60 Hz +/- 1 Hz
Output power, W - 800
Output power, W - 3000
Output power capacity (VA) - 1000
Output power capacity (VA) - 3000
Output power ports - 3 x IEC-C13
OutputVoltage - 230 V
PackageContents -
CD with softwareRack Mounting support railsUser Manual
Packaging content - Cables included - USB cable
Packaging content - Manual - Yes
Packaging content - Rack mount kit - Yes
Packaging data - Package depth - 551 mm
Packaging data - Package height - 218 mm
Packaging data - Package weight - 13.1 kg
Packaging data - Package width - 455 mm
Packaging data - Software CD - Yes
PeriodofWarranty - 2 Y
Ports & interfaces - AC outlets quantity - 3 AC outlet(s)
Ports & interfaces - AC outlet types - C13 coupler
Ports & interfaces - Power plug - C14 coupler
Ports & interfaces - Serial interface - Yes
Ports & interfaces - Serial interface type - RS-232
Ports & interfaces - Serial ports quantity - 1
Ports & interfaces - SmartSlot - Yes
Ports & interfaces - USB 2.0 ports quantity - 1
Ports & interfaces - USB port - Yes
Ports & interfaces - USB port type - USB Type-B
PowerVAW - 1000 VA
PowerW - 800 W
ProdDesc - APC Easy UPS On-Line SRV RM 1000 VA 230V with Rail Kit
producer - APC
Producer - APC
ProducerCode - SRV1KRI
ProducerCode - SRV1KRIRK
ProductName - Easy UPS On-Line, 1000VA/800W, Rackmount 2U, 230V, 3x IEC C13 outlets, Intelligent Card Slot, LCD, W/O rail kit
ProductName - SRV1KRIRK
ProductPicture - http://www.tdbaltic.ee/images/ds4/battery_v2.jpg
ProductPicture2 -
ProductPicture3 -
ProductPicture4 -
RechargeTime - -
RJ45 - -
Runtime - -
ShortDescription -
ShortSummaryDescription - APC Easy UPS On-Line, 1000VA/800W, Rackmount 2U, 230V, 3x IEC C13 outlets, Intelligent Card Slot, LCD, W/O rail kit, Double-conversion (Online), 1 kVA, 800 W, Sine, 160 V, 280 V
ShortSummaryDescription - APC SRV1KRIRK, Double-conversion (Online), 1 kVA, 800 W, Sine, 160 V, 280 V
SmartSlot - -
Software -
Special functions -
Stck_Kart - 1
Stck_Pal - 1
Stck_Pal - 16
Storage temperature range (T-T), °C - -20-50
Storno - N
Title - APC Easy UPS On-Line, 1000VA/800W, Rackmount 2U, 230V, 3x IEC C13 outlets, Intelligent Card Slot, LCD, W/O rail kit
Title - APC SRV1KRIRK uninterruptible power supply (UPS) Double-conversion (Online) 1 kVA 800 W 3 AC outlet(s)
Topology - Line interactive
UPS Architecture - on-line double conversion
UPS devices and accessories - Yes
URL - https://www.apc.com/
URL - https://www.apc.com/shop/dk/en/products/APC-Easy-UPS-On-Line-SRV-RM-1000-VA-230V-with-Rail-Kit/P-SRV1KRIRK
USB - Yes
vendpn - SRV1KRIRK
Warranty - 2 years
WarrantyInfo - 2 years repair or replace
WaveformType - Sine wave
Weight - 11 kg
Weight - 11.000 Kg
Weight - 13.940000
Weight - 15.630000
Weight & dimensions - Battery depth - 55.1 cm
Weight & dimensions - Battery height - 21.8 cm
Weight & dimensions - Battery weight - 13.1 kg
Weight & dimensions - Battery width - 45.5 cm
Weight & dimensions - Depth - 312 mm
Weight & dimensions - Height - 86 mm
Weight & dimensions - Weight - 11 kg
Weight & dimensions - Width - 437 mm
Weight, kg - 11
Width - 437 mm
Width - 448.000000
Width - 450.000000
Width, mm - 437
