ID: 173250
Product code: EL1200USBIEC
In stock 1 units
Warranty: 2 years
Eaton EL1200USBIEC, 1200VA 750W, IEC
Picture may differ from actual product, there can be accessories and parts not supplied with the actual product.
Delivery options
- Delivery to Smartpost 1.99 €: on Monday, 17.03.2025
- Delivery to Omniva parcel locker 1.99 €: on Monday, 17.03.2025
- Courier delivery 3.99 €: on Monday, 17.03.2025
Main product parameters All parameters
- Battery capacity (VA): 1200 VA
- Output power (W): 750 W
Display characteristics
Display
: Nav
Basic information
Battery capacity (VA)
1200 VA
The capacity of the battery pack is the index of the long-term operation of the UPS device without a permanent power supply source. This parameter applies to a UPS device with a fully charged battery pack. If you want to verify how big capacity is required for your computer equipment visit www.apc.ru where you will find the UPS capacity determination configuration tool.
Battery type
: Lead acid
Charging time (hours)
: Nav norādīts
Output power (W)
: 750 W
Ports and equipment
Number of nests (total)
: 8
Number of sockets (Battery Backup)
: 4
RJ-45
: 2
Socket type
: IEC320
USB
: 0
More detailed specification
Alarm - -
ARTIKEL1 - EATON ELLIPSE ECO 1200 USB IEC
ARTIKEL2 - IN
Battery - Automatic battery test - Yes
Battery - Battery technology - Sealed Lead Acid (VRLA)
Battery - Cold start - Yes
Battery - Hot-swap battery - No
Battery - Typical backup time at half load - 10 min
BatteryType - Replaceable sealed lead acid
Breite - 0.36
Category Code - UPW
CnCode CnCode - 85044095
Color - -
ControlPanel - -
Depth - 312 mm
Description - Eaton Ellipse ECO 1200 IEC USB
Design - Form factor - Tower
Design - LED indicators - Battery replacement
Design - Product colour - Black
Design - Rack capacity - 2U
Design - Safety - IEC 62040-1, IEC 60950-1, IEC 62040-2, CB Report, CE mark, IEC 61643-1
Desktop/pedestal Mounting Type - Yes
dimensionalWeight - 3931
Dimensions - 305 x 81 x 312mm
EANCode - 3553340621239
Features - Audible alarm(s) - Yes
Features - Audible alarm modes - Battery replacement
Features - Emergency Power Off (EPO) - No
Features - Input frequency - 50/60 Hz
Features - Input operation voltage (max) - 284 V
Features - Input operation voltage (min) - 161 V
Features - Output operation voltage (max) - 240 V
Features - Output operation voltage (min) - 220 V
Features - Output power - 750 W
Features - Output power capacity - 1.2 kVA
Features - Surge protection - Yes
Features - Surge protection features - Fax
Features - Surge protection features - Modem
Features - Surge protection features - Network
Features - Surge protection features - Telephone
Features - UPS topology - Standby (Offline)
FormFactor - Other
Full Description Line - 750 Watts|1200 VA|Input ports Single, IEC320 C14|Output power connector type IEC 320 C13|1xUSB|Desktop/pedestal|Rack
GrossWeight - 7.750 kg
GRUPPE1 - Power Protection
GRUPPE2 - UPS (Uninterruptable Power Supply)
Height - 305 mm
HERSTELLER - EATON
Hoehe - 0.14
HSTNUMMER - EL1200USBIEC
InputConnections - -
InputFrequency - 50-60 Hz autoselect
Input ports - Single, IEC320 C14
InputVoltage - 184 V - 264 V (adjustable to 161 V - 284 V)
InterfacePorts - -
Laenge - 0.4
Logistics data - Harmonized System (HS) code - 85078000
LongDesc - With an efficient electrical design and the EcoControl function (USB models), which automatically disables peripherals when the master device is turned off, the Eaton Ellipse ECO helps you make energy savings of up to 25 per cent compared to previous-generation UPSs.
MANUFDATASHEET - http://www.google.ee/url?sa=t&rct=j&q=&esrc=s&frm=1&source=web&cd=1&cad=rja&ved=0CCgQFjAA&url=http%3A%2F%2Flit.powerware.com%2Fll_download.asp%3Ffile%3DEaton-Ellipse-ECO-datasheet-rev-B-low-pdf.pdf&ei=RuKAUpzhBsPNhAf2mYHIDg&usg=AFQjCNHHroTtcgPB-33mgzDEb-J4xFyDpg&bvm=bv.56146854,d.bGE
Other features - Compatible operating systems - Windows 7/Vista/XP\r\nMac OS X\r\nLinux
Other features - Input connection type - IEC
Other features - Mac compatibility - Yes
Other features - Nominal input voltage - 230 V
Other features - Nominal output voltage - 220-240 V
Other features - Overload protection - Yes
OutputConnections - 8
OutputFrequency - -
Output power capacity, VA - 1200 VA
Output power capacity, W - 750 Watts
Output power connector type - IEC 320 C13
OutputVoltage - 230 V (adjustable to 220 V, 230 V, 240 V
PackageContents - -
Packaging data - Bundled software - Eaton Intelligent Power
Ports & interfaces - AC outlets quantity - 8 AC outlet(s)
Ports & interfaces - AC outlet types - C13 coupler
Ports & interfaces - Ethernet LAN (RJ-45) ports - 1
Ports & interfaces - Modem (RJ-11) ports - 1
Ports & interfaces - Power plug - C14 coupler
Ports & interfaces - USB 2.0 ports quantity - 1
PowerVAW - 1200 VA
PowerW - 750 W
ProdDesc - 1200VA/750W UPS, offline, IEC 4+4, Windows/MacOS/Linux support, USB
producerCode - EL1200USBIEC
productName - Eaton Ellipse ECO 1200 USB IEC uninterruptible power supply (UPS) Standby (Offline) 1.2 kVA 750 W 8 AC outlet(s)
ProductPicture - http://www.tdbaltic.ee/images/ds4/EL800USBIEC-01.jpg
ProductPicture2 -
ProductPicture3 -
ProductPicture4 -
productSize - Normal
Rack Mounting Type - Yes
RechargeTime - -
RJ45 - -
Runtime - 10/6
Shipping Box Depth Shipping/Package Box Dimensions - 39.7 cm
Shipping Box Height Shipping/Package Box Dimensions - 35.7 cm
Shipping box quantity - 1
Shipping Box Weight Shipping/Package Box Dimensions - 7.6 kg
Shipping Box Width Shipping/Package Box Dimensions - 13.6 cm
sizeX - 140
sizeY - 390
sizeZ - 360
SmartSlot - -
Stck_Kart - 9998
Stck_Pal - 5
Storno - Y
Topology - Offline
Unit Box Height - 0.357
Unit Box Length - 0.397
Unit Box Width - 0.136
Unit Brutto Volume - 0.01928 cubm
Unit Gross Weight - 7.6 kg
Unit Net Weight - 6.7 kg
USB - Yes
USB Communication ports - 1
Vendor Homepage - powerquality.eaton.com/EL1200USBIEC.aspx?cx=66
Warranty - 2 years
Warranty - 24 months
warrantyLength - 24
warrantyType - F
WaveformType - -
Weight - 6.700 Kg
weight - 7690
Weight & dimensions - Depth - 312 mm
Weight & dimensions - Height - 305 mm
Weight & dimensions - Weight - 6.7 kg
Weight & dimensions - Width - 81 mm
Width - 81 mm
