ID: 147234
Product code: CHAMP 3K RACK
Can be ordered 8 units Availability: 14 days after order approval
Warranty: 2 years
FSP Champ Rack 3K, 3000VA 2700W
Picture may differ from actual product, there can be accessories and parts not supplied with the actual product.
Delivery options
- Courier delivery 3.99 €: 28.03.2025
Main product parameters All parameters
- Battery capacity (VA): 3000 VA
- Output power (W): 2700 W
Display characteristics
Display
: Ir
Basic information
Battery capacity (VA)
3000 VA
The capacity of the battery pack is the index of the long-term operation of the UPS device without a permanent power supply source. This parameter applies to a UPS device with a fully charged battery pack. If you want to verify how big capacity is required for your computer equipment visit www.apc.ru where you will find the UPS capacity determination configuration tool.
Battery type
: Nav norādīts
Charging time (hours)
: 4h
Output power (W)
: 2700 W
Ports and equipment
Number of nests (total)
: 3
Number of sockets (Battery Backup)
: 3
RJ-45
: 0
Socket type
: Schuko
USB
: 0
More detailed specification
Battery - Battery capacity - 9 Ah
Battery - Battery recharge time (90%) - 4 h
Battery - Battery voltage - 12 V
Battery - Number of battery cells - 6
Brand - FSP
BrandPartCode - PPF27A1102
Category - Uninterruptible Power Supplies (UPSs)
Category 1 - Energie & USV
Category 2 - USV & Stromversorgung
Certificates - Compliance certificates - CE
Code - CHAMP 3K RACK
Design - Built-in fan - Yes
Design - Control type - Buttons
Design - Cooling type - Active
Design - Display type - LCD
Design - Form factor - Rackmount
Design - LED indicators - Yes
Design - Product colour - Black
Design - Rack capacity - 2U
EAN - 2000000865683
EAN - 4713224520624
Features - Audible alarm(s) - Yes
Features - Audible alarm modes - Alarm when on battery, Fault, Low battery alarm, Overload alarm
Features - Crest factor - 3:1
Features - Input frequency - 40 - 70 Hz
Features - Input operation voltage (max) - 300 V
Features - Input operation voltage (min) - 120 V
Features - Noise level - 50 dB
Features - Output frequency - 47/63 Hz
Features - Output operation voltage (max) - 240 V
Features - Output operation voltage (min) - 110 V
Features - Output power - 2700 W
Features - Output power capacity - 3 kVA
Features - Output voltage regulation - 1%
Features - Power factor - 0.99
Features - Response time - 0 ms
Features - Total Harmonic Distortion (THD) (linear load) - 3%
Features - Total Harmonic Distortion (THD) (non-linear load) - 6%
Features - UPS topology - Double-conversion (Online)
Features - Waveform - Pure sine
Gross weight - 29.6 kg
GTIN - 4713224520624
Link - https://energy.fsp-europe.com/product/champ-rack-3k/
Logistics data - Harmonized System (HS) code - 85078000
LongDesc - FSP Champ Rack Series is the high density version of double-conversion online UPS with a output power factor 0.9. It’s designed in small cabinet with microprocessor controller. It also has USB and RS-232 communication ports as standard, with a built-in intelligent slot for additional adapters, protocol converters and relate contact cards.
LongProductName - 3000 VA, 2700 W, 110 - 240 V, 3:1, 438 x 630 x 88 mm, 29.3 kg
LongSummaryDescription - FSP Champ Rack 3K. UPS topology: Double-conversion (Online), Output power capacity: 3 kVA, Output power: 2700 W. AC outlet types: Type F, AC outlets quantity: 3 AC outlet(s), USB port type: USB Type-B. Battery capacity: 9 Ah, Battery voltage: 12 V, Battery recharge time (90%): 4 h. Form factor: Rackmount, Product colour: Black, Rack capacity: 2U. Compliance certificates: CE
Manufacturer - FSP
MPN - PPF27A1102
Name - FSP Champ 3K Rack Online UPS 3000VA 2700W
Name - FSP | Rack Series | CHAMP 3K RACK | 3000 VA | 110 - 300 V | 300 V | ± 1% (Batt. Mode) V
Operational conditions - Operating relative humidity (H-H) - 20 - 90%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Other features - Number of phases - 1
Other features - Packaging content - UPS, Power cable, USB cable, Software on CD, User manual
Other features > Dimensions (WxDxH) - 438 x 88 x 600 mm
Other features > Special features - Input power factor correction. Microprocessor control optimizes reliability. Output power factor 0.8.
Package features > Classification of battery - CL126:PE:2016-12-09
Package features > Composition of battery - CL127:NK:2016-12-09
Package features > Embeeded battery - Yes
Package features > Gross depth (mm) - 765 mm
Package features > Gross height (mm) - 250 mm
Package features > Gross width (mm) - 600 mm
Package features > Packing quantity - 1.00 pc(s)
Package features > Palette Qty - 15 pc(s)
Package features > Paper/Pasteboard - 755.00 g
Package features > Plastic (No PET) - 148.00 g
Package features > Tare weight (kg) - 0.903 kg
Package features > TI weight (kg) - 25.40 kg
Package features > Type of battery - Accumulator
Package features > Volume (m3) - 0.11475 m³
Package features > WEE classification - CL109:4:2017-04-01
Package features > WEEE tax - Yes
Packaging content - Batteries included - Yes
Packaging content - Cables included - Input power cable, USB cable
Packaging content - Manual - Yes
Packaging data - Software CD - Yes
Performance > Capacity - 3000 VA
Performance > UPS topology - On line
Ports & interfaces - AC outlets quantity - 3 AC outlet(s)
Ports & interfaces - AC outlet types - Type F
Ports & interfaces - RS-232 ports - 1
Ports & interfaces - Serial interface - Yes
Ports & interfaces - Serial interface type - RS-232
Ports & interfaces - USB 2.0 ports quantity - 1
Ports & interfaces - USB port - Yes
Ports & interfaces - USB port type - USB Type-B
Power > AC input frequency - 40 - 70 Hz
Power > AC input voltage - 110 - 300 V
Power > Input operation voltage (max) - 300 V
Power > Output operation voltage (min) - ± 1% (Batt. Mode) V
Power > Output power - 2400 W
Producer product family - Rack Series
Producer product name - CHAMP 3K RACK
ProductName - Champ Rack 3K
ShortSummaryDescription - FSP Champ Rack 3K, Double-conversion (Online), 3 kVA, 2700 W, Pure sine, 120 V, 300 V
Sustainability - Sustainability compliance - Yes
Technical details > Net weight - 28.697 kg
Technical details > Producer - FSP
Technical details > Warranty - 24 month(s)
Title - FSP Champ Rack 3K uninterruptible power supply (UPS) Double-conversion (Online) 3 kVA 2700 W 3 AC outlet(s)
URL - https://energy.fsp-europe.com/product/champ-rack-3k/
Warranty - 24
WarrantyInfo -
Weight - 29.76
Weight & dimensions - Depth - 630 mm
Weight & dimensions - Height - 88 mm
Weight & dimensions - Weight - 29.3 kg
Weight & dimensions - Width - 438 mm
Weight & dimensions > Weight - 29000 g
