ARTIKEL1 - TX-2202A 54.6CM 21.5IN
ARTIKEL2 - 10P PCAP TOUCH IP-65 METAL CASE
Brand - AG Neovo
BrandPartCode - TX2A0011E0100
Breite - 0
Category - Computer Monitors
Design - Glass thickness - 2.05 mm
Design - Housing material - Metal
Design - Market positioning - Office
Design - Product colour - Black
Display - Anti-glare screen - Yes
Display - Contrast ratio (typical) - 1000:1
Display - Display brightness (typical) - 250 cd/m²
Display - Display diagonal - 54.6 cm (21.5")
Display - Display number of colours - 16.7 million colours
Display - Display resolution - 1920 x 1080 pixels
Display - Display technology - LCD
Display - Haze rate - 25%
Display - HD type - Full HD
Display - Horizontal scan range - 30 - 84 kHz
Display - Native aspect ratio - 16:9
Display - Number of simultaneous touchpoints - 10
Display - Panel type - VA
Display - Pixel pitch - 0.248 x 0.248 mm
Display - Response time - 5 ms
Display - Screen shape - Flat
Display - Surface hardness - 7H
Display - Touchscreen - Yes
Display - Touchscreen technology - Capacitive
Display - Touch technology - Multi-touch
Display - Vertical scan range - 50 - 76 Hz
Display - Viewing angle, horizontal - 178°
Display - Viewing angle, vertical - 178°
EANCode - 4710739597967
Ergonomics - Panel mounting interface - 100 x 100 mm
Ergonomics - Tilt angle range - -5 - 90°
Ergonomics - VESA mounting - Yes
GRUPPE1 - Displays
GRUPPE2 - Led Small Format
GTIN - 4710739597288
GTIN - 4710739597967
HERSTELLER - AG NEOVO TECHNOLOGY
Hoehe - 0
HSTNUMMER - TX2A0011E0100
Laenge - 0
LongDesc - The TX-2202A touch screen monitor adopts PCAP multi-touch technology that is relatively unaffected by contamination, offering 10-point multi-touch capability, giving an accurate and responsive touch experience, even responsiveness to latex gloves. Featuring DisplayPort, HDMI, VGA input connectivity, and dual speakers, the TX-2202A touch monitor is built for flexible use such as self-check-in, self-ordering, and information kiosk. The screen is complemented by the IP65 and IK08 rating, metal casing, and an edge-to-edge 7H tempered glass design, enhancing durability for continuous operation in public and high-traffic spaces.10-point PCAP Touch ScreenThe TX-2202A 22” 10-point touch screen monitor adopts PCAP touch technology with a 10-point multi-touch capability that is unaffected by contamination, giving a fast, accurate, and responsive touch experience. These seamless touch senses are identical to those used in smartphones and tablets, even responsive to latex gloves.Seamless IntegrationTouch support works with various operating systems, compatible with Windows, Linux, macOS, and certain Android versions. This enables more choices of the operating system you use.Front IP65 Dust and Water ProtectionThis 22” 10-point touch screen monitor with a front-sided IP65 rating is designed to protect from dust and liquid spills, making it ideal for high-use public locations.DURABLE AND SCRATCH RESISTANT TOUCH SCREENFor 24/7 operations in public settings, AG Neovo uses metal housing and 7H tempered glass displays to offer high durability and scratch resistance levels, all without compromising touch sensitivity.ERGONOMIC MONITORS WITH FLEXIBLE MOUNTINGThanks to VESA compatibility, the TX-2202A 22” 10-point touch screen monitor offers flexible mounting options, from desk mount to wall mount or attached to a monitor arm. The included ergonomic stand allows a huge -2 to 180 degrees of tilt adjustment, creating extra ergonomics when using. The display is 178-degrees wide viewing angles to provide consistent colour performance for better viewing.Versatile ConnectivityThe TX-2202A provides maximum versatility and facilitates users to connect to their own devices, such as a high-performance PC or a media player, using the DisplayPort, HDMI or VGA inputs.
LongProductName - 21.5", VA, 1920 x 1080px, 250 cd/m², 1000:1, 16.7M, 5 ms, 1 x DisplayPort, 1 x HDMI, 1 x VGA, RJ-11, 2 x 2W, 6.7 kg
LongSummaryDescription - AG Neovo TX-2202A. Display diagonal: 54.6 cm (21.5"), Display resolution: 1920 x 1080 pixels, HD type: Full HD, Display technology: LCD, Response time: 5 ms, Native aspect ratio: 16:9, Viewing angle, horizontal: 178°, Viewing angle, vertical: 178°. Built-in speaker(s). VESA mounting. Product colour: Black
Multimedia - Built-in camera - No
Multimedia - Built-in speaker(s) - Yes
Multimedia - Number of speakers - 2
Multimedia - RMS rated power - 4 W
Operational conditions - Operating relative humidity (H-H) - 20 - 80%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 10 - 90%
Operational conditions - Storage temperature (T-T) - -20 - 60 °C
Other features - Compliance certificates - CE, Low Voltage Directive (LVD), REACH, RoHS, UKCA, WEEE
Other features - International Protection (IP) code - IP65
Other features - Protection features - Dust resistant, Waterproof
Other features - Transmission rate - 90%
Packaging content - Cables included - AC, Audio, HDMI, USB, VGA
Packaging content - Power adapter included - Yes
Packaging content - Quick start guide - Yes
Packaging data - Package depth - 320 mm
Packaging data - Package height - 460 mm
Packaging data - Package weight - 9.8 kg
Packaging data - Package width - 610 mm
Performance - AMD FreeSync - No
Performance - Mac operating systems supported - Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave
Performance - NVIDIA G-SYNC - No
Performance - Other operating systems supported - Android
Performance - Windows operating systems supported - Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 11, Windows 11 Enterprise, Windows 11 Enterprise x64, Windows 11 Home, Windows 11 Pro, Windows 11 x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64
Ports & interfaces - Audio input - Yes
Ports & interfaces - Built-in USB hub - No
Ports & interfaces - DisplayPorts quantity - 1
Ports & interfaces - HDMI - Yes
Ports & interfaces - HDMI ports quantity - 1
Ports & interfaces - HDMI version - 1.4
Ports & interfaces - Headphone out - No
Ports & interfaces - Number of USB Type-B upstream ports quantity - 1
Ports & interfaces - USB upstream port type - USB Type-B
Ports & interfaces - VGA (D-Sub) ports quantity - 1
Power - Energy consumption (SDR) per 1000 hours - 15 kWh
Power - Energy efficiency class (HDR) - Not available
Power - Energy efficiency class (SDR) - E
Power - European Product Registry for Energy Labelling (EPREL) code - 1372216
Power - Power consumption (off) - 0.3 W
Power - Power consumption (standby) - 0.7 W
Power - Power consumption (typical) - 15 W
Power - Power supply type - External
ProductName - TX-2202A
ShortSummaryDescription - AG Neovo TX-2202A, 54.6 cm (21.5"), 1920 x 1080 pixels, Full HD, LCD, 5 ms, Black
Stck_Kart - 1
Stck_Pal - 7
Storno - Y
Sustainability - Sustainability compliance - Yes
Title - AG Neovo TX-2202A computer monitor 54.6 cm (21.5") 1920 x 1080 pixels Full HD LCD Touchscreen Black
URL - https://www.agneovo.com/global/touchscreens/touch-monitors/tx-series/tx-2202a
WarrantyInfo -
Weight & dimensions - Depth (without stand) - 48.5 mm
Weight & dimensions - Depth (with stand) - 214.2 mm
Weight & dimensions - Height (without stand) - 324.3 mm
Weight & dimensions - Height (with stand) - 346.7 mm
Weight & dimensions - Weight (without stand) - 4.8 kg
Weight & dimensions - Weight (with stand) - 6.7 kg
Weight & dimensions - Width (without stand) - 528.6 mm
Weight & dimensions - Width (with stand) - 528.6 mm
