Accessories included -
ARTIKEL1 - TM-22 54.6CM 21.5IN LED
ARTIKEL2 - 10TP MULTITOUCH HDMI
Aspect ratio - 16:9
Brand - AG Neovo
BrandPartCode - TM220011E0100
Breite - 0.42
Brightness - 220 cd/m²
Category - Computer Monitors
Certificates - CB
Certificates - CE
Certificates - FCC Class B
Certificates - GOST-R
Certificates - RoHS
Color - Black
Depth - 385 mm
Description - Thanks to TM-22 AG Neovo, industry professionals can fit into the budget without losing the quality of operation. Thanks to the advanced capacitive touch technology, the TM-22 is not only a stylish design, the monitor also offers a smooth and accurate touch response. In addition to LED backlight and Full HD resolution, the display supports 10 touch points, ensuring seamless compatibility with Windows 7 and 8 touch functions. The flexible two-hinged base provides convenience and efficient use for many users. TM-22 is the perfect solution for a variety of interactive environments.
Design - Certification - FCC, CE, LVD, WEEE, RoHS, REACH, EAC, UKCA
Design - Glass thickness - 2.4 mm
Design - Market positioning - Business
Design - Product colour - Black
dimensionalWeight - 8413
dimension depth - 420 mm
dimension height - 580 mm
dimension weight - 8000 g
dimension width - 190 mm
Display - Backlight type - LED
Display - Contrast ratio (typical) - 20000000:1
Display - Digital horizontal frequency - 30 - 83 kHz
Display - Digital vertical frequency - 55 - 75 Hz
Display - Display brightness (typical) - 250 cd/m²
Display - Display diagonal - 54.6 cm (21.5")
Display - Display diagonal (metric) - 55 cm
Display - Display number of colours - 16.78 million colours
Display - Display resolution - 1920 x 1080 pixels
Display - Display technology - LCD
Display - HD type - Full HD
Display - Maximum refresh rate - 60 Hz
Display - Native aspect ratio - 16:9
Display - Number of simultaneous touchpoints - 10
Display - Panel type - TN
Display - Pixel pitch - 0.248 x 0.248 mm
Display - Response time - 3 ms
Display - Screen shape - Flat
Display - Surface hardness - 7H
Display - Touchscreen - Yes
Display - Touchscreen technology - Capacitive
Display - Touchscreen type - Multi-user
Display - Touch technology - Multi-touch
Display - Viewable size diagonal - 54.6 cm
Display - Viewing angle, horizontal - 170°
Display - Viewing angle, vertical - 160°
Dot pitch - 0.248 mm
ean - 4710739592429
EANCode - 4710739592429
Ergonomics - Cable lock slot - Yes
Ergonomics - Cable lock slot type - Kensington
Ergonomics - Height adjustment - 38.7 cm
Ergonomics - Height adjustment - Yes
Ergonomics - Panel mounting interface - 100 x 100 mm
Ergonomics - Plug and Play - Yes
Ergonomics - Tilt adjustment - Yes
Ergonomics - Tilt angle range - -5 - 90°
Ergonomics - VESA mounting - Yes
Ergonomics - Wall mountable - Yes
Frequency, horizontal max. - 83 kHz
Frequency, horizontal min. - 30 kHz
Frequency, vertical max. - 75 Hz
Frequency, vertical min. - 55 Hz
Gewicht - 7.64
GRUPPE1 - Displays
GRUPPE2 - Lcd Touchscreen
GTIN - 0813086002987
GTIN - 813086002987
GTIN - 4710739592429
guarantee - 36
guarantee_type - normal
Height - 238.5 mm
HERSTELLER - AG NEOVO TECHNOLOGY
Hoehe - 0.18
HSTNUMMER - TM22E011E0100
I/O connectors - 1 x 3,5 mm minijack
I/O connectors - 1 x 15-pin D-Sub
I/O connectors - 1 x DisplayPort
I/O connectors - 1 x HDMI
I/O connectors - 4 x USB 3.0
Laenge - 0.59
Logistics data - Harmonized System (HS) code - 85285210
LongDesc - With the AG Neovo TM-22, industry professionals can keep an eye on budgets without losing sight of performance. Incorporating the advanced projected capacitive touch technology, the TM-22 not only comes with a stylish design but also offers smooth and accurate touch response. On top of LED backlighting and Full HD resolution, it comes with 10-point multi-touch capability that delivers seamless compatibility with Windows® 7, 8 & 10 touch functions. The flexible dual-hinge stand ensures multi-user comfort and productivity. The TM-22 is the ideal multi-touch solution for a great diversity of interactive environments.
LongProductName - 21.5" LED TFT LCD, 1920x1080, 0.248x0.248mm, 220cd/m2, 1000:1, 170°/160°, 3ms, D-Sub, HDMI, DisplayPort, USB3.0x4, 2Wx2
LongSummaryDescription - AG Neovo TM-22. Display diagonal: 54.6 cm (21.5"), Display resolution: 1920 x 1080 pixels, HD type: Full HD, Display technology: LCD, Response time: 3 ms, Native aspect ratio: 16:9, Viewing angle, horizontal: 170°, Viewing angle, vertical: 160°. Built-in speaker(s). Built-in USB hub, USB hub version: 3.2 Gen 1 (3.1 Gen 1). VESA mounting, Height adjustment. Product colour: Black
Matrix type - TFT LCD
Model - TM-22
Multimedia - Built-in camera - No
Multimedia - Built-in microphone - No
Multimedia - Built-in speaker(s) - Yes
Multimedia - Number of speakers - 2
Multimedia - RMS rated power - 2 W
name - Touch screen TM-22 22 inches Full HD Multi-Touch
Number of colors - 16,7 mln
Operational conditions - Operating relative humidity (H-H) - 10 - 85%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 5 - 93%
Operational conditions - Storage temperature (T-T) - -25 - 55 °C
Optional accessory -
Other features -
Packaging content - Cables included - AC, Audio (3.5mm), HDMI, USB
Packaging data - Package depth - 186 mm
Packaging data - Package height - 422 mm
Packaging data - Package weight - 8.1 kg
Packaging data - Package width - 586 mm
Performance - AMD FreeSync - No
Performance - NVIDIA G-SYNC - No
Performance - Operating hours (hours/days) - 24/7
Performance - Operating system installed - Windows 10
Ports & interfaces - Audio input - 1
Ports & interfaces - Built-in USB hub - Yes
Ports & interfaces - DisplayPorts quantity - 1
Ports & interfaces - HDMI - Yes
Ports & interfaces - HDMI ports quantity - 1
Ports & interfaces - HDMI version - 1.3
Ports & interfaces - Headphone connectivity - 3.5 mm
Ports & interfaces - Headphone out - Yes
Ports & interfaces - Headphone outputs - 1
Ports & interfaces - Number of upstream ports - 4
Ports & interfaces - USB hub version - 3.2 Gen 1 (3.1 Gen 1)
Ports & interfaces - VGA (D-Sub) ports quantity - 1
Power - AC input frequency - 50 - 60 Hz
Power - AC input voltage - 100 - 240 V
Power - Energy consumption (SDR) per 1000 hours - 14 kWh
Power - Energy efficiency class (SDR) - E
Power - Energy efficiency scale - A to G
Power - Power consumption (off) - 0.3 W
Power - Power consumption (standby) - 0.5 W
Power - Power consumption (typical) - 22 W
Power - Power supply type - Internal
Power consumption - 25 W
producer - AG NEOVO
producerCode - TM-22
productName - AG Neovo TM-22 touch screen monitor 54.6 cm (21.5") 1920 x 1080 pixels Multi-user Black
ProductName - TM-22
productSize - Normal
Resolution - 1920 x 1080 (FHD 1080)
Response time - 7 ms
Screen size (diag.) - 21.5"
ShortSummaryDescription - AG Neovo TM-22, 54.6 cm (21.5"), 1920 x 1080 pixels, Full HD, LCD, 3 ms, Black
sizeX - 410
sizeY - 570
sizeZ - 180
Speakers built-in - Yes
Static contrast - 1 000:1
Stck_Kart - 1
Stck_Pal - 9
Storno - Y
Sustainability - European Product Registry for Energy Labelling (EPREL) code - 430365
Sustainability - Sustainability certificates - CE, Federal Communications Commission (FCC), Low Voltage Directive (LVD), REACH, RoHS, UKCA, WEEE
Title - AG Neovo TM-22 computer monitor 54.6 cm (21.5") 1920 x 1080 pixels Full HD LCD Touchscreen Multi-user Black
Touch screen - Yes
Transreflective technology - LED
TV tuner built-in - No
URL - https://nl.agneovo.com/global/content/tm-22.asp
vendpn - TM-22
VESA - 100 x 100
Viewing angle, horizontal - 170 °
Viewing angle, vertical - 160 °
Warranty -
WarrantyInfo -
warrantyLength - 36
warrantyType - F
Web camera - None
Weight - 6.6 kg
weight - 7854
Weight & dimensions - Depth (without stand) - 57.2 mm
Weight & dimensions - Depth (with stand) - 238.5 mm
Weight & dimensions - Height (without stand) - 318.4 mm
Weight & dimensions - Height (with stand) - 387.4 mm
Weight & dimensions - Weight (without stand) - 3.9 kg
Weight & dimensions - Weight (with stand) - 6.3 kg
Weight & dimensions - Width (without stand) - 522.4 mm
Weight & dimensions - Width (with stand) - 522.4 mm
Width - 522.5 mm
