Intel Core i7-14700 (8P+12E/28T, 2.1GHz, 33MB Cache, LGA1700, 65W)

Architecture - 64-bit
ARTIKEL1 - CORE I7-14700 2.10GHZ .
ARTIKEL2 - SKTLGA1700 33.00MB CACHE BOXED
Breite - 0.11
Cache - 33MB
category - PC Components|CPUs / Processors|Intel Processors|Sockel 1700
Category - Root/Electronics/PC parts/Processors
Category 1 - CPUs
Category 2 - Intel CPUs
Category Code - CPU
Category_1 - Processors
Category_2 - Processors - Intel 1700
Clock speed - 2100 MHz
code - BX8071514700
Code - BX8071514700
Compatible with -
Core name - Raptor Lake
CPU application - Desktop
CPU Boost frequency - 5.4 GHz
CPU code - BX8071514700
CPU Family name - Core i7
CPU socket - LGA1700
Description -
Description - Boxed Intel® Core™ i7 processor 14700 (33M Cache, up to 5.40 GHz) FC-LGA16A
dimensionalWeight - 204
dimension depth - 80 mm
dimension height - 125 mm
dimension weight - 450 g
dimension width - 105 mm
EAN - 5032037279239
ean - 5032037279239
EANCode - 5032037279239
Eans - 5032037279239
EAN_code - 5032037279239
ECC support - Yes
Extra cooling - Yes
Features - Commodity Classification Automated Tracking System (CCATS) - 740.17B1
Features - CPU configuration (max) - 1
Features - Direct Media Interface (DMI) Revision - 4.0
Features - Embedded options available - Yes
Features - Execute Disable Bit - Yes
Features - Export Control Classification Number (ECCN) - 5A992C
Features - Idle States - Yes
Features - Market segment - Desktop
Features - Maximum number of PCI Express lanes - 20
Features - PCI Express configurations - 1x16+1x4
Features - PCI Express configurations - 2x8+1x4
Features - PCI Express slots version - 4.0
Features - PCI Express slots version - 5.0
Features - Scalability - 1S
Features - Supported instruction sets - AVX 2.0
Features - Supported instruction sets - SSE4.1
Features - Supported instruction sets - SSE4.2
Features - Thermal Monitoring Technologies - Yes
Features - Use conditions - PC/Client/Tablet
Features - Use conditions - Workstation
Frequency speed - 3200/5600 MHz
Full Description Line - Desktop|Core i7|i7-14700|Raptor Lake|2100 MHz|Number of cores 20|Cache 33MB|Socket LGA1700|Wattage 65 Watts|Turbo frequency 5400 MHz|GPU Model UHD 770|Packing type BOX
Gewicht - 0.45
GPU Model - UHD 770
Graphics - Discrete graphics card - No
Graphics - Discrete graphics card model - Not available
Graphics - Multi-Format Codec Engines - 2
Graphics - Number of displays supported (on-board graphics) - 4
Graphics - Number of execution units - 32
Graphics - On-board graphics card - Yes
Graphics - On-board graphics card base frequency - 300 MHz
Graphics - On-board graphics card DirectX version - 12.0
Graphics - On-board graphics card dynamic frequency (max) - 1600 MHz
Graphics - On-board graphics card ID - 0xA780
Graphics - On-board graphics card maximum resolution (DisplayPort) - 7680 x 4320 pixels
Graphics - On-board graphics card maximum resolution (eDP - Integrated Flat Panel) - 5120 x 3200 pixels
Graphics - On-board graphics card maximum resolution (HDMI) - 4096 x 2160 pixels
Graphics - On-board graphics card model - Intel UHD Graphics 770
Graphics - On-board graphics card OpenGL version - 4.5
Graphics - On-board graphics card outputs supported - DisplayPort 1.4a
Graphics - On-board graphics card outputs supported - Embedded DisplayPort (eDP) 1.4b
Graphics - On-board graphics card outputs supported - HDMI 2.1
Graphics - On-board graphics card refresh rate at maximum resolution (DisplayPort) - 60 Hz
Graphics - On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel) - 120 Hz
Graphics - On-board graphics card refresh rate at maximum resolution (HDMI) - 60 Hz
Gross Weight Kg - 0,1
GRUPPE1 - Memory & Processors
GRUPPE2 - Processors / Math Corp
guarantee - 36
guarantee_type - normal
HERSTELLER - INTEL
Hoehe - 0.08
HSTNUMMER - BX8071514700
Integrated graphics - Yes
L2 cache - 28 MB
L3 cache - 33 MB
Laenge - 0.12
Link - https://www.intel.com/content/www/us/en/products/sku/236781/intel-core-i7-processor-14700-33m-cache-up-to-5-40-ghz/specifications.html
Logistics data - Harmonized System (HS) code - 8542310001
Manufacturer - Intel
Manufacturer Code - BX8071514700
Manufacturer Name - Intel
Manufacturer_code - BX8071514700
Memory - ECC - Yes
Memory - Maximum internal memory supported by processor - 192 GB
Memory - Memory bandwidth (max) - 89.6 GB/s
Memory - Memory channels - Dual-channel
Memory - Memory types supported by processor - DDR4-SDRAM
Memory - Memory types supported by processor - DDR5-SDRAM
Memory type - DDR4/DDR5
Model number - i7-14700
MPN - BX8071514700
Name - Intel Core i7-14700
Name - Intel Core i7-14700 - Socket 1700 - processor (boxed version)
name - Intel Core i7-14700 2,1 GHz (Raptor Lake Refresh) Sockel 1700 - boxed
Name - Intel S1700 CORE i7 14700 BOX GEN14
Name - Intel | i7-14700 | 2.1 GHz | FCLGA1700 | Processor threads 28 | Processor cores 20
name - Processor Core i7-14700 BOX UP TO 5,4GHz, LGA1700
Number of cores - 20
Number of threads - 28
Operational conditions - Tjunction - 100 °C
Other features - Graphics output - eDP 1.4b, DP 1.4a, HDMI 2.1
Other features - L2 cache - 28672 KB
Other features - Maximum internal memory - 192 GB
Other information -
Package features > Embeeded battery - No
Package features > Gross depth (mm) - 105.00 mm
Package features > Gross height (mm) - 120.00 mm
Package features > Gross width (mm) - 80.00 mm
Package features > Packing quantity - 1.00 pc(s)
Package features > Palette Qty - 857 pc(s)
Package features > Paper/Pasteboard - 100.00 g
Package features > Plastic (No PET) - 44.00 g
Package features > Tare weight (kg) - 0.14 kg
Package features > Volume (m3) - 0.00 m³
Package features > WEE classification - CL109:6:2017-04-01
Package features > WEEE tax - Yes
Packing type - BOX/BOX
Processor - Box - Yes
Processor - Cooler included - Yes
Processor - Efficient-core base frequency - 1.5 GHz
Processor - Efficient-core boost frequency - 4.2 GHz
Processor - Efficient cores - 12
Processor - Maximum number of DMI lanes - 8
Processor - Maximum turbo power - 219 W
Processor - Memory bandwidth supported by processor (max) - 89.6 GB/s
Processor - Performance-core base frequency - 2.1 GHz
Processor - Performance-core boost frequency - 5.3 GHz
Processor - Performance cores - 8
Processor - Processor ARK ID - 236781
Processor - Processor base power - 65 W
Processor - Processor boost frequency - 5.4 GHz
Processor - Processor cache - 33 MB
Processor - Processor cache type - Smart Cache
Processor - Processor codename - Raptor Lake
Processor - Processor cores - 20
Processor - Processor family - Intel® Core™ i7
Processor - Processor generation - Intel® Core™ i7 (14th gen)
Processor - Processor manufacturer - Intel
Processor - Processor model - i7-14700
Processor - Processor operating modes - 64-bit
Processor - Processor socket - LGA 1700
Processor - Processor threads - 28
Processor - Stepping - B0
Processor > Processor cores - 20
Processor > Processor frequency - 2.1 GHz
Processor > Processor model - i7-14700
Processor > Processor socket - FCLGA1700
Processor > Processor threads - 28
Processor family - Intel Core i7
Processor special features - Enhanced Intel SpeedStep Technology - Yes
Processor special features - Intel 64 - Yes
Processor special features - Intel Turbo Boost Max Technology 3.0 - Yes
Processor special features - Intel Virtualization Technology (VT-x) - Yes
Processor special features - Intel Virtualization Technology for Directed I/O (VT-d) - Yes
Processor special features - Intel VT-x with Extended Page Tables (EPT) - Yes
Processor special features - Intel® AES New Instructions (Intel® AES-NI) - Yes
Processor special features - Intel® Boot Guard - Yes
Processor special features - Intel® Clear Video HD Technology (Intel® CVT HD) - Yes
Processor special features - Intel® Control-flow Enforcement Technology (CET) - Yes
Processor special features - Intel® Deep Learning Boost (Intel® DL Boost) - Yes
Processor special features - Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0 - Yes
Processor special features - Intel® Hyper Threading Technology (Intel® HT Technology) - Yes
Processor special features - Intel® OS Guard - Yes
Processor special features - Intel® Quick Sync Video Technology - Yes
Processor special features - Intel® Secure Key - Yes
Processor special features - Intel® Speed Shift Technology - Yes
Processor special features - Intel® Standard Manageability (ISM) - Yes
Processor special features - Intel® Thread Director - Yes
Processor special features - Intel® Turbo Boost Max Technology 3.0 frequency - 5.4 GHz
Processor special features - Intel® Turbo Boost Technology - 2.0
Processor special features - Intel® Volume Management Device (VMD) - Yes
Processor special features - Mode-based Execute Control (MBE) - Yes
producer - Intel
Producer - Intel
producerCode - BX8071514700
ProducerCode - BX8071514700
productName - Intel Core i7-14700 processor 33 MB Smart Cache Box
productSize - Normal
Shipping Box Depth Shipping/Package Box Dimensions - 41 cm
Shipping Box Height Shipping/Package Box Dimensions - 13 cm
Shipping box quantity - 5
Shipping Box Weight Shipping/Package Box Dimensions - 2.473 kg
Shipping Box Width Shipping/Package Box Dimensions - 12 cm
Short description - CPU Intel Core i7-14700 / LGA1700 / Box 20 Cores / 28 Threads / 33M Cache
ShortDescription - Intel Core i7 | Socket 1700 | 2,1-5,40Ghz | Raptor Lake Refresh|
sizeX - 122
sizeY - 105
sizeZ - 80
Socket - LGA1700
Stck_Kart - 0
Stck_Pal - 0
Storno - Y
Technical details - Launch date - Q1'24
Technical details - OpenCL version - 3.0
Technical details - Status - Launched
Technical details > Gross weight - 0.46 kg
Technical details > Net weight - 0.32 kg
Technical details > Producer - Intel
Technical_details - The 14th generation Intel® Core™ desktop processors called Raptor Lake-S bring a new chip layout with different CPU cores for different application scenarios. The Performance Cores ensure performance in computing-intensive applications, while the Efficiency Cores ensure energy efficiency with low loads. The Raptor Lake-S processors support PCIe Gen 5.0 and 4.0, DDR5 and DDR4. The processor is compatible with motherboards based on the Intel® 700 and 600 chipsets. Item no.: 100029725 Desktop type EAN 5032037279239 Manufacturer no. BX8071514700 CPU type Core i7 Base 1700 Max supported PCIe version 5.0 Core name Core i7 14xxx (Raptor Lake-S) Supported standards up to DDR4-2133, DDR4-2400, DDR4-2666, DDR4-2800, DDR4-2933, DDR4-3000, DDR4-3200, DDR5-4800, DDR5-5600 Cache Level 2: 28672 KB, Level 3: 33792 KB Fan No fan included Memory Controller Supports ECC Graphics GPU Intel® UHD Graphics 770 Power consumption (TDP) 65 watts Max. power consumption (TDP) 219 watts Note boxed version
Turbo frequency - 5400 MHz
Unit Box Height - 0.1
Unit Box Length - 0.12
Unit Box Width - 0.08
Unit Brutto Volume Retail box Dimensions - 0.0012792/0.0012792 cubm
Unit Gross Weight - 0.4946/0.4946 kg
Unit Net Weight - 0.03 kg
Vendor Homepage - ark.intel.com/content/www/us/en/ark/products/236781/intel-core-i7-processor-14700-33m-cache-up-to-5-40-ghz.html
vendpn - BX8071514700
Version - Box
Warranty - 36
Warranty - 36 month(s)
Warranty - 36 months
warrantyLength - 36
warrantyType - G
Wattage - 65 Watts
Weight - 0.46
Weight - 1
weight - 475
Weight & dimensions - Processor package size - 45 x 37.5 mm
