ID: 1117975
Tootekood: CGR GEX X2 850
Laos 4 üksused
Garantii: 2 aastat
Cougar GEX X2, 850W, 80PLUS Gold, PCI-E 5.0
Pilt võib erineda tegelikust tootest, võib esineda tarvikuid ja osi, mis ei ole tegeliku tootega kaasas.
Tarnevõimalused
- Kohaletoimetamine Smartposti pakiautomaati 1,99 €: neljapäeval, 14.11.2024
- Omniva pakiautomaati kohaletoimetamine 1,99 €: neljapäeval, 14.11.2024
- Kulleri kohaletoimetamine 3,99 €: neljapäeval, 14.11.2024
Peamised tooteparameetrid Kõik parameetrid
- Tootja: Cougar
- Võimsus: 850W
- 80 PLUS certification: 80 PLUS Gold
- Ventilaatori Läbimõõt: 120 mm
- Modulaarkaablid: Fully-Modular
- Protsessori pistikprogramm: 2 x 8-pin(4+4) EPS
- PCI-E: 3 x 6+2pin
Põhiteave
Cybenetics Mürataseme sertifitseerimine
: Cybenetics A +
Cybenetics tõhususe sertifitseerimine
: Cybenetics Platinum
Toiteallika tüüp
: ATX
Võimsus
850W
Toiteploki võimsus vatides. Suurem võimsus tähendab suuremat arvuti töötamise stabiilsust. Tänapäevase keskmise arvuti soovitatav toiteploki võimsus on 500W, või enam. Juhul, kui kasutate mitut kõvaketasst, võimsat videokaarti ja protsessorit, on soovitav soetada toiteplokk 600W, või suurema võimsusega.
80 PLUS certification
: 80 PLUS Gold
Kogu voolutugevus (+12V)
: 70.8A
Ventilaatori Läbimõõt
: 120 mm
Funktsionaalsus
Kaabli värvus
: Must
Valgustus
: Ei ole
Värv
: Must
Modulaarkaablid
: Fully-Modular
Sadamad ja seadmed
PCI-E 5.0
: 1 x 12VHPWR
Protsessori pistikprogramm
: 2 x 8-pin(4+4) EPS
Emaplaadi pistik
: 20+4pin
PCI-E
: 3 x 6+2pin
SATA pistikud
: 10
Molex PATA lisamoodulid
: 2
Täpsem spetsifikatsioon
+3.3V - 20 A
+5V - 20 A
+5VSB - 3 A (15 W)
+12V - 70.8 A (850 W)
-12V - 0.3 A (3.6 W)
4-pin Peripheral Power Connector - 2
4/8-pin +12V Power Connector - 1
6/8-pin PCI Express Connector - 3
8-pin +12V Power Connector - 1
16-pin PCI Express 5.0 Connector - 1
20+4-pin Main Connector - 1
80 Plus Certification - 80 Plus Gold
Box Height (mm) - 241 mm
Box Length (mm) - 550 mm
Box Weight Brutto (kg) - 15.68 kg
Box Width (mm) - 345 mm
Cable Included - Modular Cables
Circuit Protection - Over Voltage Undervoltage Over Temperature Over Current Short Circuit Protection Over Power
Depth (mm) - 140 mm
EAN Code - 4710483775437
Efficiency - 91%
External Color - Melna
Form Factor - ATX
Height (mm) - 86 mm
Image - https://content.it4profit.com/pimg/s/resize/600x600x600x600/240528160013736237.jpg
Image - https://content.it4profit.com/pimg/s/resize/600x600x600x600/240528160013808153.jpg
Included Accessories - Documentation
Input Frequency - 50/60 Hz
Input Power Connectors Quantity - 1
Input Power Connectors Type - IEC-320 C14
Input Voltage - AC 100-240 V
Modular Power Supply - Yes
Nominal Weight - 1.54 kg
Package Type - Box
Pack Height (mm) - 107 mm
Pack Length (mm) - 330 mm
Packs in Box - 5
Pack Weight Brutto (kg) - 2.76 kg
Pack Weight Netto (kg) - 1.16 kg
Pack Width (mm) - 215 mm
Pieces in pack - 1
Power Device Location - Internal
Power Device Type - Power Supply
ProductCard - https://content.it4profit.com/itshop/itemcard_cs.jsp?ITEM=240226064235616337&THEME=asbis&LANG=lv
ProductCategory - Kabeļi
ProductCode - CGR GEX X2 850
ProductDescription - Cougar | GEXX2 850 (Fully Modular) | PSU 80plus Gold | 850W | PCI-E 5.0 support
ProductType - Power Supply Unit
Retail Packaging Net Weight Carton - 0.93 kg
Retail Packaging Net Weight Plastic - 0.23 kg
S-ATA Connector - 10
Vendor - COUGAR GAMING
Warranty Products Returnable - Yes
Warranty Term (month) - 24 mēneši
Warranty validation Criteria - Serial Number
Width (mm) - 150 mm
