Deepcool PL750D, 750W, 80 PLUS Bronze

Pilt võib erineda tegelikust tootest, võib esineda tarvikuid ja osi, mis ei ole tegeliku tootega kaasas.
ID: 1084030 Tootekood: R-PL750D-FC0B-EU
Saab tellida 153 üksused Kättesaadavus: 14 päeva pärast tellimuse kinnitamist
Garantii: 2 aastat
76.95 €
Peamised tooteparameetrid Kõik parameetrid
  • Tootja: Deepcool
  • Võimsus: 750W
  • 80 PLUS certification: 80 PLUS Bronze
  • Ventilaatori Läbimõõt: 120 mm
  • Modulaarkaablid: Ei ole
  • Protsessori pistikprogramm: 2 x 8-pin(4+4) EPS
  • PCI-E: 3 x 6+2pin
Põhiteave
Cybenetics Mürataseme sertifitseerimine : Nav
Cybenetics tõhususe sertifitseerimine : Nav
Toiteallika tüüp : ATX
Võimsus 750W
Toiteploki võimsus vatides. Suurem võimsus tähendab suuremat arvuti töötamise stabiilsust. Tänapäevase keskmise arvuti soovitatav toiteploki võimsus on 500W, või enam. Juhul, kui kasutate mitut kõvaketasst, võimsat videokaarti ja protsessorit, on soovitav soetada toiteplokk 600W, või suurema võimsusega.
80 PLUS certification : 80 PLUS Bronze
Kogu voolutugevus (+12V) : 62.5A
Ventilaatori Läbimõõt : 120 mm
Funktsionaalsus
Kaabli värvus : Must
Valgustus : Ei ole
Värv : Must
Modulaarkaablid : Ei ole
Sadamad ja seadmed
PCI-E 5.0 : 1 x 450W 12VHPWR
Protsessori pistikprogramm : 2 x 8-pin(4+4) EPS
Emaplaadi pistik : 20+4pin
PCI-E : 3 x 6+2pin
SATA pistikud : 8
Molex PATA lisamoodulid : 2
Juhtum
Täpsem spetsifikatsioon
Lisateave tootja veebilehel Deepcool PL750D, 750W, 80 PLUS Bronze
Category_1 - Power
Category_2 - Computer Power Supplies
Code - R-PL750D-FC0B-EU
Design - Cooling type - Active
Design - Fan diameter - 12 cm
Design - Fan location - Top
Design - Number of fans - 1 fan(s)
Design - On/off switch - Yes
Design - Product colour - Black
dimensionalWeight - 1310
dimensionalWeight - 1392
EAN - 6933412718055
EAN_code - 6933412721338
Link - https://www.deepcool.com/products/PowerSupplyUnits/powersupplyunits/PL750D-ATX3.0-Direct-Power-Supply/2023/17602.shtml
Manufacturer - Deepcool
Manufacturer_code - R-PL750D-FC0B-EU
Name - DeepCool PL750-D ATX black
Name - Deepcool PSU | PL750D | 750 W
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Package features > Embeeded battery - No
Package features > Gross depth (mm) - 155.00 mm
Package features > Gross height (mm) - 91.00 mm
Package features > Gross width (mm) - 145.00 mm
Package features > Packing quantity - 1.00 pc(s)
Package features > Palette Qty - 422 pc(s)
Package features > Paper/Pasteboard - 240.00 g
Package features > Plastic (No PET) - 60.00 g
Package features > Tare weight (kg) - 0.30 kg
Package features > Volume (m3) - 0.00 m³
Package features > WEEE tax - No
Packaging data - Package type - Box
Performance - 80 PLUS certification - 80 PLUS Bronze
Performance - ATX version - 3.0
Performance - Bearing technology - HYB
Performance - Certification - CE/FCC/CCC/RCM/EAC/CAN ICES-003(B)/NMB-003(B) /TUV-RH
Performance - Mean time between failures (MTBF) - 100000 h
Performance - Power supply unit (PSU) form factor - ATX
Performance - Purpose - PC
Ports & interfaces - ATX power connector (20+4 pin) - Yes
Ports & interfaces - Cabling type - Non-Modular
Ports & interfaces - CPU power connector (4+4 pin) - Yes
Ports & interfaces - Motherboard power cable length - 55 cm
Ports & interfaces - Motherboard power connector - 20+4 pin ATX
Ports & interfaces - Number of SATA power connectors - 8
Ports & interfaces - PCI Express power connectors (6+2 pin) - 3
Ports & interfaces - PCI Express power connectors (16-pin) - 1
Ports & interfaces - Peripheral (Molex) power connectors (4-pin) - 2
Ports & interfaces - SATA power cable length - 450
Ports & interfaces - SATA power cable length - 550
Ports & interfaces - SATA power cable length - 650
Ports & interfaces - SATA power cable length - 750 mm
Power - AC input frequency - 50/60 Hz
Power - AC input voltage - 100 - 240 V
Power - Combined power (+3.3V) - 100 W
Power - Combined power (+5V) - 100 W
Power - Combined power (+5Vsb) - 15 W
Power - Combined power (+12V) - 750 W
Power - Combined power (-12V) - 3.6 W
Power - Efficiency - 85%
Power - Hold time - 16 ms
Power - Input current - 10 - 5 A
Power - Max output current (+3.3V) - 20 A
Power - Max output current (+5V) - 20 A
Power - Max output current (+5Vsb) - 3 A
Power - Max output current (+12V) - 62.5 A
Power - Max output current (-12V) - 0.3 A
Power - Power Factor Correction (PFC) type - Active
Power - Power Good signal delay range - 100 - 150 ms
Power - Power protection features - No load operation
Power - Power protection features - Over current
Power - Power protection features - Overheating
Power - Power protection features - Over power
Power - Power protection features - Over voltage
Power - Power protection features - Surge & inrush protection (SIP)
Power - Power protection features - Surge protection
Power - Power protection features - Under voltage
Power - Total power - 750 W
Power > Nominal power - 750 W
producerCode - R-PL750D-FC0B-EU
producerCode - R-PL750D-FC0B-EU-V2
productName - DeepCool PL750D power supply unit 750 W 20+4 pin ATX ATX Black
productSize - Normal
sizeX - 120
sizeX - 280
sizeY - 195
sizeY - 290
sizeZ - 120
sizeZ - 200
Technical details - Compliance certificates - RoHS
Technical details - Compliance certificates - WEEE
Technical details - Sustainability certificates - ErP
Technical details - Sustainability certificates - Triman
Technical details - Sustainability compliance - Yes
Technical details > Gross weight - 1.40 kg
Technical details > Net weight - 1.10 kg
Technical details > Producer - Deepcool
Technical details > Producer product family - PSU
Technical details > Producer product name - PL750D
Warranty - 60
Warranty - 60 month(s)
warrantyLength - 24
warrantyType - G
Weight - 2,40
weight - 2391
weight - 2450
Weight & dimensions - Depth - 140 mm
Weight & dimensions - Height - 86 mm
Weight & dimensions - Width - 150 mm
