64, 128-bit WEP Security - Yes
802.1X (EAP-MD5, EAP-TLS, EAP-TTLS and EAP-PEAP) Security - Yes
Accessories included - Archer TX3000E Magnetized Antenna Base with 1m RF Cable Two 5 dBi High Gain Antennas Low-Profile Bracket Bluetooth Header Cable Quick Installation Guide Resource CD
Antenna - Fixed external
Antenna > Antenna type - 2xHigh-Gain External Antennas
Brand - TP-Link
BrandPartCode - ARCHER TX3000E
Category - Datortehnika :: Datoru komponentes :: Tīkla kartes (PCI/USB)
Category - Network Cards
Category - Root/Electronics/Networks and communication/Network interface cards
Category 1 - Netzwerk
Category 2 - Netzwerkkarten
Category Code - WRA
Chipset type -
CnCode CnCode - 84733020
Code - ARCHER TX3000E
Code - Archer TX3000E
Data transmission speed - 3000 Mbps
Desc - Slots: PCIe, Ātrums: 2976 Mbit/s, Garantija: 2 gadi
Description - - Unrivaled Wi-Fi 6 Speed—Breaks the gigabit barrier with speed up to 2402 Mbps (5 GHz) + 574 Mbps (2.4 GHz) - Smoother Experience—75% lower latency ensures ultra-responsive real-time gaming - Reliable Connections—Intel® Wi-Fi 6 chipset brings faster and clearer Wi-Fi to fully unlock the potential of your Wi-Fi 6 router - Wider Signal Coverage—Two multi-directional antennas with magnetized base are designed for optimum signal reception - Bluetooth 5.0—The latest Bluetooth technology achieves 2× Faster Speed and 4× Broader Coverage than BT 4.2 - Improved Security—The latest security enhancements WPA3 provides enhanced protection in personal password safety - Fine Crafting—Specialized heatsink and gold plating is crafted to improve stability and reliability even in hot environments - Backward Compatibility – Full support for 802.11ac/a/b/g/n standards
Description - Unrivaled Wi-Fi 6 SpeedBreaks the gigabit barrier with speed up to 2402 Mbps (5 GHz) + 574 Mbps (2.4 GHz) Smoother Experience75% lower latency ensures ultra-responsive real-time gaming Reliable ConnectionsIntel Wi-Fi 6 chipset brings faster and clearer Wi-Fi to fully unlock the potential of your Wi-Fi 6 router Wider Signal CoverageTwo multi-directional antennas with magnetized base are designed for optimum signal reception Bluetooth 5.0The latest Bluetooth technology achieves 2× Faster Speed and 4× Broader Coverage than BT 4.2 Improved SecurityThe latest security enhancements WPA3 provides enhanced protection in personal password safety Fine CraftingSpecialized heatsink and gold plating is crafted to improve stability and reliability even in hot environments Backward Compatibility Full support for 802.11ac/a/b/g/n standards The very latest Wi-Fi 6 standard guarantees extreme speed, ultra-low latency, and uninterrupted connectivity. Utilizing the Wi-Fi 6 foundation, Archer TX3000E is designed to liberate your gaming from cables and fully optimize your gameplay. Discover the missing component of your gaming arsenal!
Design - Antenna - Yes
Design - Antenna design - External
Design - Chipset - Intel Wi-Fi 6
Design - Component for - PC
Design - Internal - Yes
Design - Operating modes - Infrastructure mode
Design - Product colour - Black
Design - Product colour - Black, Red
Design - Product colour - Red
Design - Receiver sensitivity - 5 GHz :
11ax HT160：-56.25dBm
11ax HT80: -59dBm
11ax HT40: -62.25dBm
11ax HT20: -65dBm
11ac HT160：-62dBm
11ac HT80: -65.5dBm
11ac HT40: -69.75dBm
11ac HT20: -73.75dBm
11n HT40: -74.5dBm
11n HT20: -77.5dBm
11a 54Mbps: -77.75dBm
11a 6Mbps: -94.5dBm
2.4GHz :
11ax HT40: -60.75dBm
11ax HT20: -63.75dBm
11n HT40: -73dBm
11n HT20: -76.25dBm
11g 54Mbps: -76.5dBm
11b 11Mbps: -89dBm
Design - Transmitting power (CE) - 23 dBm
Design - Transmitting power (FCC) - 27 dBm
dimensionalWeight - 616
dimension depth - 50 mm
dimension height - 220 mm
Dimensions - 95,2 x 120,8 x 21,5 mm
dimension weight - 467 g
dimension width - 270 mm
EAN - 6935364088897
ean - 6935364088897
Eans - 6935364088897
Features > Data transfer rate (max) - 574+2402 Mbit/s
Full Description Line - Type Adapter|Data transmission speed 3000 Mbps|IEEE 802.11a|IEEE 802.11n|IEEE 802.11ac|IEEE 802.11ax|64, 128-bit WEP|WPA - Wi-Fi Protected Access|WPA2 - Wi-Fi Protected Access|WPA3|802.1X (EAP-MD5, EAP-TLS, EAP-TTLS and EAP-PEAP)|Wireless Frequency Range 5GHz, 2.4GHz|Included Accessories Magnetized Antenna Base with 1m RF Cable,Two 5 dBi High Gain Antennas,Low-Profile Bracket,Bluetooth Header Cable,Quick Installation Guide,Resource CD
GTIN - 6935364088897
guarantee - 36
guarantee_type - normal
I/O ports - None
IEEE 802.11ac Network standard - Yes
IEEE 802.11a Network standard - Yes
IEEE 802.11ax Network standard - Yes
IEEE 802.11n Network standard - Yes
ImageUrl - https://www.balticdata.lv/Gfx/ProductImages/Info/Product_75400_1.jpg
Included Accessories - Magnetized Antenna Base with 1m RF Cable,
Two 5 dBi High Gain Antennas,
Low-Profile Bracket,
Bluetooth Header Cable,
Quick Installation Guide,
Resource CD
Interface - PCIe
LargeDescHTML -
Link - https://www.tp-link.com/us/home-networking/pci-adapter/archer-tx3000e/#overview
Logistics data - Harmonized System (HS) code - 85176990
LongDesc - Next-Level GamingThe very latest Wi-Fi 6 standard guarantees extreme speed, ultra-low latency, and uninterrupted connectivity. Utilizing the Wi-Fi 6 foundation, Archer TX3000E is designed to liberate your gaming from cables and fully optimize your gameplay. Discover the missing component of your gaming arsenal!Stay Immersive1024-QAM and a 160 MHz bandwidth deliver powerful, continuous WiFi to fully unlock the potential of your Wi-Fi 6 router. Wi-Fi 6 drives your PC to peak performance so your setup keeps pace with your jaw-dropping skills.Incredibly Smooth GameplayLower latency is essential to gaming success. Revolutionary OFDMA reduces lag by up to 75%. Enjoy ultra-responsive real-time gaming or immersive VR experiences.Broader CoverageTwo multi-directional and high-performance antennas with a magnetized base extends your existing WiFi reception capabilities, allowing you to game anywhere and anytime. Place the magnetized antenna base anywhere on your desktop to find the optimal location for signal reception.Simultaneous Entertainment for AllA revolutionary combination of OFDMA and MU-MIMO technologies ensures the most efficient WiFi connection for your PC. OFDMA technology divides band resources into smaller units while MU-MIMO allows more devices to communicate simultaneously—without lag.Bluetooth 5.0 CompatibleArcher TX3000E is compatible with the latest Bluetooth 5.0 Technology, achieving 2× faster speed and 4× broader coverage than Bluetooth 4.2. Connect as many devices as you want, including game controllers, headphones, and keyboards, to enjoy a smoother experience.Advanced SecurityThe latest security enhancements—WPA3 provides more secure and individualized encryption in personal password safety, protecting your network from wireless hacking. Always keep your network safe while gaming online.Fine Crafting for Ultimate PerformanceBuilt with a specialized heatsink crafted to improve stability and reliability even in hot environments. Careful attention to every detail, such as gold plating on every contactor to resist oxidation, delivers a superior network experience.
LongProductName - Intel Wi-Fi 6 Chipset, 2.4/5 GHz, Bluetooth 5.0
LongSummaryDescription - TP-Link Archer TX3000E. Internal. Connectivity technology: Wireless, Host interface: PCI Express, Interface: WLAN / Bluetooth. Maximum data transfer rate: 2402 Mbit/s, Top Wi-Fi standard: Wi-Fi 6 (802.11ax), Wi-Fi band: Dual-band (2.4 GHz / 5 GHz). Product colour: Black, Red
Manufacturer - TP-Link
MPN - Archer TX3000E
name - Archer TX3000E PCI-E WiFi AX30000 BT 5.0
Name - TP-Link Archer TX3000E
Name - TP-LINK Archer TX3000E - AX3000 Dual Band Wi-Fi 6 Bluetooth PCI Express Adapter
Name - Tp-Link Archer TX3000E Wi-Fi 6 Bluetooth 5.0
Name - TP-LINK | AX3000 Wi-Fi 6 Bluetooth 5.0 PCIe Adapter | TX3000E | 2.4GHz/5GHz | Antenna type 2xHigh-Gain External Antennas | 574+2402 Mbit/s
Network - Bluetooth - Yes
Network - Bluetooth version - 5.0
Network - Frequency range - 2.4 - 5 GHz
Network - Maximum data transfer rate - 2402 Mbit/s
Network - Modulation - 16-QAM
Network - Modulation - 16-QAM, 64-QAM, 256-QAM, CCK, DBPSK, DQPSK, OFDM
Network - Modulation - 64-QAM
Network - Modulation - 256-QAM
Network - Modulation - CCK
Network - Modulation - DBPSK
Network - Modulation - DQPSK
Network - Modulation - OFDM
Network - Networking standards - IEEE 802.11a
Network - Networking standards - IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Network - Networking standards - IEEE 802.11ac
Network - Networking standards - IEEE 802.11ax
Network - Networking standards - IEEE 802.11b
Network - Networking standards - IEEE 802.11g
Network - Networking standards - IEEE 802.11n
Network - Security algorithms - 64-bit WEP
Network - Security algorithms - 64-bit WEP, 128-bit WEP, 802.1x RADIUS, WPA, WPA-PSK, WPA2, WPA2-PSK, WPA3
Network - Security algorithms - 128-bit WEP
Network - Security algorithms - 802.1x RADIUS
Network - Security algorithms - WPA
Network - Security algorithms - WPA-PSK
Network - Security algorithms - WPA2
Network - Security algorithms - WPA2-PSK
Network - Security algorithms - WPA3
Network - Top Wi-Fi standard - Wi-Fi 6 (802.11ax)
Network - Wi-Fi - Yes
Network - Wi-Fi band - Dual-band (2.4 GHz / 5 GHz)
Network - Wi-Fi standards - 802.11a
Network - Wi-Fi standards - 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Network - Wi-Fi standards - 802.11b
Network - Wi-Fi standards - 802.11g
Network - Wi-Fi standards - Wi-Fi 4 (802.11n)
Network - Wi-Fi standards - Wi-Fi 5 (802.11ac)
Network - Wi-Fi standards - Wi-Fi 6 (802.11ax)
Network - WLAN data transfer rates supported - 54
Network - WLAN data transfer rates supported - 54,300,574,1733,2402 Mbit/s
Network - WLAN data transfer rates supported - 300 Mbit/s
Network - WLAN data transfer rates supported - 574
Network - WLAN data transfer rates supported - 1733 Mbit/s
Network - WLAN data transfer rates supported - 2402 Mbit/s
Network Device Type - Adapter
Networking > Bluetooth version - 5.0
Number of antennas - 2
Operating frequency - 2,4 GHz
Operating frequency - 5 GHz
Operational conditions - Operating relative humidity (H-H) - 10 - 90%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 5 - 90%
Operational conditions - Storage temperature (T-T) - -40 - 70 °C
Other features - Modulation Technology: DBPSK, DQPSK, CCK, OFDM, 16-QAM, 64-QAM, 256-QAM, 1024QAM Archer TX3000E support the native BT profiles implemented in Windows 10.
Other features > Colour - Black
Package features > Embeeded battery - No
Package features > Gross depth (mm) - 270.00 mm
Package features > Gross depth master carton - 450 mm
Package features > Gross height (mm) - 215 mm
Package features > Gross height master carton - 275 mm
Package features > Gross width (mm) - 50 mm
Package features > Gross width master carton - 295 mm
Package features > Net weight master carton - 4.86 kg
Package features > Packing quantity - 10 pc(s)
Package features > Palette Qty - 470 pc(s)
Package features > Paper/Pasteboard - 80.00 g
Package features > Plastic (No PET) - 20.00 g
Package features > Tare weight (kg) - 0.10 kg
Package features > Tare weight master carton - 0.621 kg
Package features > Volume (m3) - 0.0029025 m³
Package features > WEE classification - CL109:5:2017-04-01
Package features > WEEE tax - Yes
Packaging content - Bluetooth header cable - Yes
Packaging content - Mounting brackets included - Yes
Packaging content - Quick installation guide - Yes
Packaging content - Resource CD - Yes
Packaging data - Package depth - 215 mm
Packaging data - Package height - 47 mm
Packaging data - Package weight - 480 g
Packaging data - Package width - 270 mm
Ports & interfaces - Connectivity technology - Wireless
Ports & interfaces - Host interface - PCI Express
Ports & interfaces - Interface - WLAN / Bluetooth
producer - TP-LINK
Producer - TP-Link
producerCode - Archer TX3000E
ProducerCode - Archer TX3000E
ProductName - Archer TX3000E
productName - TP-Link Archer TX3000E Internal WLAN / Bluetooth 2402 Mbit/s
productSize - Normal
Security - 64/128-bit WEP, WPA / WPA2 / WPA3, WPA-PSK / WPA2-PSK, 802.1x encryption
Shipping Box Depth Shipping/Package Box Dimensions - 27 cm
Shipping Box Height Shipping/Package Box Dimensions - 5 cm
Shipping box quantity - 1
Shipping Box Weight Shipping/Package Box Dimensions - 0.47 kg
Shipping Box Width Shipping/Package Box Dimensions - 21.5 cm
ShortDescription - Karta sieciowa PCIe, Wi-Fi 6, Bluetooth 5.0, AX3000
ShortSummaryDescription - TP-Link Archer TX3000E, Internal, Wireless, PCI Express, WLAN / Bluetooth, 2402 Mbit/s, Black, Red
sizeX - 220
sizeY - 280
sizeZ - 50
Standards - 802.11a
Standards - 802.11ac
Standards - 802.11ax
Standards - 802.11b
Standards - 802.11g
Standards - 802.11n
Supported operating systems - Windows 10
Sustainability - Sustainability certificates - CE
Sustainability - Sustainability certificates - CE, Federal Communications Commission (FCC), RoHS
Sustainability - Sustainability certificates - Federal Communications Commission (FCC)
Sustainability - Sustainability certificates - RoHS
Sustainability - Sustainability compliance - Yes
System Requirements -
System requirements - Windows operating systems supported - Windows 10 Education x64
System requirements - Windows operating systems supported - Windows 10 Education x64, Windows 10 Enterprise x64, Windows 10 Home x64, Windows 10 Pro x64, Windows 10 x64
System requirements - Windows operating systems supported - Windows 10 Enterprise x64
System requirements - Windows operating systems supported - Windows 10 Home x64
System requirements - Windows operating systems supported - Windows 10 Pro x64
System requirements - Windows operating systems supported - Windows 10 x64
Technical details > Gross weight - 0.486 kg
Technical details > Net weight - 0.386 kg
Technical details > Producer - TP-LINK
Technical details > Producer product family - AX3000 Wi-Fi 6 Bluetooth 5.0 PCIe Adapter
Technical details > Producer product name - TX3000E
Title - TP-Link Archer TX3000E Internal WLAN / Bluetooth 2402 Mbit/s
Type - WiFi
Unit Box Height - 0.05
Unit Box Length - 0.27
Unit Box Width - 0.215
Unit Brutto Volume - 0.002903 cubm
Unit Gross Weight - 0.47 kg
Unit Net Weight - 0.08 kg
URL - https://www.tp-link.com/us/home-networking/pci-adapter/archer-tx3000e/
Vendor Homepage - www.tp-link.com/my/home-networking/adapter/archer-tx3000e/
vendpn - Archer TX3000E
Warranty - 36
Warranty - 36 month(s)
Warranty - 36 months
WarrantyInfo - 3 year
warrantyLength - 36
warrantyType - G
Weight - 0.48
weight - 471
Weight & dimensions - Depth - 120.8 mm
Weight & dimensions - Height - 21.5 mm
Weight & dimensions - Width - 95.2 mm
Wireless Frequency Range - 5GHz, 2.4GHz
Wireless LAN features > Wi-Fi band - 2.4GHz/5GHz
Wireless LAN features > Wi-Fi standards - 802.11ax
WPA - Wi-Fi Protected Access Security - Yes
WPA2 - Wi-Fi Protected Access Security - Yes
WPA3 Security - Yes
