Antenna - Antenna design - External
Antenna - Antenna gain level (max) - 5 dBi
Antenna - Antennas quantity - 2
ARTIKEL1 - TD-W9970 MODEM ROUTER
ARTIKEL2 - 300MBIT/S WLAN N USB VDSL2
Brand - TP-Link
BrandPartCode - TD-W9970 V2
Breite - 0.24
Category - Wireless Routers
Certificates - Certification - CE, FCC, RoHS
Design - LED indicators - Yes
Design - On/off switch - Yes
Design - Product colour - White
Design - Product type - Tabletop router
Design - Wall mountable - Yes
DSL features - ADSL - Yes
DSL features - ADSL2 - Yes
DSL features - ADSL2+ - Yes
DSL features - VDSL2 - Yes
EANCode - 6935364092535
Features - Firmware upgradeable - Yes
Gewicht - 0.71
GRUPPE1 - Network
GRUPPE2 - Wireless Lan Broadba
GTIN - 5055309620317
GTIN - 6935364092535
GTIN - 6935364092542
GTIN - 6935364093440
HERSTELLER - TP-LINK
Hoehe - 0.07
HSTNUMMER - TD-W9970
Laenge - 0.27
Logistics data - Harmonized System (HS) code - 85176990
LongDesc - Fast, Everyday Wi-Fi300Mbps Wireless N USB VDSL/ADSL Modem RouterHigh-Speed VDSL Modem RouterThe latest VDSL2 technology allows the TD-W9970 to deliver impressive VDSL broadband speeds of up to 100Mbps, which is almost 4 times faster than ADSL2+. The integrated DSL port supports all standard DSL connections* for compatibility with most ISPs. The TD-W9970 serves as a DSL modem and wireless router, combining two devices in one.Wi-Fi Speed Up to 300 MbpsWith 300 Mbps wireless speeds on the 2.4 GHz band and 4 megabit LAN ports, the TD-W9970 is perfect for streaming in HD, online gaming and other bandwidth-intensive applications.Versatile ConnectivityThe TD-W9970 is built to connect you to the internet, no matter your situation. The Ethernet WAN port supports wired connection to cable or fiber modem, letting you take full charge of its wireless capabilities as a router. In case your internet goes down, attach a 3/4G adapter to USB 3.0 port to serve as a backup option so you can get back online in no time.Easy Setup and ManagementSet up the TD-W9970 in minutes thanks to its intuitive web interface and the powerful Tether app. Manage network settings, including Parental Controls and Access Control, from any Android or iOS device. Tether also provides Automatic Firmware Updates to always give your network the latest performance and security.Powerful AntennasTwo external 4dBi high-gain antennas beam signal to every corner of your home, creating a strong, stable Wi-Fi network.6kV Lightning ProtectionLightning protection shields TD-W9970 from electrical damage caused by thunderstorms, so even in bad weather, you can enjoy internet with peace of mind.Secure SurfingParental Controls limit the online time and access of specified devices. Guest Network creates a separate Wi-Fi network for visitors, keeping your main network secure.
LongProductName - RJ45 x 4, RJ11, USB 2.0, 2 x 5dBi, 300Mbps, VDSL2
LongSummaryDescription - TP-Link 300Mbps Wireless N USB VDSL/ADSL Modem Router. WAN connection type: RJ-45. Wi-Fi band: Single-band (2.4 GHz), Top Wi-Fi standard: Wi-Fi 4 (802.11n), WLAN data transfer rate (max): 300 Mbit/s. Ethernet LAN interface type: Fast Ethernet, Ethernet LAN data rates: 10,100 Mbit/s, Cabling technology: 10/100Base-T(X). Security algorithms: 128-bit AES, 128-bit WEP, 192-bit AES, 256-bit AES, 3DES, 64-bit WEP, DES, MD5, SHA-1, WPA,.... Product type: Tabletop router, Product colour: White
Management features - Quality of Service (QoS) support - Yes
Management features - Reset button - Yes
Management features - Web-based management - Yes
Management features - Wi-Fi Multimedia (WMM)/(WME) - Yes
Management features - WPS push button - Yes
Network - Built-in FTP server - Yes
Network - Cabling technology - 10/100Base-T(X)
Network - Dynamic DNS (DDNS) - Yes
Network - Ethernet LAN - Yes
Network - Ethernet LAN data rates - 10,100 Mbit/s
Network - Ethernet LAN interface type - Fast Ethernet
Network - Media server - Yes
Network - Networking standards - IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Network - Number of guest networks (2.4 GHz) - 1
Network - Port forwarding - Yes
Network - USB sharing - Yes
Network - VPN Passthrough - Yes
Network - VPN support - PPTP, L2TP, IPSec Pass-through
Network - VPN tunnels quantity - 10
Network - Wireless Distribution System (WDS) bridge - Yes
Operational conditions - Operating relative humidity (H-H) - 10 - 90%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 5 - 90%
Operational conditions - Storage temperature (T-T) - -40 - 70 °C
Other features - Frequency range - 2.4 - 2.4835 GHz
Other features - USB ports quantity - 1
Other features - USB version - 2.0
Other features - WLAN data transfer rates supported - 300 Mbit/s
Other features - xDSL connection - Yes
Packaging content - AC adapter included - Yes
Packaging content - Cables included - LAN (RJ-45), Phone (RJ-11)
Packaging content - Quick start guide - Yes
Packaging data - Package depth - 232 mm
Packaging data - Package height - 70 mm
Packaging data - Package weight - 550 g
Packaging data - Package width - 260 mm
Ports & interfaces - Ethernet LAN (RJ-45) ports - 4
Ports & interfaces - RJ-11 ports quantity - 1
Ports & interfaces - USB 2.0 ports quantity - 1
Ports & interfaces - USB port - Yes
Power - Output current - 1 A
Power - Output voltage - 12 V
Power - Power source type - DC
ProductName - 300Mbps Wireless N USB VDSL/ADSL Modem Router
Protocols - DHCP client - Yes
Protocols - Universal Plug and Play (UPnP) - Yes
Security - DMZ support - No
Security - Filtering - Yes
Security - Firewall - Yes
Security - Guest access - Yes
Security - IP address filtering - Yes
Security - MAC address filtering - Yes
Security - Network address translation (NAT) - Yes
Security - Parental control - Yes
Security - Security algorithms - 128-bit AES, 128-bit WEP, 192-bit AES, 256-bit AES, 3DES, 64-bit WEP, DES, MD5, SHA-1, WPA, WPA-PSK, WPA2, WPA2-PSK
Security - Stateful Packet Inspection (SPI) - Yes
Security - URL filtering - Yes
ShortSummaryDescription - TP-Link 300Mbps Wireless N USB VDSL/ADSL Modem Router, Wi-Fi 4 (802.11n), Single-band (2.4 GHz), Ethernet LAN, VDSL2, White, Tabletop router
Stck_Kart - 20
Stck_Pal - 40
Storno - N
System requirements - Linux operating systems supported - Yes
System requirements - Mac operating systems supported - macOS
System requirements - Windows operating systems supported - Windows 10, Windows 2000, Windows 7, Windows 8, Windows 8.1, Windows 98SE, Windows NT, Windows XP
Title - TP-Link 300Mbps Wireless N USB VDSL/ADSL Modem Router
URL - https://www.tp-link.com/en/home-networking/dsl-modem-router/td-w9970/
WAN connection - 3G/4G USB modem compatibility - Yes
WAN connection - DSL WAN - Yes
WAN connection - Ethernet WAN - Yes
WAN connection - SIM card slot - No
WAN connection - WAN connection type - RJ-45
WarrantyInfo - 3 Years
Weight & dimensions - Depth - 130 mm
Weight & dimensions - Height - 36 mm
Weight & dimensions - Width - 195 mm
Wireless LAN features - Top Wi-Fi standard - Wi-Fi 4 (802.11n)
Wireless LAN features - Wi-Fi band - Single-band (2.4 GHz)
Wireless LAN features - Wi-Fi standards - 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Wireless LAN features - WLAN data transfer rate (max) - 300 Mbit/s
