Antenna - Antenna design - External
Antenna - Antennas quantity - 4
Brand - TP-Link
BrandPartCode - ARCHER A5 V4
Category - Wireless Routers
Category 1 - Netzwerk
Category 2 - Accesspoints
Certificates - Certification - CE, FCC, RoHS
Design - Product colour - White
Design - Product type - Tabletop router
EAN - 6935364084134
GTIN - 6935364083137
GTIN - 6935364084134
LongDesc - High-Speed Dual Band Wi-Fi for Better ConnectionsThe Archer A5 lets your PC or laptop enjoy connections 3x faster than Wireless N with Wireless AC technology.With 300Mbps over the 2.4GHz band and 867Mbps over the the crystal clear 5GHz band, the Archer A5 is the superior choice for seamless HD streaming, online gaming and other bandwidth-intensive tasks.Innovative Antenna Design for Maximum CoverageFour well-ordered antennas make all of your connections more efficient and stable. Advanced antenna technology increases the receiving sensitivity to enlarge Wi-Fi coverage for your home.Easy Parental ControlSupervise children and staff with responsible access, controlled by parents or administrators. Use key words to easily set up a black list and limit the level of web access.Guest Network AccessAllow guests to join your Wi-Fi network, while protecting your privacy. Make sharing easy, maintain security.Efficient Guest Authentication with FacebookCaptive portal helps maintain only authorized guests to use the network, presenting devices with a convenient, user-friendly authentication method to grant Wi-Fi access. Easily share your facebook account to anyone who connects to your network.Easy Setup and UseSet up the Archer A5 in minutes thanks to its intuitive web interface and the powerful Tether app. Tether also lets you manage its network settings from any Android or iOS device, including parental controls and access control.
LongProductName - Archer A5 AC1200 Wireless Dual Band Router
LongSummaryDescription - TP-Link AC1200 Wireless Dual Band WiFi Router. WAN connection type: RJ-45. Wi-Fi band: Dual-band (2.4 GHz / 5 GHz), Top Wi-Fi standard: Wi-Fi 5 (802.11ac), WLAN data transfer rate (max): 867 Mbit/s. Ethernet LAN interface type: Fast Ethernet, Ethernet LAN data rates: 10,100 Mbit/s, Cabling technology: 10/100Base-T(X). Security algorithms: 64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK. Supported network protocols: IPv4, IPv6
Management features - Reset button - Yes
Management features - WPS push button - Yes
Manufacturer - TP-Link
Mobile network - 3G - No
Mobile network - 4G - No
MPN - Archer A5
Name - Archer A5 - Wi-Fi 5 (802.11ac) - Dual-Band (2.4 GHz/5 GHz) - Eingebauter Ethernet-Anschluss - Weiß - Tabletop-Router
Network - Cabling technology - 10/100Base-T(X)
Network - Dynamic DNS (DDNS) - Yes
Network - Ethernet LAN - Yes
Network - Ethernet LAN data rates - 10,100 Mbit/s
Network - Ethernet LAN interface type - Fast Ethernet
Network - Networking standards - IEEE 802.3, IEEE 802.3u
Network - Port forwarding - Yes
Network - Receiver sensitivity - 5GHz:
11a 54M: -73dBm
11ac VHT20 MCS8: -68dBm
11ac VHT40 MCS9: -64dBm
11ac VHT80 MCS9: -60dBm
2.4GHz:
11g 54M: -76dBm
11n HT20 MCS7: -74dBm
11n HT40 MCS7: -71dBm
Network - Static route - Yes
Network - VPN Passthrough - Yes
Operational conditions - Operating relative humidity (H-H) - 10 - 90%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 5 - 90%
Operational conditions - Storage temperature (T-T) - -40 - 70 °C
Packaging content - AC adapter included - Yes
Packaging content - Cables included - LAN (RJ-45)
Packaging content - Quick installation guide - Yes
Packaging data - Package depth - 240 mm
Packaging data - Package height - 76 mm
Packaging data - Package width - 290 mm
Ports & interfaces - Ethernet LAN (RJ-45) ports - 4
Ports & interfaces - Memory card slot(s) - No
Ports & interfaces - USB port - No
Power - Output current - 0.85 A
Power - Output voltage - 9 V
Power - Power source type - DC
ProductName - AC1200 Wireless Dual Band WiFi Router
Protocols - DHCP client - Yes
Protocols - DHCP server - Yes
Protocols - Supported network protocols - IPv4, IPv6
Protocols - Universal Plug and Play (UPnP) - Yes
Security - Access Control List (ACL) - Yes
Security - DMZ support - Yes
Security - DoS attack prevention - Yes
Security - Filtering - Yes
Security - Firewall - Yes
Security - IP address filtering - Yes
Security - MAC address filtering - Yes
Security - Security algorithms - 64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
ShortSummaryDescription - TP-Link AC1200 Wireless Dual Band WiFi Router, Wi-Fi 5 (802.11ac), Dual-band (2.4 GHz / 5 GHz), Ethernet LAN, White, Tabletop router
System requirements - Linux operating systems supported - Yes
System requirements - Mac compatibility - Yes
System requirements - Mac operating systems supported - macOS
System requirements - Windows operating systems supported - Windows 10, Windows 2000, Windows 7, Windows 8, Windows 8.1, Windows 98SE, Windows Vista, Windows XP
Title - TP-Link AC1200 Wireless Dual Band WiFi Router
URL - https://www.tp-link.com/pt/products/details/Archer-A5.html
WAN connection - 3G/4G USB modem compatibility - No
WAN connection - DSL WAN - No
WAN connection - Ethernet WAN - Yes
WAN connection - SIM card slot - No
WAN connection - WAN connection type - RJ-45
WarrantyInfo -
Weight & dimensions - Depth - 144.2 mm
Weight & dimensions - Height - 36.9 mm
Weight & dimensions - Width - 229.9 mm
Wireless LAN features - Top Wi-Fi standard - Wi-Fi 5 (802.11ac)
Wireless LAN features - Wi-Fi band - Dual-band (2.4 GHz / 5 GHz)
Wireless LAN features - Wi-Fi standards - 802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Wireless LAN features - WLAN data transfer rate (first band) - 300 Mbit/s
Wireless LAN features - WLAN data transfer rate (max) - 867 Mbit/s
Wireless LAN features - WLAN data transfer rate (second band) - 867 Mbit/s
