ID: 279235
Tootekood: NH-U12A
Saab tellida 57 üksused Kättesaadavus: 14 päeva pärast tellimuse kinnitamist
Garantii: 3 aastat
Noctua NH-U12A
Pilt võib erineda tegelikust tootest, võib esineda tarvikuid ja osi, mis ei ole tegeliku tootega kaasas.
Peamised tooteparameetrid Kõik parameetrid
- Dzesētāja klase: Extreme
- Jahutusvõimsus (TDP), W: Ei ole märgitud
- Kõrgus, mm: 158
- LED izgaismojuma krāsa: Ei ole
- Tootja: Noctua
- Ventilaatorite arv: 2
Kirjeldus
Jahuti peab olema 158mm kõrge. Seda jahutit valides kontrollige kindlasti, kas selle kõrgus võimaldab teil seda sobitada oma valitud korpusesse!
Kõik parameetrid
Dzesētāja klase
: Extreme
Jahutusvõimsus (TDP), W
: Ei ole märgitud
Kõrgus, mm
: 158
LED izgaismojuma krāsa
: Ei ole
Müratase (MAX), dB(A)
: 22.6
Radiaatori värvus
: Hõbedane
Tootja
: Noctua
Ühendus
: 4-pin (PWM)
Ühilduvus
: AM2, AM2+, AM3, AM3+, AM4, FM1, FM2, FM2+, LGA1150, LGA1151, LGA1155, LGA1156, LGA1200, LGA2011, LGA2066
Ventilaatori kiirus (MAX), rpm
: 2000
Ventilaatori kiirus (MIN), rpm
: 450
Ventilaatori suurus, mm
: 120
Ventilaatori värvus
: Beež, Pruun
Ventilaatorite arv
: 2
Täpsem spetsifikatsioon
Additional fan mounting - no
Approved for - active air flow
category - Aircooling|Coolers|CPU Coolers|Intel|Socket 2011/2066
Category_1 - Computer Cases and Cooling
Category_2 - Fans
code - NH-U12A
CPU cooler depth - 50 to 59 mm
CPU cooler depth (accurate) - 58 mm
CPU cooler fan(s) included - 2x 120 mm
CPU cooler height - 150 to 159 mm
CPU cooler height (accurate) - 158 mm
CPU cooler type - Single Tower
CPU cooler width - 120 to 129 mm
CPU cooler width (accurate) - 125 mm
CPU socket - 2066, 2011-V3, 2011, 1156, 1155, 1151, 1150, AM4, AM3+, AM3, AM2, FM2+, FM2, FM1
Design - Base plate material - Copper
Design - Fan connector - 4-pin
Design - Number of fan blades - 9
Design - Number of fans - 2 fan(s)
Design - Product colour - Beige
Design - Product colour - Bronze
Design - Product colour - Silver
Design - Radiator material - Aluminum
dimensionalWeight - 1346
ean - 9010018000160
EAN_code - 9010018000160
Fan colour - brown
Fan connector - 4 Pin (PWM)
Heatpipe diameter - 6 mm
Heat sink colour - silver
Lighting - no
Manufacturer - Noctua
Manufacturer_code - NH-U12A
Material base plate - nickel-plated copper
Material heat sink - aluminium
max. Air volume - 100 - 124 m³/h
max. Air volume (exact) - 102,1 m³/h
max. Noise level - 20 - 24 dB(A)
max. Noise level (exact) - 22,6 dB(A)
max. RPM - 2,000 - 2,499 rpm
max. RPM (exact) - 2,000 rpm
Name - Noctua NH-U12A, CPU cooler
name - Noctua NH-U12A CPU-Kühler - 120mm
No. of Heatpipes - 7
Packaging content - Cables included - Fan
Packaging content - Mounting kit - Yes
Performance - Airflow - 102.1 m³/h
Performance - Bearing type - Self-Stabilising Oil-pressure (SSO) bearing
Performance - Fan diameter - 12 cm
Performance - Maximum air pressure - 2.34 mmH2O
Performance - Mean time between failures (MTBF) - 150000 h
Performance - Minimum air pressure - 1.65 mmH2O
Performance - Noise level (high speed) - 22.6 dB
Performance - Noise level (low speed) - 18.8 dB
Performance - Pulse-width modulation (PWM) support - Yes
Performance - Quantity per pack - 1 pc(s)
Performance - Rotational speed (max) - 2000 RPM
Performance - Rotational speed (min) - 450 RPM
Performance - Suitable for - Processor
Performance - Supported processor sockets - LGA 1150 (Socket H3)
Performance - Supported processor sockets - LGA 1151 (Socket H4)
Performance - Supported processor sockets - LGA 1155 (Socket H2)
Performance - Supported processor sockets - LGA 1156 (Socket H)
Performance - Supported processor sockets - LGA 1200 (Socket H5)
Performance - Supported processor sockets - LGA 2011 (Socket R)
Performance - Supported processor sockets - LGA 2066
Performance - Supported processor sockets - Socket AM2
Performance - Supported processor sockets - Socket AM2+
Performance - Supported processor sockets - Socket AM3
Performance - Supported processor sockets - Socket AM3+
Performance - Supported processor sockets - Socket AM4
Performance - Supported processor sockets - Socket FM1
Performance - Supported processor sockets - Socket FM2
Performance - Supported processor sockets - Socket FM2+
Performance - Type - Cooler
Power - Rated voltage - 12 V
producerCode - NH-U12A
productName - Noctua NH-U12A computer cooling component Processor Cooler 12 cm Beige, Brown, Silver 1 pc(s)
productSize - Normal
sizeX - 220
sizeY - 170
sizeZ - 180
TDP - keine Angabe
warrantyLength - 72
warrantyType - F
Weight - 2,04
weight - 1795
Weight & dimensions - Depth - 112 mm
Weight & dimensions - Fan dimensions (W x D x H) - 120 x 120 x 25 mm
Weight & dimensions - Height - 158 mm
Weight & dimensions - Weight - 1.22 kg
Weight & dimensions - Width - 125 mm
