Accessories included - VIGI network camera Quick Installation Guide Sealing elements for the cable Mounting accessories
Audio - Built-in microphone - Yes
Brand - TP-Link
BrandPartCode - VIGI C230(2.8MM)
Camera - Angle of rotation - 360°
Camera - Camera pan control - Yes
Camera - Camera tilt control - Yes
Camera - Lens viewing angle, diagonal - 128.7°
Camera - Lens viewing angle, horizontal - 107.5°
Camera - Lens viewing angle, vertical - 57.2°
Camera - Minimum illumination - 0 lx
Camera - Pan range - 0 - 360°
Camera - Tilt angle range - 0 - 85°
Category - Root/Electronics/Networks and communication/Monitoring/Monitoring IP
Category - Security Cameras
Certificates - CE BSMI VCCI ONVIF
Code - VIGI C230(2.8mm)
Color - White
Connectors - RJ-45
Description - VIGI C230 Dome Vandal Resistant Full Color VIGI 3MP Network Camera High Quality 3MP: The camera is equipped with a 3MP sensor that is able to capture even the smallest details. Full color for 24 hours: Full color details are available all day long, even in total darkness. This is possible thanks to a sensitive sensor and built-in LED spot light. People and Vehicle Classification: Distinguishes people and vehicles from other objects, so you get more accurate event notifications. Smart Detection: Receive notifications and check channels when someone crosses the border, enters the area you set, locks the camera or removes/abandons objects. Built-in Mic: It has a built-in microphone to record everything that happens within 4.5 meters of the camera. IK10 Mechanical Grade Vandalproof and IP67 Waterproof: With mechanical strength, rugged housing and waterproof design, this VIGI dome camera is built to withstand vandalism and harsh environmental conditions with rain and dust, keeping you safe anytime, anywhere. H.265+: Without using extra bandwidth, your cameras can transmit compressed and crystal-clear video while conserving disk space, reducing network load and lowering surveillance costs without sacrificing image quality. Smart Video Enhancement: VIGI's professional technologies including Smart IR, WDR, 3D DNR and Night Vision process video to greatly enhance video quality which is essential for monitoring. PoE/12V DC: Two power supply methods make camera wiring much easier. Flexible management: Take full control of your security with four management methods: web interface, NVR interface, VIGI App and VIGI Security Manger. Full of color, all the time VIGI 3MP full color vandal resistant dome network camera. Transparency and colors, all in one Monitor the area for 24 hours in clear and colorful detail, even during the dark night. VIGI's full color camera provides a maximum resolution of 3MP and guarantees color monitoring thanks to its large lens size, high sensitivity sensor and built-in auxiliary lighting. Classification of people and vehicles Integrated AI chips support advanced algorithms that distinguish people and vehicles from other objects. You can flexibly customize alarm rules to suit your monitoring needs and receive more accurate event notifications. We keep an eye on your business. Intelligent detection. Powered by AI algorithms, the VIGI camera offers more intelligent detection. You will receive notifications when someone crosses the border, enters the zone you set, covers the camera or removes / abandons objects. No more silent surveillance. Built-in microphone. The VIGI camera has a built-in microphone to record everything that happens within 4.5 meters of the camera. This provides more detailed monitoring for greater peace of mind. IK10 mechanical grade vandal resistance and IP67 water resistance. With mechanical strength, rugged housing, and waterproof design, this VIGI dome camera is built to withstand vandalism and harsh environmental conditions with rain and dust, keeping you safe anytime, anywhere. More compression. More savings. Same quality. Without using extra bandwidth, your cameras can transmit compressed and crystal-clear images, while saving disk space, reducing network load and lowering surveillance costs without sacrificing image quality. Never miss a detail. Smart video enhancement. VIGI's professional technologies including Smart IR, WDR, 3D DNR and Night Vision process the video to significantly improve its quality, which is essential for monitoring. Discover the best way to power your camera. PoE/12V DC. Two ways of power supply not only provide more convenience, but also make wiring extremely simple. Flexible management Take full control of your security with four management methods: Web Interface, VIGI NVR, VIGI App and Security Manager. Flexible installation Easily route the camera cable to a suspended ceiling or avoid drilling by routing it through the camera's side exit. One system. Full security. Run your business with peace of mind. The professional TP-Link monitoring system will allow you to protect your company - regardless of the place and time. Unique features, trustworthy quality, simple installation and convenient management are a combination that will ensure the security of your company.
Design - Form factor - Dome
Design - Housing material - Plastic
Design - IK code - IK10
Design - International Protection (IP) code - IP67
Design - Mounting type - Ceiling
Design - Product colour - White
Design > Chassis type - Dome
Design > Protection features - IP67, IK10
dimension depth - 120 mm
dimension height - 150 mm
Dimensions - 115 x 115 x 86 mm
dimension weight - 474 g
dimension width - 190 mm
EAN - 4897098689905
ean - 4897098689905
Eans - 4897098689905
Environment requirements - Permissible operating temperature: -30 - 60 °C
Features > Package content - VIGI Network Camera; Waterproof Cable Attachments; Mounting Accessories
Frames per second - 30
guarantee - 36
guarantee_type - normal
Image sensor - Optical sensor size - 25.4 / 2.8 mm (1 / 2.8")
Image sensor - Sensor type - CMOS
Lens - Focal length: 2.8mm Aperture: F1.6 Lens mount: M12
Lens system - Fixed focal length - 2.8 mm
Lens system > Lens type - 2.8mm
Link - https://www.tp-link.com/in/business-networking/vigi-network-camera/vigi-c230/v1%20(2.8mm%20lens)/
LongDesc - Clarity and Colors, All in OneMonitor 24-hour clear and colorful details even in pitch dark night. VIGI Full-Color camera provides maximum 3MP resolutions and ensures colorful monitoring with its large-aperture lens, high-sensitivity sensor, and attached supplemental lights.Human & Vehicle ClassificationIntegrated AI chips support advanced algorithms to distinguish humans and vehicles from other objects. You can flexibly customize alarm rules to match your monitoring needs and receive more accurate event notifications.We keep an eye on your business.Smart DetectionBacked by AI algorithms, the VIGI camera offers more smart detection. You will receive notifications when someone crosses a boundary, enters an area you've set, obstructs the camera, or removes/abandons objects.No more silent surveillance.Built-In MicrophoneThe VIGI camera features a built-in microphone to record anything going on within a 15-ft radius of the camera. This gives you more detailed monitoring for greater peace of mind.IK10 Vandal-Proof & IP67 WaterproofWith vandal-resistant, rugged housing and waterproof design, this VIGI dome camera is built tough to withstand vandalism and harsh environments with rain and dust for constant security anywhere and anytime.
LongProductName - VIGI 3MP Full-Color Dome Network Camera
LongSummaryDescription - TP-Link VIGI C230(2.8mm). Type: IP security camera, Placement supported: Indoor & outdoor, Connectivity technology: Wired. Mounting type: Ceiling, Product colour: White, Form factor: Dome. Angle of rotation: 360°, Lens viewing angle, horizontal: 107.5°, Lens viewing angle, vertical: 57.2°. Sensor type: CMOS, Optical sensor size: 25.4 / 2.8 mm (1 / 2.8"). Fixed focal length: 2.8 mm
Management, monitoring, configuration - API: ONVIF Simultaneous live view: 3 main streams and 3 sub streams Client: VIGI Application, VIGI Security Manager, VIGI NVR, web interface
Memory > Memory slots - N/A
Memory card reader - No
Memory standard - Not applicable
Microphone - Yes
Min. illuminance - 0 lx
Motion detection - Yes
name - Network Camera VIGI C230(2.8mm) 4MP Dome
Name - TP-Link VIGI C230(2.8mm)
Name - TP-LINK | Full-Color Dome Network Camera | VIGI C230 | Dome | 3 MP | 2.8mm | IP67, IK10 | H.265+/H.265/H.264+/H.264 | N/A
Network - Bluetooth - No
Network - Ethernet interface type - Fast Ethernet
Network - Ethernet LAN - Yes
Network - Supported network protocols - TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS
Network - Wi-Fi - No
Network protocols - TCP/IP UDP ICMP HTTP HTTPS DHCP DNS RTSP NTP UPnP UDP SSL/TLS
Night mode - Yes
Night vision - Infra-red wavelength - 850 nm
Night vision - LED type - IR
Night vision - Night vision - Yes
Night vision - Night vision distance - 30 m
Night vision - Number of illumination LEDs - 1
Operational conditions - Operating temperature (T-T) - -30 - 60 °C
Operational conditions > Operating temperature (T-T) - -30–60 °C
Other features - Rotation: 0° - 360° Tilt: 0° - 85° Digital Noise Reduction: 3D DNR WDR: DWDR Mechanical strength class: IK10 Infrared LED: Range: 30m; Wavelength: 850nm White LED: Range: 30m Video Compression: Main stream: H.265+/H.265/H.264+/H.264 Substream: H.265/H.264
Package features > Embeeded battery - No, No
Package features > Gross depth (mm) - 193.00, 193.00 mm
Package features > Gross height (mm) - 120.00, 120.00 mm
Package features > Gross width (mm) - 153.00, 153.00 mm
Package features > Packing quantity - 1.00, 1.00 pc(s)
Package features > Palette Qty - 244, 244 pc(s)
Package features > Paper/Pasteboard - 190.00, 190.00 g
Package features > Plastic (No PET) - 10.00, 10.00 g
Package features > Tare weight (kg) - 0.20, 0.20 kg
Package features > Volume (m3) - 0.00, 0.00 m³
Package features > WEE classification - CL109:6:2017-04-01, CL109:6:2017-04-01
Package features > WEEE tax - Yes, Yes
Packaging content - Number of cameras - 1
Performance - Connectivity technology - Wired
Performance - Day/night mode - Yes
Performance - Placement supported - Indoor & outdoor
Performance - Type - IP security camera
Performance > Built-in microphone - Yes
Performance > Video compression formats - H.265+/H.265/H.264+/H.264
Performance > Wide Dynamic Range (WDR) - DWDR
Picture quality > Camera type - Indoor/Outdoor
Power - DC output voltage - 12
Power - Power consumption (max) - 4.7 W
Power - Power source type - DC
Power > Power - 12V DC: Max 4.7 W
Power supply - 12V DC 5%, 5.5mm coaxial power plug PoE (802.3af/at, class 0)
producer - TP-LINK
Producer - TP-Link
ProducerCode - VIGI C230(2.8mm)
ProductName - VIGI C230(2.8mm)
Protection class - IP67
Resolution - 2304 x 1296
Security - Password protection HTTPS encryption IP address filter Digest authorization
Security - Active tampering alarm - Yes
Security - HTTPS encryption - Yes
Security - IP address filtering - Yes
Security - Mirror - Yes
Security - Password protection - Yes
Security - Password reset via email - Yes
Security - Video motion detection - Yes
Sensor - 1/2.8" Progressive Scan CMOS
ShortDescription -
ShortSummaryDescription - TP-Link VIGI C230(2.8mm), IP security camera, Indoor & outdoor, Wired, Ceiling, White, Dome
Speakers built-in - No
Special functions - Two streams Mirror reflection Privacy masks Password reset via email HTTP listening Image adjustments: Mirror, Brightness, Contrast, Saturation, Sharpness, Exposure, WDR, White balance fixed by client software, Rotation (90°/270°) Intelligent event detection Classification of people and vehicles Intrusion detection Line crossing detection Human detection Vehicle detection Zone entrance detection Zone exit detection Object abandonment detection Object removal detection Notifications and Alerts: Motion detection Camera manipulation detection Exception (invalid login)
Standards - 802.3af
Standards - 802.3at
Storage - Built-in HDD - No
System Requirements -
Technical details > Gross weight - 0.40 kg
Technical details > Net weight - 0.20 kg
Technical details > Other features - Obtain 24-hour color details, even in pitch-black conditions, with its large-aperture lens, high-sensitivity sensor, and attached supplemental lights. Digital Noise Reduction 3D DNR
Technical details > Producer - TP-LINK, TP-LINK
Technical details > Producer product family - Full-Color Dome Network Camera
Technical details > Producer product name - VIGI C230
Technical details > Sensors - 1/2.8” Progressive Scan CMOS
Title - TP-Link VIGI C230(2.8mm) Dome IP security camera Indoor & outdoor 2304 x 1296 pixels Ceiling
Two-way transmission - No
type - fixed dome camera
URL - https://www.tp-link.com/ae/business-networking/vigi-network-camera/vigi-c230/#overview
vendpn - VIGI C230(2.8mm)
Video - Back Light Compensation (BLC) - Yes
Video - Digital Wide Dynamic Range (DWDR) - Yes
Video - Highlight Compensation (HLC) - Yes
Video - Image quality adjustment - Brightness, Contrast, Mirror, Saturation, Sharpness
Video - Maximum resolution - 2304 x 1296 pixels
Video - Noise reduction - Yes
Video - Noise reduction technology - 3D noise reduction
Video - Privacy masking - Yes
Video - Smart IR - Yes
Video - Supported graphics resolutions - 320 x 240, 352 x 288, 640 x 480 (VGA), 704 x 576, 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2048 x 1280, 2304 x 1296
Video - Total megapixels - 3 MP
Video - Video compression formats - H.264, H.264+, H.265, H.265+
Video - Video streaming - Yes
Video > Maximum video resolution - 2304 x 1296 pixels
Video > Max IR distance - 30m
Video > Megapixel - 3 MP
Viewing angle, horizontal - 107 °
Viewing angle, vertical - 57 °
Warranty - 36
Warranty - 36 month(s)
WarrantyInfo -
Weight & dimensions - Depth - 86 mm
Weight & dimensions - Height - 115 mm
Weight & dimensions - Width - 115 mm
Wireless communication - No
