Qnap TS-264-8G, 2-Bay

2.5GbE Ports - 2
3.5" SATA Hot-swap Drive Bays - 2
Accessories included -
ARTIKEL1 - TS-264-8G 2 BAY 8 GB DDR4
ARTIKEL2 - 2X2.5GBE 2X USB 2.0
Brand - QNAP
BrandPartCode - TS-264-8G
Breite - 0.28
Built-in flash memory - 4 GB
Built-in RAM memory - 8 GB
Category - NAS & Storage Servers
Category - Root/Electronics/Networks and communication/NAS - file servers
Category 1 - Netzwerk
Category 2 - NAS-Systeme
Category Code - STS
Code - TS-264-8G
CPU - Intel® Celeron® N5095 4-core/4-thread processor, burst up to 2.9 GHz
Description - TS-264 Intel-based quad-core 2.5GbE NAS with two ports supports M.2 SSD cache and PCIe expansion, enabling high-speed data transfer and virtualisation applications. Equipped with a quad-core Intel Celeron N5095 processor (clocked up to 2.9GHz), the TS-264 offers two 2.5GbE RJ45 ports and port trunking for combined throughput of up to 5Gb/s. With M.2 PCIe Gen3 and PCIe Gen 3 slots, the TS-264 provides the flexibility to expand NAS functionality by allowing the installation of a QM2 card for M.2 SSD caching or Edge TPU for AI-based image recognition and various 10GbE/5GbE network cards. The TS-264 is equipped with 8GB RAM to support lightweight VMs and containers, and supports multi-cloud backup, cloud storage gateways, 4K HDMI output and real-time transcoding. It also provides expandable storage and feature-rich applications, acting as a cost-effective, reliable 2.5GbE NAS. 2.5GbE connectivity By setting up port trunking with two built-in 2.5GbE ports (2.5 G / 1 G / 100 M), transfer speeds of up to 5 Gbps can be achieved. M.2 SSD cache Two M.2 PCIe Gen3 slots allow NVMe SSD cache or SSD storage pools to be activated for greater performance, or Edge TPU for AI-based image recognition. PCIe expandability By installing a PCIe Gen3 x2 card, you can expand the core functionality of the TS-264, including adding a 10GbE/5GbE/2.5GbE multi-gigabit network card, QM2 card or USB 3.2 Gen 2 (10Gb/s) card. Virtualised, licence-free environment Support for multiple containerised applications for different services and programmes. Automatic disk tiering Qtier automatic tiering technology and SSD cache ensure continuous storage optimisation. 4K HDMI Hardware 4K H.264 decoding and real-time transcoding ensures smooth media playback on the big screen.
Design - Cable lock slot - Yes
Design - Cable lock slot type - Kensington
Design - Chassis type - Tower
Design - Cooling type - Active
Design - Fan diameter - 7 cm
Design - LED indicators - HDD, LAN, Power, Status, USB
Design - Number of fans - 1 fan(s)
Design - Product colour - Black, Gold
Design > Chassis type - Tower
Design > Number of 3.5" bays - 2
Desktop/pedestal Mounting Type - Yes
dimension depth - 205 mm
dimension height - 275 mm
Dimensions - 168 x 105 x 226 mm
dimension weight - 2630 g
dimension width - 310 mm
Disk type - HDD
Disk type - SSD
EAN - 4711103082331
ean - 4711103082331
EANCode - 4711103082331
Eans - 4711103082331
Expansion slots - 1 x PCIe 3.0 x 2
Fan - 7 cm
Form factor (width) - 2,5'' (SFF)
Form factor (width) - 3,5'' (LFF)
Full Description Line - NAS Ready-to-go|CPU Intel® Celeron® N5095 4-core/4-thread processor, burst up to 2.9 GHz|Drives/bays 2|Desktop/pedestal|2x2.5GbE|1xHDMI|2xUSB 2.0|2xUSB 3.2|Memory 8 GB|DDR4|2xM.2|Power supply requirements 65W adapter
Gewicht - 2.63
Gross Weight Kg - 2,85
GRUPPE1 - Storage
GRUPPE2 - Raid System
GTIN - 4711103082331
guarantee - 36
guarantee_type - normal
HDD interface - SATA III - 6 Gb/s
HDMI Input/Output connectors - 1
HERSTELLER - QNAP
Hoehe - 0.21
Hot-swapping support - Yes
Housing - Tower
HSTNUMMER - TS-264-8G
I/O connectors - 1 x HDMI
I/O connectors - 2 x RJ-45 LAN
I/O connectors - 2 x USB 2.0
I/O connectors - 2 x USB 3.1
Laenge - 0.32
Link - https://www.qnap.com/en/product/ts-264
LongDesc - Powered by an Intel® Celeron® N5105/N5095, quad-core processor (burst up to 2.9GHz), the TS-264 features two 2.5GbE RJ45 ports and Port Trunking for up to 5Gbps combined bandwidth. With M.2 PCIe Gen3 and PCIe Gen 3 slots, the TS-264 provides flexibility in extending NAS functionality, allowing you to install a QM2 card for M.2 SSD caching, or Edge TPU for AI image recognition and various 10GbE/5GbE network cards. The TS-264 comes with 8 GB RAM for running light VMs and Containers, and supports multi-cloud backup, cloud storage gateways, 4K HDMI output and real-time transcoding, alongside expandable storage capacity and feature-rich apps to perform as a cost-efficient, reliable 2.5GbE NAS.2.5GbE connectivityUp to 5 Gbps transfer speeds can be achieved by setting port trunking with the two built-in 2.5GbE (2.5G/1G/100M) ports.M.2 SSD cachingDual M.2 PCIe Gen 3 slots enable NVMe SSD caching or SSD storage pools for improved performance, or Edge TPU for AI image recognition.PCIe expandabilityInstall a PCIe Gen3 x2 card to expand the core functionality of the TS-264, including a Multi-Gig 10GbE/5GbE/2.5GbE network card, a QM2 card, or a USB 3.2 Gen 2 (10Gbps) card.License-free virtualized environmentHost multiple containerized apps to run a wide range of applications and services.Drives Auto-TieringQtier™ auto-tiering technology and SSD caching enable constant storage optimization.4K HDMI4K H.264 hardware decoding and real-time transcoding for smooth big screen multimedia experience.Quad-core high performance and up to 8 GB RAMThe TS-264 is powered by an Intel Celeron N5105 / N5095 quad-core processor and supports up to 8 GB DDR4 memory, two 2.5GbE ports and SATA 6 Gb/s drives. The integrated Intel® AES-NI encryption engine also helps protect confidential data without impacting system performance.Accelerate AI–powered image recognition and caching with TPU and PCIe expansionThe TS-264 has two M.2 PCIe Gen3 slots, enabling SSD caching or SSD storage pools for improved performance, or Edge TPU for AI image recognition.Install M.2 NVMe SSDs for cache acceleration or efficient tiered storageThe TS-264 supports SSD caching and features two M.2 slots that support M.2 PCIe NVMe SSDswith 2280 form factors (sold separately) for boosting overall NAS performance. Qtier™ technology can also be used to empower the TS-264 with auto tiering that helps continuously optimize storage efficiency across all installed storage devices.Accelerate AI–powered image recognition with TPUBy leveraging a Google Edge TPU to QNAP AI Core (the AI-powered engine for image recognition), the TS-264 can perform high-speed face and object recognition. Google Edge TPU enables QuMagie to quickly process thousands of photos with high-speed AI Image recognition and classification, and QVR Face to analyze real-time video for instant facial recognition.SSD caching and auto-tiering enable 24/7 optimized storage efficiencyWhile SSD prices continue to fall, and SSD capacity and performance continue to increase, organizations can easily take advantage of SSD strengths. The TS-264 supports numerous SSD-aware features that significantly maximize NAS performance with high cost-effectiveness.SSD over-provisioning(Over-provisioning)You can add additional SSD over-provisioning (1% ~60%) to avoid write amplification and improve SSD random write speeds and endurance. You can potentially attain enterprise-grade SSD performance levels from affordable consumer SSDs!SSD cache accelerationEnables SSD caching for increasing IOPS performance and reducing latency for storage volume. This feature is perfect for IOPS-demanding applications including databases and virtualization. The TS-264 also supports write-only cache to boost write-intensive applications.Qtier for auto-tieringQtier technology drives auto-tiered storage with continuous data optimization across high-performance SSDs and high-capacity HDDs based on access frequency. I/O-Aware Qtier can reserve a cache-like space in the SSD tiered to handle burst I/O in real time.Streamline large file transfers and video editing with 2.5GbEThe TS-264 comes with two 2.5GbE RJ45 (2.5G/1G/100M) LAN ports that allow you to use existing CAT5e cables to upgrade network speeds from 1 Gigabit to 2.5 Gigabit. The dual 2.5GbE ports also support Port Trunking for up to 5 Gbps transmission speeds, improving the efficiency of bandwidth-hungry business applications such as large file transfers, fast backup/restore, and multimedia transfer & editing.Future-proof your IT infrastructure for high-speed networksThe TS-264 is ideally matched with QNAP’s managed and unmanaged 2.5GbE/10GbE switches to form high-speed, secure, and scalable network environments without going over budget. QNAP also provide 2.5GbE/5GbE/10GbE PCIe cards and USB 5GbE adapters for Windows®/Linux® workstations, allowing you to easily build a high-speed network environment for productive team collaboration.Enhance productivity with multiple USB portsWith two USB 3.2 Gen 2 (10Gbps) ports and two USB 2.0 (480Mbps) ports, you can quickly backup and transfer large files to/from the TS-264. UPS and other compatible USB devices can also be connected for greater functionality and application potential.Abundant I/O capabilities with PCIe expansionThe TS-264 has one PCIe Gen 3 x2 slot that allow for installing various expansion cards for expanding application potential.Direct 4K HDMI output for multimedia and virtual machine displayThe TS-264 features Intel® UHD Graphics that supports dual-channel hardware decoding and real-time transcoding*. The HDMI 2.0 output supports up to 4K, providing great benefits for applications like video production/editing or industrial design that demands high resolution and color realism as well as intensive media storage, transfer, and display. By connecting the TS-264 to an HDMI display, you can directly watch multimedia content saved on the NAS, or use the TS-264 as a versatile workstation by directly outputting virtual machines from Virtualization Station or Ubuntu Linux Station.Faster image identification with integrated Intel® OpenVINO™ AI engine.With integrated Intel® OpenVINO™ AI computing resources, the TS-264 accelerates AI image recognition performance without impacting other applications or services. QNAP AI Core primarily works with the QuMagie application.QuMagie photo managementEasy-to-use photo management solution that integrates AI image recognition and intelligent classification for your collection.QTS 5, Fast, smooth, and easy-to-use!The TS-264 comes with the QTS 5 operating system as standard, providing a next-generation usage experience with an updated system kernel, optimized user interface, and advanced security features.Brighter. Smoother. You’ll like it.When navigating QTS 5, you will notice a finer attention to detail for a superior browsing experience. Enjoy a smoother NAS experience, comfortable visual design, and find your favorite apps quicker.Get started with the notice boardWhen performing first-time installation, the notice board guides you through the setup process. Simply follow the step-by-step instructions for a quick and easy setup.Smooth and reactive user interfaceWhether clicking buttons, switching between apps, expanding/collapsing windows – every action is much smoother. The search bar in the main menu also assists in quickly finding desired apps.Comprehensive backup and disaster recovery solutionThe TS-264 supports various apps that cover all your backup needs. Practice safe IT habits by regularly backing up files and device content, allowing them to be easily restored when needed.PC/Laptop backupFor Windows®, install NetBak Replicator to back up your PC to QNAP NAS. In macOS®, just set up the built-in Time Machine® to secure your data.Remote backup for NASHybrid Backup Sync makes it easy to back up data from a TS-264 to another QNAP NAS or remote server to fulfill your 3-2-1 backup strategy. VM backupEnjoy license-free VMware® and Hyper-V VM backup with source-side incremental backup, global deduplication, and recovery compression.SaaS backupSafeguard enterprise cloud data by backing up/syncing files, emails, calendars, and contacts from Google™ Workspace and Microsoft® Office 365® to the NAS.Cloud backup for NASHybrid Backup Sync supports mainstream cloud storage for NAS data backup. For backup to object cloud storage, VJBOD Cloud is especially useful to reduce bandwidth usage and backup time.QuDedup technologyHybrid Backup Sync eliminates redundant data at the source and then backs up the deduplicated data, helping to save time and storage costs while providing efficient multi-version backups.Multi-version snapshots mitigate ransomware threatsThe TS-264 supports block-based snapshots that record the state of the system at any time. It helps protect data, which can be restored back to a specific point of time, greatly helping in mitigating the threat of ransomware.Volume and LUN snapshotsTake snapshots in seconds and revert the entire volume/LUN back to a specific point in time to prevent loss of important data.Instantly restore snapshotsSnapshot content can be quickly restored to a local NAS, or restored on a folder/file basis to a local/remote NAS or cloud storage. You can also conveniently view and restore snapshots from the client side.Back up snapshotsMultiply data protection by backing up snapshot files! Replicate volume/LUN snapshots in the TS-264 to a remote NAS (Snapshot Replica) by copying only the changes made. This helps save time & bandwidth, and can be run manually or on a scheduled basis.All-in-one solution for hosting virtual machines and containersBy running multiple virtual machines and containers on the TS-264, you can deploy multi-tenant environments and applications to increase management efficiency and save hardware costs. Coupled with the Network & Virtual Switch app that boosts interoperability between virtual machines, containers, QNAP NAS, and other physical devices on the network, you can flexibly allocate physical and virtual network resources to simplify network deployment.Virtualization StationRun multiple Windows®, Linux®, UNIX®, Android™, and QuTScloud virtual machines and access them via a web browser or Virtual Network Computing (VNC). Businesses can run virtualized server applications on a single NAS without needing additional physical servers.Conainer StationExperience Docker®, LXD, and Kata Containers lightweight virtualization technologies, download apps from the built-in Docker Hub Registry®, import/export containers, and create abundant microservices.Linux StationRun Linux® applications (including apps from the Software Center) directly on the NAS and remotely access the Linux® desktop from a web browser. The open-source Linux® platform is also ideal for Internet of Things development.Comprehensive security and privilege settingsThe TS-264 is loaded with flexible privilege settings and security measures. Besides IP blocking, 2-step verification, HTTPS connection, there are more apps that help ensure optimal NAS protection against threats like malware and hackers.myQNAPcloud secures remote accessmyQNAPcloud allows convenient connection to the TS-264 through the Internet without any complex DDNS settings. To ensure your remote access service is secure, myQNAPcloud strengthens keys on SSL Certificates to 2048-bits.Simplified privilege settingsThe TS-264 supports comprehensive access right settings for shared folders, Azure Active Directory Domain Services (Azure AD DS), LDAP, and Windows ACL to help IT staff efficiently manage user accounts and access rights for multiple NAS systems.QuFirewall protectionSupports IPv6, firewall access lists, and GeoIP filtering to restrict access based on geographical locations for higher NAS network security. Superior security with QVPNA virtual private network (VPN) allows secure access to network resources and services across public networks. QVPN supports creating a VPN client, using the TS-264 as a VPN server, and WireGuard® VPN service with an easy-to-use interface for setting up a secure connection.QuWAN SD-WANTo facilitate digital transformation, multi-site expansion and remote working, QuWAN SD-WAN helps automatically mesh multi-site VPN. It features IPsec encryption and cloud-centric management, allowing secure multi-site network including QNAP NAS and VMware ESXi platforms.Security CounselorA security portal for the TS-264 to check for weaknesses and offer recommendations for enhancing NAS security. It also integrates anti-virus and anti-malware scanning software.Malware RemoverRegularly scan your TS-264 using the latest malware definitions. If infected files are detected, they will be immediately removed to ensure NAS data security.The best file storage and collaboration centerThe TS-264 integrates rich apps for storing, managing, synchronizing, searching, and archiving files. It supports SMB/CIFS, AFP, and NFS protocols for streamlined file sharing across Windows®, Mac®, and Linux®/UNIX®, and provides the smartest NAS solution for professionally managing your files.File StationManage, access, and share all the files in the TS-264 and view snapshots files – all from your web browser. You can also easily mount remote NAS folders and cloud storage.QsyncMake any file uploaded to a TS-264 available to linked devices, such as computers, laptops and mobile devices. You can sync shared folders and team folders for group file sharing to enhance the flexibility of team projects and collaboration.QsirchQNAP’s powerful, Google-like search tool helps you quickly find images, music, videos, documents, and emails by keywords, color, and more search conditions. It also supports Qfiling to perform one-time or automatic archival tasks based on your search criteria.QfilingAutomate your file organization ─ all you need to do is categorize files, set a schedule, and Qfiling will do the rest. Qfiling also enables smart recycling that instantly moves filtered files to the Recycle Bin.Smart surveillance solution for 24/7 securityQVR Elite is QNAP’s subscription-based smart surveillance solution, allowing you to easily build a surveillance system with lower TCO and higher scalability. Recordings are saved as MP4 files, allowing playback on nearly every device. QVR Elite also integrates QNAP AI-based solutions to build smart facial recognition for retail and door access systems with QNAP NAS. You can arrange a dedicated, independent storage space for surveillance data on the TS-264 and enjoy simplified camera management, storage space allocation, camera live viewing and playback. Flexible and economical storage expansionQNAP provides easy ways to expand your storage capacity. Here are several ways to expand your TS-264 storage as needed to accommodate data and business growth.Attach QNAP expansion enclosuresConnect expansion enclosures to the TS-264, and manage NAS storage expansion with the user-friendly Storage & Snapshots Manager app.Mount cloud storage or remote file serversMount cloud storage or remote file servers to expand the capacity of the TS-264 while also centrally managing files on the NAS, cloud storage, and remote devices.Migrate to a new NASInstall your NAS hard drives into a larger QNAP NAS and retain all your existing data and configurations.Upgrade RAID capacityHot-swap lower-capacity drives with larger-capacity drives to expand your NAS capacity so it can grow with your business.More productivity-boosting applicationsThe TS-264 provides an App Center that includes feature-rich apps to expand your NAS potential!QuObjectsRun a high-performance S3 compatible development environment on your TS-264 to simplify service development workflows from testing to production. You can also move cold data from the cloud to an on-premises QuObjects to save cloud storage costs.Notification CenterConsolidates all system events, alerts, and notifications for smooth and easy NAS management, keeping you always informed of your NAS status.Proxy ServerBy using a high-capacity TS-264 as a proxy server, online resources can be efficiently accessed with greater cost-savings and productivity, while network security is also enhanced at the same time.QmailAgentThe best email backup solution that allows you to easily backup/recover and manage multiple email accounts in their native format with strong security and data integrity.QcontactzCentrally manage all your contacts, import contacts from Google™, import/export contact information using CSV or vCard files, and enjoy an always-online database of contact information.QuFTPThe TS-264 can perform as an FTP server featuring SSL/TLS encryption, QoS bandwidth controls, and permission settings for efficiently and securely transferring large amounts of data. FTP Client is also supported.A health check for your hard drivesHard drives are at the heart of your NAS, and ensuring their long-term health and reliability is absolutely crucial. QNAP provides various methods and tools to help you monitor hard drive health, ensuring that you can take proactive decisions to safeguard your data and files.S.M.A.R.T. and back block scanningIf any of the S.M.A.R.T. values are reported as abnormal, or bad blocks are detected, you can take early action and replace drives before potential data loss occurs.DA Drive AnalyzerThe DA Drive Analyzer leverages ULINK cloud-based AI to predict the expected lifespan of drives, assisting you in planning future drive replacements to protect against NAS downtime and data loss.Seagate® IronWolf™ Health ManagementWhen using supported IronWolf™ or IronWolf Pro™ hard drives, overall system reliability is improved by providing you with actionable prevention, intervention, and recovery options.
LongProductName - Intel Celeron N5095 2 GHz, Intel UHD Graphics, 8 GB, 4GB Flash, 2 x 3.5" SATA 6Gb/s, 2 x M.2 2280 PCIe Gen 3 x1, 2 x RJ-45, 1.55 kg
LongSummaryDescription - QNAP TS-264. Type: NAS. Chassis type: Tower. Device class: Home & Home Office. Processor family: Intel® Celeron®, Processor model: N5095, Processor frequency: 2 GHz. Internal memory: 8 GB. Total installed storage capacity: 0 TB. Operating system installed: QNAP QTS
M.2 Expansion slots - 2
Management, monitoring, configuration -
Manufacturer - QNAP
Manufacturer Code - TS-264-8G
Manufacturer Name - QNAP
Max. number of disks - 2
Max memory size - 8 GB
Memory - 8 GB
Memory - Flash memory - 4000 MB
Memory - Internal memory - 8 GB
Memory - Maximum RAM supported - 8 GB
Memory > Internal RAM - 8 GB
Memory type - DDR4
Memory type - SODIMM DDR4
Model - TS-264-8GB
MPN - TS-264-8G
Name - 2-Bay QNAP TS-264-8G Intel Celeron 8 GHz Quad Core
Name - QNAP TS-264-8G
Name - QNAP | 2-Bay desktop NAS | TS-264-8G | Intel Celeron | N5095 4-core | Processor frequency 2.9 GHz | 8 GB
name - TS-264-8G Intel N5095 2x 0HDD 8GB
NAS features - Ready-to-go
Network - DHCP server - Yes
Network - Dynamic DNS (DDNS) - Yes
Network - Ethernet LAN - Yes
Network - Ethernet LAN data rates - 10,100,1000,2500 Mbit/s
Network - iSCSI support - Yes
Network - Jumbo frames support - Yes
Network - Supported network protocols - IPv4, IPv6
Network architecture - GigabitEthernet
Network interface - 2 x 10/100/1000/2500 Mbit/s
Network protocols -
Number of available memory slots - 0
Number of drives/bays - 2
Number of fans - 1
Number of HDDs installed - 0
Number of memory slots used - 0
Operational conditions - Operating relative humidity (H-H) - 5 - 95%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage temperature (T-T) - -20 - 70 °C
Other disk parameters - Drive bay: 2 3.5" SATA 6 Gb/s HDDs Drive Compatibility: 3.5" SATA hard drives 2.5-inch SATA HDDs 2.5-inch SATA SSDs
Other features -
Other features - Fibre Channel - Yes
Other features > Drive bays - 2
Other features > Ethernet LAN (RJ-45) ports - 2
Package features > Embeeded battery - No
Package features > Gross depth (mm) - 278.00 mm
Package features > Gross height (mm) - 205.00 mm
Package features > Gross width (mm) - 313.00 mm
Package features > Packing quantity - 1.00 pc(s)
Package features > Palette Qty - 48 pc(s)
Package features > Paper/Pasteboard - 1000.00 g
Package features > Plastic (No PET) - 130.00 g
Package features > Tare weight (kg) - 1.13 kg
Package features > Volume (m3) - 0.02 m³
Package features > WEE classification - CL109:5:2017-04-01
Package features > WEEE tax - Yes
Packaging content - Cables included - AC, LAN (RJ-45)
Packaging content - External power adapter - Yes
Packaging content - Number of screws - 12
Packaging content - Power cables quantity - 1
Packaging content - Quick installation guide - Yes
PDF - https://www.blobs.lt/products/5/0/6/3/0/4/cc6c3abbfa0278d425c2e1190c8f519f/original.pdf
Performance - Access Control List (ACL) - Yes
Performance - Backup features - USB drive, iSCSI LUN
Performance - Backup function - Yes
Performance - Browser supported - Apple Safar, Google Chrome, Microsoft Edge, Mozilla Firefox
Performance - Built-in FTP server - Yes
Performance - Buzzer - Yes
Performance - Device class - Home & Home Office
Performance - Hot spare - Yes
Performance - Multilingual support - Yes
Performance - Number of users - 4096 user(s)
Performance - On/off switch - Yes
Performance - Remotely operated - Yes
Performance - Reset button - Yes
Performance - S.M.A.R.T. support - Yes
Performance - Security algorithms - 256-bit AES, FIPS 140-2
Performance - Share folder - 512
Performance - Share folder access right management - Yes
Performance - Snapshot - Yes
Performance - System log - Yes
Performance - Type - NAS
Performance - USB copy function - Yes
Ports & interfaces - Concurrent connections - 1500
Ports & interfaces - Ethernet LAN (RJ-45) ports - 2
Ports & interfaces - HDMI ports quantity - 1
Ports & interfaces - HDMI version - 2.0
Ports & interfaces - PCI Express x2 (Gen 3.x) slots - 1
Ports & interfaces - USB 2.0 ports quantity - 2
Ports & interfaces - USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity - 2
Ports & interfaces - USB port - Yes
Ports & interfaces > Interface - 1x HDMI 2.0; 2 x M.2 2280 PCIe Gen 3 x1; 2 x USB Type-A
Power - AC input voltage - 100 - 240 V
Power - Fan voltage - 12 V
Power - Power consumption (sleep) - 8.198 W
Power - Power consumption (typical) - 12.448 W
Power - Power supply location - External
Power - Power supply unit (PSU) capacity - 65 W
Power supply - Power supply 65W, 100-240V
Power supply requirements - 65W adapter
Processor - Intel Celeron N5095 4-core/4-threads, burst up to 2.9 GHz Processor architecture 64-bit x86
Processor - CPU configuration (max) - 1
Processor - On-board graphics card model - Intel® UHD Graphics
Processor - Processor boost frequency - 2.9 GHz
Processor - Processor cache - 4 MB
Processor - Processor cores - 4
Processor - Processor family - Intel® Celeron®
Processor - Processor frequency - 2 GHz
Processor - Processor manufacturer - Intel
Processor - Processor model - N5095
Processor - Processor threads - 4
Processor > Processor family - Intel Celeron
Processor > Processor frequency - 2.9 GHz
Processor > Processor model - N5095 4-core
Processor special features - Enhanced Intel SpeedStep Technology - Yes
Processor special features - Idle States - Yes
Processor special features - Intel 64 - Yes
Processor special features - Intel Trusted Execution Technology - No
Processor special features - Intel Virtualization Technology (VT-x) - Yes
Processor special features - Intel Virtualization Technology for Directed I/O (VT-d) - Yes
Processor special features - Intel VT-x with Extended Page Tables (EPT) - Yes
producer - QNAP
Producer - Qnap
ProducerCode - TS-264-8G
Producer product family - 2-Bay desktop NAS
Producer product name - TS-264-8G
ProductName - TS-264
RAID - Yes
RAID levels - 0
RAID levels - 1
Shipping Box Depth Shipping/Package Box Dimensions - 31 cm
Shipping Box Height Shipping/Package Box Dimensions - 27.5 cm
Shipping box quantity - 1
Shipping Box Weight Shipping/Package Box Dimensions - 2.62 kg
Shipping Box Width Shipping/Package Box Dimensions - 20.5 cm
ShortDescription -
Short description - QNAP NAS TS-264-8G (2 Bay)
ShortSummaryDescription - QNAP TS-264, NAS, Tower, Intel® Celeron®, N5095, 8 GB, 0 TB
Software - Linux operating systems supported - Yes
Software - Mac operating systems supported - Mac OS X 10.13 High Sierra, Mac OS X 11.0 Big Sur, Mac OS X 10.14 Mojave, Mac OS X 12.0 Monterey, Mac OS X 10.15 Catalina, Mac OS X 10.10 Yosemite, Mac OS X 10.15.3 Catalina, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra
Software - Operating system installed - QNAP QTS
Software - Operating system version - 5.0.1
Software - Other operating systems supported - Solaris 10, Solaris 10 SPARC, Solaris 11, Solaris 11 SPARC, IBM AIX 7.1, IBM AIX 7.2
Software - Server operating systems supported - Windows Server 2019, Windows Server 2012 R2, Windows Server 2008 R2, Windows Server 2012
Software - Windows operating systems supported - Windows 7 Ultimate x64, Windows 10, Windows 7 x64, Windows 10 Education, Windows 8, Windows 10 Education x64, Windows 7, Windows 8 Enterprise, Windows 10 Enterprise, Windows 7 Enterprise, Windows 8 Enterprise x64, Windows 10 Enterprise x64, Windows 7 Enterprise x64, Windows 8 Pro, Windows 10 Home, Windows 7 Home Basic, Windows 8 Pro x64, Windows 10 Home x64, Windows 7 Home Basic x64, Windows 8 x64, Windows 10 IOT Core, Windows 7 Home Premium, Windows 8.1, Windows 10 IoT Enterprise, Windows 7 Home Premium x64, Windows 8.1 Enterprise, Windows 10 Pro, Windows 7 Professional, Windows 8.1 Enterprise x64, Windows 10 Pro x64, Windows 7 Professional x64, Windows 8.1 Pro, Windows 10 x64, Windows 7 Starter, Windows 8.1 Pro x64, Windows 11, Windows 7 Starter x64, Windows 8.1 x64, Windows 11 x64, Windows 7 Ultimate
Stck_Kart - 4
Stck_Pal - 4
Storage - Disk roaming - Yes
Storage - Hot-swap drive bays - Yes
Storage - Installed storage drive type - No
Storage - Number of M.2 (M & B) slots - 2
Storage - Number of storage drives supported - 2
Storage - Online RAID expansion - Yes
Storage - Online RAID migration - Yes
Storage - RAID levels - 0, 1, JBOD
Storage - RAID rebuild - Yes
Storage - RAID support - Yes
Storage - Storage drives installed - No
Storage - Storage drive sizes supported - 2.5,3.5"
Storage - Supported file systems - FAT32, HFS+, NTFS, exFAT, ext3, ext4
Storage - Supported storage drive interfaces - Serial ATA III
Storage - Supported storage drive types - HDD & SSD
Storage - Total installed storage capacity - 0 TB
Storno - Y
Technical details > Gross weight - 2.68 kg
Technical details > Net weight - 1.55 kg
Technical details > Other features - Fan: 1 x 70mm, 12VDC; Power Supply Unit 60W/65W adapter, 100-240V
Technical details > Producer - QNAP
Title - QNAP TS-264 NAS Tower Intel® Celeron® N5095 8 GB 0 TB QNAP QTS Black, Gold
Total number of memory slots - 0
Unit Box Height - 0.275
Unit Box Length - 0.31
Unit Box Width - 0.205
Unit Brutto Volume - 0.01748 cubm
Unit Gross Weight - 2.62 kg
Unit Net Weight - 1.55 kg
URL - https://preview.qnap.com/en/product/ts-264
USB 2.0 Input/Output connectors - 2
USB 3.2 Input/Output connectors - 2
vendpn - TS-264-8G
Warranty - 24
Warranty - 24 month(s)
Warranty - 24 months
WarrantyInfo - 5 Years
Weight - 1.55 kg
Weight - 2.66
Weight & dimensions - Depth - 226 mm
Weight & dimensions - Height - 168 mm
Weight & dimensions - Package weight - 2.68 kg
Weight & dimensions - Weight - 1.55 kg
Weight & dimensions - Width - 105 mm
